Configuration Manual
MagLink LX4
M2051-EU
Revision: 1

NOTE: Before you use this manual, make sure you have the most recent revision. Look at the
revision of this document to make sure it agrees with the most current revision found at
http://www.opwglobal.com/opw-fms/tech-support/manuals-how-to-videos. Download the
latest revision if necessary.
ProGauge is a part of Dover Fueling Solutions.
Contact
START ITALIANA S.r.l.
Via Pola 6
20813 Bovisio Masciago (MB)
Italy
Tel. [phone]
Fax [phone]
Copyright Information
© 2020 Dover Fueling Solutions. All rights reserved. DOVER, the DOVER D Design, DOVER FUELING
SOLUTIONS, and other trademarks referenced herein are trademarks of Delaware Capital Formation.
Inc./Dover Corporation, Dover Fueling Solutions UK Ltd. and their affiliated entities.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 2

Table of Contents
Section 1 Preface 6
Section 2 General Warnings 7
Section 3 Introduction 8
3.1 Safety Warnings 10
3.2 Information Panels 10
Direct Connection 12
Section 5 Login Procedure 15
Section 6 Admin Account 18
6.1 System Settings 19
6.1.1 Site Info 19
6.1.2 System 20
6.1.3 Protocols 22
6.1.4 Tank Group 23
6.1.5 Shifts 24
6.1.6 Fairbanks 25
6.1.7 SMTP 26
6.1.8 Site Mapping (for Reconciliation/Autocalibration mode only) 26
6.1.8.1 Map Dispensers and Nozzles to Tanks 27
6.1.9 IFSF 28
6.1.10 DIP-Switches 29
6.2 Notifications Menu 29
6.2.1 Contacts 29
6.2.2 Notifications 30
6.3 Tank Setup Menu 31
6.3.1 Settings 31
6.3.2 Thresholds 33
M2051-EU Rev.: 1 Dover Fueling Solutions Page 3

6.3.3 Density 34
6.3.4 Relays 35
6.3.5 Straptable 36
6.3.6 ACR mode 37
6.3.6.1 ACR Configuration Parameters 37
6.3.6.2 Calibration Parameters 37
6.3.7 ACR Results 38
6.3.8 Reconciliation 38
Section 7 Sensor Setup 40
7.1 On/Off 40
7.2 Discriminating sensors 41
7.3 Wireless 42
Section 8 Tank Status 44
Section 9 Tank Group Status 46
Section 10 Reports Menu 47
10.1 History 47
10.2 Tank Alarms 49
10.3 Sensor Alarms 49
10.4 Delivery 50
10.5 Leak Tests 51
10.6 Sales 52
10.7 Shifts 52
10.8 Reconciliation 53
Section 11 Maintenance 56
11.1 Timezone 56
11.2 Network Configuration 56
11.3 Utility 57
M2051-EU Rev.: 1 Dover Fueling Solutions Page 4

11.4 Console Settings 57
Section 12 Change Password 58
Section 13 Logout 59
Section 14 Guest Account 60
Section 15 Technical Support 61
M2051-EU Rev.: 1 Dover Fueling Solutions Page 5

Section 1 Preface
Start Italiana S.r.l. has made every effort possible to see that this document is complete, accurate and
updated. With every revision of the console, the related information is added to the document. Start Italiana
S.r.l. reserves the right to make unannounced improvements and/or changes in the product and/or
associated programs. Start Italiana S.r.l. is not liable for damages of any kind, including those resulting in the
document, including typographical errors.
Making copies, citing quotes or other reproductions of all or part of this document is permitted only after
written consent of Start Italiana S.r.l.
Patents protect trademark or name.
Copyright 2019© Start Italiana S.r.l. – All rights reserved
M2051-EU Rev.: 1 Dover Fueling Solutions Page 6

Section 2 General Warnings
Carefully read the instructions in this manual before you do the installation procedures.
Only approved persons are permitted to install this equipment and configure the console.
The manufacturer is not responsible for operations that are not included in this manual.
The manufacturer is not liable in regards to competent bodies for changes to the equipment and software that
are not approved.
In case of failure or defect, refer directly to an authorized service provider or manufacturer.
The manufacturer is not liable for injury and/or damage to persons and/or property and/or pets caused by the
failure to obey safety instructions.
All approved personnel must know all safety requirements in this manual, the configuration manual and the
user manual.
Refer directly to an approved service provider or manufacturer for questions about the operation of the
equipment.
IMPORTANT: You must read and obey all safety instructions in this manual before you use
this equipment.
WARNING: Incorrect use of this equipment that does not agree with the
instructions in this manual can cause a risk to safety.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 7

Section 3 Introduction
This manual was prepared in accordance with IEC 82079-1 standards. “Preparation of instructions for use -
Structuring, content and presentation - Part 1: General principles and detailed requirements and according to
the ATEX Directive 2014/34/EU concerning equipment and protective systems intended for use in potentially
explosive atmospheres."
This manual gives all necessary information about the configuration of the MagLink LX4 console.
IMPORTANT: This manual must be used together with the related product manuals:
M2050-EU MagLink LX4 Installation Manual
M2052-EU MagLink LX4 User Manual
You must install the console as shown in the M2050-EU MagLink LX4 Installation Manual,
configure the console as instructed in this manual and use the console in the field as shown in
the M2052-EU MagLink LX4 User Manual.
WARNING: This device must not be discarded with household waste. This
device is labeled in accordance with European Directive 2012/19/UE
concerning used electrical and electronic appliances (waste electrical and
electronic equipment – WEEE).
This guideline gives the methods for the return and recycling of used
electronic devices as applicable throughout the EU. To return your used
device, use the return and collection systems available to you.
The battery used in this device may present a risk of fire or chemical burn if
mistreated. Do not disassemble, heat above 50°C or incinerate.
The table that follows lists reference data of the manufacturer:
Data Description
Name START ITALIANA S.r.l.
Address
Via Pola 6
20813 Bovisio Masciago (MB)
Italy
Telephone [phone]
Fax [phone]
Website www.startitaliana.com
e-Mail [e-mail]
M2051-EU Rev.: 1 Dover Fueling Solutions Page 8

INFORMATION: The units of measurement contained in this manual refer to a specified
selection by the user. Refer to "System" on page20 for more information on how to set units
of measure.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 9

3.1 Safety Warnings
This manual contains many important Safety Alerts. There can be a risk of injury or damage to property if you
do not obey these alerts. The panels below show the types of safety warnings that can be seen and how
each is specified.
DANGER: Indicates an immediately hazardous condition that, if not prevented,
will result in death or serious injury.
WARNING: Indicates a possibly hazardous condition that, if not prevented,
could result in death or serious injury.
CAUTION: Indicates a possibly hazardous situation that, if not prevented,
could result in minor or moderate injury.
NOTICE: Indicates important information not related to hazards. A condition that, if not
prevented, can result in property damage.
SAFETY INSTRUCTIONS: Indicates instructions and procedures related to safety or
gives the location of safety equipment
3.2 Information Panels
NOTE: This panel gives more information about an instruction or procedure.
IMPORTANT: This panel contains special information that is important and must be read
and obeyed.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 10

REMINDER: This panel shows information that has been given before in the manual that is
important to show again.
TIP: A step or procedure that is recommended to make another step or procedure easier.
INFORMATION: This panel shows references to more information in other sources.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 11

Direct Connection
This section covers how to connect directly to the console using a standard RJ45 cable.
NOTE: If you have a connection problem with a standard RJ45, as an option, try an RJ45
Crossover cable.
Connect an RJ45 cable from your laptop Ethernet port to the Ethernet port on the bottom panel of the
console.
Navigate to C o n tr o l P a n e l > A l l C o n tr o l P a n e l It e ms > N e tw o r k a n d S h a ri n g C e n te r on your
laptop.
1. Click Change adapter settings in the left-side panel.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 12

2. Right-click Local Area Connections.
3. Select Properties from the menu.
4. Select to highlight Internet Protocol version 4 (IPv4) on the list in the pop-up.
5. Click Properties.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 13

6. Set the IP address. The unit comes shipped from the factory with the IP address 10.90.10.92. Your
laptop must be set one number higher or one number lower to connect to the console.
a. Click the button next to Use the following IP address.
b. Enter the IP address: 10.90.10.92.
c. Enter the Subnet mask: 255.255.255.0.
7. Click OK.
Your laptop is now set up to communicate directly with your MagLink LX4 console. Enter the IP address into
your browser to connect.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 14

Section 5 Login Procedure
The Home Screen shown below will come into view after you enter the IP Address into your browser.
Under Language selection, select the radio button adjacent to the language that will be used for the
configuration.
The table that follows shows the languages that can be selected:
Bosnian Czech Hungarian (Magyar) Romanian Slovenian
Bulgarian English Italian Russian Spanish
Chinese Simplified, Chinese Traditional French Polish Serbian (Cyrillic and Latin) Turkish
Croatian German Portuguese Slovakian Ukrainian
Arabic Hindi
Push the Enter button. The Login page will come into view.
1. Select a User type from the drop-down. There are three (3) types of Users:
nGuest: Can only see Tank Status, Sensor Status and Reports (measures, deliveries,
leakages, sudden loss). A Guest User cannot make changes to the configuration.
nAdmin: Has the same rights as Guest and can also make changes to the configuration.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 15

nSuperAdmin: This is for internal use only.
2. Enter the Password.
NOTE: The initial password for a Guest user is GUEST-LX4. The initial password for an
Admin User is ADMIN-LX4. These passwords are case-sensitive.
Only and Admin user can change passwords.
IMPORTANT: The administrator must change the password as soon as possible to prevent
access by personnel that are not approved. See "Change Password" on page58 for
information.
TIP: As you type your password only neutral "bullet" characters will show (e.g. • • • • • •). Select
the "eye" icon to show the password characters as you type.
3. Push the LOGIN button to log in to the console with the selected user type.
4. If you did not select the applicable language in the Home screen you can push the LANGUAGE button
to go back to the Home screen.
The table that follows shows the types of data that can be seen by the two User types:
M2051-EU Rev.: 1 Dover Fueling Solutions Page 16

Data Type Guest Admin
Inventory X X
Historical Data Table X X
Alarm status X X
Delivery/Leakage X X
Login X X
Logout X X
Association of alarm to relays (per tank) X
Managing internal and external sensors X
Automatic print features X
Managing strapping tables X
Configuring email address book X
Configuration of all dispensers X
TCP/IP address configuration, DNS X
Utility operations (Backup/restore, Clean historical data: Historical readings, alarms, reconciliation,
shift reports, Touch screen calibration of the console; Restarting the console, Restarting the
operating system of the console)
X
Reconciliation (if enabled) X
Shift report with scheduling X
IFSF module configuration X
Sensors current status X X
Autocalibration Analysis X
Print stock at predefined time of the day X
SMS config X
M2051-EU Rev.: 1 Dover Fueling Solutions Page 17

Section 6 Admin Account
1. When an Admin User is logged in, the screen will show a Main Menu on the right side of the display.
2. When a menu item is selected, its related tabs will come into view along the top of the display (the
selected menu item will be highlighted by a blue background).
3. When a Tab is selected in the Tabs Bar it is highlighted by a yellow line.
4. When an entry in a tab has a character limit it is shown as "number of characters entered / character
limit" to the right of its entry line.
5. Each tab has a SAVE button that is used to save that tab's configuration data after it is entered.
IMPORTANT: Make sure you save the configuration data that you entered before you
continue to another tab.
6. When all applicable tabs have been configured you can click the APPLY SETTINGS TO
CONSOLE button to save all of the configuration data to the console.
TIP: It is recommended to start from the Site Info tab and complete all applicable fields. Then,
continue to the next tab to the right and complete all applicable fields. Continue this procedure
until you have completed all tabs.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 18

6.1 System Settings
6.1.1 Site Info
Enter the applicable information into the fields and make the correct selections as shown in the table that
follows:
Field Description
Name The name of your site or station.*
Console serial Enter your console's serial number. This field is read-only. Only a superuser can change it.
Total Tanks This field shows the number of probes connected to the console. Enter 1-32*
Total external relays This field shows the number of external output relays connected to the console. Enter 1-32*
Total dispensers This read-only field shows the number of pumps configured for reconciliation/autocalibration.
Total sensors This field shows the number of environmental sensors configured in the console.
Optional cards Select the applicable radio button: None, Modem (for SMS functionality), IFSF
*Fields marked with an asterisk are mandatory.
Click Save. A confirmation message will come into view.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 19

Select CLOSE.
6.1.2 System
NOTE: All fields have selections (but not Alarm settings/Tolerance & Leak threshold) with
default values. Changes to level and/or volume unit and number of decimals can automatically
change with the selection.
M2051-EU Rev.: 1 Dover Fueling Solutions Page 20
