Dover PSG All-Flo A075-NAA-VVYV-A30 Owner's manual

IOM
INSTALLATION OPERATION
& MAINTENANCE
A075
METAL 3/4 INCH
AIR-OPERATED DOUBLE-DIAPHRAGM PUMP

ALF-12040-E-01 All-Flo2
TABLE OF
CONTENTS
SECTION 1 WARNINGS, DANGERS AND CAUTIONS 3
SECTION 2 MODEL DESIGNATION MATRIX & REPAIR KITS 4-5
SECTION 3 PRINCIPLES OF OPERATION 6
SECTION 4 DIMENSIONAL DRAWINGS 7-8
SECTION 5 PERFORMANCE CURVES
RUBBER DIAPHRAGMS..............................................................9
TPE DIAPHRAGMS........................................................................9
PTFE DIAPHRAGMS .....................................................................9
SECTION 6 INSTALLATION
INSTALLATION ................................................................................... 10-11
TROUBLESHOOTING ..................................................................12
OPERATION.....................................................................................13
MAINTENANCE ............................................................................13
SECTION 7 REPAIR AND ASSEMBLY
PUMP WET END REMOVAL............................................ 14-15
AIR VALVE REMOVAL .........................................................16-17
PILOT VALVE REMOVAL.................................................. 18-19
TORQUE SPECIFICATIONS.......................................................19
SECTION 8 EXPLODED VIEWS AND PARTS LISTS 20-25
SECTION 9 ELASTOMERS 26
SECTION 10 WARRANTY AND REGISTRATION 27

ALF-12040-E-01 All-Flo3
READ THESE WARNINGS AND SAFETY PRECAUTIONS PRIOR
TO INSTALLATION OR OPERATION. FAILURE TO COMPLY
WITH THESE INSTRUCTIONS COULD RESULT IN PERSONAL
INJURY AND OR PROPERTY DAMAGE. RETAIN THESE
INSTRUCTIONS FOR FUTURE REFERENCE.
This product can expose you to chemicals
including Nickel, Chromium, Cadmium, or Cobalt, which are
known to the State of California to cause cancer and/or birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
WARNING Pump, valves and all containers must be
properly grounded prior to handling flammable fluids and/or
whenever static electricity is a hazard.
WARNING Prior to servicing the pump, ensure that
the air and fluid lines are closed and disconnected. While
wearing personal protective equipment, flush, drain and
process liquid from the pump in a safe manner.
WARNING The TX marking refers to the maximum
surface temperature depending not on the equipment
itself, but mainly on operating conditions. In this case,
the maximum surface temperature depends upon the
temperature of the process fluids.
CAUTION The temperature of the process fluid
and air input must be no more than 36°F (20C) less of the
maximum temperature allowed for the appropriate non-
metallic material. See the list of temperatures below for each
material’s maximum recommended temperature:
Buna-N (Nitrile): 10°F to 180°F (-12°C to 82°C)
Geolast®: 10°F to 180°F (-12°C to 82°C)
EPDM: -40°F to 280°F (-40°C to 138°C)
Santoprene®: -40°F to 225°F (-40°C to 107°C)
FKM: -40°F to 350°F (-40°C to 177°C)
PTFE: 40°F to 220°F (4°C to 104°C)
Polyethylene: 32°F to 158°F (0°C to 70°C)
Polypropylene: 32°F to 180°F (0°C to 82°C)
PVDF: 0°F to 250°F (-18°C to 121°C)
Nylon: 0°F to 200°F (-18°C to 93°C)
Temperature limits are solely based upon mechanical stress
and certain chemicals will reduce the maximum operating
temperature. The allowable temperature range for the
process fluid is determined by the materials in contact with
the fluid being pumped. Consult a chemical resistance
guide for chemical compatibility and a more precise safe
temperature limit. Always use minimum air pressure when
pumping at elevated temperatures.
CAUTIONS — READ FIRST!
WARNING
CAUTION
= Hazards or unsafe practices
which could result in severe
personal injury, death or
substantial property damage
= Hazards or unsafe practices
which could result in minor
personal injury, product or
property damage.
CAUTION Do not lubricate air supply.
CAUTION Do not connect a compressed air source to
the exhaust port of the pump.
WARNING Use only with liquid process fluid.
WARNING Maintenance must not be performed when
a hazardous atmosphere is present.
CAUTION Do not exceed 120 psig (8.3 bar)
air-inlet pressure.
CAUTION Do not exceed 10 psig (0.7 bar)
or 23 ft-H2O suction pressure.
CAUTION Ensure all wetted components are
chemically compatible with the process fluid and the cleaning
fluid.
CAUTION Ensure pump is thoroughly cleaned and
flushed prior to installation into a process line.
CAUTION Always wear Personal Protective
Equipment (PPE) when operating pump.
CAUTION Close and disconnect all
compressed air and bleed all air from the pump
prior to service. Remove all process fluid in a safe manner
prior to service.
CAUTION Blow out all compressed air
lines in order to remove any debris, prior to
pump installation. Ensure that the muffler is properly
installed prior to pump operation.
CAUTION Ensure air exhaust is piped to
atmosphere prior to a submerged installation.
CAUTION Ensure all hardware is set to
correct torque values prior to operation.
SECTION 1
WARNING

ALF-12040-E-01 All-Flo4
MODEL DESIGNATION MATRIX & REPAIR KITS- ALUMINUM
SECTION 2
PRODUCT SERIES
FLUID CONNECTION TYPE
LIQUID SECTION
DIAPHRAGM
VALVE/BALL
VALVE SEAT
O-RINGS
SPECIAL (OTHER)
PORTING
AIR SECTION
SPECIAL (HARDWARE,
MUFFLER, LUG)
A 0 7 5 -1 2 3- 4 5 6 7 - 8 9 10
FLUID CONNECTION TYPE
N = NPT
B = BSPT
AIR SECTION
A = Aluminum
P = Polypropylene (Glass Filled)
LIQUID SECTION
A = Aluminum
DIAPHRAGMS
G = Geolast®
S = Santoprene®
T = PTFE with Santoprene® Backup
V = FKM
VALVE/BALL
G = Geolast®
S = Santoprene®
T = PTFE
V = FKM
3 = Stainless Steel
VALVE SEAT
P = Polypropylene
3 = Stainless Steel
A = Aluminum
Y = Nylon
O-RINGS
E = EPDM
N = Buna-N
T = PTFE
V = FKM
PORTING
A = Standard (Suction Center Front/ Discharge Center
Front)
B = Suction Center Front / Discharge Center Rear
F = Suction Center Rear / Discharge Center Front
G = Suction Center Rear / Discharge Center Rear
SPECIAL OPTION (HARDWARE, MUFFLER, LUG)
3 = Standard (Zinc Plated Steel Hardware, Plastic Muffler)
4 = Zinc Plated Steel Hardware, Metal Muffler
7= Stainless Steel Hardware, Plastic Muffler
8 = Stainless Steel Hardware, Metal Muffler
B = PTFE Coated Stainless Steel Hardware,
Plastic Muffler
C = PTFE Coated Stainless Steel Hardware,
Metal Muffler
D = Zinc Plated Steel Hardware, Plastic Muffler,
Grounding Lug Installed
E = Zinc Plated Steel Hardware, Metal Muffler,
Grounding Lug Installed
F = Stainless Steel Hardware, Plastic Muffler,
Grounding Lug Installed
G = Stainless Steel Hardware, Metal Muffler,
Grounding Lug Installed
H = PTFE Coated Stainless Steel Hardware,
Plastic Muffler, Grounding Lug Installed
I = PTFE Coated Stainless Steel Hardware,
Metal Muffler, Grounding Lug Installed
SPECIAL OPTION (OTHER)
0 = Standard (None)
1 = Cycle Counter Valve
2 = Solenoid Adaptor Valve 110/50 Volt AC,
120/60 Volt AC, DIN 43650B Connector
3 = Solenoid Adaptor Valve 110/50 Volt AC,
120/60 Volt AC Explosion Proof
4 = Solenoid Adaptor Valve 220/50 Volt AC,
240/60 Volt AC, 12 Volt DC, DIN 43650B Connector
5 = Solenoid Adaptor Valve 220/50 Volt AC,
240/60 Volt AC, 12 Volt DC Explosion Proof
6 = Solenoid Adaptor Valve 220/50 Volt AC,
240/60 Volt AC, 125 Volt DC, DIN 43650B Con-
nector
7 = Solenoid Adaptor Valve 220/50 Volt AC,
240/60 Volt AC, 125 Volt DC Explosion Proof
8 = Solenoid Adaptor Valve 24 Volt DC, DIN 43650B
Connector
9 = Solenoid Adaptor Valve 24 Volt DC,
Explosion Proof
A = Grease Free (No Lubrication Assembly)
SIZE
WET END REPAIR KIT
Wet end kits are available and
consist of diaphragms, (back-up
diaphragms if required), balls,
seats and seat O-rings.
See matrix below.
1
2
6
7
8
9
10
AIR SECTION
A = Aluminum
P = Polypropylene (Glass Filled)
AIR END REPAIR KIT
Air end repair kit contains pilot sleeve
assembly and main air valve.
MATERIAL
AAK-075-2
PRODUCT
SERIES
PUMP SIZE
AIR END
REPAIR KIT
3
4
5
* Solenoid Adaptor Valves only available on select pump models with polypropylene intermediate
Bold indicates recommended options
DIAPHRAGM
VALVE/BALL
VALVE SEAT
O-RINGS
AWE-075-4567-M
PRODUCT
SERIES
WET END
REPAIR KIT
PUMP SIZE
METALLIC WET END

ALF-12040-E-01 All-Flo5
MODEL DESIGNATION MATRIX & REPAIR KITS - STAINLESS STEEL
PRODUCT SERIES
FLUID CONNECTION TYPE
LIQUID SECTION
DIAPHRAGM
VALVE/BALL
VALVE SEAT
O-RINGS
SPECIAL (OTHER)
PORTING
AIR SECTION
SPECIAL (HARDWARE,
MUFFLER, LUG)
A 0 7 5 -1 2 3- 4 5 6 7 - 8 9 10
FLUID CONNECTION TYPE
N = NPT
B = BSPT
AIR SECTION
P = Polypropylene (Glass Filled)
A = Aluminum
LIQUID SECTION
3 = Stainless Steel
DIAPHRAGMS
S = Santoprene®
T = PTFE with Santoprene® Backup
V = FKM
G = Geolast®
VALVE/BALL
S = Santoprene®
T = PTFE
V = FKM
G = Geolast®
3 = Stainless Steel
VALVE SEAT
3 = Stainless Steel
P = Polypropylene
A = Aluminum
Y = Nylon
O-RINGS
E = EPDM
T = PTFE
N = Buna-N
V = FKM
PORTING
A = Standard (Suction Center Front/ Discharge Center
Front)
B = Suction Center Front / Discharge Center Rear
F = Suction Center Rear / Discharge Center Front
G = Suction Center Rear / Discharge Center Rear
SPECIAL OPTION (HARDWARE, MUFFLER, LUG)
7 = Standard (Stainless Steel Hardware, Plastic Muffler)
8 = Stainless Steel Hardware, Metal Muffler
B = PTFE Coated Stainless Steel Hardware,
Plastic Muffler
C = PTFE Coated Stainless Steel Hardware,
Metal Muffler
F = Stainless Steel Hardware, Plastic Muffler,
Grounding Lug Installed
G = Stainless Steel Hardware, Metal Muffler,
Grounding Lug Installed
H = PTFE Coated Stainless Steel Hardware,
Plastic Muffler, Grounding Lug Installed
I = PTFE Coated Stainless Steel Hardware,
Metal Muffler, Grounding Lug Installed
SPECIAL OPTION (OTHER)
0 = Standard (None)
1 = Cycle Counter Valve
2 = Solenoid Adaptor Valve 110/50 Volt AC,
120/60 Volt AC
3 = Solenoid Adaptor Valve 110/50 Volt AC,
120/60 Volt AC Explosion Proof
4 = Solenoid Adaptor Valve 220/50 Volt AC,
240/60 Volt AC, 12 Volt DC
5 = Solenoid Adaptor Valve 220/50 Volt AC,
240/60 Volt AC, 12 Volt DC Explosion Proof
6 = Solenoid Adaptor Valve 220/50 Volt AC,
240/60 Volt AC, 125 Volt DC
7 = Solenoid Adaptor Valve 220/50 Volt AC,
240/60 Volt AC, 125 Volt DC Explosion Proof
8 = Solenoid Adaptor Valve 24 Volt DC
9 = Solenoid Adaptor Valve 24 Volt DC,
Explosion Proof
A = Grease Free (No Lubrication Assembly)
SIZE
1
2
6
7
8
9
10
AIR SECTION
P = Polypropylene (Glass Filled)
A = Aluminum
MATERIAL
AAK-075-2
PRODUCT
SERIES
PUMP SIZE
AIR END
REPAIR KIT
3
4
5
AIR END REPAIR KIT
Air end repair kit contains pilot
sleeve assembly and main air valve.
* Solenoid Adaptor Valves only available on select pump models with polypropylene intermediate
PRODUCT
SERIES
WET END REPAIR KIT
Wet end kits are available and
consist of diaphragms, (back-up
diaphragms if required), balls,
seats and seat O-rings.
See matrix below.
Bold indicates recommended options
DIAPHRAGM
VALVE/BALL
VALVE SEAT
O-RINGS
AWE-075-4567-M
WET END
REPAIR KIT
PUMP SIZE
METALLIC WET END
