IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
including the following:
• Read all instructions.
• To protect against risk of electrical shock, do not immerse the cord or the juice
extractor’s base in water or other liquid. If base or cord falls into liquid, unplug the
cord from outlet immediately. Do not reach into the liquid.
• Close supervision is necessary when the juice extractor is used near children. Never
allow a child to use this product.
• Unplug from outlet when not in use, before putting on or taking off parts, and before
cleaning.
• Avoid contacting moving parts. Keep hands, hair, clothing as well as spatulas and
other utensils away from juice extractor during operation, to prevent personal
injury and/or damage to the appliance. A scraper may be used but must be used
only when the juice extractor is not running.
• Caution: Sharp blade. Never put your fingers into the feeding chute or tube. Always
use food pusher. Unplug before cleaning and before assembling or removing
parts.
• Do not operate appliance with a damaged cord or plug, or after the appliance
malfunctions or is dropped or damaged in any manner. Call our toll-free customer
assistance number for information on examination, repair, or adjustment.
• The use of attachments, not recommended by the manufacturer may cause injury
to persons.
• Do not use outdoors or in a damp area.
• Do not let cord hang over edge of table or counter.
• Always operate juice extractor with lid locked in place by the latches.
• When using juice extractor do not remove lid until the blade has stopped rotating.
• Do not process for longer than the time periods recommended.
• Do not overfill the sieve. Add food in small quantities.
• Do not use the sieve if is damaged or deformed. Have it replaced with a new one.
• Do not process hot foodstuffs.
• Regularly empty the pulp container.
• All parts must be properly in place before operating the appliance.
• Do not place juice extractor on or near a hot burner (gas or electric).
• Do not use appliance for other than intended use.
SAVE THESE INSTRUCTIONS!
2
169201-EN-06.indd 2 4/30/2009 10:04:00 AM

ADDITIONAL SAFEGUARDS
This appliance is for HOUSEHOLD USE ONLY.
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE OR IF
APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
EXTENSION CORDS
A short power-supply cord is to be provided to reduce the risk resulting from becoming
entangled in or tripping over a longer cord. Longer detachable power-supply cords or
extension cords are available and may be used if care is exercised in their use. If a longer
detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance, and
2) The longer cord should be arranged so that it will not drape over the countertop or
tabletop where it can be tripped over, snagged, or pulled on unintentionally
(especially by children).
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If
the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the plug in any way.
3
169201-EN-06.indd 3 4/30/2009 10:04:00 AM

PARTS
1
2
3
4
9
7
6
12
13
11
14
10
8
5
1. Food pusher
2. Lid with feeding chute
3. Stainless steel filter
4. Filter holder
5. Spout
6. Locking latches
7. Stem
8. Base
9. Power cord and plug
10. Rubber feet
11. Control panel
12. Pulp container
13. Indicator light
14. Speed control
4
169201-EN-06.indd 4 4/30/2009 10:04:01 AM

ILLUSTRATIONS
5
a c
de
h i
b
f
g
169201-EN-06.indd 5 4/30/2009 10:04:02 AM

6
l
j
ILLUSTRATIONS
k
mno
p q r
169201-EN-06.indd 6 4/30/2009 10:04:05 AM

OPERATION
Before first use
• Remove all packaging materials, labels and/or stickers from your juice extractor.
• Clean your juice extractor thoroughly before using for the first tim ( Cleaning). The
juice extractor must not be connected to power during cleaning.
Warning: Do not immerse the juice extractor in water or any liquids. This may cause
electric shock or damage the appliance.
Before operation
• Unwind the power cord (9) from the base (8) of juice extractor (ill. a).
• Lead the power cord (9) through the guide on the bottom of base (8) (ill. b).
• Place the rubber feet (10) on the bottom of base (8) on a flat, even and steady
surface (ill. c).
Operating instructions
Always disconnect the power plug (9) from the outlet when putting on or taking off
parts.
Before plugging in the juice extractor check that the electrical circuit is not overloaded
with other appliances.
Assembly
• Place the pulp container (12) next to the base (8). Make sure the guide rail of
the base is inserted into the pulp container’s groove (ill. d/e).
• Place the filter holder (4) on the base (8) (ill. f/g).
• Insert the stainless steel filter (3) and turn until it locks unto place (ill. h).
Warning: Danger of laceration. The center of the stainless steel filter (3) contains
small blades to process fuits and vegetables. Do not touch the blades
when handling the stainless steel filter (3).
• Place lid (2) on the appliance (ill. i).
• Insert the food pusher (1) in the feeding chute (2). Make sure the ridge of the
feeding chute (2) fits into the notch on the food pusher (1) (ill. j).
• Close locking latches (6): Lift up the two latches (ill. k)until they lock into
place (ill. l/m).
• Connect the power plug (9) with a wall outlet (ill. n).
• Place a glass or mug underneath the spout (5) (ill. o).
7
169201-EN-06.indd 7 4/30/2009 10:04:05 AM

OPERATION
Preparing fruits/vegetables
• This juice extractor can be used to make juices from many different fruits and
vegetables, but some preparations are needed to create flavorful and tasty juices.
Rinse and dry fruits under running fresh water.
Cut large fruits into pieces that fit into the feeding chute (2).
Remove large seeds, stones, and pits from cherries, peaches, etc.
Peel thick-skinned fruits (pineapples, melons, etc).
Extracting juice
• Assemble the juice extractor as described above. Connect the juice extractor with a
suitable outlet, and place a container underneath the spout (5).
• Remove food pusher (1) from the feeding chute (2).
• Set the speed control (14) to the desired setting:
Setting Suitable for
Strawberries, watermelon, pears, apricots, blueberries, grapes,
kiwi, mangoes, melons, nectarines, peaches, plums, raspberries,
tomatoes, broccoli, cabbage, cauliflower, cucumber,
Apples, carrots, beetroot, brussels sprouts, celery, fennel, oranges,
pineapple
• Fill the prepared ingredients into feeding chute (2). Do not overload the feeding
chute. Add small pieces at a time. Fruit pulp is ejected into the pulp container
(12)while the extracted juice will be flowing through the spout (5) into the prepared
container.
Warning: Do not put your hand or fingers into the feeding chute (2) to push food or clear
the feeding chute (2) from food. Use the food pusher (1). Danger of serious
injury through the rotating blades.
• Insert the food pusher (1) into the feeding chute (2). Make sure the ridge of the
feeding chute (2) fits into the notch on the food pusher (1) (ill. j).
• Set speed control (14) to 0when all of the food has been processed.
• Wait until stainless steel filter (3) has stopped rotating before removing lid (2).
See the table on page 9for recommended amounts and processing times.
8
169201-EN-06.indd 8 4/30/2009 10:04:05 AM

9
OPERATION
Recommended amounts and processing times
Types of food Max vol. Speed Time
Strawberries, blueberries,
raspberries
70oz/2000g
soft
90-120 sec
Pears, peaches, apricots, nectarines 70oz/2000g 130-150 sec
Spinach, cauliflower, broccoli,
cabbage, cucumber
70oz/2000g 180-210 sec
Watermelon, melons, grapes, kiwi,
mangoes, melons, plums
70oz/2000g 60-90 sec
Tomato 70oz/2000g 60-90 sec
Apples 70oz/2000g
crisp
120-150 sec
Carrots 70oz/2000g 60-90 sec
Beetroot, brussels sprouts, celery,
fennel, oranges, pineapple
70oz/2000g 120-150 sec
Potatoes
Do not process with this appliance
Bananas
Avocados
Caution: Do not process for longer than recommended time.
Do not exceed recommended maximum volumes.
Warning: Always turn the juice extractor off and unplug when not in use, otherwise the
motor would continue to rotate when a button is pressed.
169201-EN-06.indd 9 4/30/2009 10:04:06 AM

10
OPERATION
Information on fruits and vegetables
Fruits / vegetables Nutrition facts Energy in kj/kcal per 3.5oz/100g
Apples Rich in protein, fibers,
vitamin C
218kj/52kcal
Oranges Rich in vitamin C, folates,
vitamin A
207kj/49kcal
Strawberries Rich in vitamin C, folates,
lutein
136kj/32kcal
Pears Rich in fibers, carotene,
vitamin A
242kj/58kcal
Watermelon Rich in carotene, vitamin
A, lycopene
127kj/30kcal
Grapes (seedless) Rich in calcium, vitamin
C, vitamin A
288kj/69kcal
Peaches Rich in vitamin A, vitamin
C, folate
165kj/39kcal
Nectarines Rich in vitamin A, vitamin
C, carotene
185kj/44kcal
Tomatoes Rich in calcium, vitamin
C, folates
75kj/18kcal
Fennel Rich in calcium, vitamin
C, vitamin A
130kj/31kcal
Celery Rich in calcium, folates,
carotene
67kj/16kcal
Cucumber Rich in carotene, vitamin
A, lutein
65kj/15kcal
Carrots Rich in fibers, calcium,
vitamin A
173kj/41kcal
169201-EN-06.indd 10 4/30/2009 10:04:06 AM

11
CLEANING
Always unplug the power plug (9) from wall outlet before cleaning.
Clean the juice extractor after every use. This appliance contains no user serviceable
parts and requires little maintenance. Leave any servicing or repairs to qualified
personnel.
Disassembly
• Disconnect the power plug (9) from the wall outlet.
• Remove the glass or mug from underneath the spout (5).
• Remove the pulp container (12) from the base (8).
• Remove the food pusher (1) from the feeding chute (2).
• Remove the lid (2) from the appliance.
• Open the locking latches (6) (ill. p).
• Lift the filter holder (4) together with the stainless steel filter (3) from the
base (8) (ill. q).
• Remove the stainless steel filter (3) from the filter holder (4).
Warning: Danger of laceration. The center of the stainless steel filter (3) contains
small blades to process fuits and vegetables. Do not touch the blades
when handling the stainless steel filter (3).
• Disconnect the power plug (9) from the wall outlet.
• Do not immerse the appliance in water (ill. r).
• Clean base (8) and control panel (11) with a damp soft cloth.
• Filter holder (4), stainless steel filter (3), and pulp container (12) may be washed by
hand in hot soapy water. Do not place in the dishwasher. Do not use abrasives.
• Clean the stainless steel filter (3) carefully, it is very sharp.
• Always clean the parts that have come into contact with food in hot, soapy water
immediately after use.
Storage
• Clean and dry all parts before storing.
• Assemble the juice extractor ( Assembly).
• Never wrap power cord (9) tightly around the appliance; use the cord storage on the
bottom of the base (8) (ill. a).
• Store the juice extractor in its box or in a clean, dry place.
169201-EN-06.indd 11 4/30/2009 10:04:06 AM

12
TROUBLESHOOTING
Problem Possible Cause Solution
The motor works very
slowly.
Too many ingredients in
the sieve.
Unplug. Remove some
food and restart.
The motor does not
work.
Too many foods in the
container.
The motor is damaged.
Unplug. Remove some
food and restart.
If additional assistance is needed, please contact our Customer Assistance at
1.877.207.0923 (U.S.) or 1.877.556.0973 (Canada).
TECHNICAL DATA
Rated voltage: 120V ~60Hz
Rated current: 6.7A
Rated power input: 800W
Filling capacity: 70oz (2000g)
Dimensions: 313mm (L) x 200mm (W) x 387mm (H)
Weight (without package): 3.18kg
169201-EN-06.indd 12 4/30/2009 10:04:06 AM

CUSTOMER ASSISTANCE
If you have a claim under this warranty, please call our Customer Assistance Number. For faster
service, please have the model number and product name ready for the operator to assist you. This
number can be found on the bottom of your appliance and on the front page of this manual.
Model Number: __________________ Product Name: __________________
Customer Assistance Number 1.877.207.0923 (U.S.) or 1.877.556.0973 (Canada).
Keep these numbers for future reference!
For more information, please visit us at WWW.GEHOUSEWARES.COM
Two-year limited warranty
What does your warranty cover?
• Any defect in material or workmanship.
For how long after the original purchase?
• Two years.
What will we do?
• Provide you with a new one.
• For those items still under warranty but
no longer available, WAL-MART reserves
the right to replace with a similar GE
branded product of equal or greater
value.
How do you make a warranty claim?
• Save your receipt.
• Properly pack your unit. We recommend
using the original carton and packing
materials.
• Return the product to your nearest
WAL-MART store or call Customer
Assistance at 1-877-207-0923 (U.S.)
or 1-877-556-0973 (Canada).
What does your warranty not cover?
• Parts subject to wear, including, without
limitation, glass parts, glass containers,
cutter/strainer, blades, seals, gaskets,
clutches, motor brushes, and/or agitators,
etc.
• Commercial use or any other use not
found in printed directions.
• Damage from misuse, abuse, or
neglect, including failure to clean
product regularly in accordance with
manufacturer's instructions.
How does state law relate to this warranty?
• This warranty gives you specific legal
rights, and you may also have other rights
which vary from state to state or province
to province.
• This warranty is in lieu of any other
warranty or condition, whether express or
implied, written or oral, including, without
limitation, any statutory warranty or
condition of merchantability or fitness for
a particular purpose.
• WAL-MART, GE and the product
manufacturer expressly disclaim all
responsibility for special, incidental, and
consequential damages or losses caused
by use of this appliance. Any liability is
expressly limited to an amount equal to
the purchase price paid whether a claim,
however instituted, is based on contract,
indemnity, warranty, tort (including
negligence), strict liability, or otherwise.
Some states or provinces do not allow
this exclusion or limitation of incidental
or consequential losses, so the foregoing
disclaimer may not apply to you.
What if you encounter a problem with this
product while using it outside the country of
purchase?
• The warranty is valid only in the country of
purchase and if you follow the warranty
claim procedure as noted.
is a trademark of General Electric
Company and is used under the
license by Wal-Mart Stores Inc.,
Bentonville, AR 72716
Marketed in Canada by:
Wal-Mart Canada Corp.
1940 Argentia Road, Mississauga,
Ontario L5N1P9
169201-EN-06.indd 13 4/30/2009 10:04:06 AM
