Draper 16128 User manual

16128
EN
Original Instructions
Version 1
750L/MIN 7HP PETROL
TRASH WATER
PUMP

1. Preface
– 2 –
These are the original product instructions. This
document is part of the product; retain it for the life
of the product, passing it on to subsequent holders.
Read this manual in full before attempting to
assemble, operate, or maintain this product.
This Draper Tools manual describes the purpose
of the product and contains all the necessary
information to ensure its correct and safe use.
Following all the instructions and guidance in
this manual will ensure the safety of both the
product and the operator and increase the
lifespan of the product.
All photographs and drawings within this manual are
supplied by Draper Tools to help illustrate correct
operation of the product.
Every eort has been made to ensure the
information contained in this manual is accurate.
However, Draper Tools reserves the right to amend
this document without prior warning. Always use the
latest version of the product manual.
1.1 Product Reference
User Manual for: 750L/Min 7HP Petrol Trash Water
Pump
Stock No: 16128
Part No: PWP82T
1.2 Revisions
Version 1: May 2016
First release
Version 2: June 2022
General format and content revisions
As our manuals are continually updated, always ensure
that the latest version is used.
Download the latest version from:
drapertools.com/manuals
1.3 Understanding the Safety Content
WARNING! – Situations or actions that may result in personal injury or death.
ATTENTION
Situations or actions that may result in damage to
the product or surroundings.
Important – Information or instructions of particular
importance.
1.4 Copyright © Notice
Copyright © Draper Tools Limited.
Permission is granted to reproduce this manual for
personal and educational use ONLY. Commercial
copying, redistribution, hiring, or lending is strictly
prohibited.
No part of this manual may be stored in a retrieval system
or transmitted in any other form or means without written
permission from Draper Tools Limited.
In all cases, this copyright notice must remain intact.

2. Contents
– 3 –
EN
1. Preface 2
1.1 Product Reference 2
1.2 Revisions 2
1.3 Understanding the Safety Content 2
1.4 Copyright © Notice 2
2. Contents 3
3. Warranty 4
4. Product Introduction 5
4.1 Scope 5
4.2 Specication 5
5. Health and Safety Information 6
5.1 General Safety Instructions 6
5.2 Additional Health and Safety Instructions
for this Trash Water Pump 6
5.3 Health and Safety Information for
Machines with a Petrol Engine 7
6. Identication and Unpacking 8
6.1 Product Overview 8
6.2 What’s in the Box? 9
6.3 Packaging 9
7. Preparing the Water Pump 10
7.1 Hose Connection 10
8. Setting the Water Pump 11
8.1 Checking the Engine Oil 11
8.2 Fuelling 12
9. Basic Water Pump Operation 13
9.1 Priming the Pump 13
9.2 Starting the Pump 13
9.3 Stopping the Pump 14
10. Maintenance and Storage 15
10.1 General Maintenance 15
10.2 Cleaning out Blockages 15
10.3 Changing the Oil 16
10.4 Changing the Air Filter Element 16
10.5 Spark Plug Care 17
10.6 Changing the Engine Oil 17
10.7 Draining the Fuel 18
10.8 Storing the Pump 19
10.9 Periodic Maintenance 20
11. Optional Accessories 21
11.1 Risk of Fire 21
11.2 Risk of Injury and Property Damage When
Transporting Water Pump 22
11.3 Risk of Breathing – Inhalation Hazard 22
11.4 Risk of Unsafe Operation 22
11.5 Risk of Hot Surfaces 23
11.6 Risk of Moving Parts 23
11.7 Risk from Lifting 23
12. Optional Accessories 24
12.1 Draper Suction Hoses 24
12.2 Draper Hose Clamps 24
13. Troubleshooting 25
14. Disposal 26
15. Explanation of Symbols 27

3. Warranty
Draper Tools products are carefully tested and inspected
before shipment and are guaranteed to be free from
defective materials and workmanship.
Should the tool develop a fault, return the complete tool
to your nearest distributor or contact Draper Tools
directly. Contact information can be found at the back of
this manual.
Proof of purchase must be provided.
If, upon inspection, it is found that the fault occurring is
due to defective materials or workmanship, repairs will
be carried out free of charge. This warranty period covers
parts and labour for 12 months from the date of purchase.
Where tools have been hired out, the warranty period
covers 90 days from the date of purchase.
This warranty does not apply to any consumable parts,
batteries or normal wear and tear, nor does it cover any
damage caused by misuse, careless or unsafe handling,
alterations, accidents, or repairs attempted or made by
any personnel other than the authorised Draper Tools
repair agent.
In all cases, to make a claim for faulty workmanship or
materials within the standard warranty period, please
contact or return the product to the place of purchase.
Proof of purchase may be required.
If the place of purchase is no longer trading or if you
experience any diculties with your warranty, please
contact Customer Services with the product details and
your proof of purchase. Contact details can be found at
the back of this manual.
If the tool is not covered by the terms of this warranty,
repairs and carriage charges will be quoted and charged
accordingly.
This warranty supersedes any other guarantees
expressed or implied and variations of its terms are not
authorised.
Your Draper Tools guarantee is not eective until you can
produce, upon request, a dated receipt or invoice to
verify your purchase within the guarantee period.
Please note that this warranty is an additional benet
and does not aect your statutory rights.
Draper Tools Limited
– 4 –

4. Product Introduction
– 5 –
EN
4.2 Specication
Stock No. 16128
Part No. PWP82T
Engine 7hp 4 stroke
Suction aperture 75mm (3")
Output aperture 75mm (3")
Displacement 196cc
Max. ow 750L/min
Max. head height 26m
Max. suction head height 7m
Noise emissions:
Sound pressure level 92dB(A)
Sound power level 108dB(A)
Fuel capacity 3.6L
Dimensions W 570 x H 450 x D 460mm
Application Dirty water
Net weight 35kg
4.1 Scope
This product is designed for the transfer of wastewater
that contains solid and semi-solid substances and debris
in environments in which access to mains power is
limited. It is intended for trade use, with the quality and
features necessary to meet and exceed the expectations
of the most demanding user. Any other application
beyond the conditions established for use will be
considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
WARNING! This product is not a toy and must be respected.
Read this manual in full before attempting to assemble,
operate or maintain the product, and retain it for later use.

5. Health and Safety Information
– 6 –
EN
Important: Read all the Health and Safety instructions
before attempting to operate, maintain or repair this
product. Non-compliance with these instructions may
result in injury or damage to the user or the product.
5.1 General Health and Safety
Instructions
• ONLY trained persons familiar with the Health and
Safety information and use of this product may
operate the pump.
− DO NOT allow children or persons who are not
trained in the use of this product to operate it.
• Observe all standard safety precautions and good
practices when in a workshop environment.
• Allow adequate space for the pump and hoses during
use.
• Keep your work environment clear and well-lit, with
bystanders at a safe distance.
• Use the product only in the manner instructed in this
manual.
• DO NOT use this product while tired or under the
inuence of alcohol, drugs, or other medication.
• DO NOT modify this product in any way.
• ONLY use spare parts supplied by Draper Tools.
• Check the product for broken, worn, or loose parts
before every use.
WARNING! DO NOT use the product if any part of the machine is damaged. Have it repaired

personnel.
• Keep your hands, face, other body parts and loose
clothing away from moving parts when the pump is in
use.
• NEVER leave this machine running unattended.
− ALWAYS switch the machine o and allow it to
cool before walking away.
• ALWAYS ensure that the pump has been switched o,
cooled and has completely stopped before moving or
maintaining the product.
− After use, ALWAYS allow at least 30 minutes for
the pump to cool before moving or maintaining
the product.
− ALWAYS disconnect and drain the suction and
discharge hoses before moving or maintaining the
product.
• Maintain and clean the tool frequently and thoroughly
to ensure a long lifespan for the product.
• This product must be repaired ONLY by suitably
qualied personnel authorised to do so by
Draper Tools.
5.2 Additional Health and Safety
Instructions for this Trash Water Pump
ATTENTION
This product is NOT shipped with engine oil. ALWAYS
check and top up the engine oil before every use.
• Use this product ONLY on rm, level surfaces.
• DO NOT expose this machine to water or wet
environments.
− ONLY the connected hoses and internal pumping
system should come into contact with liquids.
• NEVER use the pump if the stop switch is faulty,
unusable, or missing.
• Ensure that the suction and discharge hoses are laid
out at and safely.
• NEVER operate the pump without rst correctly
priming it.
ATTENTION
NEVER operate the pump without water passing
through it.
• ALWAYS wear ear defenders while working near this
machine.
• NEVER obstruct the discharge outlet or hose as this
may severely damage the product.
• NEVER allow the pump or its contents to freeze.
• NEVER use this product to pump corrosive or toxic
materials.
• DO NOT cover or obstruct any ventilation points or
grilles.
• NEVER stand or step on the pump or frame.
• DO NOT attempt to move the pump by pulling on or
lifting the hosing.
− Carry the pump ONLY by the metal frame.
− The pump is heavy; use any appropriate lifting
equipment to move the pump and ask for
assistance if required.

5. Health and Safety Information
– 7 –
EN
• DO NOT drop or strike the pump.
− If sudden force is applied to the pump,
IMMEDIATELY switch it o and inspect it for
damage.
WARNING! DO NOT continue to use the pump if it has sustained any damage.
• During transportation, keep the pump well ventilated
and out of direct sunlight and other sources of heat or
ignition.
− If the journey is likely to be uneven or bumpy,
ensure that the pump has been drained before it is
moved.
5.3 Health and Safety Information for
Machines with a Petrol Engine
 vapour is explosive. Take extreme caution when
handling petrol and keep it out of reach of
children.
DO NOT operate this machinery in any
hazardous location that present a risk of
explosion from petrol fumes, gas leakage or
explosive dust.
• ALWAYS refuel the machine outdoors.
• DO NOT expose the pump to direct sunlight for
prolonged periods.
• ALWAYS securely fasten the fuel cap before use.
• NEVER smoke in the vicinity of the machine,
especially during refuelling.
• NEVER start the engine if you can smell petrol vapour
in the air.
− If petrol vapour is present, wait for it to dissipate
or move to a new location.
• ALWAYS add fuel before starting the engine, NEVER
while the engine is running.
WARNING! The engine and fuel get hot during use. The exhaust system may become hot
enough to ignite some materials.
− DO NOT touch the engine during or immediately
after use and allow it to cool before refuelling.
− Keep the pump away from ammable substances
during use and until cooled.
• NEVER remove the fuel cap while the engine is
running or immediately after use.
− Take care when opening the fuel cap after use as
hot vapour may be released from the opening.
• NEVER place objects on the engine while it is in use
and keep all air vents clear of dust, dirt and other
obstructions.
• DO NOT attempt to start the machine engine near
spilled petrol
− Allow vapours from spilled fuel to dissipate before
starting.
− Spilled fuel may be ignited by the engine.
• To reduce the risk of re, keep the engine, silencer
and petrol storage area free of vegetative material
and excessive grease.
• ONLY drain the machine of fuel and oil in a well-
ventilated outdoor environment.
• Allow the engine to cool before storing the machine.
• NEVER store the machine with fuel in the tank in an
environment where fumes may reach an open ame
or spark.
• Store fuel in containers that are specically designed
to do so
• DO NOT operate the machine in conned spaces in
which carbon monoxide fumes from the exhaust may
accumulate.
WARNING! The machine exhaust emits toxic carbon monoxide: a colourless and odourless
gas. Breathing exhaust fumes can cause loss of
consciousness, permanent respiratory damage
and eventually death. ONLY operate this
machine in a well-ventilated outdoor
environment.

6. Identication and Unpacking
6.1 Product Overview
– 8 –
EN
(1) Fuel tank cap
(2) Fuel tank
(3) Priming cap
(4) Hose barb
(5) “T” bolts
(6) Oil level dipstick
(7) Oil drain plug
(8) Air lter housing
(9) Spark plug cap
(10) HT lead
(11) Muer (exhaust)
(12) Water drain
(13) Inlet (suction)
(14) Hose barb coupling
(15) Outlet
(16) Main engine switch
(17) Recoil (pull) start handle
(18) Fuel lever
(19) Choke lever
(20) Throttle lever
(1) (2)
(3)
(4)
(5)
(6)(7)
(16)
(17)
(18)
(19)
(20)
(8)
(9)
(10)
(11)
(6)(7)
(15)
(13)
(12)
(5)
(14)

6. Identication and Unpacking
6.3 Packaging
Keep the product packaging for the duration of the
warranty period for reference should the product need to
be returned for repair. WARNING! Keep packaging materials out of
reach of children. Dispose of packaging
correctly and responsibly and in accordance
with local regulations.
Please visit drapertools.com for our full range of accessories and consumables.
– 9 –
EN
(A) 1 x Pump unit (not shown)
(B) 2 x Hose barbs
(C) 2 x Hose barb couplings
(D) 3 x Hose clamps
(E) 1 x Filter barb
(F) 1 x Strain lter
(G) 2 x O-ring seals
(H) 1 x Spark plug spanner body
(I) 1 x Spark plug spanner handle
6.2 What’s in the Box?
Carefully remove the water pump from the packaging
and examine it for any signs of damage that may have
occurred during shipment.
Before assembling the product, lay the contents out and
check them against the parts shown below. If any part is
damaged or missing, do not attempt to use the product.
Please contact the Draper Helpline; contact details can
be found at the back of this manual.
(C)
(D)(G)
(I)
(F) (E)
(B)
(H)

– 10 –
EN
7. Preparing the Water Pump
7.1 Hose Connection
Use a solid wall (reinforced) hose to stop the hose from
collapsing on the suction side of the pump. Please see
the optional accessories section for recommended
suction hose.
1. Pass the hose barb (4) through the threaded side of
the hose barb coupling (14) so that the thread sits
away from the hose barb (Fig. 1).
2. Place an O-ring seal (G) inside the hose bar coupling
so that it rests against the hose barb.
3. Screw the hose barb assembly onto the pump inlet
(13) (Fig. 2).
4. Slide a hose clamp (D) over one end of the solid wall
hose (not supplied) and push that end of the hose as
far as possible onto the hose barb (Fig. 3).
5. Move the hose clamp so that it sits centrally on the
covered hose barb and twist the clamp screw
clockwise until tight to secure the hose in place.
6. Screw the lter barb (E) into the strain lter (F) (Fig. 4).
7. Slide a hose clamp onto the other end of the hose and
push the hose onto the lter barb as far as possible.
8. Place the hose clamp centrally on the lter barb and
twist the clamp screw clockwise until tight.
Repeat steps 1–5 for the discharge hose (not supplied)
if required. Connect the discharge hose to the pump
outlet (15).
4 Fig.
3 Fig.
2 Fig.
1 Fig.
(4)
(14) (F)
(14) (4)

– 11 –
EN
8.1 Checking the Engine Oil
ATTENTION
This product is NOT shipped with engine oil. ALWAYS

Important: Ensure that the oil reservoir is lled with
SAE30 four-stroke oil before starting the motor.
Damage to the motor is NOT covered under warranty if
the motor is run without oil.
1. Before checking or relling the oil, ensure that the
pump is switched o, cool and is positioned on a
stable and level surface.
2. Remove the oil lter cap (6) by rotating the cap
anticlockwise.
3. Wipe the dipstick clean and re-insert it into the oil
reservoir (Fig. 5).
4. Remove the dipstick from the reservoir again and
inspect the oil level against the high and low markers.
Important: DO NOT screw the dipstick back into the
reservoir when checking the oil level, simply insert it
and pull it out.
5. If the oil level is below the lower line, rell it until the
upper line is reached.
6. If the oil is contaminated or has discoloured, ensure
you change the oil; see section 10.1 (Fig. 6).
This motor is tted with a low oil sensor and will stop
operating or will not start if the oil level is too low. Check
the oil level each time the pump is used.
6 Fig.
5 Fig.
8. Setting the Water Pump
Oil dipstick cap
Upper level
Lower level

– 12 –
EN
8.2 Fuelling
Use unleaded petrol ONLY.
1. Remove the petrol cap (2) (Fig. 7).
2. Check that the fuel lter (2.1) is in place and pour the
fuel into the tank (Figs. 8–9).
ATTENTION

fuel and the roof of the tank.
3. Screw down the fuel cap securely and clean up any
spilled fuel immediately.
WARNING! DO NOT start the engine in the presence of spilled petrol or petrol vapour as
sparks may cause it to ignite.
4. Move the water pump at least 4m (12ft) away from the
fuelling area before starting.
WARNING!
• Do not rell the fuel tank while the engine is running
or is hot.
• Check to ensure that the petrol cap has been
tightened and that fuel is not leaking.
• Be careful not to admit dust, dirt, water or other
foreign objects into the fuel.
• Wipe o spilt fuel thoroughly before starting the engine.
• Ensure you do not fuel the pump in close proximity to
any open ames.
9 Fig.
8 Fig.
7 Fig.
8. Setting the Water Pump
(2)
(2.1)

– 13 –
EN
Important: Place the pump on a rm and level surface
during use. Keep in mind that the length of the hoses and
the dierence in elevation between the pump and the
source and delivery reservoirs may impact the ow rate.
ATTENTION
This pump is NOT shipped with engine oil. ALWAYS add

9.1 Priming the Pump
ATTENTION

1. Remove the priming cap (3) and ll the pump housing
with water before retting the cap and starting your
pump (Fig. 10).
This will allow the pump to create a low-pressure
vacuum that will draw the water up for pumping.
2. Fill the suction hose up with water.
Important: Ensure that the strain lter (F) is tted to
the suction hose and remains completely submerged
throughout the pumping operation.
Important: Once your pump is started, it may take
several minutes to complete priming. This time will
vary due to the length of the suction hose tted
(a longer suction hose will take longer to fully prime
and start pumping water).
Once the pump has fully primed, it will draw the water
from the water source and pump it out through the
pump's outlet and into any layat discharge hose that is
tted to direct the pumped water to the desired location.
9.2 Starting the Pump
Important: Read and understand all Health and Safety
guidance and preparation instructions before attempting
to operate the pump.
1. Slide the fuel lever (18) to the right to turn on the fuel
supply.
2. Slide the throttle lever (20) to the left to open the
throttle slightly.
3. Open or close the choke as appropriate (Fig. 11):
− When performing a cold start, keep the choke
closed (pushed to the right).
− When performing a warm start, open the choke
(pushed to the left) while starting the engine.
10 Fig.
9. Basic Water Pump Operation
(3)
11 Fig.
(19) (20)
ON OFF
CLOSED OPEN
OFF ON
(18)

– 14 –
EN
4. Turn the engine switch (16) to the ON position
(Fig. 12).
5. Gently pull on the recoil starter (17) until resistance is
felt, then pause and pull it out rapidly (Fig. 13).
ATTENTION
DO NOT attempt to start the engine when the recoil
starter is full retracted. DO NOT allow the recoil starter to
snap back against the engine. Return it gently to prevent
damage to the starter.
6. Allow the engine to run for a few minutes and
warm up.
7. Close the choke so that the engine runs smoothly
(Fig. 14), then increase the throttle speed to begin
pumping.
Important: Lower the throttle to idle (pushed to the right)
or switch o the engine whenever the pump is not in use.
9.3 Stopping the Pump
Important: Before stopping the engine, lower the
throttle to idle (pushed to the left) and run the engine for
a few minutes.
• If the engine is only being stopped for a moment, slide
the fuel lever to the left and turn the engine switch
(16) o.
• If the engine is being stopped and later stored, slide
the fuel lever to the left and wait for the engine to cut
out before turning the engine switch (16) to the OFF
position.
• In the event of an emergency, immediately turn the
engine switch (16) to the OFF position.
13
Fig.
12 Fig.
9. Basic Water Pump Operation
(17)
(16)

– 15 –
EN
Important: ALWAYS drain the product of BOTH FUEL
AND OIL before returning it to Draper Tools for repairs.
Important: This product may only be serviced by
qualied and authorised personnel.
WARNING! DO NOT attempt to perform any maintenance on this product unless the engine

This water pump has been designed to operate over a
long period of time.
Continuous satisfactory operation depends upon proper
machine care, regular cleaning and following the
periodic maintenance schedule. If the pump is operating
in unusually dusty or hot conditions, the time between
servicing the pump must be decreased.
10.1 General Maintenance
• ONLY use spare parts supplied by Draper Tools.
• Inspect the pump and any attached pipes for damage,
blockage or loose xings and attachments before
each use.
− Clean any dirty, dusty or blocked parts.
− Tighten all loose bolts or xings.
− Replace any broken or worn parts before use.
WARNING! DO NOT use this product if any part is broken or damaged.
• Clean the pump with a damp cloth ONLY.
Important: DO NOT use solvents as this may damage the
plastic parts of the product.
• Protect the pump and its components from adverse
environmental and weather conditions, both during
use and when stored.
− DO NOT use the pump in the rain or in wet
surroundings.
• Keep all air vents clean and free from obstructions at
all times.
10.2 Cleaning out Blockages
ALWAYS ensure that the water pump is turned o before
attempting to open the pump.
1. To open the pump, twist the six “T” handles
anticlockwise and pull the cover away from the
pump (Fig. 14).
2. Clean inside the housing and around the impeller.
3. Remove and clean the impeller (Fig. 15).
4. Reattach the impeller and reassemble the housing.
Important: After the blockage has been removed, the
pump must be primed again before use.
10. Maintenance and Storage
14 Fig.
15 Fig.
(5)

– 16 –
EN
10.3 Changing the Oil
Important: The engine oil should be changed after the
rst 20 hours of operation and then every 100 hours
thereafter.
1. Unscrew and remove the dipstick, followed by the
sump bolt (7). Catch the used oil in a suitable
container and dispose of it in an approved manner
(Fig. 16).
2. When all the oil has drained from the engine block,
replace the sump bolt and rell the engine oil up to
the maximum level.
3. Use oil grade SAE10W-30 or equivalent.
10.4 Changing the Air Filter Element
Important: The air lter element should be replaced
after every 50 hours of operation.
ATTENTION

installed.
1. Unscrew the wingnut and remove the air lter
housing (11).
2. Remove and clean the lter element (11.1) in warm
soapy water or a high-ashpoint solvent and allow it
to dry completely (Fig. 17).
3. When the lter element is dry, soak it in engine oil.
4. Squeeze the excess oil from the element before
retting it and replacing the air lter housing.
17 Fig.
16 Fig.
10. Maintenance and Storage
(7)
(11) (11.1)

– 17 –
EN
20 Fig.
19 Fig.
10.5 Spark Plug Care
Important: The spark plug should be checked and
cleaned after every 50 hours of use and replaced if
necessary.
1. Remove the spark plug cap (9) by hand (Fig. 18).
2. Pass the spark plug spanner handle (I) through the
holes in the spark plug spanner body (H) and use the
assembled spanner to remove the spark plug (Fig. 19).
3. Inspect and clean the spark plug:
a. The spark plug should be tan in colour.
b. Check the spark plug for cracks or chips in the
ceramic insulator.
c. Measure the gap using a feeler gauge (not
supplied) and correct it as appropriate by gently
bending the electrode into position.
Important: The gap should be 0.7–0.8mm.
d. Replace the spark plug if necessary.
4. Install the spark plug using 20Nm of torque.
10.6 Changing the Engine Oil
Important: The engine oil should be changed after the
rst 20 hours of operation and then every 100 hours
thereafter.
1. Unscrew and remove the dipstick (6), then the sump
bolt (7) and drain the oil into a suitable container.
(Fig. 20).
Important: ALWAYS dispose of oil in accordance
with local regulations.
2. When all the oil has drained from the engine block,
replace the sump bolt and rell the engine oil up to
the maximum level.
Important: Use oil grade SAE10W-30 or equivalent.
10. Maintenance and Storage
18 Fig.
(9)
(9.1) (7)
(I)
(H)

– 18 –
EN
10. Maintenance and Storage
22 Fig.
21 Fig.
10.7 Draining the Fuel
Important: Read all the Health and Safety guidance for
the use of petrol as a fuel before lling or using this
product.
1. Ensure that the fuel lever (18), throttle lever (20),
choke lever (19) and engine switch (16) are in their
OFF or lowest positions and allow the engine to cool
for at least 30 minutes (see Fig. 14).
2. Unscrew the fuel tank cap (1) and remove the fuel
lter.
3. Use a siphon to empty the fuel tank into a suitable
petrol container (Fig. 21).
4. Reinstall the fuel lter and fuel tank cap securely.
5. Loosen the carburettor drain screw and drain the
carburettor into a suitable container (Fig. 22).
6. Gently pull the recoil start handle (17) until resistance
is felt, then pull it rmly.
Do this four times to empty the fuel pump of petrol
into a suitable container.
7. Tighten the carburettor drain screw.

– 19 –
EN
10. Maintenance and Storage
10.8 Storing the Pump
Prepare the pump correctly if it is to be stored for a
prolonged period:
1. Ensure that all switches are in the OFF or lowest
position.
2. ALWAYS allow the pump to cool for at least
30 minutes when storing it after use.
3. Remove, drain and dry the suction and discharge
hoses and clean around the inlet and outlet openings.
Ensure all other water is also drained from the pump.
4. Drain the fuel from the engine before storage
(see 10.5 Draining the Fuel).
5. Drain the engine oil (see 10.3 Changing the
Engine Oil).
6. Cover the pump with a plastic sheet to protect it
against dust and moisture.
Observe the following points when storing the pump:
• Store the pump in a dry and dust-free environment,
out of reach of children.
• Store the pump in its operating position.
− NEVER store the pump on its side as this may
cause fuel or oil to leak and damage the pump or
the surrounding property.
− Where possible, secure the pump in its upright
position to prevent it from tipping over while
unattended.
• Prepare and run the engine at periodic intervals to
prevent seizure within the engine and driveshaft.

– 20 –
EN
10.9 Periodic Maintenance
Item Remarks Pre-
operation
check
(daily)
Initial 1
month
or 20hrs
Every 3
months
or 50hrs
Every 6
months
or
100hrs
Every 12
months
or
300hrs
Spark plug Check condition, adjust
gap and clean. Replace
if necessary.
•
Engine oil Check oil level. •
Replace. • •
Air lter Clean. Replace if
necessary. •
Fuel lter Clean fuel drain lter.
Replace if necessary. •
Valve clearance Check and adjust when
engine is cold. •
Fuel line Check fuel hose for
cracks or damage.
Replace if necessary.
•
Exhaust system Check for leakage.
Retighten or replace
gasket if necessary.
•
Check muer screen.
Clean/replace if
necessary.
•
Carburettor Check choke operation. •
Starting system Check key start ignition
operation. •
Decarbonisation More frequently if
necessary. •
Fittings/fasteners Check all ttings and
fasteners correct if
necessary.
•
Regular maintenance is most important for the best performance and safe operation. For guidance relating to any of
the listed procedures, contact the Draper Helpline; details can be found on the back page of this manual.
10. Maintenance and Storage
