Dometic CoolFreeze CF-18 User manual

CF-18, CF-25, CF-35,
CF-40, CF-50, CF-60
CF-18 CF-25
CF-35
CF-40
CF-50
CF-60
Instruction Manual
Manuel d’utilisation
Instrucciones de uso
_CF-18_60.book Seite 1 Donnerstag, 26. Juli 2007 3:18 15
THE SIGN OF COMFORT
EN 7 Compressor Cooler
FR 26 Glacière à compression
ES 48 Nevera por compresor
LaGrange IN 46761
Form No.54-AA-MAD65A 4/08
Dometic Corporation

Notes on using the manual
1 Notes on using the manual
The following symbols are used in this operating manual:
aCaution!
Safety instruction: Failure to observe this instruction can cause
personal injury or damage the device.
eCaution!
Safety instruction relating to a danger from an electrical current
or voltage. Failure to observe this instruction can cause injury or
damage the device and impair its function.
INote
Supplementary information for operating the device.
➤Action: This symbol indicates that action is required on your
part. The required action is described step-by-step.
✓This symbol indicates the result of an action.
Fig. 2 1, page 3: This refers to an element in an illustration.
In this case, item 1 in figure 2on page 3.
Please observe the following safety instructions.
2 Safety instructions
azCaution!
DOMETIC International will not be held liable for claims for dama-
ge resulting from the following:
– Damage to the device resulting from mechanical influences
and overvoltage
– Alterations to the device made without the explicit permis-
sion of DOMETIC International
– Use for purposes other than those described in the operating
manual
_CF-18_60.book Seite 28 Donnerstag, 26. Juli 2007 3:18 15
7

Safety instructions
2.1 General safety
ezCaution – Danger of electrocution!
When using the device on boats: If the device is powered by the
mains, ensure that the power supply is protected with a ground
fault interrupter circuit.
zCheck that the voltage specification on the type plate corres-
ponds to that of the energy supply.
zOnly connect the device as follows:
– With the cable supplied (Fig. 12, page 3) to the cigarette
lighter in the vehicle or to a 12/24 V plug socket in the vehicle
– or with the enclosed connection cable (Fig. 1 3, page 3) to
the 120 V AC mains (only
CF-35 , CF-40 , CF-50 , CF-60 ).
zIf the connection cable is damaged, it must be replaced by a
special cord or assembly available from the manufacturer or
service agent.
zDo not pull the plug out of the cigarette lighter or the socket by
the cable.
zPull out the connection cable:
– Before cleaning and maintenance
– After use
– Before changing a fuse
zDisconnect the cooling device and other power consuming de-
vices from the battery before you connect the battery to a quick
charging device. Overvoltage can damage the electronics of the
device.
azElectronic devices are not toys!
Always keep and use the device out of the reach of children.
zDo not operate the device if it is visibly damaged.
zThis device may only be repaired by qualified personnel. Inade-
quate repairs can lead to considerable hazards.
Should your device need to be repaired, please contact DOME-
TIC customer service.
zDo not open the refrigerant circuit under any circumstances!
zThe cooler is not suitable for transporting caustic materials or
materials containing solvents.
zFood may only be stored in its original packaging or in suitable
containers.
_CF-18_60.book Seite 29 Donnerstag, 26. Juli 2007 3:18 15
8

Safety instructions
2.2 Operating the device safely
ezCaution – Danger of electrocution!
Do not touch exposed cables with your bare hands. This especially
applies when operating the device from an AC mains.
zBefore starting the device, ensure that the power supply line
and the plug are dry.
azDo not place any electrical devices inside the cooler.
zSet up the device in a dry location where it is protected against
splashing water.
zProtect the device and the cable against rain and moisture.
zDo not place the device near naked flames or other heat sour-
ces (heaters, direct sunlight, gas ovens etc.)
zCaution! Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the
heat generated during normal operation is able to dissipate.
Ensure that the ventilation slots are not covered. Make sure that
the device is sufficiently far away from walls and other objects
so that the air can circulate.
zNever immerse the device in water.
zDo not fill the inner container with ice or fluid.
_CF-18_60.book Seite 30 Donnerstag, 26. Juli 2007 3:18 15
9

Scope of delivery
3 Scope of delivery
Fig. 1, page 3, shows the scope of delivery.
4 Intended use
The cooler is suitable for cooling and freezing foods. The device is
also suitable for use on boats.
The device is designed to be operated from a 12 VDC or 24 VDC
on-board supply socket of a vehicle (e. g. cigarette lighter), boat or
caravan as well as from a 120 VAC mains (for CF-18 and CF-25
only with the accessory to 220–240 VAC).
aCaution – When cooling perishable medicines!
If you wish to cool medicines, please check if the cooling capacity
of the device is adequate for this purpose.
Item Quantity Description
1 1 Cooler
2 1 Connection cable for 12/24 VDC connection
3 1
Only CF-35, CF-40, CF-50, CF-60
Connection cable for 120 VAC connection
4 2
Only CF-35, CF-40, CF-50, CF-60
Carrying handle, consisting of:
– 2 holders
– 1 handle
– 4 fastening screws
– 1 Operating manual
_CF-18_60.book Seite 31 Donnerstag, 26. Juli 2007 3:18 15
10

Function description
5 Function description
The cooler can chill products, keep them cool as well as freeze
them. A maintenance-free, CFC-free refrigerant circuit with
compressor provides the cooling. The extra strong CFC-free
insulation and powerful compressor ensure especially fast cooling.
The cooler is designed for mobile use and can be carried by using
a folding carrying bracket (CF-18), two recessed grips (CF-25) or
two removable carrying handles (CF-35, CF-40, CF-50, CF-60).
When used on boats, the cooler can be withstand a constant heel
(inclination) of 30°.
Scope of functions:
CF-18 CF-25 CF-35, CF-40,
CF-50, CF-60
Power supply with
priority circuit for
connecting to the
AC mains
– – z
Battery monitor for
protecting the vehicle
battery
2-level 3-level
Turbo mode for rapid
cooling –z z
Display with temperature
gauge –z z
Temperature setting With
rotary-
control
With two buttons in steps of 1 °C (2 °F)
Removable carrying
handles – – z
_CF-18_60.book Seite 32 Donnerstag, 26. Juli 2007 3:18 15
11

Function description
5.1 Operating and display elements
CF-25, CF-35, CF-40
Lock for lid: Fig. 21, page 3
CF-18
Operating panel and connection socket (Fig. 3, page 3):
Item Description Explanation
1 TEMPERATURE Temperature controller,
cooling temperature at the end positions:
COLD: +10 °C (+50 °F)
FREEZE: –18 °C (0 °F)
2 POWER Operating display
LED is lit green: Device is switched
on and ready for
operation
LED is lit yellow: Set temperature has
been reached
3 ERROR LED flashes red: Switched on device
is not ready for
operation
4 BATTERY
MONITOR
Switch-on device/battery monitor:
0: Device is switched
off
HIGH: Device is switched
on, battery monitor
is in HIGH mode
LOW: Device is switched
on, battery monitor
is in LOW mode
5 12/24V DC Connection socket DC voltage supply
_CF-18_60.book Seite 33 Donnerstag, 26. Juli 2007 3:18 15
12

Function description
CF-25, CF-35, CF-40, CF-50, CF-60
Operating panel (Fig. 4, page 4)
CF-25
Connection sockets (Fig. 5, page 4):
CF-35, CF-40, CF-50, CF-60
Connection sockets (Fig. 6, page 4):
Item Description Explanation
1 ON
OFF
Switches the cooler on or off when the
button is pressed for between one and
two seconds
2 POWER Status indication
LED lights up
green:
Compressor is on
LED lights up
orange:
Compressor is off
3 ERROR LED flashes red: Device is switched
on but not ready for
operation
4 SET Selects the input mode
- Temperature setting
- Celsius or Fahrenheit display
- Set battery monitor
5 – Display, shows the information
6 UP + Press once to increase the value
7 DOWN – Press once to decrease the value
Item Description
1 Connection socket DC voltage supply
Item Description
1 Connection socket AC voltage supply
2 Fuse holder
3 Connection socket DC voltage supply
_CF-18_60.book Seite 34 Donnerstag, 26. Juli 2007 3:18 15
13

Operation
5.2 Accessories
If you want to operate the coolers CF-18 and CF-25 from the
220–240 V AC mains, be sure to use the rectifier DOMETIC
CoolPower EPS100.
6 Operation
6.1 Before initial use
INote
Before starting your new cooler for the first time, you should clean
it inside and outside with a damp cloth for hygienic reasons (please
also refer to the chapter “Cleaning and maintenance” on page 43).
Mounting the handles
CF-35, CF-40, CF-50, CF-60
The handles are enclosed unassembled. If you wish to attach the
handles, proceed as follows:
➤Make a handle by putting two holders (Fig. 71, page 4) and a
handle (Fig. 72, page 4) together.
➤Fasten the grip with the enclosed screws in the holes provided.
Turning the lid stop around
CF-50, CF-60
You can turn the lid stop around if you want to open the lid from the
other side.
To do this, proceed as follows:
➤Open the lid and pull it out (Fig. 8A, page 5).
➤Turn the lid.
➤Insert the lid in the lid holders on the side opposite the cooler
(Fig. 8B, page 5).
_CF-18_60.book Seite 35 Donnerstag, 26. Juli 2007 3:18 15
14

Operation
Selecting the temperature units
CF-25, CF-35, CF-40, CF-50, CF-60
You can switch the temperature display between Celsius and Fahr-
enheit. This is how to do it:
➤Switch on the cooler.
➤Press the “SET” button (Fig. 44, page 4) twice.
➤Use the “UP +” (Fig. 46, page 4) and “DOWN -” (Fig. 47,
page 4) buttons to select Celsius or Fahrenheit.
✓The selected temperature units then appear in the display for a
few seconds. The display flashes several times before it returns
to the current temperature.
6.2 Energy saving tips
zChoose a well ventilated installation location which is protected
from direct sunlight.
zAllow hot food to cool down first before you place it into the
device.
zDo not open the cooler more often than necessary.
zDo not leave the lid open for longer than necessary.
zDefrost the cooler once a layer of ice forms.
zAvoid unnecessary low temperatures.
_CF-18_60.book Seite 36 Donnerstag, 26. Juli 2007 3:18 15
15

Operation
6.3 Connecting the cooler
Connecting to a battery (Vehicle or boat)
The cooler can be operated with 12 V or 24 V DC.
eCaution – Danger of damaging the device!
Disconnect the cooler and other consumer units from the battery
before you connect the battery to a quick charging device.
Overvoltage can damage the electronics of the device.
For safety reasons the cooler is equipped with an electronic system
to prevent the polarity reversal. This protects the cooler against
short-circuiting when connecting to a battery.
➤Plug the 12/24-V connection cable (Fig. 12, page 3) into the
DC voltage socket and also into the cigarette lighter or a 12 V
or 24 V socket.
Connecting to a 120 V AC mains (E.g. in the home or office)
eCaution – Danger of electrocution!
Never handle plugs and switches with wet hands or if you are
standing on a wet surface.
eCaution – Danger of electrocution!
If you are operating your cooler on board a boat from a mains con-
nection of 120 V AC, you must install a residual current circuit
breaker between the 120 V AC mains and the cooler.
Seek advice from a trained technician.
CF-35, CF-40, CF-50, CF-60
The coolers CF-35, CF-40, CF-50, CF-60 have an integrated multi-
voltage power supply with priority circuit for connecting to an AC
voltage source of 120 V. The priority circuit automatically
switches the cooler to mains operation, if the device is connected
to a 120 V AC mains, even if the 12/24 V connection cable is
still attached.
When switching between the AC mains and the battery supply,
the red LED may light up briefly.
_CF-18_60.book Seite 37 Donnerstag, 26. Juli 2007 3:18 15
16

Operation
➤Plug the 120 V connection cable (Fig. 13, page 3) into
the AC voltage socket and connect it to the 120 V AC
voltage mains (only CF-35, CF-40, CF-50, CF-60).
CF-18, CF-25
To operate the coolers CF-18 and CF-25 from the 220–240 V AC
mains, use the rectifier DOMETIC CoolPower EPS100 (accessory).
6.4 Using the battery monitor
The device is equipped with a multi-level battery monitor that
protects your vehicle battery against excessive discharging when
the device is connected to the on-board 12/24 V supply.
If the cooler is operated when the vehicle ignition is switched off,
the cooler switches off automatically as soon as the supply voltage
falls below a set level. The cooler will switch back on once the
battery has been recharged to the restart voltage level.
aCaution – Danger of damage!
When switched off by the battery monitor, the battery will no longer
be fully charged. Avoid starting repeatedly or operating current
consumers without longer charging phases. Ensure that the battery
is recharged.
In “HIGH” mode, the battery monitor responds faster than at the
levels “LOW” and “MED” (see the following table).
CF-18 CF-25, CF-35, CF-40,
CF-50, CF-60
Battery monitor mode LOW HIGH LOW MED HIGH
Switch-off voltage at 12 V 10.4 V 11.5 V 10.1 V 11.4 V 11.8 V
Restartvoltage at 12 V 11.5 V 12.5 V 11.1 V 12.2 V 12.6 V
Switch-off voltage at 24 V 22.1 V 24.0 V 21.5 V 24.1 V 24.6 V
Restart voltage at 24 V 23.6 V 25.4 V 23.0 V 25.3 V 26.2 V
_CF-18_60.book Seite 38 Donnerstag, 26. Juli 2007 3:18 15
17

Operation
This is how to select the battery monitor mode:
CF-25, CF-35, CF-40, CF-50, CF-60
➤Switch on the cooler.
➤Press the “SET” button (Fig. 44, page 4) three times.
➤Use the “UP +” (Fig. 46, page 4) and “DOWN -” (Fig. 47,
page 4) buttons to select the battery monitor mode.
✓The selected mode then appears in the display for a few sec-
onds. The display flashes several times before it returns to the
current temperature.
INote
When the cooler is supplied by the starter battery, select the battery
monitor mode “HIGH”. If the cooler is connected to a supply battery,
the battery monitor mode “LOW” will suffice.
If you wish to operate the cooler from the AC mains, set the battery
monitor to the “LOW” position.
6.5 Using the cooler
aCaution – Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the
heat that generated during operation can dissipate. Ensure that
the ventilation slots are not covered. Make sure that the device
is sufficiently far away from walls and other objects so that the
air can circulate.
➤Place the cooler on a firm foundation.
Make sure that the ventilation slots are not covered and that the
heated air can dissipate.
INote
Place the cooler as shown (Fig. 1, page 3).If you operate the box
in a different position it can be damaged.
➤Close the cooler, see “Connecting the cooler” on page 37.
INote
If you wish to operate the cooler from the AC mains, set the battery
monitor to the “LOW” position.
_CF-18_60.book Seite 39 Donnerstag, 26. Juli 2007 3:18 15
18
There should be a clearance.of~150mm from the
fridge handle.

Operation
aCaution – Danger from excessively low temperature!
Ensure that the only those objects are placed in the cooler that are
intended to be cooled at the selected temperature.
CF-18
➤CF-18: Slide the sliding switch (Fig. 34, page 3) to HIGH if
you wish to operate from a starter battery or to “LOW” if you
want to operate from a supply battery.
✓The “POWER” LED is lit green.
✓The cooler starts cooling the interior.
✓When the cooling temperature has been reached, the “POWER”
LED is yellow lit.
CF-25, CF-35, CF-40, CF-50, CF-60
➤Press the “ON/OFF” button (Fig. 41, page 4) for between one
and two seconds.
✓The “POWER” LED lights up.
✓The display (Fig. 45, page 4) switches on and shows the
current cooling temperature.
INote
The temperature displayed is that of the middle of the interior.
The temperatures elsewhere can deviate from this temperature.
✓The cooler starts cooling the interior.
Locking the cooler
➤Close the lid.
➤Press the lock (Fig. 21, page 3) down, until it latches in
place audibly.
6.6 Setting the temperature
CF-18
➤Set the cooling temperature with the temperature controller
(Fig. 31, page 3).
_CF-18_60.book Seite 40 Donnerstag, 26. Juli 2007 3:18 15
19

Operation
CF-25, CF-35, CF-40, CF-50, CF-60
➤Press the “SET” button (Fig. 44, page 4) once.
➤Use the “UP +” (Fig. 46, page 4) and “DOWN -” (Fig. 47,
page 4) buttons to select the cooling temperature.
✓The cooling temperature appears in the display for a few
seconds. The display flashes several times and then the current
tempera-ture is displayed again.
6.7 Switching off the cooler
➤Empty the cooler.
➤Switch the cooler off.
➤Pull out the connection cable.
If you do not want to use the cooler for a longer period of time:
➤Leave the cover slightly open. This prevents odour build-up.
6.8 Defrosting the cooler
Humidity can form frost in the interior of the cooling device or on the
vaporiser. This reduces the cooling capacity. Defrost the device in
good time to avoid this.
aCaution – Danger of damaging the device!
Never use hard or pointed tools to remove ice or to loosen objects
which have frozen in place.
To defrost the cooler, proceed as follows:
➤Take out the contents of the cooling device.
➤If necessary, place them in another cooling device to keep them
cool.
➤Switch off the device.
➤Leave the cover open.
➤Wipe off the defrosted water.
_CF-18_60.book Seite 41 Donnerstag, 26. Juli 2007 3:18 15
20

Operation
6.9 Replacing the device fuse
Only CF-35, CF-40, CF-50, CF-60
eCaution – Danger of electrocution!
Disconnect the connection cable before you replace the device
fuse.
➤Pull off the connection cable.
➤Pry out the fuse insert (Fig. 62, page 4) with a screwdriver.
➤Replace the defective fuse with a new one that has the same
rating (T2,5AL 250V).
➤Press the fuse insert back into the housing.
6.10 Replacing the plug fuse (12/24 V)
➤Pull the adapter sleeve (Fig. 94, page 5) off of the plug.
➤Unscrew the screw (Fig. 95, page 5) out of the upper half of
the housing (Fig. 91, page 5).
➤Carefully raise the upper half of the housing from the lower
(Fig. 96, page 5) half.
➤Take out the contact pin (Fig. 93, page 5).
➤Replace the defective fuse (Fig. 92, page 5) with a new one
that has the same rating (8A 32V).
➤Re-assemble the plug in the reverse order.
_CF-18_60.book Seite 42 Donnerstag, 26. Juli 2007 3:18 15
21

Cleaning and maintenance
6.11 Replacing the light bulb
Only CF-25, CF-35, CF-40, CF-50, CF-60
➤Press the switch pin (Fig. 02, page 5) downwards so that the
transparent part (Fig. 01, page 5) of the lamp can be removed
at the front.
➤Replace the light bulb.
INote
Make sure that the polarity is correct. The side of the light bulb
marked with a plus must be placed at the contact which is connect-
ed to the red cable.
INote
The LEDs in the light bulb must be aligned with the transparent part
of the lamp.
➤Press the transparent part of the lamp back into the housing.
7 Cleaning and maintenance
eCaution – Danger of electrocution!
Always pull out the mains plug before you clean and service the de-
vice.
aCaution – Danger of damaging the device!
Never clean the device under running water or in dish water.
Do not use abrasive cleaning agents or hard objects during clean-
ing as these can damage the device.
Never use brushes, scouring pads or hard or pointed tools to re-
move ice or to loosen objects which have frozen in place.
➤Occasionally clean the inside of the device with a damp cloth.
_CF-18_60.book Seite 43 Donnerstag, 26. Juli 2007 3:18 15
22

Guarantee
8 Guarantee
Our general guarantee conditions apply. If the product is defective,
please send it back to the DOMETIC branch in your country
(addresses on the back of the operating manual) or to your dealer.
For repair and guarantee processing, please include the following
documents when you send in the device:
zA copy of the receipt with purchasing date
zReason for the claim or a description of the fault
9 Troubleshooting
Fault Possible cause Suggested remedy
Device does not
function, LED does
not glow.
There is no voltage
present in the 12/24 V
socket (cigarette lighter)
in your vehicle.
The ignition must be switched on in most
vehicles to apply current to the cigarette
lighter.
No voltage present in the
AC voltage socket.
Try using another plug socket.
The device fuse is
defective.
Replace the device fuse, see “Replacing
the device fuse” on page 42.
The integrated mains
adapter is defective.
This can only be repaired by an
authorised repair centre.
The device does not
cool (plug is inserted,
“POWER” LED is lit).
Defective compressor. This can only be repaired by an
authorised customer services unit.
The device does not
cool (plug is inserted,
“ERROR” LED flashes).
Battery voltage is too
low.
Test the battery and charge it as needed.
When operating from
the 12/24-V socket
(cigarette lighter):
The ignition is on
and the device is not
working and the LED
is not lit.
Pull the plug out of the
socket and make the
following checks.
The cigarette lighter
socket is dirty. This results
in a poor electrical
contact.
If the plug of your cooler becomes very
warm in the cigarette lighter socket, either
the lighter socket must be cleaned or the
plug has not been assembled correctly.
The fuse of the 12/24 V
plug has blown.
Replace the fuse (5 A) in the cigarette
lighter plug, see “Replacing the plug fuse
(12/24 V)” on page 42.
The vehicle fuse has
blown.
Replace the vehicle’s 12/24 V socket fuse
(usually 15 A). Please refer to your
vehicle’s operating manual.
The display shows an
error message (e.g.
“Err1”) and the appli-
ance does not cool.
The appliance has
switched off due to an
internal fault.
This can only be repaired by an
authorised repair centre.
_CF-18_60.book Seite 44 Donnerstag, 26. Juli 2007 3:18 15
23

Disposal
10 Disposal
➤Place the packaging material in the appropriate recycling waste
bins wherever possible.
If you wish to finally dispose of the device, ask your local recycling
centre or specialist dealer for details about how to do this in
accordance with the applicable disposal regulations.
11 Technical data
INote
If the ambient temperature is above +32°C (+90 °F), the minimum
temperature cannot be attained.
CF-18 CF-25 CF-35
Overall capacity: 18 litres 23 litres 31 litres
Connection voltage: 12/24 VDC 12/24 VDC and
120VAC
Rated current:
– 12 VDC: 3.1 A 6.8 A 6.0 A
– 24 VDC: 1.9 A 3.0 A 3.0 A
– 120 VAC
Cooling capacity: +10 °C to –18 °C (+50 °F to 0 °F)
Dimensions (WxHxD)
in mm:
465x414x300 550x425x260 580x385x360
Weight: 11.5 kg 12 kg 15 kg
CF-40 CF-50 CF-60
Overall capacity: 37 litres 49 litres 59 litres
Connection voltage: 12/24 VDC and 120 VAC
Rated current:
– 12 VDC: 6.0 A 7.0 A 7.0 A
– 24 VDC: 3.0 A 3.0 A 3.0 A
– 120 VAC
Cooling capacity: +10 °C to –18 °C (+50 °F to 0 °F)
Dimensions (WxHxD)
in mm:
580x445x360 630x480x360 630x582x360
Weight: 16 kg 18 kg 21.6 kg
_CF-18_60.book Seite 45 Donnerstag, 26. Juli 2007 3:18 15
24
: – – 1.3 to 0.7 A
: 1.3 to 0.7 A 1.3 to 0.7 A 1.3 to 0.7 A

Technical data
Test/certificates:
Versions, technical modifications and delivery options reserved.
This device is CFC-free. The coolant circuit contains R134a.
– 73/23/EEC – Low Voltage Electrical Equipment
Directive
– 89/336/EEC – EMC Directive
– 95/54/EEC
_CF-18_60.book Seite 46 Donnerstag, 26. Juli 2007 3:18 15
25
