DOUGHXPRESS DXP-GF001 User manual

Warning Page 1
Installation and Setup 2-3
Parts List 4-6
Equipment Explode Image 7
Warranty 8
DXP-GF001
OPERATIONS MANUAL
CONTENTS
BEFORE warranty repair you MUST get Prior Authorization:
BREAD SLICER
For Customer Service, Call 1-800-835-0606
or Visit www.doughxpress.com
11100 RV A_022020

2
INSTALLATION & SETUP
1. INSTALLATION
Put the Slicer on a stable table and make sure the Slicer seats rmly on the
table. If the Slicer vibrates seriously during operation, put paper or rubber
underneath the frame of the Slicer.
2. ELECTRICAL CONNECTION
Before making electrical connections, check the specications on the name
plate to make sure they agree with those of your electrical service.
3. SPECIAL ATTENTION
The operator should not put his ngers into the vibrating knives. The last
bread can not be sliced easily. Please do not try to push the last bread with
nger from the chute or take out the bread from front.
PLEASE SWITCH OFF THE SLICER WHEN YOU CLEAN IT.
4. CHANGE OF BLADES
When Slicer slices the bread slowly, the blades have become dull and must
be changed.
TO DISMANTLE THE BLADES
1. Take o󰀨 Top cover (9).
2. Take o󰀨 Outgoing Chute (10) secured by 4 Screws,
3. Loosen the screws on Bracket (6) Remove Outfeed Guides (7).
4. Remove Guide Rod (33) by backing o󰀨 Screw and JUST loosening
Locking Nut. 5 Loosen 4 Screws on part (40) to remove Blade Frames
(25) and (26)
6. Compress Spring (30) to take out Blade one by one. You can use C-Clamp
or Vice Grips to compress Spring. Cut slot in tool, thickness of Blade to be
able to slip over Blade to be able to compress, Special Tool is available
upon request, Part Number GF001/BL/001

3
INSTALLATION & SETUP
TO REMOUNT THE BLADES
1. Compress Spring (29) to put the Blades onto the Frames (25) and (26)
one by one.
2. Put Frames (25) and (26) into position and lightly tighten bolts that
screw into (40) that secure Blade Frames, insert the Guide Rod (35) into
Top of Frames. NOTE: MAKE SURE BOLT THAT SECURES GUIDE ROD
(30) IS PROPERLY SEATED IN INDENTATION ON GUIDE ROD, IF NOT
THE GUIDE POD MAY COME LOOSE AND HIT TOP COVER (9)
3. Make sure Blade Frames will travel up and down freely with out hitting
one another, there should be about 1/32 of an inch between Blade Hold-
ing Brackets. Once this is done and Blade Frames don’t collide with one
another tighten bolts that screw into part Number (40) to secure bottom of
Blade Frame
4. Reinstall parts Number (7) Tighten the screw (6)
5. Put in Outgoing Chute (10).
6. Turn on Bread Slicer to make sure all parts are secure and no unusual
noises
7. Reinstall Top Cover (9) and turn on unit once again before using to
make sure Guide Rods (33) are not hitting Top Cover (9)
*PARTS LIST ON NEXT PAGE*

4
PARTS LIST
DXP-GF001 Parts List
S.NO Description Qty.
1 Machine Wall (left) 1
3 Screw Nut 1
5 Fixed lever 3
7 Outfeed Guide 2
9 Front / Top Cover 1
11 Pressing Plate for Toast 1
13 Fixing Block 1
15 Ball Bearing 4
17 Upper Slide Board 1
2 Machine Wall (right) 1
4 Handle 2
6 Plastic Lock Bolt 3
8 L Plate Fixed Block 1
10 Plate for Receiving Bread 1
12 Pressing Plate Block 1
14 Fixed Rod for Knife Shelf 1
16 Acrylic Plate 2
18 Slide Board Fixed Block 3
19 Rear Cover 1

5
PARTS LIST
1 Machine Wall (left) 1
3 Screw Nut 1
5 Fixed lever 3
7 Outfeed Guide 2
9 Front / Top Cover 1
11 Pressing Plate for Toast 1
13 Fixing Block 1
15 Ball Bearing 4
17 Upper Slide Board 1
2 Machine Wall (right) 1
4 Handle 2
6 Plastic Lock Bolt 3
8 L Plate Fixed Block 1
10 Plate for Receiving Bread 1
12 Pressing Plate Block 1
14 Fixed Rod for Knife Shelf 1
16 Acrylic Plate 2
18 Slide Board Fixed Block 3
19 Rear Cover 1
DXP-GF001 Parts List
S.NO Description Qty.
20 Lock Bolt 4
22 Slide Bar Shaft 1
24 Slide Board Shaft 1
26 Knife Shelf / Blade Frame 1
28 Fixed Pin 31
30 Spring 30
32 TeonGuideforRodLink   2
34 L Plate 2
36 Linking Bar Joint Block 1
21 Guide Bolt 2
23 Slide Board Shaft 1
25 Knife Shelf / Blade Frame 1
27 Knife 31
29 Knife Blade Fixed Block 62
31 Tee Tube 1
33 Driving Rod Link 2
35 Cable 1
37 Linking Bar Seat (left) 1
38 Shaft bearing 6

6
PARTS LIST
DXP-GF001 Parts List
S.NO Description Qty.
39 Joint Bar 2
41 Linking Bar Seat (right) 1
43 Belt 1
45 Capacitor 1
47 Motor Seat (right) 1
49 Drive Pulley 1
51 Screw Nut 1
53 Live Axle 1
55 Switch 1
40 Bush 4
42 Drive Pulley 1
44 Motor 1
46 Motor Seat (front) 1
48 Joint Pin 1
50 Drive Pulley 1
52 Plastic Linking Rod 1
54 Switch Plate 1
56 L Plate 2
57 Circular Sticker 2
58 Motor Starting 1
NOTE: Quantities of No. 27,28,29,30 are changeable according to slice thickness

7
PARTS VIEW
39 Joint Bar 2
41 Linking Bar Seat (right) 1
43 Belt 1
45 Capacitor 1
47 Motor Seat (right) 1
49 Drive Pulley 1
51 Screw Nut 1
53 Live Axle 1
55 Switch 1
40 Bush 4
42 Drive Pulley 1
44 Motor 1
46 Motor Seat (front) 1
48 Joint Pin 1
50 Drive Pulley 1
52 Plastic Linking Rod 1
54 Switch Plate 1
56 L Plate 2
57 Circular Sticker 2
58 Motor Starting 1

8
WARRANTY
1201 E. 27th Terrace • Pittsburg, KS 66762 • U.S.A.
Web site: www.doughxpress.com • Phone: [phone]
E-Mail: [email protected]
©2020 DXP
BEFORE warranty repair you MUST get
Prior Authorization: Call 1-800-835-0606
Warranty will be voided otherwise.
WARRANTY & SERVICE
DOUGHXPRESS will automatically register the equipment on the date it was shipped, please keep a copy of
their sales invoice showing the serial number and date it was sold/shipped to you with this warranty. We will
use the distributor’s invoice date as the beginning warranty date. STAPLE A COPY OF YOUR PROOF OF
PURCHASE TO THIS WARRANTY and keep in a safe place to provide verication of your warranty should a
problem occur.
Please ll in the following information and attach a copy of your receipt for your records.
Date Purchased: _______________________________ From:_______________________________
Model #: _____________________________________ Serial #: _____________________________
This warranty applies to equipment manufactured by the HIX Corporation (DOUGHXPRESS), Pittsburg, Kan-
sas, U.S.A. DOUGHXPRESS warrants to the original purchaser, the full line of DOUGHXPRESS products
against defects in workmanship and material, except for wear and tear for a period of one year parts and
labor limited warranty on most items, there are selected items which may carry a two year warranty (refer to
owners manual.) All dough press carts, compressors, and accessories are warranted for 90 days from the
date of purchase.
Repairs include parts and labor only, excluding is the following:
1. Overtime Labor Rates
2. Expedited Freight for Parts
3. DoughXpress assumes no responsibility for down time or loss of product. All defective parts must
be returned to DOUGHXPRESS for credit. Repairs must be pre-authorized by DOUGHXPRESS prior to work
commencing.
4. Travel time is not covered by DOUGHXPRESS, unless pre-authorized by DOUGHXPRESS.
In the event of a defect, DOUGHXPRESS, at its option, will repair, replace or substitute the defective item at
no cost during this period subject to the limitations of insurance and shipping costs stated below.
This warranty does not cover normal wear and tear, damages due to accident, misuse/abuse, alterations or
damage due to neglect, or lack of proper lubrication or maintenance. DOUGHXPRESS shall not be responsi-
ble for repairs or alterations made by any person without the prior written authorization by DOUGHXPRESS.
This warranty is the sole and exclusive warranty of DOUGHXPRESS and no person, agent, distributor, or
dealer of DOUGHXPRESS is authorized to change, amend or modify the terms set forth herein, in whole or
in part.
In the case of a problem with the equipment identied herein, DOUGHXPRESS should be contacted during
regular business hours to discuss the problem and verify an existing warranty. DOUGHXPRESS personnel
will assist the customer to correct any problems which can be corrected through operation or maintenance
instructions, simple mechanical adjustments, or replacement of parts. In the event the problem cannot be
corrected by phone, and upon the issuance of a return authorization by DOUGHXPRESS, the equipment
shall be returned to DOUGHXPRESS or an authorized service representative. All insurance, packaging
and shipment/freight costs are solely the responsibility of the customer, and DOUGHXPRESS shall not be
responsible for improper handling or damage in transit. DOUGHXPRESS customer service personnel may
be contacted for complete return authorization and reconditioning information.
This expressed warranty is given in lieu of any and all other warranties, whether expressed or implied, includ-
ing but not limited to those of merchantability and tness for a particular purpose, and constitutes the only
warranty made by DOUGHXPRESS.
In no event shall DOUGHXPRESS’ liability for breach of warranty extend beyond the obligation to repair
or replace the nonconforming goods. DOUGHXPRESS shall not be liable for any other damages, either
incidental or consequential, or the action as brought in contract, negligence or otherwise.
This warranty gives you specic legal rights and you may also have other rights which vary from state to
state.
