DRAGONN DN-CH-K02B DN-CH-K02B User manual

Black Kneeling Chair with Back Support
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://idragonn.com/collections/products/products/ergonom-
ic-kneeling-chair-with-back-support-adjustable-stool-for-home-
and-oice-improve-your-posture-with-an-angled-seat-thick-com-
fortable-cushions-black
SKU: DN-CH-K02B
[e-mail] www.idragonn.com 309-278-5303
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2
PACKAGE CONTENTS
F (x6)
M6x12
G(x6)
M6x20 Panhead
Screw
H(x4)
M6x40
O (x1)
Allen Wrench
P (x1)
Wrench
Q (x1)
Adjustable
Support
R (x2)
Grip Handle
I(x8)
M6x20
J (x2)
Caster
K (x2)
Locking
Caster
L(x1)
Short Sleeve
Nut
M (x1)
Medium
Sleeve Nut
N (x1)
Long Sleeve
Nut
TOOLS NEEDED
Phillips
Screwdriver
Drill
T (x2)
M6x25
S (x1)
Back Seat
Support
U (x1)
Back Seat Hinge
with Cover
A (x1)
Seat Pad
B(x1)
Knee Pad
C(x1)
Back Seat Pad
D(x1)
Upper Frame
E(x1)
Lower Frame
250lbs
(113.40kg)
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may
cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do
not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly
or inappropriate use.
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
WARNING: THIS PRODUCT CAN RESTRICT CIRCULATION TO LEGS WITH PROLONGED USE.

3
ASSEMBLY STEPS
STEP 1
Insert upper frame (D) into lower frame (E) and align front holes to one of three positions,
depending on the user leg length. Assemble frames using the long sleeve nut (N) with x2
M6x12 screws (F) and tighten using the Allen wrench (O).
STEP 2
Assemble adjustable support (Q) to rear of upper frame (D) using medium sleeve nut (M)
with x2 M6x12 screws (F) and tighten using the Allen wrench (O).

4
STEP 3
Connect adjustable support (Q) to rear of lower frame (E) using short sleeve nut (L) with x2
M6x12 screws (F) and tighten using the Allen wrench (O).
STEP 4
Assemble seat pad (A) to rear of upper frame (D) using x3 M6x20 pan head screws (G), and
knee pad to front of lower frame (E) using M6x40 screws (H). Tighten all screws with the
Allen wrench (O).

5
STEP 5
Press fit casters (J, K) into holes on underside of the frames.
E
F
STEP 6
Assemble grip handles (R) to seat pad (A) using M6x20 screws (I).
D
M
R

6
STEP 8
Secure back seat support (S) with
back seat hinge and cover (U) to back
seat pad (C) using M6x25 screws (T).
Tighten with the Allen wrench (O).
STEP 7
Insert end of back seat support (S) into slots in back seat hinge (U), then place
cover on the hinge.

7
STEP 9
Attach back seat assembly to seat pad (A) using x3 M6x20 pan head screws (G). Tighten
with the Allen wrench (O).
STEP 10
Adjust seat height and angle by turning the knob on the adjustable support (Q).

FOR MORE DRAGONN PRODUCTS, CHECK OUT OUR WEBSITE AT: www.idragonn.com
Love your new Dragonn setup and want to share?
Tag us in your photo! @dragonnbrands
[e-mail] www.idragonn.com 309-278-5303
Chat live with an agent!
Open Monday - Friday 7:00am - 7:00pm CST,
our dedicated support team can oer immediate assistance with rapid response times. If any
parts are received damaged or defective, please contact us. We are happy to replace parts to
ensure you have a fully functioning product.
LAST UPDATED: 07/03/2020
