Draper Crank-Operated FlexShade User manual

Installation Instructions
Crank-Operated FlexShades by Draper
Copyright © 2009 Draper Inc. Form CrankFlexShades_Inst09 Printed in U.S.A.
®
If you encounter any difficulties installing or servicing your Crank-Operated FlexShades, call
your dealer or Draper, Inc. in Spiceland, Indiana, 765-987-7999, or fax [phone].
Crank-Operated FlexShades—Endcaps
➀Mark wall, jamb or ceiling for placement of mounting endcaps.
Caution: Before mounting shades, verify measurements on the card
provided with the shade, and ensure the brackets are installed at the
correct width.
➁Drill small starter hole (if necessary) in mounting surface.
➂Mount endcaps using appropriate fasteners for surface (see Fig. 1 for
endcap dimensions). If this is a coupled unit, be sure to mount coupled
endcap in the center position. The installer is responsible for selecting
mounting hardware appropriate for site conditions.
Crank Endcap Dimensions
Caution
➀ Inspect all boxes to make sure you have received proper shades/parts.
Open cartons lengthwise.
➁All endcaps, fascia, headboxes, pockets, wall clips, and other hardware
must be installed level. Shades must be level and square.
➂There is no lower limit. Overcranking the shade past sill may cause
product to fall or otherwise fail, and invalidates warranty.
Please Note: If shade fabric is uneven, see “Field Adjustments” below.
➃Please read the following installation guidelines thoroughly and
follow them carefully. Failure to do so may cause product to fall or
otherwise fail, and invalidates warranty.
Please Note: Custom products/installations may not be reflected by this
document. Call Draper, Inc. if you have questions about your installation.
Figure 1
➅ Place groove along top of fascia over endcaps, and snap into place (see
Fig. 5).
Fascia
➀Snap end covers onto endcaps.
➁Follow steps 1 through 3 under “Crank Operated FlexShades—Endcaps”.
➂Remove crank handle assembly from crank (operator) endcap and remove
the washers (see Fig. 4). Insert shank into hole in center of crank assembly,
then slide fabric/roller onto shank (see Fig. 2).
➃For coupled units see separate instruction sheet for Coupled FlexShades.
➄Slide notched pin into idler endcap (see Fig. 2).
➃Insert shank into hole in center of crank assembly, then slide fabric/roller
onto shank (see Fig. 2).
➄For coupled units see separate instruction sheet for Coupled FlexShades.
➅Slide notched pin into idler endcap (see Fig. 2).
➆ Attach crank handle.
Figure 3
Figure 4
Large Small
33/4"2"
5/16"
31/4"
21/2"
2"
2"
11/4"11/4"
17/8"
17/8"
41/2"
5/8"
41/2"
3"
3"
5/8"7/8"
21/4"
21/4"
27/8"
27/8"
Figure 2
Idler End
Operator
End
➇ Snap end covers into place (see Fig. 3).
3¼"
hardware
4½"
hardware
Figure 5
➆ Re-attach crank handle assembly to endcap (see Fig. 6). Make sure the
fascia is in place before attaching crank handle, so that the screws attach
both the handle assembly and the fascia to the endcap.
Figure 6
Be sure retainer
clip is installed.
STEP 1 STEP 2
Two-Piece Handle
Standard Handle

Field Adjustments
Each Draper Solar Control Shade is tested to ensure proper operation.
Even with this testing, some field adjustments may be needed for telescoping.
If the shade is telescoping, place a piece of high quality gaffer tape about 1"
wide on the exposed roller (where the fabric will cover it) on the side that you
want the fabric drawn toward. For example: if the fabric is tracking to the left,
place the tape on the right side.
Surface (Ceiling/Wall) Headbox or Large Pocket Headbox
➀Snap endcap covers onto endcaps.
➁Place endcaps into back/top portion of wall/ceiling headbox or into pocket
extrusion of large pocket headbox. Using pre-drilled holes in endcaps, mark
the headbox for drilling.
Caution: Before mounting shades, verify measurements on the card
provided with the shade, and ensure the brackets are installed at the
correct width.
➂Drill holes in back or top, depending on whether you will be mounting the
headbox to the wall or ceiling, or in a pocket.
➃Attach endcaps and wall/ceiling headbox back/top or large pocket headbox
extrusion to wall, ceiling or pocket using mounting hardware appropriate for
site conditions.
➄Install shade following steps 3 through 5 under “Crank Operated Flex-
Shades—Fascia”.
➅ Attach headbox fascia or pocket closure (see Fig. 7).
Figure 9
Crank-Operated FlexShades by Draper Page 2 of 2
www.draperinc.com (765) 987-799
9
➆Re-attach crank handle (see Fig. 6, page 1). Make sure the headbox fascia
or pocket closure is in place before attaching crank handle, so that the
screws attach both the handle and the fascia to the endcap.
Figure 7
STEP 1 STEP 2 STEP 3
Surface Headbox
Large Pocket Headbox
Small (3¼” Hardware) Pocket Headbox
➀Snap endcap covers onto endcaps.
➁Place endcaps into pocket extrusion of small pocket headbox. Using pre-
drilled holes in endcaps, mark the headbox for drilling (see Fig. 8).
Caution: Before mounting shades, verify measurements on the card
provided with the shade, and ensure the brackets are installed at the
correct width.
Figure 8
33/4"2"
5/16"
31/4"
21/2"
2"
2"
11/4"11/4"
17/8"
17/8"
➂ Drill holes in back or top, depending on how you will be mounting the small
pocket.
➃ Attach endcaps and small pocket headbox extrusion to wall, ceiling or in
pocket using mounting hardware appropriate for site conditions.
➄ Remove crank handle assembly from crank (operator) endcap (see Fig. 4
—note: there are no washers with small pocket headbox crank operators).
Insert shank into hole in center of crank assembly, then slide fabric/roller
onto shank (see Fig. 2).
➅ Slide notched pin into idler endcap (see Fig. 9).
➇Attach small pocket closure (see Fig. 10).
➈Re-attach crank handle assembly (see Fig. 6, page 1).
Secure closure
panel to endcap
with screw
Figure 10
Small Pocket Headbox
Cleaning and Maintenance
Window covering products manufactured by Draper, when properly
installed, should require no operational maintenance or lubrication.
Most of Draper’s standard fabrics may be cleaned at the window by
vacuuming with a soft brush attachment. They may also be cleaned by using
a sponge or soft cloth and mild solution of warm soapy water. A dishwashing
liquid, such as Ivory liquid, is recommended. A clean dry cloth is recommend-
ed for the metal finish. Exceptions are Flocké, Roc-Rol, Obion and Phifer
SW7000 fabrics, which must be cleaned with a dry art sponge.
STEP 1 STEP 2
Be sure retainer
clip is installed.
