doping S7 User manual

3510005- 1 -
Thank you for your purchase
USER MANUAL
IMPORTANT SAFETY INSTRUCTIONS
- Read these instructions carefully before use of the sound system.
- Use the sound system only for the intended purposes and in the manner specied in the
instructions.
- Do not cover the ventilation openings of the appliance to prevent it from overheating.
- Do not place the appliance near heating sources (i.e., radiators, ovens, etc.).
- Do not place objects with an open ame, e.g., candles on the appliance.
- Disconnect the appliance from the power source during storms.
- The appliance must not be exposed to water or other liquids.
- It is forbidden to take the appliance out of the case and to repair the appliance.
- Do not connect the appliance to a system with any damages.
- Do not expose the batteries to excessive heat, e.g., sun, re or other heat sources.
- Check the appliance and charger on a regular basis. In case of any visible damage, take the
appliance to its authorised service centre to repair the damage.
- Avoid sharp impacts, strong vibration, dirt, humidity, extreme heat (above 40°C).
- Always turn off the appliance before connection / disconnection of cables.
- Avoid power cords being pulled hard and bent severely.
- For safety reasons do not allow children to play with the charger, power cords and packaging
materials.
- Do not attempt to replace the sound system battery yourself. This way you might damage the
battery and this might cause overheating, ignition and injuries.
- Do not use loudspeakers set to an extreme volume for a long time to avoid any hearing
impairments.
DESCRIPTION
Portable sound system with FM radio. Bluetooth to connect with smartphone. Charge with
smartphone charger (microB). Built-in RGB lights.
Content of the set:
• DOPING S7
• Charging cable USB-A/microB
• Dynamic microphone
• Quick Start Guide (manual)
FUNCTIONS
- Sound system equipped with USB ash memory, 3.5 mm linear in/out, and two 6.3 mm
microphone ports.
- USB ash memory records in MP3 format.
- Full FM range overlay (87.5 - 108.0 MHz).
- After restarting renews frequency and composition.
- Lithium battery ensures independent use of the device.
- Stylish and attractive design, LED lighting with rhythmic colour effects.
- Microphone recording function with storage on USB ash memory drive.
- Solid housing provides good quality sound.
PORTABLE SOUND SYSTEMEN

3510005- 2 -
Control panel
PREPARATION (See component numbers on the picture)
Unpacking
- Take the device out of packing.
- Take off all the packing materials and bracings.
Charging the battery
- Add the cable plug found in the set to jack USB 5V (16), add the other cable USB plug to jack
of the computer or adapter, a red charging mode indicator will light up (15).
When indicator (15) turns off, battery is charged.
Charging adapter in USB output shall be 5V±10%. Charge the battery approximately 3 hours.
ATTENTION: The voice notication indicates the need to charge the battery.
NOTE: If the device is powered on at the time of charging, the time of charging is longer.
USING THE DEVICE
Switching on:
To turn the device on, set the main OFF/ON switch (17) to position ON.
Volume control:
By turning the button of volume regulator VOL 1 (1) you can change the level of volume.
Playing MP3 les:
1. Insert USB ash containing MP3 recordings USB (14).
IMPORTANT: For the proper functioning of the memory card, be sure to insert USB ash
drive before switching on the device by using the OFF/ON switch (17) ON. Do not insert or
remove the USB ash drive while the device is in operation. Inserting or removing a USB
ash drive while the device is in operation may cause loss of information and/or damage
the equipment!
2. Turn on the device by using OFF/ON switch. MP3 playback will begin.
EN

3510005- 3 -
- If you have previously used another mode (Bluetooth mode, FM radio mode, Line in), press
[MODE] (6) to select the MP3 mode (in Music mode).
- Press [ ] (8) if you wish to turn on the Pause mode - playback will be stopped.
- If you press the button [ ] (8) again, playback will be resumed from where it was stopped.
- Selecting the next or previous track:
Briey press [ ] (9).
Briey press [ ] (7).
3. After listening to recordings, press [ ] (8).
4. Turn the device off by moving the main switch OFF/ON to position OFF.
5. Remove the USB ash memory.
Choosing repetition/recording mode
By pressing the key [REPEAT] (4) you can select one of the following modes:
Press the [REPEAT] button and hold it for 2 seconds (one sound signal): repeat one track.
Press the [REPEAT] button twice (two sound signals): play all tracks.
Playback of the analogue signal from external source:
1. Put in the cable plug found in the set in the 3.5mm jack AUX IN (12), put the other cable
plug in the source (for example, smartphone, tablet PC, MP3/MP4 player, etc.) LINE OUT or
earphone jack.
2. Switch on the device and with the button [MODE] (6) choose the mode "Line in".
3. Adjust volume.
Bluetooth wireless connection:
NOTES:
• Bluetooth is a technology that uses radio waves to wirelessly connect devices located
within a close range of each other.
• Since there are many different manufacturers, models and software versions, complete
functionality cannot be guaranteed.
Device pairing
a. Make sure that the Bluetooth function is activated on your mobile device (e.g.
smartphone).
To do this, refer to your mobile device's manual.
b. Turn on the device by using the OFF/ON switch (17).
c. Press the [MODE] button (6). Turn on Bluetooth mode.
Sound system is now attempting to connect to the device with which it was previously
paired. If sound system nds the paired device, a signal will sound. If the paired device is
not found, sound system is ready to be paired with another device.
d. Find the Bluetooth menu on your mobile device and register the device on your mobile
device. To do this, refer to your mobile device's manual. Information should appear on your
mobile device’s display regarding the paired device (BT ID) with the name "DOPING_S7".
e. If password is requested, enter "0000" (or another depending on the model or software
version of you mobile device).
INFO: Use the mobile device's controls to select the piece and play mode and set the start
volume (see the mobile device’s user manual). You can adjust the volume with the volume
regulator of the sound system (1).
EN

3510005- 4 -
3. Re-Connecting via Bluetooth
a. Activate the Bluetooth feature on your mobile device.
b. Turn on the sound system and choose the mode Bluetooth mode.
c. If your mobile device was paired only with the sound system, connection will take place
automatically. If your mobile device was paired with several other devices, connection with
the sound system will have to be made manually.
NOTES:
• Depending on the playback device manufacturer, re-registration may be required
(PAIRING).
• If you experience any problems connecting to the device, deactivate WiFi and mobile data
features on your device.
• Bluetooth compatibility cannot be guaranteed for devices (e.g. mobile phones), which will
be produced in the future.
• To ensure optimum connection, make sure your device's battery is fully charged.
• Some mobile devices have a power-saving mode. Deactivate the power-saving mode, as
it may cause problems in the transmission of data in the Bluetooth mode.
Reception of FM radio stations:
1. Turn the radio mode (FM radio mode) on by pressing button [MODE] (6).
2. Press button [ ] (8) and hold pressed for 1 second, range scanning and registration of radio
station frequencies in the memory and a short fragment of broadcast will be playbacked.
In order to prematurely stop search for FM radio stations, press the key [ ].
When scanning of FM radio stations is done, broadcast of the radio station found rst will be
playbacked.
3. By shortly pressing the button [ ] (7) or [ ] (9), choose any of the xed stations in the
memory.
4. Adjust volume.
Connecting a microphone:
1. Turn off the device.
2. Turn the volume control (1) to minimum.
3. Insert the 6.3 mm dynamic microphone connector in the MIC 1 (10) or MIC 2 (11) port (the
microphone is included with the product).
IMPORTANT: Move the dynamic microphone switch to the ON position.
4. Turn on the device by using the OFF/ON switch (17).
5. Speak into the microphone and set the necessary volume level with the control regulator (1).
Karaoke function:
To use the karaoke function, you must rst connect the microphone, as described under
"Connecting a microphone" and insert a USB ash drive with pre-recorded music (you can also
use a mobile device with a Bluetooth connection or another external music player, which is
connected to the socket AUX IN (12), as a music source).
1. Turn on the device by using the OFF/ON switch (17).
2. Press [MODE] button (6) to select the MP3 music source (Bluetooth mode/ Music mode/ FM
radio mode/ Line in).
EN

3510005- 5 -
3. Adjust the volume level of music and microphone. When using Bluetooth mode or Line in
mode, also adjust volume on your mobile device or external player.
Recording from microphone to USB ash drive
• The maximum length of the recorded material depends on the capacity of the memory
device.
• Records will be saved in the JL_REC folder.
1. Turn off the sound system with the switch OFF/ON (17).
2. Insert the USB ash drive into the USB socket (14).
3. Turn the main volume control VOL 1 (1) to the minimum. Use the key ECHO (3) to set the
echo level to minimum.
4.Move the microphone switch to the ON position.
4.1 Insert the microphone connector into the MIC 1 or MIC 2 port.
5. Turn on the sound system with the switch OFF/ON (17).
• If the sound system is in another mode, press the key [MODE](6), turn on the Music
mode.
6. Press the [RECORD] (5) button and hold it, until two sound signals are produced.
7. Speak into the microphone.
• Press the [RECORD]button and release it to stop the recording, and then press the
[RECORD] button and release it again to continue the recording.
8. To end the recording, press the [RECORD] (5) button and hold it. The recording will be saved
on the ash drive.
• If the recording fails, make sure that the ash drive still has a free space.
Playback of the microphone recordings
After completion of the recording, the last recording will be played automatically. If you want to
play other microphone records, press the key [] (7).
To exit the microphone recording playback mode, press the RECORD (5) button and release it.
• To play microphone recordings back, press the RECORD (5) button and release it in
Music mode.
• To exit the microphone recording playback mode, press the RECORD (5) button and
release it; MP3 track playback will start.
Lighting effects:
Front panel of the device may be lit with multicoloured LED diodes.
These light effects may be switched on/off by pressing the key [LIGHT] (2).
PROVISIONS FOR PROPER USE
This is a complex device and it must be treated carefully. For device to serve for a long time and
trustworthy, please take into consideration the following:
1. Do not place the device in a very hot place (over 40˚C). In heat, electronic devices and
batteries damage faster and plastic details can even become deformed.
2. make sure the device is not in contact with water and any other liquids.
3. Do not draw the device near powerful sources of electric eld and static electricity.
4. Do not arbitrarily open the device and repair it.
5. Do not insert non-standard, unqualied or broken spare parts, accessories, batteries in the
device.
EN

3510005- 6 -
6. If the device is brought from cold into a warm room, do not switch it on, but allow dewy details
to get dry for approximately two hours.
7. Do not allow unqualied persons to open the device.
8. Protect the device from blows, falls and powerful vibrations.
9. If the device has got wet, switch it off, wipe it and let it dry for at least 24 hours in a warm place.
CLEANING
Clean the device with soft, dry or slightly wet cloth, use no solvents (petrol, acetone, spirit etc.)
for cleaning.
Do not use any abrasive or caustic cleaning agents. After cleaning, carefully dry the device.
Technical data
Functions: USB ash card socket,
dynamic microphone 6.3mm input (x 2),
linear 3.5mm intput,
3.5 mm out port
FM radio 87.5 - 108 MHz
Wireless connectivity: Bluetooth V5.0 + EDR
Speaker: 2 x 4'' (102mm)
Output power: 30W
Playback freq. range: 90Hz - 20kHz
Signal/noise ratio: >60dB
Charging power supply: 5V, 1A, direct current (USB)
Battery: Li-ion 3.7V, 2400mAh
Battery charging time: approximately 3 hours
Battery operation time*: to 8 hours
Playback le format: MP3/WAV
Temperature of environment: 0˚C to 40˚C
Relative humidity of environment: 20% - 90%
Size: 393 x 243 x 200mm
Weight: 3,35kg
*The measurement was taken at 33% volume, with the LED lights switched off; its result is
approximate (depends on the design of the ash memory drive and the content of the record).
Technical changes are possible.
The symbol above means that according to local laws and regulations your product
and/or its battery shall be disposed of separately from household waste. When
this product reaches its end of life, take it to a collection point designated by local
authorities. The separate collection and recycling of your product and/or its battery at
the time of disposal will help conserve natural resources and ensure that it is recycled
in a manner that protects human health and the environment.
Duplication of this instruction for commercial purposes is not allowed.
EN
