Dometic MPS 50 User manual

MPS50
Mains rectifier
Installation and Operating Manual
EN
ENERGY & LIGHTING
COOLPOWER
MPS50-IO-AU.book Seite 1 Mittwoch, 14. Dezember 2016 8:41 08

MPS50-IO-AU.book Seite 2 Mittwoch, 14. Dezember 2016 8:41 08

EN
MPS50
3
Please read this instruction manual carefully before installation and first
use, and store it in a safe place. If you pass on the product to another
person, hand over this instruction manual along with it.
Contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
6 Mounting the mains rectifier. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
7 Using the mains rectifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8 Maintaining and cleaning the mains rectifier . . . . . . . . . . . . . . . . . . . . . . . . .12
9 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
10 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
MPS50-IO-AU.book Seite 3 Mittwoch, 14. Dezember 2016 8:41 08

EN
Explanation of symbols MPS50
4
1 Explanation of symbols
D
!
!
A
2 General safety instructions
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences and excess voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
Note the following basic safety information when using electrical devices to protect
against:
•Electric shock
•Fire hazards
•Injury
DANGER!
Safety instruction: Failure to observe this instruction will cause fatal or
serious injury.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
MPS50-IO-AU.book Seite 4 Mittwoch, 14. Dezember 2016 8:41 08

EN
MPS50 General safety instructions
5
2.1 General safety
DDANGER!
•In the event of fire, use a fire extinguisher which is suitable for electrical
devices.
!WARNING!
•Only use the device as intended.
•Ensure that the red and black terminals never come into contact.
•Disconnect the device from the mains:
– Before cleaning and maintenance
–Afteruse
– Before changing a fuse
•If you disassemble the device:
– Detach all connections
– Make sure that no voltage is present at any of the inputs and
outputs
•The device may not be used if the device itself or the connection cable
are visibly damaged.
•The supply cord cannot be replaced. If the cord is damaged, the appli-
ance should be scrapped.
•This device may only be repaired by qualified personnel. Inadequate
repairs may cause serious hazards.
•This device can be used by children aged 8 years or over, as well as by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
•Cleaning and user maintenance shall not be made by children without
supervision.
•Electrical devices are not toys.
Always keep and use the appliance out of the reach of children.
•Children must be supervised to ensure that they do not play with the
device.
ANOTICE!
•Before start-up, check that the voltage specification on the type plate
is the same as that of the power supply.
•Ensure that other objects cannot cause a short circuit at the contacts
of the device.
MPS50-IO-AU.book Seite 5 Mittwoch, 14. Dezember 2016 8:41 08

EN
General safety instructions MPS50
6
•Never pull the plug out of the socket by the connection cable.
•Store the device in a dry and cool place.
2.2 Safety when installing the device
DDANGER!
•Never mount the device anywhere where there is a risk of gas or dust
explosion.
!CAUTION!
•Ensure that the device is standing firmly.
The device must be set up and fastened in such a way that it cannot tip
over or fall down.
ANOTICE!
•Do not expose the device to a heat source (such as direct sunlight or
heating). Avoid additional heating of the device in this way.
•Set up the device in a dry location where it is protected against splash-
ing water.
2.3 Safety when connecting the device electronically
DDANGER! Danger of electrocution
•For installation on boats:
If electrical devices are incorrectly installed on boats, corrosion dam-
age might occur. Have the device installed by a specialist (marine)
electrician.
•If you are working on electrical systems, ensure that there is somebody
close at hand who can help you in emergencies.
!WARNING!
•Always use sockets which are grounded and secured by residual cur-
rent circuit breakers.
•Make sure that the lead has a sufficient cross-section.
•Lay the cables so that they cannot be damaged by the doors or the
bonnet.
Crushed cables can lead to serious injury.
MPS50-IO-AU.book Seite 6 Mittwoch, 14. Dezember 2016 8:41 08

EN
MPS50 General safety instructions
7
!CAUTION!
•Lay the cables so that they cannot be tripped over or damaged.
ANOTICE!
•Use ductwork or cable ducts if it is necessary to lay cables through
metal panels or other panels with sharp edges.
•Do not lay the 230 V mains cable and the 12 V DC cable in the same
duct.
•Do not lay the cable so that it is loose or heavily kinked.
•Fasten the cables securely.
•Do not pull on the cables.
2.4 Operating the device safely
DDANGER! Danger of electrocution
•Do not touch exposed cables with your bare hands. This applies espe-
cially when operating the device from the AC mains.
•To be able to disconnect the device quickly from the mains, the socket
must be close to the device and be easily accessible.
!WARNING!
•Only use the device in closed, well-ventilated rooms.
•Do not operate the device in systems with lead acid batteries. These
batteries give off explosive hydrogen gas that can be ignited by sparks
on electrical connections.
!CAUTION!
•Do not operate the device
– In salty, wet or damp environments
– In the vicinity of corrosive fumes
– In the vicinity of combustible materials
– In areas where there is a danger of explosions.
•Before starting the device, ensure that the power supply line and the
plug are dry.
•Always disconnect the power supply when working on the device.
•Please observe that parts of the device may still conduct voltage even
if the fuse has blown.
•Do not disconnect any cables when the device is still in use.
MPS50-IO-AU.book Seite 7 Mittwoch, 14. Dezember 2016 8:41 08

EN
Scope of delivery MPS50
8
ANOTICE!
•Make sure the air inlets and outlets of the device are not covered.
•Ensure good ventilation.
3Scopeofdelivery
•Mains rectifier
•Operating manual
4Properuse
The MPS50 mains rectifier is for operating coolers and refrigerators with BDF50
compressors at 110 – 240 Vw.
MPS50-IO-AU.book Seite 8 Mittwoch, 14. Dezember 2016 8:41 08

EN
MPS50 Technical description
9
5 Technical description
The mains rectifier can operate all coolers and refrigerators with BDF50 compressors
at 110 – 240 Vw. With a 110 – 240 Vwmains connection, the rectifier automatically
switches from battery to mains operation.
When disconnected from the 110 – 240 Vwmains supply, the rectifier automatically
switches back to battery operation. Mains operation via the rectifier always takes
priority over battery operation.
5.1 Control elements
Item Explanation
1 12/24 V socket
2 Glass fuse (250 V, 12 A, slow-blow)
3 Fastening holes
4 Compressor output terminals
5 Battery input terminals
6 Mains cable
2
1
3
5
4
6
1
MPS50-IO-AU.book Seite 9 Mittwoch, 14. Dezember 2016 8:41 08

EN
Mounting the mains rectifier MPS50
10
6 Mounting the mains rectifier
If you wish to mount the mains rectifier in a fixed position, please observe the
following mounting instructions:
•Do not mount the device
– In wet or damp environments
– In the vicinity of combustible materials
– In areas where there is a danger of explosions
•The place of installation must be well-ventilated. A ventilation system which is at
least equivalent to the air openings in the device must be present for installations
in closed housings.
•The air intake on the underside or the air outlet on the back of the device must
remain clear.
•The installation surface must be level and sufficiently sturdy.
➤Secure the mains rectifier with screws through the fastening holes at the front and
the back of the device (fig. 13, page 9).
MPS50-IO-AU.book Seite 10 Mittwoch, 14. Dezember 2016 8:41 08

EN
MPS50 Using the mains rectifier
11
7 Using the mains rectifier
!
A
!
To avoid drops in voltage and therefore performance, keep the cable route as short
as possible and only disconnect it when necessary.
The cables between mains rectifier and compressor must not exceed 1.5 m and must
have a cross section of at least 2.5 mm².
WARNING!
Do not reverse the polarity. If the poles are reversed device may over-
heat and be damaged.
NOTICE!
Replace defective fuses with new ones of the same rating (12 A slow-
blow).
WARNING!
Ensure that the battery’s positive supply line is secured with a fuse
(fig. 21, page 11) of the following value:
•at 12 Vg: 15 A
•at 24 Vg: 7.5 A
The fuse must be installed as close to the battery as possible.
1
12/24 V
2
MPS50-IO-AU.book Seite 11 Mittwoch, 14. Dezember 2016 8:41 08

EN
Maintaining and cleaning the mains rectifier MPS50
12
➤Fit wire sleeves to the ends of wires which you wish to connect to the mains
rectifier.
➤Connect the battery using the B+ and B– terminals on the front plate (fig. 3,
page 12).
➤Connect the BDF50 compressor
– using the C+ and C– terminals (fig. 41, page 12) or
– using the socket on the front plate (fig. 42, page 12).
8 Maintaining and cleaning the
mains rectifier
!
A
➤Occasionally clean the device with a damp cloth.
WARNING! Danger of electrocution!
Always disconnect the mains plug before you clean and service the
device.
NOTICE! Danger of damaging the device!
Never clean the device under running water or in dish water.
Do not use abrasive cleaning agents or hard objects during cleaning as
these can damage the device.
3
2
1
4
MPS50-IO-AU.book Seite 12 Mittwoch, 14. Dezember 2016 8:41 08

EN
MPS50 Guarantee
13
9Guarantee
The statutory warranty period applies. If the product is defective, please contact the
manufacturer's branch in your country (see the back of the instruction manual for the
addresses) or your retailer.
For repair and guarantee processing, please include the following documents when
you send in the device:
•A copy of the receipt with purchasing date
•A reason for the claim or description of the fault
10 Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
MPS50-IO-AU.book Seite 13 Mittwoch, 14. Dezember 2016 8:41 08

EN
Technical data MPS50
14
11 Technical data
Battery operation
CoolPower MPS50
Reference number: 9109002476
Rated input voltage: 110 – 240 Vw, 50/60 Hz
Input voltage range: 100 – 250 Vw
Input current: 3 A
Rated output voltage: 27,0 Vg
Rated output current: 6 A
Peak output current: 18 A
Constant output power: 150 W
Operating temperature range: 0 °C to +40 °C
Fuse: 12 A slow-blow
Dimensions (W x H x D): 120 x 70 x 200 mm
Weight: 1.0 kg
Testing/certification:
Input voltage: 12/24 Vg
Output voltage: 12/24 Vg
Input/output current: 12/6 A
5375
MPS50-IO-AU.book Seite 14 Mittwoch, 14. Dezember 2016 8:41 08

MPS50-IO-AU.book Seite 15 Mittwoch, 14. Dezember 2016 8:41 08

YOUR LOCAL
SALES OFFICE
dometic.com/sales-offices
YOUR LOCAL
DEALER
dometic.com/dealer
YOUR LOCAL
SUPPORT
dometic.com/contact
dometic.com
A complete list of Dometic companies, which comprise the Dometic Group, can be found in the public filings of:
DOMETIC GROUP AB Hemvärnsgatan 15 SE-17154 Solna Sweden
4445101943 07/2019
