Dongguan Taide Industrial Co. BT009 User manual

Dongguan Taide Industrial Co., Ltd.
Bluetooth Speaker
User’s Manual for BT009
I. OuterAppearance and Function Buttons
Touch colorful rings
Function key
LCD display screen
LED colorful rings

1. MODE/Mode selector: Press the Mode Selector to select SD card, Flash Memory Stick, AUX,
FM, Bluetooth and working state.
2. /Play/Pause: Click Pause while playing music and click Play during pausing. Press and hold
Automatic Search button under the conditin of FM. Under the condition of AUX, click Slience
and then click again to open the voice.
3.
1
/Alarm 1: Press this button to enable or disable the alarm 1. When enabled, the icon
1
shows up. Press and hold
1
to set up the time of alarm and the LCD display screen
displays
1
. Meanwhile, the clock flashes. Press and to configure the time. Finally,
press the Set Button to quit or quit automatically.
4.
2
/Alarm 2: [Hint: The alarm lasts 1minute and to turn it off, press the Alarm Button]
5. SNOOZE/DIMMER: Backlight control/Alarm setup. Backlight control: There are 3 options
like bright, dark and off. Press this button to select.
Alarm setup: SNOOZE/DIMMER can be regarded as snooze
function only when the alarm rings and the alarm can
ring again after five minutes.
6. /Upward: Press and hold the button to increase or decrease volume, press is to select songs
upwards while playing music.
7. /Downward: Press and hold the button to increase volume; press is to select songs
downwards.
8. SET/Set button: Set：Check the time and set up the calendar. Calendar setup: Press and hold the
Set Button to initiate date configuration. When the year flashes, press and to adjust and
then move to the month by pressing the Set Button again, continue to adjust via and .
When configuration is done, press any button to quit or quit automatically. Time check: When
the time is not available, press the Set Button to check it out.
9. SLEEP/ Automatic shut-down when time is up: The speaker turns itself off when the time is up.
Options of this button include OFF, 15, 30, 45, 60, 75, 90 and 120minutes. Such function is set
to OFF by default.
10. / Power On and Off: Press to start after power supply is connected and press to
shutdown in operation.
11. /Colorful LED On/Off button: Press to open colorful LED after power supply is connected;
Touch colorful rings to choose your favorite LED luminescent color after opened; Hold ,
colors can be changed automatically after opened, automatically-changed color time is 5

minutes; press to close colorful LED when opened.

II. Product functions and characteristics
1. FM radio: Internal FM Radio modules, antenna surrounded, automatic station search and stored
stations. 3.5mm Aux cable used as antenna must be plugged.
2. LCD display screen: Display corresponding working mode and calendar and time.
3．Time display: Set calendar and clock.
4．DC power: Use DC power supply with DC12/2,000mA.
5．Power-off memory play: Memorize exactly interrupted position of last time automatically.
6．AUX Audio-in jack: Input 3.5MM audio cable to connect various sound sources of audiovisual
products easily, including computer and MP3/MP4/IPOD/IPHONE.
7. Colorful LED: Touch control and colorful color bring warm and colorful for your life.
8. Alarm clock function: Remember time all the time and enhance life memory.
9. Internal high quality Bluetooth device and wireless transmission can make fashion more
convenient.
III: Product parameter
Bluetooth spec：Bluetooth V2.1+EDR
Transmission distance：≤10M
Speaker standard：8Ω、2.5inch
Output power：5W×2
Frequency response：90Hz-20KHz
Sensitivity：80db±2db
SNR：≥80dB
Distortion factor：≤0.3%
product standard：W260×D156×H99MM
IV. Power supply applied
The system applies DC power supply and specification of power supply is DC12V-2,000MA.
V. Common function description
Music Playback：Click “Mode” button to switch working mode, click “Play/Pause” button to
pause or continue playing and hold “Upward” or “Downward” button for 3
seconds to adjust volume.
AUX playback: Use the supplied audio cable to connect the speaker to another music player
such as computer by plugging one end to the speaker's AUX port and the other
end to the music player's audio port. Plug and play mode shall be supported.
Press Mode button to switch into working mode, hold “Upward” or
“Downward” button for 3 seconds to adjust volume. Click “ ” button, the
voice shall be silent under the condition of AUX and then click “ ” to open
the voice.
FM radio: Click “Mode” button to choose FM working mode, hold “Play/Pause” to
initiate automatic (save) station search, save station and delete station. Press
“Upward” or “Downward” to choose station after FM search station is made,
hold “Upward” or “Downward” button for 3 seconds to adjust volume.
Important tips: Audio-in jack cable must be plugged at the state of FM.
Clock query and calendar settings: Calendar settings: Hold SET button and enter calendar

settings: year can flicker, press and button to
adjust and then press SET button to have month flickering
and then press and button to adjust; Press any
button to exit or exit automatically after day, hour and minute
are adjusted in sequence.
Clock query: Press SET for query under the condition of
non-display time.
Alarm clock settings: Press
1
button to enable or disable the alarm 1. When enabled, the icon
1
shows up. Press and hold
1
to set up the time of alarm and the LCD
display screen displays
1
. Meanwhile, the clock flashes. Press and
to configure the time. Finally, press the Set Button to quit or quit
automatically.
Bluetooth connection: Press MODE button to switch into Bluetooth, the display can show: BLUE,
attached with prompt tone and the Bluetooth is open. Bluetooth connections
can be conducted by Bluetooth connection equipment. Bluetooth equipment
prompts whether to pair up or not. If selected Yes, it pairs up with the
device and a beep is also generated by the speaker. If failed to detect any
other Bluetooth device within 5minutes, the speaker will shut itself down. It
is necessary to restart if reconnections are needed (MODE shall be
switched into working mode of Bluetooth).
Tips: Please shutdown to restart or restart Bluetooth equipment if
connections are failed.
Bluetooth music playback: When connected, the speaker plays music immediately. Press and
to select tracks upwards or downwards. Press and hold and
to adjust the volume. While playing music, press to pause
and to resume
Use of colorful lamps: Press to open colorful LED after power supply is connected; Touch
colorful rings to choose your favorite LED luminescent color after opened;
Hold , colors can be changed automatically after opened and press
to close colorful LED when opened.

VI、Troubleshooting:
Faults Solution
NO FM radio Please make sure that you have plugged 3.5mm Aux cable,check if FM
signal is covered.
Bluetooth can not connected
1、Check if speaker is under bluetooth status，or restart your device or this
spekaer
2、Turn off other bluetooth devices around
Bluetooth speaker staccato 1、check if the distance is too far，if there is barrier between speaker and your
device。
FCC warning statement:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could
void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
