Dorel Home Products DA3003249CL User manual

DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
DA3003249CL (Gold)
B34DA3003249CL00-100072
Date of Purchase
Console Table
V.K. - 8/29/2020
Lot Number (TAKEN FROM CARTON)
Thank you for purchasing from Dorel!
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1
© 2014 Dorel Home Products All Rights Reserved
Weight Limit: 50 Lb / 22.68 Kg

2
Read Before Beginning Assembly
• Work in a spacious area and near where the unit will be used, preferably on a
carpet, or use a piece of the cardboard packaging to protect your floor and
product.
• Make sure all parts are included. Most parts are labeled or stamped on the raw
•edge.
• Read each step carefully. It is very important that each step of the instructions is
performed in the correct order. If these steps are not followed in sequence,
assembly difficulties will occur.
• This product may contain small components. Please ensure that they are kept
away from small children.
• This product is designed for home use and is not intended for commercial use.
Contact Us!
For help with assembly, identifying parts, product information or to order parts,
please contact us:
Limited 1 year Warranty
Dorel warrants this product to be free from defects in material and
workmanship and agrees to remedy any such defect. This warranty covers
one year from the date of original purchase from authorized retailers. This is
solely limited to the repair or replacement of defective parts and assembly
labor is not included.
This warranty does not apply to any product which has been improperly
assembled, subjected to misuse or abuse or which has been altered or repaired
in any way.The warranty does not cover wearing, tearing, fading or splitting of the
fabric (where applicable). Liability for consequential damages is excluded to the
extent exclusion is permitted by law. This warranty gives you specific legal rights
and you may also have other rights which vary from state to state or province to
province.
To obtain warranty service, purchaser must present original bill of sale.
Components repaired or replaced are warranted through the remainder of the
original warranty period only. The defective components will be repaired or
replaced without charge, subject to the terms and conditions described above.
Visit www.dhpfurniture.com to view the limited warranty valid in the U.S.
and Canada.
Do NOT use
powertools
This product is packaged in
1 carton
1-800-267-1739
Monday to Friday
Saturday Sunday
DHP Consumer Services
12345 Albert Hudon, Suite 100,
Montreal, Quebec H1G 3L1
[e-mail]
9am to 9 pm (Eastern Time)
10 am to 6:30 pm (Eastern Time)
11 am to 7 pm (Eastern Time)
www.dhpfurniture.com
Phillips head screwdriver
（Not included）
Needed for assembly:

PARTS LIST
A
C
B
3

4
PARTS LIST
A B C
FRAME PANEL
2PCS
SIDE PANEL
2PCS
GLASS TOP
1PC
PART NUMBERS
PART
LABELS
DA3003249CL
(Gold)
AT705750
BT705760
CT705770
Each part has a unique part number. Please
reference the appropriate part number when contacting
customer service for replacement parts.
Before throwing any packaging, please verify all
contents and make sure you have received all the parts
listed above!

Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of the
page.
HARDWARE LIST
11
φ1/4"*3/4"
22
φ8*2.5
33
M4
BOLT
12 PCS
SUCTION CUP
8PCS
ALLEN KEY
1PC
5
DA3003249CL (Gold) (Bronze) TDA3003249CL-00
Hardware Pack
HP # :

Attached side panels(B) to frame panel( A) with
bolts(1) as shown.
NOTE: Do not fully tighten the bolts. Loose
bolts will facilitate assembly the following steps.
Step 1
6
x6
1
B
1
A
1
B
1
1
1
1

Attach the other frame panel (A) to the
previous assembly with bolts (1) as shown
below.
NOTE: Do not fully tighten the bolts. Loose
bolts will facilitate assembly the following
steps.
Step 2
7
x6
1
A
1
1
BB
1
1
1

Place suction cap (2) on frame panels (A)
and side panels (B) as shown.
Place glass top (3) onto the frame as shown.
Make sure all the parts are flush before
tightening the bolts.
Step 3
8
x8
↓
B
B
C
↓A
A
2

The product is equipped with adjustable
levelers.
Rotate the adjustable levelers clockwise or
counterclockwise to make sure the table
rests evenly on the floor.
Step 4
9

CAUTION: This unit is intended for use only with the products and/or maximum
weights indicated. Use with other products and/or products heavier than the
maximum weights indicated may result in instability or cause possible injury. •Move your new furniture carefully, with two
people lifting and carrying the unit to its new
location.
•Your furniture can be disassembled and
reassembled to move.
•Dust this item regularly with a soft, lint-free
cloth to prevent soil build up. Do not soak or
wash in hot water. Wipe with a soft, damp
cloth if necessary. Do not use abrasives,
cleansers or polish.
•Check bolts and nuts periodically and tighten if
necessary.
Helpful Hints
Weight Limit:
50 Lb / 22.68 Kg
That's it ! You've finished assembling your Console Table!!
10
