Dometic RM8 Series User manual

DOMETIC ABSORTION-
REFRIGERATOR
for LEISURE VEHICLES –
the new 8 series
DOMETIC GMBH
TECHNICAL DOCUMENTATION
SIEGEN
RM 8XXX
SERVICE MANUAL
TD MBA 2007-10 EN

MODELS
OPERATING
COMPONENTS
INSTALLATION
SERVICE + MAINTENANCE
TD S2
Content
TD S21
TD S3
Page
TD S46
TD S32
TD S39

MODELS
TD S3

MODELS
TD S4
0 = manual ignition (battery
igniter)
1 = Automatic ignition
5 = Automatic ignition and
automatic energy selection
RM(S)(T) 8400 L
L = with interior light
0 = Standard Depth
5 = Depth + 55 mm
6 = Depth + 65 mm
series
RM
Refrigerator Mobile
Description of models
S = housing with
step
T = TecTower
D = large
L = extra Large
O = single-door
fridge with oven
4 = width 486 mm
5 = width 525 mm

MODELS
TD S5
RM(S)8xx1 MES 85-122 l
RM(S)8xx5 AES 85-122 l
Width of Housing: 486 mm or 525 mm
Height: 821 mm
Depth: 568mm, 623mm or 633mm
Fridges of the 8-series are only available
with curved door
Model Description

MODELS
TD S6
RM(S)8xx0 Battery Igniter 85-122 l
Width of Housing: 486 mm or 525 mm
Height: 821 mm,
Depth: 568 mm, 623 mm or 633 mm
Fridges of the 8-series with manual ignition
are provided with a battery igniter and a
Gas-Operation-Indicator (Galvanometer)
Model Description

MODELS
Special Features RM 8xxx
The housing of the fridge RM 8xxx consists of
absolute plastic material (Polystyrene) and is
equipped with carrying handles on the side. Due
to this a decrease of weight of ca. 1.5 kg is
achieved compared to similar models like
RM 7401 or RM 7405.
There is a continuous groove on the outsides
and bottom part. A flexible sealing has to be
fitted into this groove, in order to enable an
airtight assembly.
TD S7

MODELS
Special Features RM 8xxx
Building in the fridge,
please note, that the
feet are not screwed
onto the housing
anymore, but are
injected directly onto it.
Thus, when building in
the fridge, it is not
possible anymore to
save 8mm height by
taking off the feet.
TD S8

MODELS
Special Features RM 8xxx
The color of the inner liner is not papyrus
white anymore, but white. The shelves
and the vegetable bin are ice-blue.
An innovative shelf system enables
individual usage of the cooling
compartment. The shelves and the bin
are dishwasher-suitable. The vegetable
bin is available with and without lid.
The rubber sealing is exchangeable.
TD S9

MODELS
Special Features RM 8xxx
In all single-door RM
8xxx fridges, the
freezing compartment
can be taken out if
needed. This
increases the capacity
as well as the cooling
performance in the
cooling compartment.
TD S10

MODELS
Special Features RM 8xxx
RM 8xxx with
removable
freezer
compartment
Locking of freezing compartment
TD S11

Special Features RM 8xxx
MODELS
All RM 8xxx fridges have a new door
lock. By pushing the locking button the
door is opened.
Closing the door the locking bar snaps
in and the door is locked. For using the
locking button, the panel is formed
asymmetric (recess on one side). I.e.
changing the door rabbet is not
possible anymore. The rabbet has to
be determined before the fridge is
installed.
The product number controls the side
of the door rabbet. Please notify this, if
the door or the fridge is exchanged!
TD S12

MODELS
Special Features RM 8xxx
The locking bar inside the door is fixed with two screws, which are behind a plastic cover. The
gear rods inside the door are not exchangeable. The lock in the fridge is exchangeable. It also
contains the fridge lighting, which was converted into a long-living LED-lighting. The door is
brought into winter position by moving the red hook.
TD S13

MODELS
Special Features RM 8xxx Purchasing an RM 7xxx or
an RM 8xxx, there is the
option of an electrical door-
lock. When the fridge door is
closed, it is kept shut by a
magnetic sealing, but not
locked. Starting the engine,
the electronics will
automatically lock the fridge
door, due to the recognition
of the D+ signal.Also with
this kind of door lock,
changing the door rabbet is
not possible.
TD S14

MODELS
Special Features RM 8xxx
All RM 8xxx fridges are equipped
with new door hinges made of
metal with a plastic casing
(polystyrene). This hinges are not
screwed onto the housing
anymore, but snap in. Thus it is
not necessary anymore to adjust
the height. Building in the fridge,
please note, that the door hinges
have to be supported. Minimum
requirement for the supporting
surface of the lower hinges is the
distance from the housing edge
to the outer edges of the hinges
with 40mm.
TD S15

MODELLE
Special Features RM 8xxx
Changing the decor plate, the door has
not to be demounted anymore. It can be
changed easily:
Loosen the plastic ledge on the locking
side carefully. This ledge is only
snapped in, but not screwed onto the
housing. Then pull out the decor plate
and put in the new one. After this
reattach the plastic ledge.
TD S16

MODELS
Special Features RM 8xxx
The operation panel can be loosened with
two screws, when the door is opened. The
electronics at the RM 8xx1 and RM 8xx5 is
screwed into the panel from the inside.
If the fridge is demounted, the operation
panel including the holding device can be
loosened very easily. It is only attached to
the housing.
TD S17

MODELS
Special Features RM 8xxx
If the fridge is equipped with a battery igniter, as with the 7xxx – generation, a V85 Gas /
electro fitting and the known energy-selection switch are used. Also, the RM 8xxx fridges are
equipped with a galvanometer, which indicates if the flame is burning. At all single-door fridges
of the 8-series, the main connecting block is positioned on the top of the housing. The
electronics is screwed into the panel.
TD S18

MODELS
Special Features RM 8xxx
On the backside of the 8-series
fridges the same components
are used as with the 7xxx-
Generation. Cooling unit, gas
valve GV 100, burner control
device P810, burner and
heating elements are identical.
The cooling unit and the
components are screwed onto
a metal sheet plate, which is
fixed onto the back side of the
plastic housing.
TD S19

MODELS
Special Features RM 8xxx
MES AES
The electronics were
completely renewed.
Instead of using a
semiconductor, as with
AES III or MES, the new
generation uses a
microprocessor. The AES-
models are equipped with
a 7-segment-display. If an
error occurs, there is an
acoustic signal. There is
no acoustic signal for the
MES-models. All optical
indications are shown with
LED.
TD S20
Optical differentiation:
a “BEEPER“
Electronics Electronics
