DomoClip DOP138 User manual

Instruction Manual
WWW.DOMOCLIP.COM
Reference : DOP138
Version : 1.3
Language : English
low juicer with extra-
large gutter

Instruction Manual
1
You have purchased a product DOMOCLIP brand and we thank you. We take great care in design,
ergonomics and simplify the using of our products. We hope that this product will give you complete
satisfaction.
General Instructions
PLEA E, TAKE TIME TO READ WELL THE IN TRUCTION FOR U E
PARTICULARLY BEFORE THE FIR T U E.
A misuse of the appliance can damage it or hurt the user.
Assure that you use the appliance for the use for which it is
designed; we refuse any responsibilities as for the damages by
an incorrect use or a bad manipulation.
1. Check that your mains voltage corresponds to that stated
on the appliance.
2. The safety instructions do not by themselves eliminate any
danger completely and proper accident prevention
measures must always be used.
3. Never leave the appliance unsupervised when in use. Keep
out of reach of children or incompetent persons.
4. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard (*).
5. Only use the appliance for domestic purposes and in the
way indicated in these instructions.
6. Never immerse the base of your appliance in water or any
other liquid for any reason whatsoever. Never place it into
the dishwasher.
7. Never use the appliance near hot surfaces.

Instruction Manual
2
8. Never use the appliance outside and always place it in a dry
environment.
9. Accessories, other than those supplied with the appliance,
shall include instructions for their safety use.
10. Never move the appliance by pulling the cord. Make sure
the cord cannot get caught in any way. Do not wind the
cord around the appliance and do not bend it.
11. tand the appliance on a table or flat surface.
12. Unplug the appliance when not in use.
13. This kind of appliance cannot function continuously, it is
not a professional type of appliance. It is necessary to make
temporary stops. Check the section « Important
Information » in the instruction manual.
14. Do not use the appliance if the rotating sieve is damaged
15. It is absolutely necessary to keep this appliance clean at all
times as it comes into direct contact with food.
16. Never touch the movable part with your hands in order not
to get hurt. Do not force the mechanism by squeezing the
fruits you are pressing too much. There is a device that
prevents if the press hold too firm is. o the cone rotation
will reverse itself, which means that you have to release
the pressure on the fruit lightly before continuing to
prepare.
17. The appliance is not intended to be operated by means of
external timer or separate remote control system.
18. Keep this manual with the appliance. If the appliance is to
be used by a third party, this instruction manual must be
supplied with it.

Instruction Manual
3
19. This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
20. Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and if they understand the hazards involved.
21. Children shall not play with the appliance.
22. This appliance is intended for household use and similar
applications such as:
ـstaff kitchen areas in shops, offices and other working
environments
ـfarm houses
ـby clients in hotels, motels and other residential type
environments
ـbed and breakfast type environments
23. Always disconnect the appliance from the supply if it is
left unattended and before assembling, disassembling or
cleaning.
24. witch off the appliance and disconnect from
supply before changing accessories or approaching
parts that
move in use.
25. Regarding the instructions for the use of accessories and
operation times, thanks to refer to the below paragraphs.
26. Regarding the instructions for the use of the juicer and
cleaning surfaces in contact with food, thanks to refer to
the below paragraphs.

Instruction Manual
4
(*)
Competent qualified electrician: after sales department of the producer or importer or any person who
is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any
case you should return the appliance to this electrician .
This instruction manual is available too on our website www.domoclip.com
TECHNICAL PECIFICATION
Voltage: 220-240V~50/60Hz
Power: 150W
Do not use more than 10 min at a time
DE CRIPTION
This appliance is supplied with 2 stainless steel filters to create various preparations. Use one or the other
according to desired extraction.

Instruction Manual
5
Note 1: For oleaginous milk, place vegetables one night in the cold water before extraction
Note 2: Coconut, cane sugar are not adapted to this appliance
A EMBLY AND U E
A. Assembl :
1. Assemble the bowl on the base ( insert it well)
twisting the bowl to close it.
This filter (small
holes) allows you
to create your
juices of fruits,
vegetables, herbs
and oleaginous
milk
This filter (big
holes) allows you
to create to create
smoothies and
coulis

Instruction Manual
6
2. Assemble the strainer into the holder.
3. Assemble the whole into the bowl
4. Place the squeezing screw in the center
of the bowl, you may need to turn a little
bit to make sure all elements are in position

Instruction Manual
7
5. Assemble the hopper on the bowl - To ensure
that the two elements are well positioned, check
the two red points are aligned. Turn then the
bowl in a clockwise to lock to the main body.
(the arrow should point to the base)
6. Place the bowl, pulp tank so it fits in position on the left hand side of the juicer’s main body.
7. Place the bowl for juice cup under the Juicer spout, on the right of the juicer’s main body. You can
replace this bowl by a glass.
B. Use :
Step 1 : Prepare the food
•Clean fruit and vegetables thoroughly, ready for juicing.

Instruction Manual
8
•If juicing fruit with stones or hard seeds, pit the fruit. Remove any hard inedible skins, i.e. skin of
melons, pineapples and mangoes prior to juicing. If citrus fruits are being used, remove the skin
prior to juicing.
•If pieces of fruit or vegetables are very large (more than 76 mm diameter), chop them to a size
before will fit down the juicer’s food chute. when you use fruits/vegetables with firm flesh (carrots,
apples, etc), cut them in smaller pieces to avoid any problem
•Place always food one by one into the juicer. Place too much food at the same time can stuck it
inside and/ or will not be extracted correctly.
Step 2: How to start
•Place one of the container under the pulp spout and the other under the juice spout.
•Plug the appliance
•Turn the control switch to “On” to juice
•The appliance have three settings: ON to start the appliance / OFF to turn off the appliance /
REV to use when something is stuck in the juicer and you need to unlog.
•Place the food into the hopper
• Press the food pusher slowly down until all fruit or vegetables have gone through the juicer
•The juice will flow directly on one of the container and the pulp will be collected into the
other.
•Turn the appliance off after using
Step 3: Use the spout with closure valve
The spout is fitted with a valve. This will allow you to close the spout and stops the flow of juice. If you
want to serve with a glass, you can change for the glass without dirtying your kitchen
With the valve, you can also mix different juices inside the bowl to combine the best flavors before to
serve into the bowl or glass.
Note 1:
Dry your hand before touching the power switch
If the reverse switch does not work juice is over heated, turn off the appliance, wait 3 minutes and try
again.
If using different ingredients, it’s better to alternate hard and soft foods (cucumber, parsley, mint,
watermelon are soft food, carrots, apples, celery, ginger are hard food).
Note 2: The juicer will only function correctly if all parts have been assembled correctly, the lid is in
position.
Find our ideas of recipe on our website DOMOCLIP www.domoclip.com

Instruction Manual
9
CLEANING AND TORAGE
Maintenance
Regular maintenance of your appliance will keep it safe and in proper operational order.
Before Cleaning
When not in use or before cleaning, always disconnect the appliance from the mains supply.
Cleaning
Wash removable parts in warm, soapy water then rinse and dry all parts. Regularly clean the outside of the
appliance with a soft damp cloth and dry with a dry towel.
CAUTION: To prevent damage to the appliance do not use harsh solvents, alkaline cleaning agents,
abrasive cleansers or scouring agents of any kind when cleaning.
Do not immerse the motor unit or supply cord in water.
Do not use dishwasher to clean.
Damage Check
Always check that the appliance is in good working order and that all removable parts are secure. Check
the power supply cord and plug regularly for cuts or damage .
Store in a Safe Place
When not in use store your appliance and all its accessories and instruction manual in a safe and dry place.
Check below pictures to disassemble the appliance in the right order:

Instruction Manual
10
Correct Disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection s stems)
The European Directive 2012/19/EU on Waste Facilities Electrical and Electronic (WEEE)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types
of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product or their local authority office, for details of
where and how they can take this item for environmentally safe recycling .
•Photo non contractual
• Worried about the quality of his products the manufacturer reserves the right to make modifications without advance
notice
DOMOCLIP
BP 61071
67452 Mundolsheim
