DORCHESTER DR-TC 60 Guide

DORCHESTER
DR-CC 12-160 to DR-CC 32-380
CONDENSING HOT WATER
STORAGE HEATERS
Installation, Commissioning
and Maintenance Instructions
DORCHESTER MODELS:
DR-CC 12-160, 12-200, 20-160, 20-200, 24-245,
24-285, 32-285, 32-285, 32-380
Room Sealed or Open Flue, Direct Gas Fired Condensing Hot Water
Storage Heaters with Premix Burner and Automatic Ignition for
Domestic Hot Water Installations
NOTE:
THESE INSTRUCTIONS MUST BE READ AND UNDERSTOOD BEFORE
INSTALLING, COMMISSIONING, OPERATING OR SERVICING EQUIPMENT.
PUBLICATION NO. XXXXXXXX
ISSUE: “A”.
MARCH 2018
ND
THIS WATER HEATER IS FOR USE ON GROUP H NATURAL GAS (2 FAMILY) I ,
2H
RD
OR PROPANE (3 FAMILY) I . PLEASE ENSURE RELEVANT INFORMATION
3P
REQUIRED WITHIN DOCUMENT IS FOUND RELATING TO GAS TO BE FIRED
BEFORE FIRING HEATER.
THIS WATER HEATER COMPLIES WITH ALL RELEVANT EUROPEAN DIRECTIVES.
0312934

Preface
Copyright
Copyright © 2018 Hamworthy Heating
All rights reserved.
Nothing from this publication may be copied, reproduced and/or published by means of
printing, photocopying or by whatsoever means, without the prior written approval of
Hamworthy Heating.
Hamworthy Heating reserves the right to modify specifications in this manual.
Trademarks
Brand names in this manual are registered trademarks of their respective owners.
Warranty
Refer to the appendix Warranty (see section 13.6) for the warranty provisions.
Liability
Hamworthy accepts no liability for claims from third parties caused by:
unauthorized use
use other than stated in this manual
use other than in accordance with the General Conditions registered at the Chamber
of Commerce.
For more information, refer to the General Conditions. These are available on request, free
of charge.
We believe that this manual provides you with accurate and complete descriptions of all
relevant components. If you, nonetheless find errors or inaccuracies in this manual, please
inform Hamworthy. This helps us to further improve our documentation.
Compliance
To safely produce domestic hot water, the design and construction of the DR-CC water
heaters is in accordance with:
the European Gas Appliance Directive (GAD).
the European Standard for Gas–fired storage water heaters for the production of
domestic hot water (EN89).
The European ECO-Design Directive.
The European Energy Labeling Directive
•
•
•
•
•
•
•
0312934_DR-CC_UKUK_V1.0, 2018-03-01 3

Refer to the appendix Declaration of conformity (see section 13.5).
Regulations
Gas Safety (installations and Use) Regulations 1998 (as
amended).
It is law that all gas appliances are installed by competent persons, in accordance with the
above regulations. Failure to install appliances correctly could lead to prosecution. It is in
your own interest and that of safety, to ensure that this law is complied with.
The installation of the water heater MUST be in accordance with the relevant requirements
of the Gas Safety Regulations, Building Regulations, IEE Regulations and the Water Supply
(water fittings) Regulations. The installation should also be in accordance with any
relevant requirements of the HSE, local gas region and local authority and the relevant
recommendations of the following documents:
British and European Standards
BS 6891:2015
Specification for the installation and maintenance of low pressure gas installation
pipework of up to 35 mm (R1¼) on premises.
BS 6798: 2014
Specification for selection, installation, inspection, commisioning, servicing and
maintenance of gas-fired boilers of rated input not exceeding 70 kW net.
BS 6644: 2011
Specification for installation and maintenance of gas-fired hot water boilers of rated
inputs between 70 kW (net) and 1.8 MW (net) (2nd and 3rd family gases).
BS EN 806-1: 2000
Specification for installations inside buildings conveying water for human
consumption. General.
BS EN 806-2: 2005
Specifications for installations inside buildings conveying water for human
consumption. Design.
BS EN 806-3: 2006
Specifications for installations inside buildings conveying water for human
consumption. Pipe sizing. Simplified method.
BS EN 806-4: 2010
Specifications for installations inside buildings conveying water for human
consumption. Installation.
BS EN 806-5: 2012
Specifications for installations inside buildings conveying water for human
consumption. Operation and maintenance.
BS 8558: 2015
Guide to design, installation, testing and maintenance of services suppling water to
domestic use within buildings and their curtilages. Complementary guidance to BE EN
806.
BS 5546: 2010
Specification for installation and maintenance of gas-fired water-heating appliances
of rated input not exceeding 70 kW net.
BS 5440-1: 2008
Flueing and ventilation for gas appliances of rated input not exceeding 70 kW net
(1st, 2nd and 3rd family gases). Specification for installation of gas appliances to
chimneys and for maintenance of chimneys.
BS 5440-2: 2009
Flueing and ventilation for gas appliances of rated input not exceeding 70 kW net
(1st, 2nd and 3rd family gases). Specification for the installation and maintenance of
ventilation provision for gas appliances.
•
•
•
•
•
•
•
•
•
•
•
•
4

Institute of Gas Engineers and Managers (IGEM) Publications
IGE/UP/1 Edition 3:
Strength testing, tightness testing and direct purging of industrial and commercial
gas installations.
IGE/UP/1A:Edition 3:
Strength testing, tightness testing and direct purging of small low pressure industrial
and commercial natural gas installations.
IGE/UP/2: Edition 3:
Installation pipework on industrial and commercial premises.
IGE/UP/10 Edition 4:
Installation of flued gas appliances in industrial and commercial premises.
CIBSE Publications
Guide G Aug 2014:
Public Health & Plumbing Engineering
Contact information
In the event of problems with your gas, electricity or water supply connections or when
you have any comments or questions, please contact your supplier.
•
•
•
•
•
