Donaldson Torit Delta P Control User manual

Delta P Control
Installation and Operation Manual
Installation, Operation and Service Manual
This manual contains specic precautions related to worker safety. The hazard alert image denotes safety
related instructions and warnings in this manual. DO NOT install, operate, or perform maintenance on this
collector until you have read and understood the instructions, precautions and warnings contained within this
manual.
IOM 7546301 (ENG)
Revision 14
English
Master Language

Donaldson Company, Inc.
The Safety Alert Symbol indicates a hazardous situation which, if not avoided could
result in death or serious injury. Obey all safety messages following this symbol to
avoid possible injury or death. The possible hazards are explained in the associated
text messages.
NOTICE indicates a potential situation or practice which is not expected to
result in personal injury, but which if not avoided, may result in damage to
equipment.
This manual has been supplied to assist with the installation, operation and maintenance for
the collector purchased. Please read the manual before installing, operating, or performing
maintenance on the collector as it contains specic precautions for worker safety. It is the
owner’s responsibility to ensure that this manual is available for use by installers, operators and
maintenance personnel that will be working with this collector. This manual is the property of the
owner and should be left with the collector when installation has been completed. DO NOT operate
this collector until you have read and understood the instructions and warnings located in the
installation and operation manual.
For additional copies of this manual, contact Donaldson Torit.
i
IMPORTANT NOTES

Delta P Control
ii
Contents
IMPORTANT NOTES.......................................................................................................................................................................i
1 Safety Communication ..............................................................................................................................................................1
2 Product Description...................................................................................................................................................................3
3 Operation...................................................................................................................................................................................3
4 Product Service.........................................................................................................................................................................4
Operational Checkist ..........................................................................................................................................................4
Troubleshooting..................................................................................................................................................................5
Replacement Parts.............................................................................................................................................................7
Appendix A - Installation..................................................................................................................................................................8
Installation ..........................................................................................................................................................................9
Location and Site Selection................................................................................................................................................9
Delivery and Inspection ......................................................................................................................................................9
Unloading and Positioning..................................................................................................................................................9
Electrical Wiring................................................................................................................................................................10
Setpoint Adjustments........................................................................................................................................................11
Delta P Control Calibration...............................................................................................................................................12
Optional Settings ..............................................................................................................................................................13
Analog Output (TB4, Terminals 13 & 14)..........................................................................................................................13
Product Information ..........................................................................................................................................................15
Service Notes ...................................................................................................................................................................15
Donaldson Industrial Air Filtration Warranty..............................................................................................................................16

Improper operation of dust collectors and/or dust control systems may contribute to conditions in a work area or
facility which could result in severe personal injury, and product or property damage. All dust collection equipment
should be used only for its intended purpose and should be properly selected and sized for its intended use.
Process owners have important responsibilities relating to identifying and addressing potential hazards in their
processes. When the potential for handling combustible dust exists within a process the process owner should
include combustion hazards in their risk management activities and should comply with applicable codes and
standards related to combustible dust.
Electrical installation must be performed by a qualied electrician.
This equipment is not designed to support site ducts, piping, or electrical services. All ducts, piping, or electrical
services must be adequately supported to prevent injury and/or property damage.
Site selection must account for wind, seismic zone, and other load conditions.
Equipment may reach peak sound pressure levels above 80 dB (A). Noise levels should be considered when
selecting collector location.
Most dusts present safety and health hazards that require precautions. Wear eye, respiratory, head and other
protection equipment suitable for the type of dust.
Some components may be heavier than they appear. Use appropriate lifting methods to avoid personal injury and/or
property damage.
1
Donaldson Company, Inc.
1 Safety Communication

Delta P Control
2
Combustible Dust Hazards
Among other considerations, the current NFPA standards require owners whose processes involve potentially combustible
materials to have a current Dust Hazard Analysis, which can serve as the foundation for their process hazard mitigation strategy.
Mitigation may include but is not limited to:
• Prevention of all ignition sources from entering any dust collection equipment.
• Selection and implementation of re and explosion mitigation, suppression, and isolation strategies appropriate for the
risks in their process.
• Development and use of work practices to maintain safe operating conditions, and to ensure combustible dust does not
accumulate within their plant or process equipment.
Donaldson designs, manufactures, and sells industrial air ltration products for a wide variety of applications. Some applications
may include processes or materials with inherent re and explosion hazards. Donaldson is neither an expert nor a certied
consultant in re, spark, or explosion detection, suppression, or control. Donaldson does not provide engineering consulting
services related to process or dust hazard analyses, or code and standard compliance. Complying with applicable codes and
standards and managing the risks associated with the process or materials remains the responsibility of the process owner/
operator. Donaldson may provide referrals to consultants, suppliers of equipment or services related to the detection and/
or mitigation of sparks, res and/or explosions, but Donaldson does not assume responsibility for any such referrals, nor does
Donaldson assume any liability for the tness of a mitigation strategy or product for a particular installation or application. The
process owner’s nal selection of dust collectors and risk mitigation strategies should be based on the outcome of a Dust Hazard /
Process Hazard Analysis performed by the process owner. Although early engagement of a dust collector supplier provides helpful
insights on the availability and features of various products, process owners should consult with a combustible dust expert and/or a
process safety expert before making actual product and mitigation strategy selections.
Donaldson recommends that all industrial air ltration system designs be reviewed and approved by an expert consultant who is
responsible for the integrity of the system design and compliance with applicable codes and standards. It is the process owner’s
responsibility to understand the risks in their process and mitigate those risks in accordance with all applicable laws, regulations
and standards, including those published by the NFPA. Donaldson also recommends that proper maintenance and housekeeping
procedures and work practices be evaluated, developed, and followed to maintain any industrial air ltration products in safe
operating condition.
Many factors beyond the control of Donaldson can affect the use and performance of Donaldson products in a particular
application, including the conditions under which the product is used. Since these factors are uniquely within the user’s knowledge
and control, it is essential the user evaluate the Donaldson products to determine whether the product is t for the particular
purpose and suitable for the user’s application. All products, product specications, and data (airow, capacity, dimensions, or
availability) are subject to change without notice, and may vary by region or country.

3
Donaldson Company, Inc.
The Delta P Controller monitors the differential pressure between the clean-air and dirty-air plenums, providing a visual display
of the lter condition. When combined with a pulse timer, it manages the pressure drop by turning the cleaning mechanism On
and Off at the chosen limits. There are three (3) set points: High Pressure On, Low Pressure Off, and Alarm. The rst two, High
Pressure On and Low Pressure Off, control the lter cleaning system. The third, Alarm, provides a relay output to activate an
external alarm supplied by others.
2 Product Description
3 Operation
Normal
The Delta P Controller monitors the pressure in the clean-air and dirty-air air plenums while the collector is running. The fan blower
draws air through the lters, creating a pressure drop. The Delta P Controller measures the pressure drop and provides a visual
display in inches water gauge or metric (SI) units of daPa.
Filter Cleaning
When the pressure drop across the lters exceeds the High Setpoint, the controller closes an output relay allowing a timer to
trigger the cleaning valves sequentially. When the pressure drop has decreased to the Low Setpoint, the relay opens and the
cleaning cycle stops. This sequence continues as long as the collector is in use, maintaining the pressure drop within a narrow
range.
Alarm
The Alarm setpoint is set to a higher setting than the High Pressure On setpoint used to start the lter cleaning cycle. It indicates
situations when the cleaning system cannot reduce the pressure drop due to cleaning system failure, lack of compressed air, or the
end of the lter’s useful life. There is a time delay prior to setting the Alarm to prevent nuisance trips. The Delta P Controller also
provides an input connection for a remote alarm reset.

Delta P Control
4
4 Product Service
During any service activities there is some potential for exposure to the mist in the collector. Most mists present
safety and health hazards that require precautions. Wear eye, respiratory, head and other protection equipment
suitable for the type of mist when performing any service activities.
Use appropriate access equipment and procedures. Note the standard collector is not equipped with access
platforms unless noted on the specication drawings.
LOCK-OUT all energy sources prior to performing any service or maintenance on the equipment.
Electrical service or maintenance work must be performed by a qualied electrician and comply with all applicable
national and local codes.
This equipment may start or stop unexpectedely from a remote location. Turn power off and lock out all power before
performing service or maintenance work.
1. Visually conrm Delta P display is illuminated and displaying differential pressure.
2. Observe and address any alarm conditions.
3. If cleaning light is on, conrm that the collector is advancing through the cleaning process.
Operational Checkist

5
Donaldson Company, Inc.
Troubleshooting
Problem Probable Cause Remedy
No display on the Delta P
Control
No power to the control Use a voltmeter to check for voltage at Terminal TB1.
Fuse blown Check the fuse in the F1 fuse tower. Replace if
necessary.
Display on the Delta P
Control does not read zero
when at rest
Out of calibration Disconnect pressure tubing. See Delta P Control
Calibration section.
With collector discharging outside,
differential pressure is present from
indoor to outdoor
Recalibrate with the pressure tubing attached as
described in the Delta P Control Calibration section.
Display reads “_ _ _” Pressure out of the allowable range Check that high and low pressure tubing is attached
and not leaking. Use a differential pressure
measurement device to verify that the actual
pressure does not exceed 20 " wg.
Delta P Control ON, but
cleaning system does not
start
Not wired to the timing board correctly Connect the pressure switch on the timer board to
Terminals 7 and 8 on TB3.
Faulty relay Using a multimeter, test relay for proper closure.
Replace if necessary.
Pressure tubing disconnected, ruptured,
or plugged
Check tubing for kinks, breaks, contamination, or
loose connections.
Pulse cleaning never stops Pressure switch terminals on the timer
board jumpered
Remove jumper wire on solid-state timer board
before wiring to Delta P Control.
Pressure switch not wired to the timer
board correctly
Connect the pressure switch on the timer board to
terminal 7 (normally open) and Terminal 8 (common)
on TB3.
High or low setpoint not adjusted for
system conditions
Adjust setpoints to current conditions. See Setpoint
Adjustment section.
Pressure tubing disconnected, ruptured,
or plugged.
Check tubing for kinks, breaks, contamination, or
loose connections.

Delta P Control
6
Problem Probable Cause Remedy
Alarm light is ON Alarm setpoint too low Adjust to a higher value.
Excess pressure drop Check cleaning system and compressed-air supply.
Replace lters if lters do not clean down.
Pressure tubing disconnected, ruptured,
or plugged
Check tubing for kinks, breaks, contamination, or loose
connections.
Delta P arrow keys do not
work
Improper operation Press and hold one of the three setpoint keys to use
arrow keys.
Programming keys disabled Remove the Program Disable jumper from Terminals 3
and 4 on TB2.
Cleaning light is ON,
but cleaning system not
functioning
Improper wiring Check wiring between the Delta P Control and the
timer board, and between the timer board and solenoid
valve coils.
Defective solenoids Check all solenoid coil for proper operation.
Timer board not powered Check power ON light on timer board’s LED display. If
not illuminated, check the supply voltage to the timer
board. Check the fuse on the timer board. Replace if
necessary.
Timer board defective If LED is illuminated, observe the output display.
Install a temporary jumper across the pressure switch
terminals. Output levels should ash in sequence.
Check output using a multimeter set to 150-Volt AC
range. Measure from SOL COM to a solenoid output.
The needle will deect when LED ashes for that
output if voltage is present. If LEDs do not ash, or if
no voltage is present at output terminals during ash,
replace the board.

7
Donaldson Company, Inc.
PS1
5
4 2 1
side view
autotran
BKT1
C6
R35
U6
L3
L4
L5
C16
C17
C18
R43 R42 R41
R44 R45 R46
C3
C2
Y1 D5
5 4 3 2 1
J2
U1
R50
R51
C8
R27
T36
R37
R38
RA12
U7
U2
1
2
3
4
5
6
7
8
1
2
3
4
5
1
2
3
4
5
6
7
8
RA8
RA7
RA11
ADDRESS
SW6
1
2
3
4
5
6
7
8
C14
R33 R48 R49
low
CP1
D1 D2
CR1 CR2
TB3
Mode
slave
alarm
R47
Q7
J5
7 8 9 10 11 12
hi/lo
control
alarm or
auxiliary
J3
J4
NC
2
3
NC
2
3
prog
disable alarm
reset
3 4 5 6
R26 R28 R31 R32
R25 R39 R29 R21
R22 R23
C11
C12 TB2
3 2 1
J1
in mm
L1
L2
1 2
TB1
115/230-V
input
W1 W2 W3
115V 230V 115V
UPDOWN
CP4
CP5
CP2
U4
U8
C15
high Alarm
C5 R34
R16
R15
R19
R14
Cleaning
Alarm
CP3
U3
C4
Q2
Q1
Q3
Q5
Q4
"wg
mm wg
R5 R11 R6 R8 R20
Q8 Q6
R10 R4 R9 R7
LED 1 LED 2 LED 3
LED 1-3
R1R3
Q10
R13
Q9
R12
R17
R12
R30
C13 C19 C7
VR2
U5
CONN 1
R2
R40
R24
TB4
sensor out
13
+14
GND
C10
VR1
in out
F1
D3 D4 C1 C9
7 9
10 12
T1
1 3 4 6
A144C
M9805-02-08 REV.
PJ1
1
2
3
4
5
1
2
Delta P Control
Replacement Parts
Item Part Number Description Model
1 7508201 Delta P Control (includes keypad label and printed circuit board) All
2 2334200 Plastic Tubing, Vinyl, 3/16-in ID, 5/16-in OD All
Printed Circuit BoardKeypad Label
Plastic Tubing

Delta P Control
8
Appendix A - Installation

9
Donaldson Company, Inc.
Installation
Location and Site Selection
Electrical Installation (including bonding and grounding of the collector) must be performed by a qualied electrician.
Do not install in classied hazardous atmospheres without an enclosure rated for the application.
Service must be performed by trained and qualied maintenance personnel.
This equipment may start or stop unexpectedly from a remote location
Codes may regulate recirculating ltered air in your facility. Consult with the appropriate authorities having jurisdiction
to ensure compliance with all national and local codes regarding recirculating ltered air.
Equipment location must conform to all codes and standards, should be suitable fot the type of dust being handled and should
ensure easy access for service and utility connections. Site selection must account for wind, seismic zone and other load
condidtions.
Unloading and Positioning
Equipment should be lifted only by qualied crane or fork truck operators.
Failure to lift the equipment correctly can result in severe personal injury and/or property damage.
1. Remove any crates or shipping straps.
2. Inspect for any damage and/or missing parts and report to freight carrier.
3. Check for any hardware which may have become loose during shipment and tighten as necessary.
Delivery and Inspection
Upon arrival inspect equipment and report any damage to delivery carrier. File any damage claims with the delivery carrier.
Request a written inspection report from the Claims Inspector to substantiate all damage claims.
Compare the equipment received with the description of product ordered. Report any incomplete shipments to the delivery carrier
and your Donaldson Torit representative.

Delta P Control
10
Electrical installation, service, or maintenance work must be performed by a qualied electrician and comply with all
applicable national and local codes.
This equipment may start or stop unexpectedly from a remote location.
Turn power off and lock out all power before performing service or maintenance work.
The appropriate wiring schematic and electrical rating must be used. See collector’s rating plate for required voltage.
Do not install in classied hazardous atmospheres without an enclosure rated for the application.
Electrical Wiring
The Delta P control is factory set for 115-V. To operate at 230-V, the jumper settings on the printed circuit
board must be changed. See Optional Settings.
1. Choose a location near the collector that permits access to the keypad for adjustments and observation of the pressure drop.
If possible, mount the control indoors.
2. Mount the control enclosure using four self-drilling, self-tapping screws.
Use vibration isolators in high vibration areas.
3. Install conduit between the control’s enclosure, the solid-state timer, and the solenoid valve enclosure on the collector.
4. Using the wiring diagram provided with the control, make the wiring connections to the Delta P control, the solid-state timer,
and the solenoid valves. Make the required connections to the motor starter’s low-voltage terminals.
Use proper grounding and handling procedures to prevent permanent damage to this device. Handle the
printed circuit board by the edges only. Do not touch the socketed E2PROM pins.
5. Wire the auxiliary alarm circuit, if desired. This relay activates the ALARM light on the control panel and the alarm relay if the
pressure drop exceeds the alarm setpoint. The auxiliary relay can be used to activate visual or audible alarms provided by
others.
6. Thirty-ve feet of plastic tubing is supplied with the control and must be cut in two sections. Connect one section of tubing from
the control enclosure’s high-pressure port to the pressure tap on the dirty-air plenum. Connect the remaining section of tubing
from the control enclosure’s low-pressure port to the pressure tap on the clean-air plenum. Additional tubing can be ordered
from your representative.
7. Place the program wire on the solid-state timer board pin to match the number of solenoid-valve connections used.
8. Apply power to the control. Set the high- and low-pressure setpoints to start and stop the cleaning process. Set the alarm
setpoint to activate the alarm display. See Control Calibration.

11
Donaldson Company, Inc.
Setpoint Adjustments
Low Setpoint
Press and hold the LOW SET key while using the increase or decrease arrow keys until the desired Low Setpoint is displayed. If
the desired setting cannot be reached, increase the High Setpoint to a value higher than the intended Low Setpoint and readjust
the Low Setpoint.
For collectors with pleated bags, it is recommended that the low setpoint be set to no lower than 0.5” w.g.
below the high setpoint.
High Setpoint
Press and hold the HIGH SET key while using the increase or decrease arrow keys until the desired High Setpoint is displayed. If
the desired setting cannot be reached, increase the Alarm Setpoint to a value higher than the intended High Setpoint and readjust
the High Setpoint.
Alarm Setpoint
Press and hold the ALARM SET key while using the increase or decrease arrow keys until the desired Alarm Setpoint is displayed.
If the desired setting cannot be reached, decrease the High Setpoint to a value lower than the intended Alarm Setpoint and
readjust the Alarm Setpoint.
Delta P Control Display
indicates closed
alarm relay
low setpoint
increase
setpoint
high setpoint
3-digit dieplay
indicates closed
cleaning relay
alarm setpoint
decrease
setpoint

Delta P Control
12
Delta P Control Installation
Delta P Control Calibration
The only user calibration is the zero adjustment of the display. Due to slight changes in electronic components over time, or
pressure differentials within the plant environment, the display may read something other than 0.0 while at rest. Use the following
procedure to recalibrate the operating system.
1. Turn power to the Delta P Control ON for a minimum of 30-minutes to stabilize the operating temperature.
2. Disconnect the pressure tubing, either leaving it to atmosphere or connecting the two barbed ttings together with a short
length of tubing.
3. Turn power to the control OFF.
4. Press and hold the LOW SET, HIGH SET, and ALARM SET keys while turning power to the control back ON. Continue holding
the keys as the control goes through its power-up sequence. The number 8 is displayed in each digit, and then the display
reads 0.0.
5. Release the three keys. The new calibration is automatically stored in memory.
6. Connect one section of tubing from the control enclosure’s high-pressure port to the pressure tap on the dirty-air plenum.
Connect the remaining section of tubing from the control enclosure’s low-pressure port to the pressure tap on the clean-air
plenum.
high-pressure port
dirty-air plenum
low-pressure port
clean-air plenum

13
Donaldson Company, Inc.
Optional Settings
230-V Power Supply
To operate at 230-V, remove two jumpers labeled W1 and W3. Reinsert one of the jumpers in position W2.
Change from English to Metric (SI) Units
On the J1 jumper block located above the PROG DISABLE terminals, move the jumper from the center and left pins 2 and 3, to the
center and right pins 1 and 2.
Disable Setpoint Adjustment
To restrict setpoint changes, install a jumper wire across the PROG DISABLE terminals on Terminal Block 2, TB2. The current
settings can be displayed, but no changes can be made until the jumper is removed. Interrupting the jumper with a key-operated,
normally-closed switch installed in the enclosure door provides temporary access to the setting functions without opening the door.
External Alarm Reset
Wire the ARM RESET terminals on Terminal Block 2, TB2, to a key-operated, normally-open switch. Closing the switch turns the
alarm OFF. If alarm conditions still exist, the alarm relay reactivates in 10 seconds.
Alarm Disable
Remove the jumper on Jumper Block J5 located on the lower-right quadrant of the circuit board, from the ALARM mode position.
1. Reinstall the jumper in the SLAVE mode position to operate the AUXILIARY relay in parallel with the HI/LO CONTROL relay.
2. The AUXILIARY relay will not function if no jumper is installed.
Note: Disabling the alarm relay reduces the alarm function to visual display only.
Analog Output (TB4, Terminals 13 & 14)
Terminals 13 & 14 on Terminal Block 4, TB4, in the upper-left quadrant of the circuit board, provide a 4 to 20 mA output
proportional to the 0-to-maximum span of the pressure sensor. This circuit requires a 500 ohm maximum load.

Delta P Control
14
Printed Circuit Board (Optional Settings Location)
PS1
5
4 2 1
side view
autotran
BKT1
C6
R35
U6
L3
L4
L5
C16
C17
C18
R43 R42 R41
R44 R45 R46
C3
C2
Y1 D5
5 4 3 2 1
J2
U1
R50
R51
C8
R27
T36
R37
R38
RA12
U7
U2
1
2
3
4
5
6
7
8
1
2
3
4
5
1
2
3
4
5
6
7
8
RA8
RA7
RA11
ADDRESS
SW6
1
2
3
4
5
6
7
8
C14
R33 R48 R49
low
CP1
D1 D2
CR1 CR2
TB3
Mode
slave
alarm
R47
Q7
J5
7 8 9 10 11 12
hi/lo
control
alarm or
auxiliary
J3
J4
NC
2
3
NC
2
3
prog
disable alarm
reset
3 4 5 6
R26 R28 R31 R32
R25 R39 R29 R21
R22 R23
C11
C12 TB2
3 2 1
J1
in mm
L1
L2
1 2
TB1
115/230-V
input
W1 W2 W3
115V 230V 115V
UPDOWN
CP4
CP5
CP2
U4
U8
C15
high Alarm
C5 R34
R16
R15
R19
R14
Cleaning
Alarm
CP3
U3
C4
Q2
Q1
Q3
Q5
Q4
"wg
mm wg
R5 R11 R6 R8 R20
Q8 Q6
R10 R4 R9 R7
LED 1 LED 2 LED 3
LED 1-3
R1R3
Q10
R13
Q9
R12
R17
R12
R30
C13 C19 C7
VR2
U5
CONN 1
R2
R40
R24
TB4
sensor out
13
+14
GND
C10
VR1
in out
F1
D3 D4 C1 C9
7 9
10 12
T1
1 3 4 6
A144C
M9805-02-08 REV.
PJ1
1
2
3
4
5
analog
sensor
out
voltage jumpers
power connection
alarm
disable
change units
external alarm reset
disable setpoints

Service Notes
Date Service Performed Notes
15
Donaldson Company, Inc.
Model Number _________________________________ Serial Number ___________________________________
Ship Date _____________________________________ Installation Date __________________________________
Filter Type_____________________________________________________________________________________
Collected Dust _________________________________________________________________________________
Dust Properties: Kst _______________Pmax______________ MIE ____________ MEC __________________
Accessories ___________________________________________________________________________________
Other ________________________________________________________________________________________
_____________________________________________________________________________________________
Product Information (Process Owner to complete and retain for your records)

Delta P Control
16
Donaldson warrants to the original purchaser only that the Goods will be free from defects in material and manufacture for the applicable
time periods stated below: (1) Major structural components for a period of ten (10) years from the date of shipment; (2) Non-Structural,
Donaldson-built components and accessories including Donaldson Airlocks, TBI Fans, TRB Fans, Fume Collector products, Donaldson
built electrical control components, and Donaldson-built Afterlter housings for a period of twelve (12) months from date of shipment; and
(3) Donaldson-built lter elements for a period of eighteen (18) months from date of shipment.
Buyer is solely responsible for determining if goods t Buyer’s particular purpose and are suitable for Buyer’s process and application.
Seller’s statements, engineering and technical information, and recommendations are provided for the Buyer’s convenience and the
accuracy or completeness thereof is not warranted. If, after Seller receives written notice, within the warranty period, that any goods
allegedly do not meet Seller’s warranty, and Seller, in its sole discretion, determines that such claim is valid, Seller’s sole obligation and
Buyer’s exclusive remedy for breach of the foregoing warranty or any Seller published warranty, will be, at Seller’s option, either: (i) repair
or replacement of such goods or (ii) credit or refund to Buyer for the purchase price from Seller. In the case of repair or replacement,
Seller will be responsible for the cost of shipping the parts but not for labor to remove, repair, replace or reinstall the allegedly defective
goods. Refurbished goods may be used to repair or replace the goods and the warranty on such repaired or replaced goods shall be
the balance of the warranty remaining on the goods which were repaired or replaced. Any repair or rework made by anyone other than
Seller is not permitted without prior written authorization by Seller, and voids the warranty set forth herein. Seller warrants to Buyer
that it will perform services in accordance with the Sales Documents using personnel of required skill, experience and qualications
and in a professional and workmanlike manner in accordance with generally recognized industry standards for similar services. With
respect to any services subject to a claim under the warranty set forth above, Seller shall, in its sole discretion, (i) repair or re-perform
the applicable services or (ii) credit or refund the price of such services at the pro rata contract rate and such shall be Seller’s sole
obligation and the exclusive remedy for breach of the foregoing warranty on services. Products manufactured by a third party (“Third
Party Product”) may constitute, contain, be contained in, incorporated into, attached to or packaged together with, the goods. Buyer
agrees that: (a) Third Party Products are excluded from Seller’s warranty in this Section 7 and carry only the warranty extended by the
original manufacturer, and (b) Seller’s liability in all cases is limited to goods of Seller’s design and manufacture only. EXCEPT FOR
SELLER’S WARRANTY OF TITLE TO THE GOODS, SELLER EXPRESSLY DISCLAIMS AND EXCLUDES ALL OTHER WARRANTIES
WHATSOEVER, WHETHER, EXPRESSED OR IMPLIED, ORAL, STATUTORY, OR OTHERWISE, INCLUDING BUT NOT LIMITED
TO MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT OF THIRD PARTY INTELLECTUAL
PROPERTY AND ANY WARRANTIES ARISING FROM TECHNICAL ADVICE OR RECOMMENDATIONS, COURSE OF DEALING
OR OF PERFORMANCE, CUSTOM OR USAGE OF TRADE. Seller’s obligations do not cover normal wear and tear or deterioration,
defects in or damage to any goods resulting from improper installation, accident or any utilization, maintenance, repair or modication of
the goods, or any use that is inconsistent with Seller’s instructions as to the storage, installation, commissioning or use of the goods or
the designed capabilities of the goods or that, in its sole judgment, the performance or reliability thereof is adversely affected thereby, or
which is subjected to abuse, mishandling, misuse or neglect or any damage caused by connections, interfacing or use in unforeseen or
unintended environments or any other cause not the sole fault of Seller, and shall be at Buyer’s expense. Seller’s warranty is contingent
upon the accuracy of all information provided by Buyer. Any changes to or inaccuracies in any information or data provided by Buyer
voids this warranty. Seller does not warrant that the operation of the goods will be uninterrupted or error-free, that the functions of the
goods will meet Buyer’s or its customer’s requirements unless specically agreed to, or that the goods will operate in combination with
other products selected by Buyer or Buyer’s customer for its use.
The terms of this warranty may only be modied by a special warranty document signed by a Director, General Manager or Vice
President of Donaldson. To ensure proper operational performance of your equipment, use only genuine Donaldson replacement parts.
Donaldson Industrial Air Filtration Warranty

Important Notice: Many factors beyond the control of Donaldson can affect the use and performance of Donaldson products in a particular application, including the conditions under which the product is
used. Since these factors are uniquely within the user’s knowledge and control, it is essential the user evaluate the products to determine whether the product is fit for the particular purpose and suitable for the
user’s application. All products, product specifications, availability and data are subject to change without notice, and may vary by region or country.
Significantly improve the performance of your collector with genuine DonaldsonTorit replacement filters and
parts.
