Donner DED-500 User manual

Thank You for Choosing DONNER!
Please Read This Guide Carefully Before Use.
INSTALLATION INSTRUCTION DED-500/DED-500P
- ENGLISH -

CONTENTS
1. ASSEMBLE THE STAND .................................................................................................................................................. 1
2. ASSEMBLE THE PAD ...................................................................................................................................................... 2
3. A-ATTACH THE CYMBALS ............................................................................................................................................... 3
3. B-INSTALL THE HI-HAT STAND ........................................................................................................................................ 4
4. ATTACH THE SOUND MODULE ........................................................................................................................................ 5
5. ATTACH THE KICK PEDAL ............................................................................................................................................... 6
6. POWER CONNECTION AND WIRING ................................................................................................................................ 7
7. PERFORMANCE PREPARATION ....................................................................................................................................... 8

1. ASSEMBLE THE STAND
Middle bend + one side
820mm straight pipe
Install the other 820mm
straight pipe
630mm bend pipe + 700mm
straight pipe on the right
630mm bend pipe + 820mm
straight pipe on the left
Install 350mm straight pipe
and 200mm straight pipe A-Apply to 3 cymbals
Install pad mount holder
B-3 cymbals and Hi-Hat
1

● Expand the stand according to the figure.
● Assemble the stand and pad in turn according to above figure.
● Insert pad mount and tighten
the wing nut
2. ASSEMBLE THE PAD
Wing nut
Pad nut
A-Apply to 3 cymbals B-3 cymbals and Hi-Hat
2

3. A-ATTACH THE CYMBALS
● Insert cymbal and align it with
indentation. Adjust knob nut to fix it.
Sensing range of cymbal
Knob nut
Felt washer
Check bracket
Tighten screw
3

3. B-INSTALL THE HI-HAT STAND
The screw should be
the same side of the
hole
The screw should be
the same side of the
hole
4

4. ATTACH THE SOUND MODULE
5
Connect audio cable and fix it. Insert sound module and adjust wing
knob to fix it.

5. ATTACH THE KICK PEDAL
6
● Open the kick drum stand entirely and lock the screw
at sides
● Install the beater into the holder securely by fixing
the screw
● Install the kick pedal securely
On the blanket
On the floot
Position beater at the
center of kick drum

6. POWER CONNECTION AND WIRING
● Connect the jacks as shown in the figure.
AC Adapter Audio Cable
7

7. PERFORMANCE PREPARATION
Pads: (Snare, Tom 1/2/3)
Cymbals: (Hi-Hat, Crash, Ride)
Head shot
Edge sensor
Edge shot
Pedal
Open Hi-Hat Half-open Hi-Hat Closed Hi-Hat
Adjust the beater
Adjust the center of
gravity of beater
Adjust the gradient
of beater
Adjust the tightness
of spring
8
Rim shot
Bow shot

DED-500
DED-500P
COMPLETE THE INSTALLATION ACCORDING TO THE INSTALLATION GUIDE OF THE
MODEL YOU PURCHASED.
9

Get in touch with our customer service at local time (hotline hours are listed on the Donner official website)
UNITED KINGDOM
Tel: [phone]
UNITED STATES
Tel: [phone]
CANADA
Tel: [phone]
AUSTRALIA
Tel: [phone]
SERVICE LANGUAGE
ENGLISH
Email: [email protected]
Website: www.donnermusic.com
Copyright ©2023 Donner LLC. All rights reserved.
Made in China Rev_1.0
