INSTRUCTIONS Cont.
FIXING INSTRUCTIONS
1. Unscrew the four screws located on the front of
the lamp and remove the front cover and glass.
2. Slide bulb holder and plate upwards. Carefully
open the light to access mounting holes and
terminal block. FIG.1.
3.Place light against the wall and mark the position
of the fixing holes (1) as shown in the diagram.
FIG.2. Split the centre of the grommet to allow
cable access as shown at position (2) in the
diagram.
4. Drill the holes with a suitable drill bit and plug
the mounting holes. Ensure there are no power
cables or pipes below the surface before
commencing drilling.
5. Feed the mains power cable through the grommet
(2). Now attach the backing plate to the wall
using the two screws supplied. Do not
overtighten the screws as this could damage the
base.
6. Connection to the mains power should be made
using the general wiring code shown in FIG.3.
THIS PRODUCT MUST BE EARTHED.
NOTE: make sure that the incoming mains cable
corresponds to the correctly coloured internal wire
from the unit.
7. The incoming Brown/Red live wire must be
opposite the Black live wire from the unit, the
Neutral Blue must be opposite the Blue Neutral
wire from the unit. The Green and Yellow earth
wire must be opposite the Green and Yellow
earth wire from the unit.
8 . The terminal block may be removed for ease of
connection. Tighten all terminal screws and
make sure that there are no loose strands of cable
showing. Be sure to replace the terminal block on
its fixings.
1. Terminal position for Earth (from
house mains Yellow and Green/Green.
2. Terminal position for Neutral (from
house mains Blue/Black).
3. Terminal position for Live (from house
mains Brown/Red)
FUSE VALUE
The light should be connected to a 5 amp circuit. If the existing fuse in the circuit is higher than
5 amps an inline fuse of 3 amps should be fitted. This light should only be connected to a
220/240V-50Hz electricity supply in accordance with I.E.E. wiring safety regulations.
Bulb
holder.
Plate cover.
1. Slide up to
remove
2. Slide
down to
replace.
FIG.1.
