Doms PSS 5000 User manual

Date
Document number November 30, 2010 PSS5000/TEMA/803046/05
Doms A/S Formervangen 28
DK-2600 Glostrup Tel. Fax. [phone] [phone] [email protected] [email protected]
PSS 5000
Technical Manual

2 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
Preface
Legal Notices
Copyright Statement This Doms documentation is owned by Doms or its licensors and is protected.
Your right to use this documentation is subject to the limitations and restric-
tions imposed by applicable licenses and copyright laws. Unauthorized repro-
duction, modification, distribution, display or other use of this documentation
may result in criminal and civil penalties.
About This Documentation
Purpose This documentation provides a general description of the PSS 5000 system
components and service facilities. It describes the functions available with the
PSS 5000 and contains procedures, which describe how to use the various
functions.
For documentation about specific system details, please see the documents
listed in the Software Release Document for the actual application or, alterna-
tively, look at ‘E.2 Referenced Documents’ on page 140.
Audience The content of this documentation is designed for technicians who need to
configure or service systems using PSS 5000.
It is assumed that the reader has a basic knowledge of standard PC technolo-
gies, such as Windows and Internet browsers, and has attended a foundation
course that introduces the workings of the PSS 5000.

PSS5000/TEMA/803046/05 3 of 152
PSS 5000 – Technical Manual
Contents
Contents
Legal Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About This Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part I: Getting to Know the PSS 5000 . . . . . . . . . . . . . . . . . . . . . . . .7
1 Architectural Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1 PSS 5000 Without a Network Connection . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 PSS 5000 With a Network Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 PSS 5000 in a Mixed Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2 System Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 PSS 5000 Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.1 PSS 5000 Cabinets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.2 PSS 5000 Computer Processor Boards . . . . . . . . . . . . . . . . . 12
2.1.3 Hardware Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.1.4 Service and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2 PSS 5000 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2.1 Virtual File System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2.2 Memory Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2.3 The Software Components . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2.4 Web Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.2.5 FTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.2.6 Network Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3 Configuration and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.1 Configuration and Service Menus Access . . . . . . . . . . . . . . . . . . . . . . 20
3.1.1 Local Service Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.1.2 Web Service Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.2 Software Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Part II: Using the Service Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . .26
4 Information (Menu 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1 Program Versions (Menu 1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2 Board Info (Menu 1.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.2.1 Production (Menu 1.2.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.2.2 Sealing Switch (Menu 1.2.2) . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.3 SW Blocks (Menu 1.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.4 Protocols (Menu 1.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.5 LAM (Menu 1.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5 Installation (Menu 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.1 Protocol to Port Assignment (Menu 2.1) . . . . . . . . . . . . . . . . . . . . . . . 33

4 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
Contents
5.1.1 Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.2 Date and Time (Menu 2.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.3 Communication Setup (Menu 2.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.3.1 TCP/IP Setup (Menu 2.3.1) . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.3.2 Service Port Setup (Menu 2.3.2) . . . . . . . . . . . . . . . . . . . . . . 40
5.3.3 Datalink Timeout for Serial Driver (Menu 2.3.3) . . . . . . . . . . . 42
5.3.4 Service Port Protocol (Menu 2.3.4) . . . . . . . . . . . . . . . . . . . . . 43
5.3.5 Menu 2.3.5 – Reserved for Future Use . . . . . . . . . . . . . . . . . 43
5.3.6 Dialup Setup/Test (Menu 2.3.6) . . . . . . . . . . . . . . . . . . . . . . . 44
5.3.7 Online/Offline Event Time (Menu 2.3.7) . . . . . . . . . . . . . . . . . 45
5.4 System Profile (Menu 2.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.4.1 Password (Menu 2.4.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.4.2 Name and Number (Menu 2.4.2) . . . . . . . . . . . . . . . . . . . . . . 49
5.4.3 POS Password (Menu 2.4.3) . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.4.4 Web Preferences (Menu 2.4.4) . . . . . . . . . . . . . . . . . . . . . . . . 50
5.5 Application Setup (Menu 2.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5.6 Software Upload (Menu 2.6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
5.7 Peripheral Configuration (Menu 2.7) . . . . . . . . . . . . . . . . . . . . . . . . . . 57
5.7.1 Memory Module (Menu 2.7.1) . . . . . . . . . . . . . . . . . . . . . . . . . 58
5.8 Backup (Menu 2.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
6 Operation (Menu 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
6.1 Enter Fallback Mode (Menu 3.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
6.2 Grade Prices (Menu 3.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6.3 FP Transactions (Menu 3.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6.3.1 Monitor (Menu 3.3.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6.3.2 Log (Menu 3.3.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6.4 Payment Server (Menu 3.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
6.5 Operation Mode (Menu 3.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
6.6 Menu 3.6 Reserved for Future Use . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.7 Operational Status (Menu 3.7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.8 TeleTerminal (Menu 3.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
6.9 Reconciliation Report (Menu 3.9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7 Reset (Menu 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.1 Soft Reset (Menu 4.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.2 Master Reset (Menu 4.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7.3 Super Master Reset (Menu 4.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
8 Diagnostics (Menu 5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.1 Forecourt Devices (Menu 5.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.1.1 Online List (Menu 5.1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.1.2 Device Errors (Menu 5.1.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
8.1.3 Price Pole Test (Menu 5.1.3) . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.1.4 Device Status (Menu 5.1.4) . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.1.5 Device Test (Menu 5.1.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
8.2 System Logs (Menu 5.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8.2.1 Upload Log (Menu 5.2.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8.2.2 Reset Logs (Menu 5.2.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8.2.3 Application Log (Menu 5.2.3) . . . . . . . . . . . . . . . . . . . . . . . . . 92
8.2.4 Access Log (Menu 5.2.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
8.2.5 Board Error Log (Menu 5.2.5) . . . . . . . . . . . . . . . . . . . . . . . . . 94
8.3 Communication (Menu 5.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
8.3.1 Ethernet Statistics (Menu 5.3.1) . . . . . . . . . . . . . . . . . . . . . . . 95
8.3.2 Port Statistics (Menu 5.3.2) . . . . . . . . . . . . . . . . . . . . . . . . . . 95
8.3.3 Protocols (Menu 5.3.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
8.4 Peep (Menu 5.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
8.5 Test (Menu 5.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
8.5.1 Menu 5.5.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
8.5.2 Boot (Menu 5.5.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

PSS5000/TEMA/803046/05 5 of 152
PSS 5000 – Technical Manual
Contents
8.5.3 GDB (Menu 5.5.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
8.6 Peripherals (Menu 5.6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
8.6.1 Online List (Menu 5.6.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
8.6.2 Errors (Menu 5.6.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
8.6.3 Memory Module (Menu 5.6.3) . . . . . . . . . . . . . . . . . . . . . . . . 102
9 W&M (Menu W) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
9.1 LAM Version (Menu W.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
9.2 LAM Parameters (Menu W.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
9.3 Memory Module Version (Menu W.3) . . . . . . . . . . . . . . . . . . . . . . . . . 108
9.4 Program Upload Log (Menu W.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
9.5 Recent Transactions (Menu W.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
9.6 Payment Log (Menu W.6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
9.7 Checking Devices (Menu W.7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
9.7.1 Display Error (Menu W.7.1) . . . . . . . . . . . . . . . . . . . . . . . . . 113
9.7.2 Send Error Security Telegram (Menu W.7.2) . . . . . . . . . . . . 113
9.7.3 LAM Code Error (Menu W.7.3) . . . . . . . . . . . . . . . . . . . . . . . 114
9.7.4 RTC Error (Menu W.7.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
9.7.5 Trans Memory (Menu W.7.5) . . . . . . . . . . . . . . . . . . . . . . . . 116
Part III: Reference Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
A File Formats in the PSS 5000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
A.1 Recent Transactions File Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
A.2 Transaction Log File Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
A.3 Upload Log File Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
B Upload Help Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
C Web Service Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
C.1 PC and Browser Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
C.2 Ethernet Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
C.3 Service Port Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
C.3.1 Modem Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
C.3.2 Null Modem Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
C.3.3 Installing Null Modem Connections . . . . . . . . . . . . . . . . . . . 127
C.3.4 Dialling Up Using a Null Modem Connection . . . . . . . . . . . . 128
D Virtual File System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
D.1 The Virtual File System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
D.2 System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
D.3 Board Upload Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
D.4 Load Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
D.5 Hardware Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
D.6 Ok2load File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
D.7 Boot Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
D.8 LAM (Legal Authority Module) Information . . . . . . . . . . . . . . . . . . . . . 136
D.9 Application Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
D.10 Board Error Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
E PSS 5000 Reference Information . . . . . . . . . . . . . . . . . . . . . . . . . 138
9.8 List of Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
E.1 List of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
E.2 Referenced Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
F PSS 5000 XML Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
F.1 Accessing the XML Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
F.2 Config.xml File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

6 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
Contents
F.3 Site_sta.xml File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
F.4 Site_rep.xml File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
G Revision Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

PSS5000/TEMA/803046/05 7 of 152
PSS 5000 – Technical Manual
Part I: Getting to Know the PSS 5000
Part I: Getting to Know the PSS 5000
•‘1 Architectural Overview’ on page 8
•‘2 System Description’ on page 11
•‘3 Configuration and Service’ on page 20

8 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
1 Architectural Overview
1 Architectural Overview
List of PSS 5000
configurations The PSS 5000 can be used in 3 basic configurations. These are described in the
following topics:
•‘1.1 PSS 5000 Without a Network Connection’ on page 8
•‘1.2 PSS 5000 With a Network Connection’ on page 9
•‘1.3 PSS 5000 in a Mixed Configuration’ on page 10
1.1 PSS 5000 Without a Network Connection
Illustration of a system
using serial POS driver This illustration shows how POS terminals can be used by connecting them to
the PSS 5000 using a serial POS driver.

PSS5000/TEMA/803046/05 9 of 152
PSS 5000 – Technical Manual
1 Architectural Overview
1.2 PSS 5000 With a Network Connection
Illustration of a system
using an Ethernet
network
This illustration shows how POS terminals can be used by connecting them to
the PSS 5000 using an Ethernet connection.

10 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
1 Architectural Overview
1.3 PSS 5000 in a Mixed Configuration
Illustration of a system
using both an Ethernet
network and serial
interface
This illustration shows how POS terminals can be used through a serial POS
driver even when an Ethernet connection is present.

PSS5000/TEMA/803046/05 11 of 152
PSS 5000 – Technical Manual
2 System Description
2 System Description
List of PSS 5000
components The basic components of the PSS 5000 are described in the following topics:
•‘2.1 PSS 5000 Hardware’ on page 11
•‘2.2 PSS 5000 Software’ on page 14
2.1 PSS 5000 Hardware
List of hardware
components The PSS 5000 hardware consists of several separate components. These are
described in the following topics:
•‘2.1.1 PSS 5000 Cabinets’ on page 11
•‘2.1.2 PSS 5000 Computer Processor Boards’ on page 12
•‘2.1.3 Hardware Interface Modules’ on page 13
•‘2.1.4 Service and Maintenance’ on page 14
2.1.1 PSS 5000 Cabinets
Contents of the PSS
5000 cabinet This illustrates the contents of the PSS 5000 standard cabinet with a CPU
Board CPB509, 4 Hardware Interface Modules and an Ethernet connection.
For complete details about the CPU boards available, see [4] for CPB509 and
[5] for CPB505.

12 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
2 SystemDescription
PSS 5000 cabinet types
and specifications The product specifications for the PSS 5000 cabinet are presented in the table
below:
Note: The weights given are for the basic cabinet with a power supply and
CPU board (HIMs are not included).
The external label On the outside of the cabinet, located above the power input socket, is a label.
This label provides the serial number of the PSS 5000 and informs you which
power supply voltage the PSS 5000 can use.
2.1.2 PSS 5000 Computer Processor Boards
PSS 5000 CPU Board
specifications The product specifications for the CPU boards of the PSS 5000 are presented
in the table below:
Cabinet Version
Standard - cable Standard - conduit Compact
Dimensions:
(HxWxD) 600x200x124mm (23.5x7.9x4.9") 600x200x124mm (23.5x7.9x4.9") 363x200x100mm (14.3x7.9x3.9")
Max. number of single-
width modules: 14 14 6
Material: Metal Metal Metal
Weight: 8kg (17.6lbs) 8kg (17.6lbs) 5kg (11lbs)
CE + UL Approved: Yes Yes Yes
Hinged door: Yes Yes Yes
No. of grommets: 17 (cables) 4 (conduits) 9 (cables)
Parameters CPU Board Version
CPB505 CPB509
CPU Specs

PSS5000/TEMA/803046/05 13 of 152
PSS 5000 – Technical Manual
2 System Description
See also For a full description of the computer processor boards, see:
• PSS 5000 Processor Board, Description of CPB 509 – [4]
• PSS 5000 Processor Board, Description of CPB 505 – [5]
2.1.3 Hardware Interface Modules
Hardware Interface
Modules Hardware Interface Modules are interface adapters. They provide a link be-
tween the CPU Board of the PSS 5000 and the many types of forecourt devic-
CPU Type ColdFire MCF5307 ColdFire MCF5307
CPU Bus (bit) 16 32
Flash (MB) 8 16
SRAM (MB) 2 4
Backup Battery 14 days 14 days
Real-time Clock Yes Yes
Port Types and Number
DSB 3 51
DMB 1 31
Ethernet4(Port 41) 11
Service (RS232) (Port 1) 021
Extension Socket
(LON - FTT10) 1 (option) (Port 31) 2 (option) (Ports 31 & 32)
Ports with speed rating3
Port 11 - DSB Standard High-speed
Port 12 - DSB Standard Standard
Port 13 - DSB Standard Standard
Port 14 - DSB n/a Standard
Port 15 - DSB n/a Standard
Port 21 - DMB Standard High-speed
Port 22 - DMB n/a Standard
Port 23 - DMB n/a Standard
1: one of the ports is a high-speed port
2: The boot program only supports PPP on the Service port. Software uploads on
boards with no Service port must take place via the Ethernet port.
3: the actual baud rate of the ports are determined by the devices and the HIM mod-
ules connected to the ports
(where the maximum baud rate for a port is: Standard=9600bit/s, High-speed
=115200bit/s)
4: Ethernet connection is 10Base-T (half-duplex)
Parameters CPU Board Version
CPB505 CPB509

14 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
2 SystemDescription
es, with their proprietary interfaces. There are 2 basic HIM types, which are
used to communicate with the forecourt devices:
The HIM modules provide a scalable solution. When new devices are added
to the forecourt configuration, or old devices replaced with new ones that use
a different protocol, new HIMs can be added, or existing ones replaced, so that
they suit the new protocol.
For more information about the individual HIMs, see [1].
Illustration of HIMs Examples of a DSB HIM and a DMB HIM are shown below.
Note: The black serial connectors on the DMB modules are wider than those
on the DSB models. This extra width is a result of more pins, which are
required for the signals used to control the onboard multiplexer.
2.1.4 Service and Maintenance
Spare part
recommendations It is recommended that service organizations carry a stock of spare parts that
represents 5% of the installed systems.
Note: This quantity may vary depending on logistics and the individual re-
quirements to the repair turn-around times.
2.2 PSS 5000 Software
List of software
components The PSS 5000 software consists of several separate components. These are de-
scribed in the following topics:
•‘2.2.1 Virtual File System’ on page 15
•‘2.2.2 Memory Structure’ on page 16
•‘2.2.3 The Software Components’ on page 17
•‘2.2.4 Web Server’ on page 18
•‘2.2.5 FTP Server’ on page 18
•‘2.2.6 Network Connection’ on page 19
Module Description
DSB Doms Serial Bus modules are used for addressable
devices.
DMB Doms Multiplexed Bus modules are used for non-ad-
dressable devices.

PSS5000/TEMA/803046/05 15 of 152
PSS 5000 – Technical Manual
2 System Description
2.2.1 Virtual File System
Structure of virtual file
system The PSS 5000 has a UNIX inspired virtual file system, with the following top-
level structure:
Description of the virtual
file system catalogs Each of the catalogs present in the virtual file system are described in the table
below:
Catalog Description
pss_dev The pss_dev catalog gives access to devices; both
physical devices (FLASH PROM) and logical (a NULL
device).
pss_mem The pss_mem catalog gives access to the different lev-
els of memory in the PSS 5000; both the FLASH
PROM and the static RAM.
For more information, see ‘2.2.2 Memory Structure’ on
page 16.
pss_proc The pss_proc catalog contains runtime-generated files.
All PSS 5000 systems have, as a minimum, the follow-
ing files in this catalog:
• hw_inf.txt (Hardware information)
• appl_inf.txt (Application information)
• lam_inf.txt (Legal Authority Module information)
• boot_inf.txt (BOOT information)
• bel.txt (Board Error Log)

16 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
2 SystemDescription
2.2.2 Memory Structure
Memory areas on the
CPU board The memory on the PSS 5000 CPU board is divided in to 4 areas.
The difference between the separate memory areas is indicated by what is re-
quired to clear or change the data.
Note: The RAM has a battery backup. If a power cut occurs, the battery pro-
vides power for more than 2 weeks and ensures that the data present in
the RAM is preserved.
Data in pss_mem/4 Data in memory area 4 is held in theRAM and is a "volatile working memory"
for programs. Although this area has battery back-up, all the data in this area
is cleared when a reset (software initialization) or power down takes place.
Data in pss_mem/3 Data in memory area 3 is held in RAM and is a "non-volatile working memo-
ry" for programs. This area has battery back-up, which enables data to be re-
tained during startup (initialization) and to survive a power down for weeks.
The area is cleared by a master reset. System configurations and status infor-
mation are intact after a period without power.
Data in pss_mem/2 Data in memory area 2 is held in RAM and is a "data storage memory" for the
programs. This area is cleared by a super master reset, but has battery back-up
to survive a power down for weeks. This data storage area is used for data that
must survive system re-configurations and program changes.
Data in pss_mem/1 Data in memory area 1 is held in a Flash Programmable Read Only Memory
(PROM) and is used to hold programs and system logs as described below:
Contents of FLASH Description
APPLICATION PROGRAM The Application Program holds the main fore-
court controller or converter application. The ap-
plications are specific for the devices connected
to the PSS 5000.

PSS5000/TEMA/803046/05 17 of 152
PSS 5000 – Technical Manual
2 System Description
2.2.3 The Software Components
List of PSS 5000
software components The software components of the PSS 5000 comprises 3 separate binary program
blocks. Each block is loaded separately and comes complete with its own check sum.
The blocks are:
•Boot Program
•Legal Authority Module (LAM)
•Application Program
To ease identification of the program blocks, each program is assigned an 8
digit ID, which has the following format: TTT-BB-VVV. Where Tdefines the
program type, Bdefines the program branch (or variant) andVdefines the pro-
gram version.
Boot Program The Boot Program is responsible for the following functions:
• Initializing the CPU board
• Uploading software (which includes various checking functions)
• Launching the uploaded application program
The Boot Program ID has the program type ID: 499-BB-VVV
The Legal Authority Module (LAM) provides control of parameters that are
subject to control by legal authorities. By installing the correct LAM for the
region, only parameters that are permitted by the authorities are available. The
LAM also provides Weights and Measures functions, which ensure the integ-
rity of the data and make sure that the PSS 5000 is operating correctly and
complies to the legal requirements.
The LAM ID has the program type ID: 498-BB-VVV
The program branch number (BB) normally is associated with a country or re-
gion.
The application program contains the main forecourt controller functions. The
application program loaded is specific for the devices present at the users’ sites
LAM The Legal Authority Module (LAM) is a parame-
ter module for the Application Program. It holds
country specific parameters like decimal point
settings and parameters to control functionality
required by the local legal authorities. All PSS
5000 applications require a Legal Authority
Module.
BOARD UPLOAD LOG The Board Upload Log holds a log of all the soft-
ware uploads that have taken place since the
first LAM was installed.
BOOT PROGRAM The BOOT Program is responsible for software
upload and access to board peripheral devices,
such as the local service panel, when no appli-
cation is present.
Contents of FLASH Description

18 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
2 SystemDescription
and connected to the PSS. The program works very closely with the LAM to
make sure that only permitted data is obtained.
The program type ID for the application program is not limited to a single
number. For example, the program type number (TTT) can be one of the fol-
lowing: 410, 411 or 420.
The program branch number (BB) depends on which functions that are includ-
ed in the program.
2.2.4 Web Server
Description of the web
server The embedded web server enables you to access the PSS 5000 Service Menus
using a PC with a standard web browser.
This provides a user-friendly graphics interface for the Service Menus, where
you are able to perform a multitude of tasks, such as obtaining software ver-
sion numbers, installation details, operational details and service diagnostics.
It is also an excellent entry point to the W&M menus.
Recommended browser
versions The embedded web server, which allows connection via standard browsers or
specific applications, has been tested with both Firefox and Microsoft brows-
ers. Some of the features (for example the Peeper applet) require a Microsoft
Internet Explorer version 6.0 or higher, or Firefox version 1.5 or higher.
2.2.5 FTP Server
Description of the FTP
server The FTP server enables you to connect to the PSS 5000, see the internal file
structure and upload software applications. It also enables you to extract data
logs from remote locations.
Illustration of an FTP
connection to file system
in PSS 5000
This illustrates how to access the file system in a PSS 5000 using a web brows-
er and an FTP connection. The FTP connection to the PSS 5000 is made by
typing FTP://admin:password@<IP address>.
Note: Other types of FTP client connections may be used. Use the same log
on information with the FTP client of your choice.

PSS5000/TEMA/803046/05 19 of 152
PSS 5000 – Technical Manual
2 System Description
2.2.6 Network Connection
Description of the
network connection For general access rights to devices on the network, please consult your net-
work administrator. He will know which TCP/IP parameters you must use and
will configure the network (DHCP server, firewalls and the like). In this re-
spect, the PSS 5000 is no different from any other network devices.

20 of 152 PSS5000/TEMA/803046/05
PSS 5000 – Technical Manual
3 Configuration and Service
3 Configuration and Service
Overview Information about the configuration and service functions of the PSS 5000 are
described in the following topics:
•‘3.1 Configuration and Service Menus Access’ on page 20
•‘3.2 Software Changes’ on page 24
3.1 Configuration and Service Menus Access
Methods to access
menus There are 2 methods to access the service menus that enable you to configure
and monitor the PSS 5000. Information about the access tools are described in
the following topics:
•‘3.1.1 Local Service Panel’ on page 20
•‘3.1.2 Web Service Pages’ on page 23
3.1.1 Local Service Panel
Purpose of the local
service panel The Local Service Panel allows you to access the PSS 5000 Service Menus.
The navigation buttons and the OK button, which allow you to navigate
through the service menus, are located on the CPU Board beside the front pan-
el. The function of each button is shown by an arrow or text label present on
the panel.
