Dometic RM122 User manual

Absorber refrigerator
Installation and Operating Manual. . . 8
Absorber-Kühlschrank
Montage- und Bedienungsanleitung 27
Réfrigérateur à absorption
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . 49
Nevera con extractor
Instrucciones de montaje y de uso . 70
Frigorifero ad assorbimento
Istruzioni di montaggio e d’uso . . . . 91
Absorptiekoelkast
Montagehandleiding en
gebruiksaanwijzing . . . . . . . . . . . . 111
Absorber-køleskab
Monterings- og
betjeningsvejledning . . . . . . . . . . . 131
Absorptionskylskåp
Monterings- och bruksanvisning . . 150
Absorbsjons-kjøleskap
Monterings- og bruksanvisning . . . 169
Absorptiojääkaappi
Asennus- ja käyttöohje . . . . . . . . . 188
Frigorífico de absorção
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . 207
Абсорбционный
холодильник
Инструкция по монтажу и
эксплуатации . . . . . . . . . . . . . . . . 228
EN
DE
FR
ES
IT
NL
DA
SV
NO
FI
PT
RU
Lodówka absorpcyjna
Instrukcja montażu i obsługi . . . . . 249
Absorpční lednička
Návod k montáži a obsluze. . . . . . 269
Absorpčná chladnička
Návod na montáž a uvedenie do
prevádzky . . . . . . . . . . . . . . . . . . . 289
Abszorberes hűtőszekrény
Szerelési és használati útmutató . 308
PL
CS
SK
HU
RM122, RM123

RM122, RM123
3
380 mm
300 mm100 mm
439 mm
510 mm
400 mm39 mm
586 mm
1
2
1
3
4
5
6
7
2
3
2
1
4
3
1
4

RM122, RM123
4
662 mm
420 mm
76 mm76 mm
1
5
7
6

RM122, RM123
5
12
8
1
2
3
9
1
a
y
x
0
1
b
RM123

RM122, RM123
6
RM122
RM123
c
3 AMP
3
2
1
d
RM123

RM122, RM123
7
SW13
SW17
e
1
2
g
RM123
1
2
f
RM122
i
1
h

EN
RM122, RM123
8
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is passed on to
another person, this operating manual must be handed over to the user
along with it.
The manufacturer cannot be held liable for damage resulting from
improper usage or incorrect operation.
Contents
1 Notes on using the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7 Installing the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Connecting the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9 Using the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
10 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
11 Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
12 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

EN
RM122, RM123 Notes on using the manual
9
1 Notes on using the manual
!
A
I
➤Action: This symbol indicates that action is required on your part. The
required action is described step-by-step.
✓This symbol describes the result of an action.
Fig. 15, page 3: This refers to an element in an illustration. In this case,
item 5 in figure 1 on page 3.
2 Safety instructions
2.1 General safety
!WARNING!
Do not operate the device if it is visibly damaged.
If this device's power cable is damaged, it must be replaced by
the manufacturer, customer service or a similarly qualified
person in order to prevent safety hazards.
This device may only be repaired by qualified personnel.
Improper repairs can lead to considerable hazards.
This device can be used by children aged 8 years and above as
well as persons with reduced physical, sensory or mental capa-
bilities or lack of experience and knowledge, if they are super-
vised or have been instructed to safely use the device and if
they understand the hazards resulting out of it.
Cleaning and user maintenance must not be carried out by chil-
dren without supervision.
WARNING!
Safety instruction: Failure to observe this instruction can cause
fatal or serious injury.
NOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
NOTE
Supplementary information for operating the product.

EN
Safety instructions RM122, RM123
10
Children must not play with the device.
Children must be supervised to ensure that they do not play with
the device.
Always keep and use the device out of the reach of children
under the age of 8 years.
Do not store any explosive substances such as spray cans with
a flammable propellant in the device.
!CAUTION!
Disconnect the device from the mains
– before each cleaning and maintenance
– after every use
Food may only be stored in its original packaging or in suitable
containers.
ANOTICE!
Check that the voltage specification on the type plate
corresponds to that of the energy supply.
Never pull the plug out of the socket by the cable.
The cooling device is not suitable for transporting caustic
materials or materials containing solvents.
2.2 Operating the device safely
ANOTICE!
Do not use electrical devices inside the cooler unless they are
recommended by the manufacturer for the purpose.
Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the
heat that arises during operation does not build up. Provide an
air inlet with a cross-section of at least 250 cm² as well as a vent
hole.
Ensure that the ventilation openings are not covered.
Do not fill the inner container with ice or fluid.
Never immerse the device in water.
Protect the device and the cable against heat and moisture.

EN
RM122, RM123 Safety instructions
11
2.3 Operating the appliance safely at 12 Vg
ANOTICE!
The cable between the battery and the cooling device must be
protected by a fuse with a maximum rating of 15 A.
Only select 12 Vg operation (battery mode) if you are using a
battery monitor or if the alternator in your vehicle provides suffi-
cient voltage.
Only use cables with an appropriate cross section.
2.4 Operating the appliance safely at 230 Vw
ANOTICE!
Only use the cable supplied to connect the appliance to the AC
mains.
Never pull the plug out of the socket by the cable.
If the cable is damaged, it must be replaced to prevent possible
electrical hazards. Only replace a damaged cable with one of
the same type and specifications.
Before starting the appliance, ensure that the power supply line
and the plug are dry.
Check that the voltage specification on the type plate is the
same as that of the power supply.
2.5 Operating the appliance safely with gas
ANOTICE!
Never use a naked flame to check for leaks.
Only use propane or butane gas (not natural gas).
Always operate the appliance at the pressure shown on the
type plate. Use a DIN-DVGW-approved pressure regulator with
a fixed setting in accordance with DIN EN 12864.
Never store liquid gas cylinders where there is poor ventilation
or below ground level (funnel-shaped holes in the ground).
Keep liquid gas cylinders away from direct sunlight. The temper-
ature may not exceed 50 °C.
The appliance may not be operated with gas on ferries.

EN
Scope of delivery RM122, RM123
12
If you smell gas:
– Close the gas supply cock and close the valve on the cylin-
der.
– Open the windows and leave the room.
– Do not use any electrical switches.
– Put out any naked flames.
3 Scope of delivery
Refrigerator
230 Vwconnection cable (RM123 only)
12 Vgconnection cable
Connection cable
Operating and installation manual
Flue venting kit
4 Accessories
Available as accessories (not included in the scope of delivery):
If you have questions in respect of the accessories, please contact your local
service partner.
Description Item No.
Ventilation grille LS100, with exhaust routing and winter cover
white 9105900012
beige 9105900011
Ventilation grille LS200, without exhaust routing, with winter cover
white 9105900014
beige 9105900013

EN
RM122, RM123 Intended use
13
5 Intended use
The refrigerators RM122 and RM123 are designed for installation in cara-
vans or motorhomes. They are suitable for cooling foodstuffs.
The refrigerators are designed for operation on a 12 Vgvoltage source and
can be independently powered by liquefied petroleum gas (propane or bu-
tane). The refrigerator RM123 is also designed for connection to a mains
voltage of 220–240 Vw.
6 Technical description
6.1 Description
The refrigerator is an absorption refrigerator. The device is designed to oper-
ate with different types of energy and can be operated as follows:
RM122: with 12 Vgor butane/propane gas
RM123: with 220–240 Vw, 12 Vgor butane/propane gas
The device has a locking mechanism to protect it during transport.
The unit is equipped with an automatic flame failure device which automati-
cally interrupts the gas supply after approx. 30 seconds if the flame goes out.
6.2 Control elements
Item in fig. 2,
page 3 Description
1 Locking mechanism
2 Evaporator
3 Drip collector
4 Flame control window
5 Temperature controller for operation with gas
6RM122: Button for piezo igniter
RM123: Switch for electronic ignition
7 Temperature controller for electric operation

EN
Installing the refrigerator RM122, RM123
14
7 Installing the refrigerator
7.1 Preparing the installation
Observe the following instructions when installing the refrigerator:
The refrigerator should not exceed an angle of inclination of 3° so that the
refrigerant can be circulated properly. Make make sure that the ice tray is
flat in the refrigerator when the vehicle is level.
The refrigerator must be installed in a recess so that it remains fixed in
place during movement of the vehicle. Mind the following dimensions:
(HxWxDinmm):662x384x415.
All surfaces around exhaust pipe and burner housing must be of or cov-
ered by metal or other non-flammable material.
In the outer wall an air inlet (fig. 31, page 3) and vent hole (fig. 32,
page 3) with ventilation grid has to be provided so that emerging heat can
be properly dissipated to the outside:
– air inlet: ventilation grid as flush as possible to the floor of the fitted
niche with a cross-section of at least 250 cm²
– vent hole: preferably atop the device. Here a ventilation grid with inte-
grated exhaust gases duct can be used instead.
If the air inlet‘s ventilation grid cannot be mounted flush to the floor, an
additional air inlet (fig. 34, page 3) must be provided in the floor to dis-
charge leaking gas.
The air inlet and the vent hole must not be covered by vehicle compo-
nents (e.g. bumper or open door) during operation.
At the back of the refrigerator must be enough space so that air can
circulate around the cooling element.
Provide a heat conducting plate on the upside (fig. 31, page 3) so that
heat cannot build up inside the vehicle.
The refrigerator must be installed draught-proof according to EN 1949,
see chapter “Installing the refrigerator draught-proof” on page 15.

EN
RM122, RM123 Installing the refrigerator
15
7.2 Installing the refrigerator draught-proof
Gas powered cooling devices in caravans and motorhomes must be installed
draught-proof according to EN 1949. This means that the combustion air
won‘t be taken from the interior room and that the exhaust gases are
prevented from direct entry to the living space.
A suitable sealing between the backside of the refrigerator and the interior of
the vehicle must be provided.
!
The manufacturer recommends using a flexible seal to simplify the assembly
and disassembly for maintenance.
➤Fix the lip seals (fig. 41, page 3) to a stop bar behind the refrigerator,
e.g. by gluing.
➤While mounting push the refrigerator against the stop bar with the lip
seals. Thereby the area behind the device is sealed towards the interior
of the vehicle.
7.3 Making air inlet and vent hole
I
➤Produce an air inlet and a vent hole in the outer wall. Observe the follow-
ing instructions, see chapter “Preparing the installation” on page 14.
If the air inlet‘s ventilation grid cannot be mounted flush to the floor of the fit-
ted niche, you must install an air inlet in the floor:
➤Make a vent opening of a diameter of at least 40 mm on the ground be-
hind the refrigerator in the area of the gas burner (fig. 51, page 4). The
vent pipe must be routed directly to the outside. So leaking unburnt gas
can escape to the outside.
➤Shield the end of the opening with a deflector to prevent it from mud or dirt
while driving (fig. 6, page 4).
WARNING! Fire hazards!
Do not use easily inflammable materials such as silicone
sealants, installation foam, etc. for the draught-proof installation.
NOTE
At high ambient temperatures the refrigerator can only generate
its maximum cooling capacity if a optimal ventilation and
de-aeration is provided.

EN
Installing the refrigerator RM122, RM123
16
7.4 Fixing the refrigerator
➤Fix the refrigerator using blocks of wood laterally:
Fix the blocks of wood on the side of the recess from the front to the back
(fig. 81, page 5).
7.5 Installing exhaust pipe
The exhaust pipe must lead the exhaust gases directly to the outside.
➤Make an opening with a maximum diameter of 70 mm at the opening in
the vehicle wall.
➤Put the T-piece (fig. 92, page 5) on the opening of the refrigerator.
➤Lead the extension tube (fig. 91, page 5) of the venting kit outside
through the opening.
The vent cover must touch the outer wall of the vehicle. If this is not the
case, you have to shorten the extension tube (fig. 91, page 5).
A
I
To shorten the extension tube, proceed as follows:
➤Insert extension tube (fig. 91, page 5) and tail (fig. 92, page 5) into
each other.
➤Measure the area between the vent cover and outer wall (fig. 0X,
page 5).
➤Transfer the measurement to the end of the extension tube (fig. 0Y,
page 5).
➤Shorten the extension tube accordingly.
➤Secure the end with the opening of the refrigerator with a screw (fig. 9,
page 5, ).
NOTICE! Risk of damage!
Do not extend the exhaust pipe, otherwise the water vapour con-
denses in the exhaust pipe and runs back into the unit. The burner
can be damaged.
NOTE
If the vehicle wall at the outlet of the exhaust pipe is not vertical or
flat, you have to fill the feed cover plate below with a non-combus-
tible material. The cover plate must be parallel to the back wall of
the refrigerator.

EN
RM122, RM123 Installing the refrigerator
17
➤Seal the hole with non-flammable sealant (fig. a1, page 5).
➤Fix the cover plate with four screws on the outer wall of the vehicle
(fig. 93, page 5).
7.6 Installing cover plate above the refrigerator door
➤Screw a block of wood on each side with the dimensions 25 x 66 mm on
both sides of the recess.
➤Mount the blocks 16 mm offset inwards, so that the cover plate flush with
the front of the kitchen furniture (fig. 82, page 5).
➤Screw the cover plate on the blocks.
7.7 Reversing the door hinge
A
The refrigerator is delivered with the door hinge on the right. This is how to
reverse the door hinge:
➤Turn the refrigerator on the side.
➤Pull the knob of the temperature switch.
➤Loosen the two screws and remove the lower cover plate.
➤Remove the top hinge leaf and the closure plate.
➤Hold the upper hinge leaf and the closure plate to the desired side and at-
tach it to the lower hinge leaf from the opposite side.
➤Install the vent grille with the two screws.
➤Press the knob of the temperature switch to the spindle so that it is fixed
in the recess.
➤Wait a few hours before starting the refrigerator.
NOTICE! Risk of damage
Lay the refrigerator on the side only, never on the backside.
Otherwise the aggregate may be damaged.

EN
Connecting the refrigerator RM122, RM123
18
7.8 Changing door decor
A
You can change the door decor. The door decor can consist of stainless
metal or plastic laminate and must have the following dimensions:
485 x 350 x 0.5 – 3 (H x W x D in mm).
Proceed as follows to change the door decor:
➤Turn the refrigerator on the side.
➤Remove the three screws on the bottom of the door frame.
➤Pull out the decor.
➤Slide the new decor into the opening.
➤Screw the three screws back in.
➤Wait a few hours before starting the refrigerator.
8 Connecting the refrigerator
8.1 Connecting igniter (RM123 only)
Use a cable with a diameter of 0.5 mm² and a fuse with 0.5 or 1 A.
➤Connect the terminal block of the igniter with the plus and minus pole of
the battery (fig. b1, page 5).
8.2 Connecting to 12 Vg
the device is connected with a 12-V-plug to a 12-V-socket
➤Connect the refrigerator as shown in fig. c, page 6.
➤Fit a suitable fuse to the control cable.
➤Connect the control cable to the connected positive terminal (terminal 15).
➤Install a relay between refrigerator and battery to prevent the battery is
completely discharged accidentally when the engine is switched off.
NOTICE! Risk of damage
Lay the refrigerator on the side only, never on the backside.
Otherwise the aggregate may be damaged.

EN
RM122, RM123 Connecting the refrigerator
19
8.3 Connecting to 230 Vw(RM123 only)
!
The device is connected to a 230-Vwpower outlet via a power plug.
The connecting cable is delivered without a power plug. A suitable power
plug may only be connected by a specialist. The power plug must fit the
power outlet in your vehicle and comply with the legal requirements in your
country.
If necessary, have an appropriate power plug installed at a suitable place.
The mains socket must be easily accessible so that you can unplug the
power plug if necessary, and thus the device can be disconnected from the
mains.
The cable wiring is as follows:
Green and yellow: Earth (fig. d1, page 6)
Blue: Neutral (fig. d2, page 6)
Brown: Phase (fig. d3, page 6)
8.4 Connecting to a gas source
A
WARNING!
The electrical installation must only be connected by a qualified
electrician in accordance with national regulations. Improper con-
nection can cause serious danger.
NOTICE!
The device may only be connected by a qualified electrician in
accordance with applicable regulations and standards to the
gas supply.
Only use cylinders of propane or butane gas (not natural gas)
with an approved pressure reduction valve and suitable top
part. Compare the pressure specifications on the nameplate
with the pressure indication on the propane or butane gas bot-
tle.
The device may only be operated at the pressure indicated on
the nameplate.
Please note the pressures which are permitted in your coun-
try.Use a DIN-DVGW-approved pressure regulator with a fixed
setting in accordance with DIN EN 12864.
Note the norms EN 732 and EN 1949.

EN
Using the refrigerator RM122, RM123
20
The refrigerator must be lockable separately by means of a shut-off device in
the gas connection. The shut-off device shall be easily accessible.
➤Connect the refrigerator to a gas source as shown in fig. e, page 7.
Use a cutting ring coupling according to EN 1949, firm and off circuit.
A hose connection is not permitted.
➤Check all connections with leak spray. There are no leaks if no bubbles
form.
9 Using the refrigerator
!
A
I
9.1 Switching on the refrigerator
Gas operation (RM122)
➤Open the refrigerator door. In the sight glass (fig. 24, page 3), you can
see if the flame is burning.
➤Make sure that the gas supply is turned on.
➤Turn the temperature regulator (fig. f2, page 7) to position “3”.
➤Push in the temperature regulator and keep it pressed until the burner has
ignited.
CAUTION! Health hazard!
If you wish to cool medicines, please check if the cooling capacity
of the appliance is suitable for the medicine in question.
NOTICE!
Only put items in the refrigerator which can be kept at the se-
lected temperature.
Food may only be stored in its original packaging or in suitable
containers.
NOTE
Before using the appliance for the first time, clean it inside and
out with a damp cloth for hygienic reasons.
The cooling performance can be affected by:
– The ambient temperature
– The amount of food to be conserved
– How often you open the door
