Dovre 425 Operating manual

Instructions for Use, Installation and Servicing
For use in GB, IE (Great Britain and Republic of Ireland)
THE OUTER CASING, FRONT AND GLASS PANEL BECOME EXTREMELY HOT DURING OPERATION AND
WILL RESULT IN SERIOUS INJURY AND BURNS IF TOUCHED. IT IS THEREFORE RECOMMENDED THAT A
FIREGUARD COMPLYING WITH BS 8423:2002 IS USED IN THE PRESENCE OF YOUNG CHILDREN, THE
ELDERLY OR INFIRM.
This product contains a heat resistant glass panel. This panel should be checked during Installation and at each servicing interval. If any
damage is observed on the front face of the glass panel (scratches, scores, cracks or other surface defects), the glass panel must be
replaced and the appliance must not be used until a replacement is installed. Under no circumstances should the appliance be used if any
damage is observed, the glass panel is removed or broken.
It is essential that ALL of the screws that retain the glass frame are replaced and tightened correctly. Under no circumstances should the
appliance be operated if any of these screws are loose or missing.
These Instructions must be left with the appliance for future reference and for consultation when servicing the appliance. Please make the
customer aware of the correct operation of the appliance before leaving these instructions with them.
The commissioning sheet found on Page 3 of this Instruction manual must be completed by the Installer prior to leaving the premises.
IMPORTANT
Dovre 425
Conventional Flue Log Effect Stove
With Upgradeable Control Valve
PR0986 Issue 4 (October 2014)

2
Model NATURAL GAS LPG
Matt Black DV-425CFNG DV-425CFLPG
Ivory Enamel DV-425CFNGIV DV-425CFLPGIV
Ivory White Enamel DV541-076 DV541-479
Majolica Brown DV-425CFNGMJ DV-425CFLPGMJB
Black Enamel DV-425CFNGBK DV-425CFLPGBK
Appliance Commissioning Checklist ......................3
User Instructions.......................................................4
Installation Instructions............................................9
Technical Specifications ............................................................. 9
Site Requirements.................................................................... 10
Installation ................................................................................12
Commissioning......................................................................... 16
Servicing Requirements .........................................17
Fault Finding............................................................................. 17
How to replace parts ................................................................ 19
Basic spare parts list ................................................................ 24
Service Records ......................................................................25
Covering the following models:
Contents

3
IMPORTANT NOTICE
Explain the operation of the appliance to the end user, hand the completed instructions to them for safe keeping,
as the information will be required when making any guaranteed claims.
To assist us in any guarantee claim please complete the following information:-
Appliance Commissioning Checklist
FLUE CHECK PASS FAIL
1. Flue Is correct for appliance
2. Flue ow Test N/A
3. Spillage Test N/A
GAS CHECK
1. Gas soundness & let by test
2. Standing gas pressure mb
3. Appliance working pressure (on High Setting)
NB All other gas appliances must be operating on full
mb
4. Gas rate m3/h
5. Does Ventilation meet appliance requirements N/A
SAFETY CHECK
1. Glass checked to ensure no damage, scratches, scores or cracks.
2. Glass frame secured correctly and all screws replaced
Retailer ...............................................
.......................................................
.......................................................
Contact No............................................
Date of Purchase .....................................
Model No. ............................................
Serial No..............................................
Gas Type .............................................
Installation Company................................
......................................................
......................................................
Engineer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contact No...........................................
Gas Safe Reg No. ...................................
Date of Installation ..................................
RETAILER AND INSTALLER INFORMATION

4
User Instructions
Welcome
Congratulations on purchasing your Dovre 425 stove, if
installed correctly Dovre hope it will give you many years of
warmth and pleasure for which it was designed.
The purpose of this manual is to familiarise you with your
appliance, and give guidelines for its installation, operation
and maintenance. If, after reading, you need further
information, please do not hesitate to contact your Dovre
retailer.
WARNING
In the event of a gas escape or if you can smell
gas, please take the following steps:
 • Immediatelyturnoffthegassupplyatthe 
meter/emergency control valve
 • Extinguishallsourcesofignition
 • Donotsmoke
 • Donotoperateanyelectricallightorpower
switches (On or Off)
 • Ventilatethebuilding(s)byopeningdoors 
and windows
 • Ensureaccesstothepremisescanbemade
Please report the incident immediately to the
National Gas Emergency Service Call Centre
on 0800 111 999 (England, Scotland and Wales)
, 0800 002 001 (N. Ireland) or in the case of
LPG, the gas supplier whose details can be
found on the bulk storage vessel or cylinder.
The gas supply must not be used until
remedial action has been taken to correct the
defect and the installation has been
recommissioned by a competent person.
1. General
1.1 Installation and servicing must only be carried out by a
competent person whose name appears on the Gas Safe
register. To ensure the engineer is registered with Gas Safe
they should possess an ID Card carrying the following logo:
1.2 In all correspondence, please quote the appliance type and
serial number, which can be found on the data badge or on
the Commissionoing Checklist Page 3.
1.3 Do not place curtains above the appliance:
You must have 300mm (1’) clearance between the appliance
and any curtains at either side.
1.4 No furnishings or other objects should be placed within
1 metre of the front of the appliance.
1.5 If any cracks appear in the glass panel do not use the
appliance until the panel has been replaced.
1.6 In the unlikely event the appliance is receiving interference
from other electronic devices, the handset/Control box can
be reprogrammed. Please consult your retailer if you think
this may be the case.
1.7 If, for any reason, the flue has to be removed from the
appliance, the seals must be replaced in the inner spigot.
1.8 This product is guaranteed for 2 years from the date of
installation, as set out in the terms and conditions of sale
between Dovre and your local Dovre retailer. Please consult
with your local Dovre retailer if you have any questions. In
all correspondence always quote the Model Number and
Serial Number.
2. Operating the Appliance
2.1 The control valve is at the foot on the right-hand side of the
appliance. It has two controls, Diagram 1:
1. The right-hand knob controls the pilot ignition
2. The left-hand knob controls the main burner
2.2 Refer to separate instructions if your appliance is upgraded
to include battery remote control. The instructions below
apply whether or not you have the remote upgrade.
Lighting the Pilot
2.3 To start the left-hand and right-hand control knobs must both
point to off ( ):
1
2.4 Press in the right-hand control knob and rotate anti-
clockwise until a click is heard. Continue to press in. The
knob points to the pilot ( ).
The pilot is lit
2.5 Keep the knob depressed for 10 seconds before releasing.
The pilot remains lit.
Repeat the above steps if the pilot does not stay lit
NOTE: If the pilot goes out, the Interlock system
prevents you lighting again for a short period

5
User Instructions
2.6 If, after repeating the above steps the pilot does not light,
contact your Retailer or Installer.
2.7 Turn the right-hand knob to the left to main burner setting
( )
Adjusting the Flame height
2.8 You can now adjust the flame height and temperature using
the left-hand control knob.
2.9 Turn the left-hand knob anti-clockwise to increase the
flame height
2.10 Turn clockwise to decrease the height
IMPORTANT: YELLOW FLAMES TYPICALLY
APPEAR WHEN THE APPLIANCE HAS REACHED
NORMAL OPERATING TEMPERATURE. THIS CAN
TAKE UP TO 30 MINUTES.
WARNING: IF THE APPLIANCE FAILS TO LIGHT OR
BECOMES EXTINGUISHED IN USE, WAIT 3
MINUTES BEFORE ATTEMPTING TO RELIGHT.
3. Turning OFF the Appliance
3.1 To turn the main burner off turn the left-hand knob until it
points to off ( ). Just the pilot remains lit.
3.2 Press in and turn the right-hand knob until it points to off
(). The pilot goes out.
4. Upgrading the Appliance
4.1 The appliance is fitted with a control valve that can easily be
upgraded to battery powered remote control.
There are two versions of this control which can be obtained
through your local Dovre stockist.
There is no requirement for this upgrade to be carried out by
an approved Gas engineer. However Dovre recommend that
this task is undertaken by a suitably competent person.
4.2 This upgrade can be fitted before or after installation but if
side clearances are limited then it will be easier to upgrade
the appliance before installation. Full instructions are
included with the kit.
Standard Remote Control
(PART NUMBER 8455)
4.3 This remote control can control the gas appliance after
the pilot has been lit. It can turn the main burner on and
regulate it from low through to high and back again.
It can turn the main burner off leaving the pilot burning.
Thermostatic and Timer Remote Control
(PART NUMBER 8456)
4.4 This remote control can control the gas appliance after the
pilot has been lit.
MANUAL MODE
Can be used to turn the main burner on and manually
regulate it from low through to high and back again. It can
also be used to turn the main burner off leaving the pilot
burning.
AUTO MODE
Will automatically regulate the room to a pre-set temperature.
TIMER MODE
Will turn the appliance on and off according to a pre-set
programme and automatically regulate the room temperature
during the two on periods.
5. Cleaning the Appliance
 WARNING:NEVERCLEANTHEAPPLIANCE
WHILEIT’SHOT.THEAPPLIANCE STAYS HOT
FOR A LONG TIME AFTER SHUTDOWN.
IMPORTANT: THE OUTER PANELLING OF THE
DOVRE425ISMADEFROMCASTIRON.USE
CAUTIONWHENINSTALLING,REMOVINGAND
STORINGASTHECOMPONENTSAREHEAVY
AND SHOULD BE HANDLED CAREFULLY.
5.1 Make sure the appliance and surrounds are cool before
cleaning.
REMOVINGTHEDOOR
5.2 For rear flue exit lift the top of the appliance off and put to
one side.
5.3 For top flue exit lift and support the top to give clearance,
see Diagram 2.
2

6
5.4 Lift the front upwards until it is clear of the slots and pull
away from the appliance, see Diagram 3.
3
5.5 Remove the glass frame by undoing the fixing screws and
lifting clear, see Diagram 4. Take care to support the glass
window panel when removing the screws.
5.6 Place carefully to one side.
4
5.7 Lift out the log retainer bar.
5.8 Carefully remove the ceramic fuel bed components and set
aside. Protect the floor coverings and follow the advice
given in Section 6.
5.9 The logs do not require cleaning. Do not use a vacuum
cleaner or brush to clean the coals, any large pieces of
debris can be removed by hand.
5.10 Ensure any debris is removed from the burner ports.
5.11 Replace the ceramics, see Section 6.
5.12 Use a damp cloth to clean the outer casing of the appliance.
6. Arrangement of Fuel Bed
Advice on handling and disposal
of fire ceramics
The fuel effect of the log version of this
appliance is made from Refractory Ceramic
Fibre (RCF), a material which is commonly
used for this application.
Protective clothing is not required when
handling these articles, but we recommend you
follow normal hygiene rules of not smoking,
eating or drinking in the work area and always
wash your hands before eating or drinking.
To ensure that the release of RCF fibres are
kept to a minimum, during installation and
servicing a HEPA filtered vacuum is
recommended to remove any dust
accumulated in and around the appliance
before and after working on it. When servicing
the appliance it is recommended that the
replaced items are not broken up, but are
sealed within heavy duty polythene bags and
labelled as RCF waste.
RCF waste is classed as stable, non-reactive
hazardous waste and may be disposed of at a
licensed landfill site.
Excessive exposure to these materials may
cause temporary irritation to eyes, skin and
respiratory tract; wash hands thoroughly after
handling the material.
7. Log Layout
LOGS MUST BE POSITIONED ACCORDING TO THE
FOLLOWINGINSTRUCTIONSTOGIVETHECORRECT
FLAME EFFECT
The fuel bed consists of 5 logs and 2 ash panels. The logs
have letters A,B,C,D and E moulded into them for
identification.
7.1 Take the rear log A and place it up against the rear of the fire
sitting on the two flat ledges of the burner. The two legs of
the log should sit between the rear burner ports, see
Diagram 5.
5
User Instructions

7
Ensure there is an equal gap between each side of the log
and the side of the firebox.
7.2 Place log B on the left hand side of the burner with the
location bar on the underside of the log fully located in the
long slot of the burner. Make sure the log is as far to the left
as possible, see Diagram 6.
6
7.3 Place log C on the right hand side of the burner with the
location bar on the underside of the log fully located in the
long slot in the burner. Make sure the log is as far right as
possible, see Diagram 7.
7
7.4 Place log D across from the rear log A to log B on the left-
hand side. There are cut-outs in both logs for location, see
Diagram 8.
8
7.5 There are two ash panels which lay across the front of the
burner skin. Place the panel with the flat edge facing the left
side of the firebox. There are location holes on this panel
which fit over the screw holes of the burner skin, see
Diagram 9.
9
7.6 Place the second ash panel to the right of the first, with the
pointed end of the panel fitting into the V shape. This panel
should locate on the screw holes of the burner skin. Ensure
that both panels are horizontal to the burner ports, see
Diagram 10
10
7.7 Place log E across from the rear of log A to log C on the right
hand side. Again, there are cut-outs for location. The front of
the log should sit on the front ash panels and should fit tight
to log C, see Diagram 11.
11
7.8 Replace the log retainer.
User Instructions

8
8. Completion of Assembly
8.1 Ensure the rope seal fitted to the rear of the glass frame is
intact.
8.2 Use a ceramic glass product generally sold for cleaning
ceramic hobs to clean the glass front.
8.3 Refit glass frame and tighten screws evenly,
see Diagram 12.
NEVEROPERATETHEAPPLIANCE WHEN THE GLASS
FRAMEISREMOVED,ORTHEGLASSISBROKEN.
12
8.4 With the top still supported or removed refit front by locating
in grooves and lowering into place, see Diagram 13.
13
8.5 Now replace top, see Diagram 14.
14
8.6 Replace ALL of the securing screws ensuring that a screw is
present in all fixing slots.
UNDER NO CIRCUMSTANCES SHOULD THE
APPLIANCE BE USED IF ANY OF THE GLASS
FRAME RETAINING SCREWS ARE LOOSE OR
MISSING.
9. Flue Sure System
9.1 The appliance is fitted with a Flue Sure System, which will
act to cut off the gas supply to the burners in the event of
incorrect operation of the flue. If the system acts to cut off
the gas supply, this indicates that there is insufficient flue
pull. If this occurs a minimum of 10 minutes should be
allowed before trying to relight.
Continued operation of this safety device means there may
be a serious problem with the flue system. A qualified gas
engineer should inspect this.
DO NOT USE THE APPLIANCE UNTIL AN ENGINEER
SAYS IT IS SAFE TO DO SO.
10. Flame Failure Device
10.1 This is a safety feature incorporated on this appliance which
automatically switches off the gas supply if the pilot goes out
and fails to heat the thermocouple.
IF THIS OCCURS DO NOT ATTEMPT TO RELIGHT THE
APPLIANCE FOR 3 MINUTES.
11. Running In
11.1 During initial use of a new Dovre appliance a strong odour
will be encountered as various surface coatings become hot
for the first time. Although these odours are harmless it is
recommended that the appliance is operated on maximum
for 4 to 8 hours in order to fully burn off these coatings. After
this period the odours should then disappear.
If the odours persists, please contact your installer for advice.
11.2 During the first few hours of burning there may be
discolouration of the flames. This will also disappear after a
short period of use.
12. Servicing
12.1 The appliance must be serviced every 12 months by a
qualified Gas Engineer. In all correspondence always quote
the Model number and the Serial number which may be
found on the Commissioning Checklist (Page 3).
13. Ventilation
13.1 Any purpose provided ventilation should be checked
periodically to ensure that it is free from obstruction.
14. Installation Details
14.1 Your installer should have completed the commissioning
sheet at the front of this book. This records the essential
installation details of the appliance. In all correspondence
always quote the Model number and Serial number.
15. Hot Surfaces
15.1 Parts of this appliance become hot during normal use.
Regard all parts of the appliance as a ‘working surface’.
15.2 Provide a suitable fire guard to protect young children
and the infirm.
User Instructions

9
Model Gas
CAT.
Gas Type Working
Pressure
NOX
Class
Aeration Injector Gas Rate
m3/h
Input kW (Gross) Country
High Low
DV-425CFNG I2H Natural
(G20)
20mbar 3 1 x 14.5mm 375 0.623 6.6 3.6 GB, IE
DV-425CFLPG I3P Propane
(G31)
37mbar 3 2 x 11.5mm 165 0.232 6.4 3;6 GB, IE
Efficiency Class II - 78%
Flue Outlet Size 127mm (5”) Ø
Gas Inlet Connection Size 8mm Ø
Minimum Flue Specification T260 / N2 / 0 / D / 1
Maximum Flue Temperature 180°C
Covering the following models:
Installation Instructions
Technical Specification
Packing Checklist
Qty Description
1 Stove
1 Flue Blanking plate
1 Log set (5 logs)*
2 Ash Panels* (2 sections)*
1 Fixing Kit Containing
1 Instruction Manual
*Packed in appliance
1
422
690
498
133
32 369
608
Model NATURAL GAS LPG
Matt Black DV-425CFNG DV-425CFLPG
Ivory Enamel DV-425CFNGIV DV-425CFLPGIV
Ivory White Enamel DV541-076 DV541-479
Majolica Brown DV-425CFNGMJ DV-425CFLPGMJB
Black Enamel DV-425CFNGBK DV-425CFLPGBK

10
Site Requirements
Installation Instructions
1. Flue & Chimney Requirements
1.1 The chimney or flue system must comply with the rules in
force, and must be a minimum of 127mm in diameter. (5").
1.2 The minimum flue height for the appliance must be 3
metres (10ft). Any horizontal flue run from the rear outlet
must not exceed 100mm from the back of the appliance.
1.3 The chimney or flue must be free from any obstruction. Any
damper plates must be removed or secured in the fully
open position, and no restrictor plates fitted.
1.4 The chimney must be swept prior to the installation, but it
need not be swept if it can be seen the chimney is clean
and unobstructed throughout its entire length.
1.5 A5" (127mm) liner must be used if fitting the appliance into
an existing brick built chimney.
Larger lined flues can work, but in some instances could
cause cold start flue problems resulting in nuisance
shutdown. Lined flues above 7" (175mm) are not
recommended.
1.6 Due to recent changes to European chimney standards,
new flues and chimneys are described by their temperature,
pressure and resistance to corrosion, condensation and fire.
To assist in identifying the correct flue system, the minimum
flue specification is shown in the Technical Specification.
Existing chimneys are not covered by this system.
2. Flue Options
 ArangeofVitreousEnamelGlossBlackfluepipeis
availabletocomplimenttheDovre425.Pleasecontact
your Dovre retailer for further information.
3. Gas Supply
THIS APPLIANCE IS INTENDED FOR USE ON A GAS
INSTALLATIONWITHAGOVERNEDMETER.
3.1 Before installation, ensure that the local distribution
conditions (identification of the type of gas and pressure)
and the adjustment of the appliance are compatible.
3.2 Ensure the gas supply delivers the required amount of gas
and is in accordance with the rules in force.
3.3 You can use soft copper tubing on the installation and soft
soldered joints outside the appliance and below the fire.
3.4 A means of isolating the gas supply to the appliance must
be provided independent of any appliance control.
3.5 All supply gas pipes must be purged of any debris that may
have entered prior to connection to the appliance.
3.6 The gas supply must be installed in a way that does not
restrict the removal of the appliance for servicing and
inspection.
4. Ventilation
IMPORTANT: Ensure any national ventilation
requirements are taken into account during installation
of the appliance.
UK ONLY:
The Dovre 425 has a nominal input not exceeding 7.0kW
and does not normally require any additional permanent
ventilation.
FOR THE REPUBLIC OF IRELAND REFER TO THE
RULESINFORCEFORVENTILATIONREQUIREMENTS.
5. Appliance Location
5.1 Building Regulations state this appliance must stand on a
non-combustible hearth that is at least 12mm thick and
projects 50mm minimum from the base of the appliance in
all directions, however Dovre recommend the hearth
extends to the following dimensions, see Diagram 1.
A = 908mm
B = 469mm
C = 12mm
1
MINIMUM CLEARANCE
5.2 The appliance is not suitable for installation against a
combustible wall. All combustible materials must be
removed from behind the appliance.
5.3 Ensure that all minimum clearances to combustible
materials are complied with, see Diagrams 2 & 2A.
The specified clearances provide the minimum distance to
combustible materials. If the appliance is intended to be
installed into a non-combustible opening the clearance to
the sides and above the appliance can be reduced.
However, it is recommended that the specified clearances
are maintained irrespective of the materials used in the
construction of the opening to allow adequate air flow and
access to controls. The clearance at the rear of the
appliancemustalwaysbeaminimumof50mm.

11
Site Requirements
Installation Instructions
150
225
150
2a
50mm
150mm
2b
5.4 In a non-combustible recess be careful to allow enough
clearance at the sides and rear of the appliance to
perform spillage tests and reach the controls.

12
Installation Instructions
1. Safety Precautions
1.1 For your own and other’s safety, you must install this
appliance according to local and national codes of practice.
Failure to install the appliance correctly could lead to
prosecution. Read these instructions before installing
and using this appliance.
1.2 These instructions must be left intact with the user.
1.3 Do not attempt to burn rubbish on this appliance.
1.4 Keep all plastic bags away from young children.
1.5 Do not place any object on or near to the appliance and
allow adequate clearance above the appliance.
IF THE APPLIANCE IS EXTINGUISHED OR GOES OUT
IN USE, WAIT 3 MINUTES BEFORE ATTEMPTING TO
RELIGHT THE APPLIANCE.
1.6 The appliance is fitted with a Flue Sure System, which will
act to cut off the gas supply to the burners in the event of
incorrect operation of the flue. If the system acts to cut off
the gas supply, this indicates that there is insufficient flue
pull. If this occurs a minimum of 10 minutes should be
allowed before trying to relight. Continued operation of this
safety device means there may be a serious problem with
the flue system. A qualified gas engineer should inspect
this.
1.7 Do not alter or tamper with the Flue Sure System. Use only
genuine replacement parts when servicing the system -
refer to the Servicing Section, Replacing Parts.
DO NOT USE THE APPLIANCE UNTIL AN ENGINEER
SAYS IT IS SAFE TO DO SO.
IMPORTANT: REFER TO DATA BADGE AND
TECHNICAL SPECIFICATION AT THE FRONT OF
THE MANUAL TO ENSURE THE APPLIANCE IS
CORRECTLY ADJUSTED FOR THE GAS TYPE AND
CATEGORY APPLICABLE IN THE COUNTRY OF
USE.
FOR DETAILS OF CHANGING BETWEEN GAS
TYPESREFERTOSERVICING,SECTION13,
REPLACING PARTS.
Unpacking
1.8 Remove the appliance from its packaging, and check that it
is complete and undamaged.
Put the loose ceramic parts to one side so that they are not
damaged during installation.
2. Upgrading the Appliance
2.1 The appliance is fitted with a control valve that can easily be
upgraded to battery powered remote control.
There are two versions of this control which can be obtained
through your local Dovre stockist.
There is no requirement for this upgrade to be carried out by
an approved Gas engineer. However Dovre recommend that
this task is undertaken by a suitably competent person.
2.2 This upgrade can be fitted before or after installation but if
side clearances are limited then it will be easier to upgrade
the appliance before installation. Full instructions are
included with the kit.
Standard Remote Control
(PART NUMBER 8455)
2.3 This remote control can control the gas appliance after
the pilot has been lit. It can turn the main burner on and
regulate it from low through to high and back again.
It can turn the main burner off leaving the pilot burning.
Thermostatic and Timer Remote Control
(PART NUMBER 8456)
2.4 This remote control can control the gas appliance after the
pilot has been lit.
MANUAL MODE
Can be used to turn the main burner on and manually
regulate it from low through to high and back again. It can
also be used to turn the main burner off leaving the pilot
burning.
AUTO MODE
Will automatically regulate the room to a pre-set temperature.
TIMER MODE
Will turn the appliance on and off according to a pre-set
programme and automatically regulate the room temperature
during the two on periods.
3. Installation of the Appliance
3.1 Decide whether to use top or rear flue exit.
The appliance is factory built for rear flue exit but it can be
changed to top exit by swapping the flue spigot and blanking
plate located on the appliance.
3.2 Position the appliance ensuring all appropriate clearances
are observed.
3.3 Having run the gas supply to the appliance PURGE THE
SUPPLY PIPE.
This is essential to expel any debris that can block the gas
controls.

13
Installation Instructions
3.4 Connect the gas supply to the 8mm compression elbow at
the right-hand rear corner of the appliance
There is a cutout in the right-hand rear leg to enable a
straight connection to the rear of the appliance,
see Diagram 1.
1
3.5 The flue system can now be connected to the appliance.
3.6 Ensure all joints are sealed with a fire resistant cement and
use a self-tapping screw at the flue spigot joint.
4. Gas Soundness Pressure Check
4.1 Connect a suitable pressure gauge to the test point located
on the inlet fitting and turn the gas supply on. Light the
appliance and check all gas joints for possible leaks. Turn
the appliance to maximum and check that the supply
pressure is as stated on the databadge. Turn the gas off
and replace the test point screw, turn the gas on and check
the test point for leaks.
5. Removing the Door
5.2 For rear flue exit lift the top of the appliance off and put to
one side.
5.3 For top flue exit lift and support the top to give clearance,
see Diagram 2.
2
5.4 Lift the front upwards until it is clear of the slots and pull
away from the appliance, see Diagram 3.
3
5.5 Remove the glass frame by undoing the fixing screws and
lifting clear, see Diagram 4. Take care to support the glass
window panel when removing the screws.
5.6 Place carefully to one side.
4
5.7 Lift out the log retainer bar.
5.8 Carefully remove the ceramic fuel bed components and set
aside. Protect the floor coverings and follow the advice
given in Section 6.
5.9 The logs do not require cleaning. Do not use a vacuum
cleaner or brush to clean the coals, any large pieces of
debris can be removed by hand.
5.10 Ensure any debris is removed from the burner ports.
5.11 Replace the ceramics, see Section 6.
5.12 Use a damp cloth to clean the outer casing of the appliance.

14
6. Arrangement of Fuel Bed
Advice on handling and disposal
of fire ceramics
The fuel effect of the log version of this
appliance is made from Refractory Ceramic
Fibre (RCF), a material which is commonly
used for this application.
Protective clothing is not required when
handling these articles, but we recommend you
follow normal hygiene rules of not smoking,
eating or drinking in the work area and always
wash your hands before eating or drinking.
To ensure that the release of RCF fibres are
kept to a minimum, during installation and
servicing a HEPA filtered vacuum is
recommended to remove any dust
accumulated in and around the appliance
before and after working on it. When servicing
the appliance it is recommended that the
replaced items are not broken up, but are
sealed within heavy duty polythene bags and
labelled as RCF waste.
RCF waste is classed as stable, non-reactive
hazardous waste and may be disposed of at a
licensed landfill site.
Excessive exposure to these materials may
cause temporary irritation to eyes, skin and
respiratory tract; wash hands thoroughly after
handling the material.
7. Log Layout
LOGS MUST BE POSITIONED ACCORDING TO THE
FOLLOWINGINSTRUCTIONSTOGIVETHECORRECT
FLAME EFFECT
The fuel bed consists of 5 logs and 2 ash panels. The logs
have letters A,B,C,D and E moulded into them for
identification.
7.1 Take the rear log A and place it up against the rear of the fire
sitting on the two flat ledges of the burner. The two legs of
the log should sit between the rear burner ports, see
Diagram 5.
5
Ensure there is an equal gap between each side of the log
and the side of the firebox.
7.2 Place log B on the left hand side of the burner with the
location bar on the underside of the log fully located in the
long slot of the burner. Make sure the log is as far to the left
as possible, see Diagram 6.
6
7.3 Place log C on the right hand side of the burner with the
location bar on the underside of the log fully located in the
long slot in the burner. Make sure the log is as far right as
possible, see Diagram 7.
7
7.4 Place log D across from the rear log A to log B on the left-
hand side. There are cut-outs in both logs for location, see
Diagram 8.
8
Installation Instructions

15
7.5 There are two ash panels which lay across the front of the
burner skin. Place the panel with the flat edge facing the left
side of the firebox. There are location holes on this panel
which fit over the screw holes of the burner skin, see
Diagram 9.
9
7.6 Place the second ash panel to the right of the first, with the
pointed end of the panel fitting into the V shape. This panel
should locate on the screw holes of the burner skin. Ensure
that both panels are horizontal to the burner ports, see
Diagram 10
10
7.7 Place log E across from the rear of log A to log C on the right
hand side. Again, there are cut-outs for location. The front of
the log should sit on the front ash panels and should fit tight
to log C, see Diagram 11.
11
7.8 Replace the log retainer.
8. Completion of Assembly
8.1 Ensure the rope seal fitted to the rear of the glass frame is
intact.
8.2 Use a ceramic glass product generally sold for cleaning
ceramic hobs to clean the glass front.
8.3 Refit glass frame and tighten screws evenly,
see Diagram 12.
NEVEROPERATETHEAPPLIANCE WHEN THE GLASS
FRAMEISREMOVED,ORTHEGLASSISBROKEN.
12
8.4 Replace ALL of the securing screws ensuring that a screw is
present in all fixing slots.
UNDER NO CIRCUMSTANCES SHOULD THE
APPLIANCE BE USED IF ANY OF THE GLASS
FRAME RETAINING SCREWS ARE LOOSE OR
MISSING.
8.4 With the top still supported or removed refit front by locating
in grooves and lowering into place, see Diagram 13.
13
8.5 Now replace top, see Diagram 14.
14
Installation Instructions

16
Installation Instructions/Commissioning
9. Operating the Appliance
9.1 The control valve is at the foot on the right-hand side of the
appliance. It has two controls, see Diagram 24:
1. The right-hand knob controls the pilot ignition
2. The left-hand knob controls the main burner
9.2 Refer to separate instructions if your appliance is upgraded
to include battery remote control. The instructions below
apply whether or not you have the remote upgrade.
Lighting the Pilot
9.3 To start the left-hand and right-hand control knobs must both
point to off ( ):
15
9.4 Press in the right-hand control knob and rotate anti-
clockwise until a click is heard. Continue to press in. The
knob points to the pilot ( ).
The pilot is lit
9.5 Keep the knob depressed for 10 seconds before releasing.
The pilot remains lit.
Repeat the above steps if the pilot does not stay lit
NOTE: If the pilot goes out, the Interlock system
prevents you lighting again for a short period
9.6 If, after repeating the above steps the pilot does not light,
contact your Retailer or Installer.
9.7 Turn the right-hand knob to the left to main burner setting
( )
Adjusting the Flame height
9.8 You can now adjust the flame height and temperature using
the left-hand control knob.
9.9 Turn the left-hand knob anti-clockwise to increase the
flame height
9.10 Turn clockwise to decrease the height
IMPORTANT: YELLOW FLAMES TYPICALLY
APPEAR WHEN THE APPLIANCE HAS REACHED
NORMAL OPERATING TEMPERATURE. THIS CAN
TAKE UP TO 30 MINUTES.
WARNING: IF THE APPLIANCE FAILS TO LIGHT OR
BECOMES EXTINGUISHED IN USE, WAIT 3
MINUTES BEFORE ATTEMPTING TO RELIGHT.
1. Commissioning
1.1 Close all doors and windows in the room.
1.2 Ignite the appliance and operate on maximum for 10
minutes.
1.3 Position a lighted smoke match just inside the draught
diverter opening at the rear of the appliance.
1.4 Check all smoke is drawn into the opening, see Diagram 1.
1Rear of Appliance
Draft diverter lip
Smoke match
1.5 If there is any doubt, run the appliance for a further 10
minutes, and repeat the test.
1.6 If there are any extractor fans in adjacent rooms, the test
must be repeated with the fans running on maximum and
interconnecting doors open.
IF SPILLAGE PERSISTS, DISCONNECT THE APPLIANCE AND
SEEKEXPERTADVICE.
1.7 Complete the Commissioning Checklist at the front of this
manual covering:
— Flue checks
— Gas checks
— Log layout - flame picture
1.8 Upon completion of the commissioning and testing of the
installation and correct operation of the appliance, the
installer must instruct the user how to operate the appliance.
1.9 Guide the user through the User Instructions paying
particular attention to:
a) Regular servicing (Section 12 of the User Instructions).
b) Ventilation (Section 13 of the User Instructions) - point out
the ventilation positions where applicable.
c) Hot surfaces (Section 15 of the User Instructions).

17
1. Servicing Requirements
IMPORTANT – The glass panel on this appliance should be
checked for any signs of damage on the front face of the
glass panel (scratches, scores, cracks or other surface
defects). If damage is observed, the glass panel must be
replaced and the appliance must not be used until a
replacement is installed. Under no circumstances should the
appliance be used if any damage is observed. Please isolate
the appliance until a replacement glass panel has been
obtained and installed. Replacement glass panels can be
purchased from Dovre via the retailer from which the
appliance was purchased or any other Dovre distributor.
This appliance must be serviced at least once a year by a
competent person.
All tests must be carried out in accordance with the current Gas
Safe recommendations.
1.1 Before Testing:
—Conduct a gas soundness test for the property ensuring
there are no leaks before servicing.
—Check the operation of the appliance before testing.
1.2 Special checks:
—Clean the burner using a vacuum cleaner with a soft
brush attachment. Ensure all debris is removed from the
burner ports.
—Clean away lint or fluff from the pilot.
—Clean away lint or fluff from under the burner.
—Check the spark gap on the pilot is correct, see Diagram 1.
—Ensure that the glass frame is secured correctly and that
all retaining screws are in place.
1.3 Correct any faults found during the initial test.
1.4 Re-commission the appliance in accordance with
Commissioning Procedures.
1.5 Advise the customer of any remedial work undertaken.
13mm
7 mm
1
Servicing Instructions
Servicing/Fault Finding Charts
IGNITION FUNCTIONAL CHECK 1
PILOT WILL NOT LIGHT
Ensure there is no debris around the pilot assembly,
(e.g. soot, etc.) which could short the spark, clean the
area.
Operate the valve.
Is there a spark?
Consult User
Instructions and retry.
Check alignment of pilot
burner head, change the
ignition lead,
See section 6 Replacing Part
s
Check isolation tap and
gas meter, retry.
Correct and
retry.
Purge the gas pipes and
retry.
GO TO THE NEXT
CHART IGNITION
FUNCTIONAL CHECK 2
SYSTEM OK
There is a blockage in the system, check the inlet test point,
the mag seating, valve and pilot filter.
Is the gas turned on to the
appliance?
Is the gas pressure correct?
Has the system got
any air in it?
Does the pilot light?
Is the control being
operated correctly?
Will the pilot light
with a match?
No Yes
No
Yes
No
Yes Yes
No
No
Yes
No
No
Yes
Yes

18
FLAME FAILURE FUNCTIONAL CHECK 3
IGNITION FUNCTIONAL CHECK 2
Remove the electrode lead
from the piezo. Operate the
valve. Does a spark jump from
the piezo to the valve body?
Replace the piezo
and gas valve and retry.
Yes No
PILOT WILL NOT STAY LIT OR FIRE GOES OUT IN USE
Ensure there is no debris around the pilot assembly,
(e.g. soot etc.) Check for fluff in the pilot aeration hole.
See the Diagram in the Replacing Parts section.
Problem is with the
pipe work or
fittings which lead
to the appliance.
Correct
and retry.
Is thermocouple
connection good
in back of valve?
Replace
thermocouple.
Will pilot
stay alight?
Change mag
unit.
Is the pilot flame of
the correct length?
See Servicing
Requirements
Diagram 1.
Change the
pilot unit.
Will pilot
stay alight?
With the pilot
running is the gas
pressure as stated on
the data badge?
With the appliance
running on full is the
gas at
the pressure stated
on the data badge?
Run for no more
than 60 seconds
turn off, time interval
until mag unit shuts
with a click. Is this
greater than 7
seconds?
Run for a maximum of
60 seconds, turn off,
time interval until mag
unit shuts with a click.
Is this greater than 7
seconds?
Tighten the
connection and retry.
No
No
No
No
No
No
Yes
SYSTEM OK
Yes
Yes
Yes
Yes
No
Yes
Yes
No
Light the pilot and keep the control knob pushed in
at least 10 seconds before releasing.
NO SPARK
Ensure there is no debris around the pilot assembly,
(e.g. soot etc.) which could short the spark, clean the area.
Consult the users
instructions, retry.
Operate the valve to light
the pilot, does the valve
'click'?
Is the pIlot burner
horizontal?
see Diagram 1 page 19
Has ignition lead
become detached or is
connection poor?
Remove the ignition lead
from electrode with insulated
pliers. Hold the tip 4mm from the
pilot pipework, is there a spark
when the valve ‘clicks’?
Is the electrode wire
detached from the piezo
in the valve?
Replace the combined
lead and piezo, retry.
Correct and retry.
Check for defective or
damaged control knob spindle
or cam operation. Check for
correct location of piezo
components. Correct and retry.
Is the control system being
operated correctly?
Reset the pilot burner.
Yes
Yes
Yes
No
No
No
Yes
Yes
Yes
No
No
Replace the electrode. Replace the electrode
lead and retry.
Is the flue working?
Rectify flue
No
Yes
Yes
Fault Finding Charts
Servicing Instructions

19
Servicing Instructions - Replacing Parts
1. General
1.1 All main components can be replaced without removing the
appliance from its installation.
IT IS ESSENTIAL THAT THE GAS SUPPLY TO THE
APPLIANCE IS TURNED OFF AT THE ISOLATION
DEVICEBEFOREPROCEEDINGFURTHER.
1.2 Removal of Flue
If, for any reason, the flue has to be removed from the
appliance, the seal must be replaced in the inner spigot.
2. Removing the Door
IMPORTANT: THE OUTER PANELLING OF THE
DOVRE425ISMADEFROMCASTIRON.USE
CAUTIONWHENINSTALLING,REMOVINGAND
STORINGASTHECOMPONENTSAREHEAVY
AND SHOULD BE HANDLED CAREFULLY.
2.1 For rear flue exit lift the top of the appliance off and put to
one side.
2.2 For top flue exit lift and support the top to give clearance,
see Diagram 1.
1
2.3 Lift the front upwards until it is clear of the slots and pull
away from the appliance, see Diagram 2.
2
3. Window Frame Assembly
3.1 Remove the glass frame by undoing the fixing screws and
lifting clear, see Diagram 3. Take care to support the glass
window panel when removing the screws.
3
3.2 Place carefully to one side.
3.3 Lift out the log retainer bar and carefully remove the ceramic
fuel bed components.
3.4 Refit in reverse order.
3.5 Ensure that the fibreglass seal on the back of the glass
frame and replace the screws working from the top down.
Tighten the screws evenly DONOTOVERTIGHTEN, see
Diagram 3.
NEVEROPERATETHEAPPLIANCEWHENTHEGLASS
FRAMEISREMOVEDORBROKEN.
3.6 Replace ALL of the securing screws ensuring that a screw is
present in all fixing slots.
UNDER NO CIRCUMSTANCES SHOULD THE
APPLIANCE BE USED IF ANY OF THE GLASS
FRAME RETAINING SCREWS ARE LOOSE OR
MISSING.

20
Servicing Instructions - Replacing Parts
5a Pilot Burner Bracket
5.3 Refer to Section 4 to remove the main burner.
5.4 Remove the two fixing screws from the pilot bracket, see
Diagram 5. Gently draw the assemble away from the firebox
to give access to the nuts and ignition lead.
NOTE: TAKE CARE NOT TO DAMAGE THE GASKET.
5
5b Pilot Injector
5.5 Undo the compression nut on the pilot feed pipe and
withdraw the injector which will be hooked onto the olive.
When replacing an injector always make sure it is hooked
onto the olive before inserting it into the pilot burner, see
Diagram 6.
6
5c Electrode
5.6 Disconnect the ignition lead and undo the retaining nut. The
electrode can now be removed, note the orientation of the
electrode terminal when reassembling, see Diagram 7.
7
4. Main Burner
4.1 Remove the three securing screws, two at the rear and one
at the front left hand side, see Diagram 4.
4.2 Raise the left hand side of the burner to clear the bracket,
draw the left hand side forward. The burner venturi is
engaged over the injector. When removing the burner be
sure to clear the injector, this will release the right hand side
of the burner. Take care when removing the burner so as not
to damage the pilot burner.
4
4.3 To replace the burner, engage the venturi over the injector
ensuring the burner sits on top of the fixing bracket. Push the
burner to the right and replace the three fixing screws.
NOTE: BEFORE REPLACING THE BURNER, ENSURE
THE SILICONE SEAL AROUND THE INJECTOR IS
INTACTANDCHECKTHATVENTURICOVERIS
ATTACHED.
5. Pilot Unit
5.1 The pilot assembly consists of five components, which can
be individually replaced:
5a) Pilot burner bracket
5b) Pilot injector
5c) Electrode
5d) Thermocouple
5e)Gasket
5.2 Turn the gas supply off at the isolation device, remove the
door and place to one side, carefully remove the ceramic fuel
bed components.
