7400 Series Nose Bar
Conveyors
Installation, Maintenance and Parts Manual
851-593 Rev. A

Dorner Mfg. Corp. 2 851-593 Rev. A
7400 Series Nose Bar Conveyors
Table of Contents
Introduction ......................................................................... 2
Warnings – General Safety.................................................. 3
Product Description ............................................................. 4
Specifications ...................................................................... 4
Installation ........................................................................... 6
Required Tools................................................................. 6
Recommended Installation Sequence .............................. 6
Conveyors up to 10 ft (3048 mm).................................... 6
Stand Installation.......................................................... 6
Tail Assembly Installation ........................................... 7
Nose Bar Drive Tail.................................................. 7
Nose Bar Idler Tail ................................................... 7
Nose Bar Tip Up Tail ............................................... 8
Idler Tail ................................................................... 9
Tip Up Tail ............................................................. 10
Lifter Installation........................................................ 11
Wear Strip Installation ............................................... 11
Belt Installation .......................................................... 12
Belt Return Installation .............................................. 13
Conveyors Longer than 10 ft (3048 mm) ...................... 14
Preventive Maintenance and Adjustment.......................... 16
Required Tools............................................................... 16
Checklist ....................................................................... 16
Cleaning ......................................................................... 16
Routine Cleaning........................................................ 16
Standard Conveyors................................................ 16
Conveyors with Tip Up Tails and Lifters ............... 17
Periodic Cleaning ....................................................... 17
Lubrication..................................................................... 17
Conveyor Bearings .................................................... 17
Wearstrips and Belt Returns .......................................... 17
Maintaining the Conveyor Belt...................................... 17
Troubleshooting ......................................................... 17
Conveyor Belt Replacement ......................................... 18
Conveyors with Guides............................................... 18
Standard Belts ............................................................. 18
Replacing a Section of Belt..................................... 18
Replacing the Entire Belt ........................................ 19
Specialty Intralox 1100 Series Belts........................... 19
Replacing a Section of Belt..................................... 19
Replacing the Entire Belt ........................................ 20
Conveyor Belt Tensioning.............................................. 20
Sprocket and Puck Removal........................................... 21
A - Drive Sprocket Removal ..................................... 21
B - Nose Bar Puck Removal ....................................... 23
C - Idler Puck Removal ............................................. 23
Reassembling Tail Assemblies....................................... 24
Nose Bar Drive Tail.................................................... 24
Nose Bar Assembly................................................. 24
Drive Tail Assembly ............................................... 24
Nose Bar Idler and Tip Up Tails................................. 25
Idler Tail and Tip Up Tail........................................... 25
Bearing Replacement .................................................... 26
Service Parts....................................................................... 28
Nose Bar Drive End Components .................................. 28
Nose Bar Tension End.................................................... 30
Nose Bar Tip Up Tension End ....................................... 31
Tension End Components .............................................. 32
Tip Up Tension End ....................................................... 33
Conveyor Frame and Extension ..................................... 34
3" (76 mm) High Sides................................................... 35
Flat Belt Returns............................................................. 36
Flat Belt .......................................................................... 37
Ordering a Replacement Chain ...................................... 37
Belt Removal Tool ......................................................... 37
Configuring Conveyor Part Number .............................. 38
Return Policy...................................................................... 40
Upon receipt of shipment:
• Compare shipment with packing slip. Contact factory
regarding discrepancies.
• Inspect packages for shipping damage. Contact carrier
regarding damage.Accessories may be shipped loose.
• See accessory instructions for installation.
The Dorner Limited Warranty applies.
Dorner 7400 Series conveyors have patents pending.
Dorner reserves the right to make changes at any time
without notice or obligation.
Dorner has convenient, pre-configured kits of Key Service
Parts for all conveyor products. These time saving kits are
easy to order, designed for fast installation, and guarantee
you will have what you need when you need it. Key Parts
and Kits are marked in the Service Parts section of this
manual with the Performance Parts Kits logo .
Intralox is a registered trademark of Laitram L.L.C. in the
United States and / or other countries.
Introduction
CAUTION
Some illustrations may show guards
removed. DO NOT operate equipment without
guards.

851-593 Rev. A 3 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Warnings – General Safety
ADANGER
SEVERE HAZARD!
KEEP OFF CONVEYORS. Climbing, sitting,
walking or riding on conveyor will result in
death or serious injury.
ADANGER
EXPLOSION HAZARD!
• DO NOT OPERATE CONVEYORS IN AN
EXPLOSIVE ENVIRONMENT. The electric
gearmotor generates heat and could ignite
combustible vapors.
• Failure to comply will result in death or
serious injury.
AWARNING
CRUSH HAZARD!
• DO NOT place hands or fingers inside the
conveyor while it is running.
• DO NOT wear loose garments while
operating the conveyor. Loose garments
can become caught up in the conveyor.
• Failure to comply could result in serious
injury.
AWARNING
CRUSH HAZARD!
• SUPPORT CONVEYOR SECTIONS PRIOR
TO LOOSENING STAND HEIGHT OR
ANGLE ADJUSTMENT SCREWS.
• Loosening stand height or angle
adjustment screws may cause conveyor
sections to drop down, causing serious
injury.
AWARNING
SEVERE HAZARD!
LOCK OUT POWER before removing guards
or performing maintenance. Exposed moving
parts can cause serious injury.
AWARNING
BURN HAZARD!
DO NOT TOUCH the motor while operating, or
shortly after being turned off. Motors may be
HOT and can cause serious burn injuries.
AWARNING
PUNCTURE HAZARD!
Handle drive shaft keyway with care. It may
be sharp and could puncture the skin,
causing serious injury.
AWARNING
SEVERE HAZARD!
• Dorner cannot control the physical
installation and application of conveyors.
Taking protective measures is the
responsibility of the user.
• When conveyors are used in conjunction
with other equipment or as part of a
multiple conveyor system, CHECK FOR
POTENTIAL PINCH POINTS and other
mechanical hazards before system start-
up.
• Failure to comply could result in serious
injury.

Dorner Mfg. Corp. 4 851-593 Rev. A
7400 Series Nose Bar Conveyors
Product Description
Refer to (Figure 1) for typical conveyor components.
Figure 1
Flat Belt 7400 Series Conveyor
* Refer to “Ordering and Specifications” Catalog for details.
Conveyor Supports
Figure 2
Typical Components
1Conveyor
2 Gearmotor
3Belt
4 Return
5 Support Stands
6 Motor Controller
7DriveEnd
8 Tension End
3
2
7
5
6
4
1
8
Specifications
74 M WW LLL S S C D G
Profile *
BB
Belt Material *
Drive/ Pulley Type *
Cleaning Options *
Idler Stand Location *
Drive Stand Location *
Conveyor Length
Reference *
Conveyor Width
Reference *
Document Language *
Maximum Distances:
1 = 3 ft (914 mm)
2 = 8 ft (2438 mm)**
3 = 3 ft (914 mm)
** For conveyors longer than 10 ft (3.05 m), install
support at frame joint.
1 2 3

851-593 Rev. A 5 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Specifications
Specifications
Conveyor Width Reference (WW)06 – 60 in 02 increments
Conveyor Belt Width 6" (152 mm) – 60" (1524 mm) in 2" (51 mm) increments
Maximum Conveyor Load 20 lb / ft2(97 kg / m2) with a maximum of 1000 lb / ft2(4882 kg / m2)
Belt Travel 12" (305 mm) per revolution of pulley
Maximum Belt Speed 117 ft / minute (36 m / minute)
Belt Take-up 2" (51 mm)
Conveyor Length Reference (LLL)048 – 999 in 001 increments
Conveyor Length 48" (1176 mm) – 999" (25.4 mm) in 1" (25 mm) increments
IMPORTANT
Maximum conveyor loads are based on:
• Non-accumulating product
• Product moving toward gearmotor
• Conveyor being mounted horizontally
• Conveyor being located in a dry environment
• Conveyor equipped with standard belt only

Dorner Mfg. Corp. 6 851-593 Rev. A
7400 Series Nose Bar Conveyors
Installation
Figure 3
Required Tools
• 17 mm wrench (for hexagonal head fasteners)
• 4 mm hex wrench (for bearing shaft assembly fasteners)
• Level
• Torque wrench
Recommended Installation
Sequence
1. Attach the stands to the conveyor. Refer to “Stand
Installation” on page 6.
2. Attach the tail assemblies to the frame. Refer to “Tail
Assembly Installation” on page 7.
3. Attach the lifters, if applicable. Refer to “Lifter
Installation” on page 11.
4. Install the gearmotor, if applicable. Refer to the “7400
Series Drive Package Installation, Maintenance and
Parts Manual.”
5. Attach the wearstrips. Refer to “Wear Strip Installation”
on page 11.
6. Install the belt. Refer to “Belt Installation” on page 12.
7. Attach the belt returns. Refer to “Belt Return
Installation” on page 13.
8. Attach any guides / accessories. Refer to the "Service
Parts" section starting on page 28.
Conveyors up to 10 ft (3048 mm)
Stand Installation
Typical Stand Components (Figure 4)
Figure 4
1. Position the stands on a flat, level surface.
2. Attach the stands to the frame (Figure 5).
Figure 5
CAUTION
Dorner recommends cleaning all the “food
zones” prior to placing conveyor into service.
Ensure adequate access is provided for
cleaning and servicing equipment so that the
required level of hygiene can be maintained.
CAUTION
Conveyor MUST be mounted straight, flat,
and level within confines of conveyor. Use a
level (Figure 3, item 1), during setup.
1
1 Conveyor frame
2 Stand
3 M10 - 1.5 x 12 mm hex head cap screws (x4)
1
2
3

851-593 Rev. A 7 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Installation
Tail Assembly Installation
Nose Bar Drive Tail
Typical Nose Bar Drive Tail Components (Figure 6)
Figure 6
1. Bolt the nose bar drive tail assembly to the conveyor
frame (Figure 7).
Figure 7
2. Install the drive package, if applicable. Refer to the
“7400 Series Drive Package Installation, Maintenance
and Parts Manual.”
Nose Bar Idler Tail
Typical Nose Bar Idler Tail Components (Figure 8)
Figure 8
1. Slide the nose bar idler shaft hands (Figure 9, item 1)
into the take up blocks (Figure 9, item 2).
2. Attach the nose bar transfer post (Figure 9, item 3) to
the nose bar idler shaft hands.
Figure 9
3. Ensure that the nose bar pucks (Figure 10, item 1) are
in line with the conveyor frame (Figure 10, item 2).
1 Nose bar drive tail assembly
2 M10 x 1.5 x 12mm hex head cap screws (x4)
3 Conveyor frame
3
2
1
1 Nose bar idler tail assembly
2 Pull pin (x2)
3 Conveyor frame
1
2
3
2
1
3

Dorner Mfg. Corp. 8 851-593 Rev. A
7400 Series Nose Bar Conveyors
Installation
Figure 10
Nose Bar Tip Up Tail
Typical Nose Bar Tip Up Tail Components (Figure 11)
Figure 11
1. Slide the tip up shaft (Figure 12, item 1) through the
designated slots in the frame.
Figure 12
2. Attach the key stops (Figure 13, item 1) to the tip up
shaft (Figure 13, item 2). The rounded end of the key
stop should face the tail.
Figure 13
3. Attach the nose bar idler shaft hands
(Figure 14, item 1) to the tip up shaft
(Figure 14, item 2).
NOTE
Do not insert the pull pins on the tension end
of the conveyor until the belt has been
installed.
1 Tip up tail assembly
2 Pull pin (x2)
3 Tip up shaft
4 Key stops (x2)
5 M10 - 1.5 mm acorn nut (x2)
2
1
180˚
3
2
4
5
1
1
1
2

851-593 Rev. A 9 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Installation
Figure 14
4. Attach the nose bar transfer post (Figure 15, item 1) to
the nose bar idler shaft hands (Figure 15, item 2).
Figure 15
5. Ensure that the nose bar pucks (Figure 16, item 1) are
in line with the conveyor frame (Figure 16, item 2).
Figure 16
Idler Tail
Typical Idler Tail Conponents (Figure 17)
Figure 17
1. Slide the bearing shafts (Figure 18, item 1) into the take
up blocks (Figure 18, item 2).
1
2
2
1
2
1
180˚
NOTE
Do not insert the pull pins on the tension end
of the conveyor until the belt has been
installed.
NOTE
Adjust the acorn nuts (Figure 11, item 5) on
the key stops (Figure 11, item 4) to raise or
lower the tip up tail assembly.
1 Idler tail assembly
2 Pull pin (x2)
3 Conveyor frame
3
2
1

Dorner Mfg. Corp. 10 851-593 Rev. A
7400 Series Nose Bar Conveyors
Installation
Figure 18
Tip Up Tail
Typical Tip Up Tail Components (Figure 19)
Figure 19
1. Slide the tip up shaft (Figure 20, item 1) through the
designated slots in the frame.
Figure 20
2. Attach the key stops (Figure 21, item 1) to the tip up
shaft (Figure 21, item 2). The rounded end of the key
stop should be facing the tail.
Figure 21
3. Slide the bearing shafts (Figure 22, item 1) into the
holes in the tip up shaft (Figure 22, item 2).
Figure 22
NOTE
Do not insert the pull pins on the tension end
of the conveyor until the belt has been
installed.
1 Tip up tail assembly
2 Pull pin (x2)
3 Tip up shaft
4 Key stops (x2)
5 M10 - 1.5 mm acorn nut (x2)
21
3
2
4
1
5
1
1
2
1
2

851-593 Rev. A 11 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Installation
Lifter Installation
Typical Lifter Components (Figure 23)
Figure 23
1. Slide the belt lift pivot bar (Figure 24, item 1) through
the designated holes in the frame.
Figure 24
2. Attach the lifter bars (Figure 24, item 2) to the belt lift
pivot bar (Figure 24, item 1). Make sure the hooked
ends of the lifter bars are facing down when resting
against the frame.
3. Attach the lifter handle (Figure 24, item 3) to the belt
lift pivot rod.
Wear Strip Installation
Typical Wear Strip Components (Figure 25)
Figure 25
1. Position the wear strips (Figure 26, item 1) on the
frame.
Figure 26
2. Make sure the wear strips are situated securely in the
frame slots (Figure 26, item 2).
NOTE
Do not insert the pull pins on the tension end
of the conveyor until the belt has been
installed.
NOTE
Adjust the acorn nuts (Figure 19, item 5) on
the key stops (Figure 19, item 4) to raise or
lower the tip up tail assembly.
1 Belt lift pivot bar
2 Lifter bars
3 Belt lift handle
4 M8 - 1.25 x 16 mm hex head cap screw
3
4
1
2
3
2
1
1 Wear strip
1
1
2

Dorner Mfg. Corp. 12 851-593 Rev. A
7400 Series Nose Bar Conveyors
Installation
Belt Installation
Typical Belt Components (Figure 27)
Figure 27
1. Position the belt on the conveyor frame (Figure 28).
Figure 28
2. Evenly space the sprockets (Figure 29, item 1) along
the drive spindle (Figure 29, item 2).
Figure 29
3. Wrap the belt around the conveyor, making sure the
sprocket teeth (Figure 29, item 1) have engaged the
belt.
4. Bring the ends of the belt together (Figure 30).
Figure 30
5. Insert the belt rod (Figure 31, item 1).
Figure 31
6. Push the belt rod in as far as possible.
7. Lightly tap the head of the rod with a hammer until it
snaps into position.
1 Chain belt
2Beltrod
1
2
1
2
1

851-593 Rev. A 13 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Installation
8. Extend the tension end to remove excess slack in the
belt (Figure 32).
Figure 32
9. Insert the pull pins (Figure 33, item 1) on the tension
end of the conveyor.
Figure 33
10. If no more travel is available, remove one or more belt
links to take up the tension. Refer to “Standard Belts:
Replacing a Section of Belt” on page 18.
Belt Return Installation
Typical Belt Return Components (Figure 34)
Figure 34
1. Attach the chain return shoes (Figure 35, item 1) to the
return shaft (Figure 35, item 2).
Figure 35
2. Slide the return shaft (Figure 36, item 1) up and
through the large slot (Figure 36, item 2) in the frame
(picture shown without the belt or wear strips).
1
1 Return shaft
2 Chain return shoe
1
2
1
2

Dorner Mfg. Corp. 14 851-593 Rev. A
7400 Series Nose Bar Conveyors
Installation
Figure 36
3. Push up on the return shaft (Figure 36, item 1) and slide
the notched end of the shaft through the small slot on the
opposite side of the frame.
4. Check belt sag by measuring from the top of the return
(Figure 37). Belt sag should not exceed 4" (102 mm).
Follow steps 7 – 9 in the “Belt Installation” section on
page 12 to remove slack from the belt.
Figure 37
Conveyors Longer than 10 ft
(3048 mm)
Typical Connection Components (Figure 38)
Figure 38
1. Locate the section number sequence etched on each
section of frame (Figure 39, item 1)
Figure 39
2. Position the frame sections in the correct order.
3. Connect the frame sections by bolting the hex post
connectors (Figure 40, item 1) the sections of frame.
CAUTION
Belt sag should not exceed 4" (102 mm) from
the top of the returns.
1
2
(102 mm)
Up to 4"
1 M10 x 1.5 mm hex head cap screws (x4)
2 Connector hex rods (x2)
3 Conveyor frames
3
1
2
1

851-593 Rev. A 15 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Installation
Figure 40
4. Follow the installation process described in “Conveyors
up to 10 ft (3048 mm)” starting on page 6.
1

Dorner Mfg. Corp. 16 851-593 Rev. A
7400 Series Nose Bar Conveyors
Preventive Maintenance and Adjustment
Required Tools
• 17 mm wrench (or adjustable wrench)
• 4 mm hex wrench (for bearing shaft assembly fasteners)
• 3 mm hex wrench
• Punch and hammer (to remove belt rod)
Checklist
• Keep service parts on hand. Refer to the "Service Parts"
section starting on page 28 for recommendations.
• Replace any worn or damaged parts.
Cleaning
Routine Cleaning
Dorner recommends cleaning the inside and the outside of
the conveyor on a daily basis. Refer to the following steps to
access the inside of the conveyor.
Standard Conveyors
1. Remove the guides, if applicable, by removing the pull
pins (Figure 46, item 1) that connect the guide
(Figure 46, item 2) to the frame.
Figure 41
2. Remove the pull pin (Figure 42, item 1) on the tension
end of the conveyor to release belt tension.
Figure 42
3. Lift up on the belt (Figure 43).
Figure 43
CAUTION
Dorner recommends cleaning all the “food
zones” prior to placing conveyor into service.
Ensure adequate access is provided for
cleaning and servicing equipment so that the
required level of hygiene can be maintained.
AWARNING
SEVERE HAZARD!
LOCK OUT POWER before removing guards
or performing maintenance. Exposed moving
parts can cause serious injury.
1
2
1

851-593 Rev. A 17 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Preventive Maintenance and Adjustment
Conveyors with Tip Up Tails and Lifters
1. Remove the guides, if applicable, by removing the pull
pins (Figure 46, item 1) that connect the guide
(Figure 46, item 2) to the frame.
2. Use the lifter handle (Figure 44, item 1) to raise the
lifters (Figure 44, item 2) and raise the tip up tail
(Figure 44, item 3).
Figure 44
Periodic Cleaning
Dorner recommends complete dissasembly of the conveyor
periodically for thorough cleaning.
For conveyor disassembly and reassembly instructions:
• Refer to “Conveyor Belt Replacement” on page 18.
• Refer to “Sprocket and Puck Removal” on page 21.
• Refer to “Reassembling Tail Assemblies” on page 24.
Lubrication
Conveyor Bearings
Conveyor bearing lubrication is required. Dorner
recommends using an H-1 food grade grease.
1. Add grease to the bearing using the zerk fitting
(Figure 45, item 1) on the exterior of the bearing shaft
assembly.
Figure 45
2. Replace the bearings if they become worn.
Wearstrips and Belt Returns
Replace the wearstrips and belt returns if they become worn.
For wearstrip and belt return installation instructions:
• Refer to “Wear Strip Installation” on page 11.
• Refer to “Belt Return Installation” on page 13.
Maintaining the Conveyor Belt
Troubleshooting
Inspect conveyor belt for:
• Surface cuts or wear
• Skipping
Damage to belt links or rods, surface cuts and / or
wear indicate:
• Sharp or heavy parts impacting belt
• Jammed parts
• Accumulated dirt
• Foreign material inside the conveyor
• Improperly positioned accessories
Skipping indicates:
• Excessive load on belt
• Worn sprockets or impacted dirt on drive pulley
CAUTION
DO NOT submerge or soak bearing
assemblies. This will reduce the life of the
bearing.
NOTE
Although bearings are sealed, re-greasing is
recommended to increase bearing life. An
H-1 food grade grease is recommended. The
frequency of bearing re-greasing is
dependent upon the application in which the
conveyor is being used. Frequency of re-
greasing will increase with the frequency of
conveyor washing.
3
2
1
NOTE
Visit www.dorner.com for complete list of
troubleshooting solutions.
1

Dorner Mfg. Corp. 18 851-593 Rev. A
7400 Series Nose Bar Conveyors
Preventive Maintenance and Adjustment
Damage to belt links or rods indicate:
• Excessive load on belt
• Dirt impacted on sprockets
• Excessive or improper side loading
• Improperly positioned accessories
Conveyor Belt Replacement
Conveyors with Guides
1. Remove the pull pins (Figure 46, item 1) that connect
the guide (Figure 46, item 2) to the frame.
Figure 46
2. Remove the guide (Figure 47, item 1).
Figure 47
3. Follow the belt replacement procedures described in
“Standard Belts” on page 18 or “Specialty Intralox 1100
Series Belts” on page 19.
Standard Belts
Replacing a Section of Belt
1. Remove the pull pins (Figure 48, item 1) on the tension
end of the conveyor to release tension on the belt.
Figure 48
2. Secure the retaining head (Figure 49, item 1) side of the
belt by bracing it against the flanged puck
(Figure 49, item 2).
AWARNING
SEVERE HAZARD!
LOCK OUT POWER before removing guards
or performing maintenance. Exposed moving
parts can cause serious injury.
1
2
CAUTION
Secure the retaining head side of the belt
prior to removing a belt rod in order to
prevent damaging the belt.
1
1

851-593 Rev. A 19 Dorner Mfg. Corp.
7400 Series Nose Bar Conveyors
Preventive Maintenance and Adjustment
Figure 49
3. Use a punch and hammer to push the belt rod out by
striking the rod end opposite the retaining head
(Figure 50).
Figure 50
4. Remove the belt rods on both sides of the section of belt
being replaced.
5. Replace the old section with a new section of belt.
Replacing the Entire Belt
1. Remove the belt returns by pushing up on the return
shaft (Figure 51, item 1) and sliding it through the large
hole (Figure 51, item 2) in the frame.
Figure 51
2. Lower the opposite end of the return shaft
(Figure 51, item 1) and slide it out of the frame.
3. Follow steps 1 – 3 in "Standard Belts: Replacing a
Section of Belt" on page 18.
4. Remove the belt.
5. Replace the damaged or worn belt. Refer to “Belt
Installation” on page 12 and “Belt Return Installation”
on page 13.
Specialty Intralox 1100 Series Belts
Replacing a Section of Belt
1. Place the edge of a flat head screwdriver between the
the two belt links and turn clockwise (Figure 52).
Figure 52
2. Use a second belt rod of the same size to push on the
opposite end of the belt rod. (Figure 53).
CAUTION
DO NOT reuse belt rods that are damaged or
show signs of wear.
2
1
1
2

Dorner Mfg. Corp. 20 851-593 Rev. A
7400 Series Nose Bar Conveyors
Preventive Maintenance and Adjustment
Figure 53
3. Remove the belt rods on both sides of the section of belt
being replaced.
4. Replace the old section with a new section of belt.
Replacing the Entire Belt
1. Remove the belt returns.
2. Follow steps 1 – 2 in "Specialty Intralox 1100 Series
Belts: Replacing a Section of Belt" on page 19.
3. Remove the belt.
4. Replace the damaged or worn belt. Refer to “Belt
Installation” on page 12 and “Belt Return Installation”
page 13.
Conveyor Belt Tensioning
1. Remove both pull pins (Figure 54, item 1) on the
tension end of the conveyor.
Figure 54
2. Extend the idler tail to the next groove
(Figure 54, item 2) on the bearing shaft.
3. Continue extending the tension end until the belt is
sufficiently tight (Figure 55).
Figure 55
4. Reinsert the pull pins.
5. If no more travel is available, remove one or more belt
links to take up the tension. Refer to “Replacing a
Section of Belt” on page 18.
CAUTION
DO NOT reuse belt rods that are damaged or
show signs of wear.
AWARNING
SEVERE HAZARD!
LOCK OUT POWER before removing guards
or performing maintenance. Exposed moving
parts can cause serious injury.
CAUTION
Belt sag should not exceed 4" (102 mm) from
the top of the returns.
1
2
