REM230
RaindetectorREM230 instructions
Application
The rain detector facilitates automatic
closing of windows and skylights in
conjunction with D+H 230V drives in case of
rain.
The rain detector can be cut off e.g. by a vent
button combination with weather control
switch.
The sensor surface of the detector is heated,
so that a nil return by dewing is avoided, and
the detector remains ice-free in winter.
Moreover, the response time is improved,
when the rain has stopped.
Extent of supply
Rain detector with mounted mounting
bracket and connecting cable.
* D+H-antenna mast fastening (70.600.05)
with screw parts available for fastening
of the REM 42 on antenna mast.
Mast diameter: 42 - 60mm
- Mounting on a roof on an existing
antenna mast or a corresponding
separate mast tube(at least 2m above
the highest point of roof)
- Tube for lightning protection about 0,5m
higher than REM 42
- Mount REM 42 within precipitation area
(do not mount under an eave or the like)
Observe VDE regulations 0855 as for
antenna arrays regarding mechanical
stability, electrical safety and lightning
protection.
Installand introduce separately weak current
conductions from 230 V supply mains.
Operating voltage 230 VAC!
Observe safety regulations. Mounting must
be carried out by electrical experts only.
Mounting Informations
Maintenance
Open, then check seals. Interior space must be clean and dry. Clean if necessary and
replace seals. With dirt accumulation wash rain detector electrodes and insulator with mild
soapy water, then rinse thoroughly.
Functional testing:
Put wet finger on surface. The rain closing signal will be stored for 2 minutes.
Dyer Environmental Controls Limited | 0161 491 4840 | [email protected]

All sizes in millimetre • Rights to technical modifications reserved. • Reprintingandphototechnical
reproduction also in extracts has to be expressively authorized by D+H Mechatronic AG.
Technical Data
power supply : 230VAC±10%/50Hz
Power consumption: 5VA
Interfering emission: EN 55011
Resistance to : EN 50081-2,
jamming EN 50082-2,
EN 61000-4-2, -3, -4
EN 50204
switching contact : change-over contact
230 VAC / max. 5A
Attention! Contact is not double insulated.
housing : PC RAL 7035
Mounting bracket : V2A
protected system : IP 65
connection : 8m PVC cable
REM 230
Vent button
e.g. LT 230
Drive
e.g. VKA 52
or ZA xx-K
230VAC / 50Hz
230VAC
max. 5A
L
N
PE
U
RAN
L
brown
blue black 1 black 3
black 2
Connection
Guarantee
You will get 2 years guarantee for all D+H
products from date of verified handing over
of the system up to maximal 3 years after
date of delivery, when mounting and starting
has been carried out by a D+H authorized
distributor.
D+H guarantee is expired, with connection
of D+H components with external systems
or with mixing of D+H products with parts of
other manufacturers.
