DRAX REDON RX9200 User manual

Be sure to read the manual before using the product in order to use safely and
correctly. Please keep user manual at a place to be available easily.

USER’S MANUAL RX9300 / RX9200 Series
V1.3

1. GETTING STARTED
2. INSTALLATION
- PRECAUTIONS
- PART NAME
- HOW TO MAKE INSTALLATION
- GROUNDING INSTRUCTIONS
- CENTERING THE BELT
3. USING THE TREADMILL
- DISPLAY CONSOLE
- USING WORKOUTS
4. SPECIFICATIONS
5. MAINTENANCE
6. LIMITED WARRANTY
2
3
3
3
4
5
6
7
7
11
15
16
19
CONTENTS

1 GETTING STARTED
[IMPORTANT SAFETY INSTRUCTIONS]
Read all instruction before using the treadmill.
To reduce the risk of electrical shock. Always unplug this REDON
before cleaning or attempting any maintenance activity.
Danger
• To reduce the risk of burns, fire, electric shock or injury, it is imperative to connect each product
to a properly grounded electrical outlet.
• To disconnect, turn power OFF at the ON/OFF switch, then remove plug from electrical outlet.
•
Never operate a REDON if it has damaged power cord or electrical plug, or if is has been dropped,
damaged, or even partially immersed in water. Contact DRAX INC. Customer Support Services.
• Position this product so the power cord plug is accessible the the user.
•
Keep the power cord away from heated surfaces. Do not pull the equipment by the power cord
or use the cord as a handle. Do not run the power cord on the floor under or along the side of
the treadmill.
•
If the electrical supply cord is damaged it must be replaced by the manufacturer, an authorized
service agent, or a similarly qualified person to avoid a hazard.
• Do not use this product in areas where aerosol spray products are being used or where oxygen
is being administered. Such substances create the danger of combustion and explosion.
• Always follow the console instructions for proper operation.
• Close supervision is necessary when used by, on, or near children, invalids or disabled persons.
• Do not this product outdoors, near swimming pools or in areas of high humidity.
• Never operate a REDON with the air openings blocked. Keep air openings free of lint, hair or any
obstructing material.
•
Never insert objects into any opening in this product. If an object should drop inside, turn off the
power, unplug the power cord from the outlet and carefully retrieve it.
• If the item cannot be reached, contact DRAX INC. Customer Support Services.
• Never place liquids of any type directly on the unit, except in an accessory tray or holder.
• Containers with lids are recommended.
• Wear shoes with rubber or high-traction soles. Do not use shoes with heels. Leather soles.
• Cleats or spikes. Make sure no stones are embedded in the soles.
• Keep all loose clothing, shoelaces and towels away from moving parts.
• Do not use this product in bare feet.
• Donot reach into or underneath the unit, or tip it on its side during operation.
•
Keep the area 2 meters by 1meter behind the treadmill clear of any obstructions, including walls,
furniture, and other equipment.
• Handrails may be held to enhance stability as needed, but are not for continuous use.
• Never mount or dismount the treadmill while the running belt is moving. Use the handrails
whenever additional stability is required. In case of an emergency, such as tripping, the hand-
rails should be grabed and the user should place his/her feet on the side platforms.
• Never walk or jog backwards on the treadmill.
• Use this appliance only forits intended use as described in this manual. Do not use attachments
not recommended by the manufacturer.
• There shall be a safe space of 2,000 × 1,000 mm (78.7” x 39.4”) behind the treadmill.
Warning
REDON
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
REDON
2

2 INSTALLATION
PRECAUTIONS _
The treadmill should be installed on a flat place with even leveling. If the treadmill is placed on an
unstavle pad or carpet, the belt may not be correctly arranged, and will be a cause to be overloaded.
In such a case, be sure to use the machine after you place the machine on a firm and flat object such
as plywood. Make sure that enought space is secured in front of the treadmill so that you may find it
easy to operate the power switch.
Please be sure to use a standardized plug which should be grounded.
PART NAME _
① Console Display
④ Handrail
⑦ Motor Cover
⑩ Base
⑬ Running Belt
② Touch Heart Rate Sensor
⑤ Emergency Key
⑧ Incline
⑪ Belt Adjusting Screw
③ Front Handrail
⑥ Support
⑨ Foot
⑫ Foot Rail
3

HOW TO MAKE INSTALLATION _
Please set a suitable place to install REDON according to the following requirements :
(1) A place where the base is flat. (if the base is not even condition, it may cause vibrations)
(2) Please place the power cord at a secluded place.
(3) Open the motor cover, insert the support and lock with M12 screw.
Please throw the cable to support as follow pictures.
(5)
Assemble front handrail including Emergency Key and Touch Heart Rate Sensor. Pull out cables
from left Support throughout the left Handrail.
(6) Assemble console back panel by fixing Console Support to Handrail. Cover and assemble console
front panel.
Cation :
Before cover console front panel connect Emergency Key cable and Touch Heart Rate
Sensor cable from handrail to console board.
(7) Turn the power On and check treadmill operation.
(4)
Assemble the handrail with support. Pull out the main cable from right support throughout the handrail.
4
REDON

GROUNDING INSTRUCTIONS _
This product must be grounded. If it should malfunctions or breaks down, proper grounding provides
a path of least resistance for the electric current, which reduces the risk of shock to anyone touching
or using the equipment. Each unit is equipped with an electrical cord, which includes an equipment
grounding conductor and a grounding plug. The plug must be inserted into an outlet that has been
properly installed and grounded in accordance with all local codes and ordinances.
A risk of electrical shock may result from improper connection of
the equipment-grounding conductor. Check with a qualified elec-
trician if in doubt as to proper grounding technique. DO NOT modify the plug provided with the
product. If it will not fit an electrical outlet, have a proper outlet installed by a qualified electrician.
This product is for use on a circuit having an nominal rating of 240 volts and is factory equipped
with a specific cord and plug to permit connection to a proper electric circuit. Make sure that the
product is connected to an outlet having the same configuration as the plug. No adapter should
be used with this product. If the product must be reconnected for use one a different type of
electric circuit, the reconnection must be made by qualified service personnel.
Danger
5

CENTERING THE BELT _
After the treadmill has been installed and leveled, the belt must be checked to confirm proper tracking.
First, plug the power cord into an appropriate outlet and turn the treadmill ON. The first person stands
on the sides of the treadmill and straddles the belt, not standing on it at this time. Press the Quick Start
key and increase the speed to 4km/h using the Speed up-arrow.
While the treadmill is running, if the striding belt moves to the right, the second person turns the right
tension bolt 1/4 turn clockwise and then turns the left tension bolt 1/4 turn counter-clock-wise(see
figure). This sets the striding belt tracking back to center of roller. If the striding belt moves to the left,
turn the left tension bolt 1/4 turn clockwise and then turn the right tension bolt 1/4 turn counterclock-
wise to start striding belt tracking back to center of roller. Repeat adjustments until striding belt appears
centered. Allow machine to continue running for several minutes to observed if tracking remains stabilized.
NOTE :
Do not exceed one full turn of the adjusting
screws in either direction. If after one full
turn the belt does not track properly, con-
tact Customer Support Services.
6
REDON

3 USING THE TREADMILL
DISPLAY CONSOLE _
The computerized display console is easy to use. It allows an individual to follow the progress of a workout.
The on-board computer allows a workout to be tailored to individual fitness capabilities and goals while
providing a unique means of measuring fitness improvement from one workout to the next.
SPEED SYNC EXCTING MODE SPEED SYNC COMFORTABLE MODE
① FND Window
③ Focus Key
⑤ Speed
⑦ Time
⑨ Pause
⑪ Start
⑬ Workout Mode
② Message Window
④ Key Pad
⑥ Incline
⑧ Cool Down
⑩ Stop
⑫ Speed Sync
7

① FND WINDOW
Displays a matrix of LED lights displaying the current position and the upcoming terrain. While striding,
the light columns move across the screen from right to left. The higher the column of lights, the greater
the incline and workout intensity.
② MESSAGE WINDOW
Provides simple step-by-step instructions motivational messages.
Display : INCLINE TIME HEART RATE CALORIES DISTANCE SPEED.
③ FOCUS KEY
- INCLINE FOCUS KEY :
Pressing this key will display the present incline in Workout Profile Window
and easy to see the present incline.
- TIME FOCUS KEY : During workout, pressing this key will display the workout time or remained
time in Workout Profile Window and easy to see the present incline. Pressing this key when stop
the Time Goal Workout start.
- HEART RATE FOCUS KEY :
Pressing this key will display user’s heart rate in Workout Profile Window
if heartrate detected and easy to see the user’s Heart Rate.
- CALORIES FOCUS KEY :
During workout, pressing this key will display the workout calories or re-
mained calories in Workout Profile Window and easy to see the Calories. Pressing this key when
stop the Calories Goal Workout start.
- DISTANCE FOCUS KEY :
During workout pressing this key will display the workout distance or re-
mained distance in Workout Profile Window and easy to see the present Distance. Pressing this
key when stop the Distance Goal Workout start.
- SPEED FOCUS KEY : Pressing this key will display the present speed in Workout Profile Window
and easy to see the present Speed.
④ KEY PAD
-
Numeric keys : Use these keys to enter exercise time, difficulty level,
belt speed, weight, distance, goal selection and target heart rate.
-
Clear Key : Press this key once to clear data not yet entered. Press
twice in succession while programming to reset unit and beging the
programming sequence again.
- Enter Key : This key is used to enter the data displayed in the
message center.
8
REDON

⑤ SPEED
Press these keys to increase or decrease the belt speed.
The adjacent window above keys displays the input. In addi-
tion, any of these keys may be pressed to begin a workout
or programming.
⑥ INCLINE
Press these keys to increase or decrease the incline of the
treadmill deck. The adjacent window above keys displays
the input. In Auto Incline Change mode, pressing ▲ or ▼
will continuously incline increase or decrease and pressing
same key one more will stop incline.
⑦ TIME
Press these keys to increase or decrease the workout time.
The adjacent window above the keys displays the input. In
addition, any of these keys may be pressed to begin a work-
out or programming.
⑧ COOL DOWN
Begins an automatically customized cool-down protocol.
⑨ PAUSE
Stops the belt and holds the current workout until resumed
when the Enter key is pressed or the maximum pause duration
is reached.
⑩ STOP
Pressing this key will stop the striding belt and end the cur-
rent workout.
⑪ START
Allows user to quickly enter a manual workout with the
press of one key.
9

⑫ SPEED SYNC
Press this key to use automatic speed control system.
⑬ WORKOUT MODE
Press this key to choose workout mode.
- MANUAL : Goal workout.
- CARDIO : 80% of a theoretical maximum heart rate.
-
FAT BURN : 65% of a theoretical maximum heart rate
- MARATHON : Full, Half, 10km/h, 5km/h and R -Link
(wireless communication, Option) can be selected.
Speed Sync Exciting
High speed variation using full speed
limitation.
Speed Sync Comfortable
Low speed variation using 10km/h
speed limitation.
10
REDON

USING WORKOUTS _
Selecting the REDON workout is as easy as pushing a key.
The following are preprogrammed workouts for this product.
QUICK START
is the fastest way to begin exercising, and allows the user to start a manual workout by pressing a
single key.
MANUAL MODE (GOAL Workout)
The trainer can define up to 3 different Goal workouts consisting of a pre-defined incline, target
calories or target time.
You can see the mark of Manual Mode in Workout Profile Window during goal workout.
MANUAL
ENTER
SET TIME
SET DISTANCE
SET CALORIES
TIME GOAL
DISTANCE GOAL
CALORIES GOAL
START
ENTER ENTER
CLEAR
SET WEIGHT
Automatic weight
measuring
11

FAT BURN
is a workout offering a low intensity way to burn fat. The Fat Burn workout will automatically
change the resistance level to maintain the heart rate at 65% of theoretical maximum.
You can see the mark of Fat Burn in Workout Profile Window during Fat Burn workout.
NOTE : To use the FAT BURN and CARDIO workout , the user grasps the stainless steel sensors
on the handlebars or use the optional Heart Rate chest strap when the display console prompts,
or any time the user wishes to check the heart rate. There are four sensors, two on each of the
handlebars. Contact must be made with all four sensors to obtain a heart rate. The console will
display a heart rate in 20~30 seconds. Do not attempt to grasp the touch heart rate sensors above
7km/h. For speeds above 7km/h, the use of a heart rate chest strap is recommended.
FAT BURN
ENTER
SET TIMESET WEIGHT
SET HEART RATE
ENTER ENTER
SET AGE
ENTER
SET SPEED START
Setting the start speed
12
REDON

CARDIO MODE
is a higher intensity workout emphasizing cardiovascular benefits and maximum fat burning for more
fit users. The Cardio Workout will automatically change the effort level to maintain the heart rate at
80% of the theoretical maximum.
You can see the mark of Cardio Mode in Workout Profile Window during Cardio workout.
NOTE : Both the Fat Burn and Cardio workouts measure heart rate. Wear an optional telemetry
heart rate chest strap and the heart rate will be transmitted to the onboard continuously. The
optional heart rate chest strap allows the on-board, Polar compatible, telemetry heart rate feature
of this product to continuously monitor the heart rate and in many workouts adjusts aspects of
the workout such as resistance level.
CARDIO
ENTER
SET TIMESET WEIGHT
SET HEART RATE
ENTER ENTER
SET AGE
ENTER
SET SPEED START
Setting the start speed
13

PROGRAM MODE
is an interval training workout consisting of a combination of hills and valleys proven to provide
effective, time-efficient cardiovascular results.
PROGRAM
ENTER
SET WEIGHT
HILL 1
HILL 2
HILL 2
RUN 1
RUN 2
INTERVAL 1
INTERVAL 2
ENTER
START
MARATHON MODE
is an marathon workout consisting of a FULL, HALF, 10km, 5km road profile.
MARATHON
ENTER
SET WEIGHT
FULL 1
FULL 2
HALF 1
HALF2
5 km
10 km
ENTER
START
14
REDON

4 SPECIFICATION
Spec
REDON
Speed Range
Speed Syncronizing System™
(Patent Pending)
Auto Safety Stop
Inclination
Drive Motor
Roller Diameter
Track Size
Product Dimensions
Max. allowable W.T.
Weight
Display Type
Display Information
Workout Program
Heart-Rate
Electric Power
Safety Function
RX9300S
0.8 ~ 20km/h (0.5 ~ 12.4 mph)
●
●
0 ~ 20% (Dual Incline
System™ - Patent Pending)
AC 2HP
(Max. 3HP treadmill duty)
Ø100mm (3.9”)
1620 x 520 mm
(63.8” x 20.5”) L x W
2184 x 933 x 1537 mm
(86” x 36.7” x 60.5”) L x W x H
180kg (400 lbs)
190kg (420 lbs)
Multi-color 16x48
Dot Matrix LED, 6 FND
Speed Range, Inclination,
Time, Distance, Calorie,
Heart-Rate
MANUAL, FAT BURN, CARDIO,
PROGRAM, MARATHON
Intelligent Heart Rate
Control with Hand Touch
Sensor or Polar Telemetry
System
Emergency Stop Button
Supported
Auto Belt Tension System
Smart Shock Absorption
System
Message Focus
Display Function™
Polar Heart Rate Receiver
R-Link wireless communication
System among machines
Other Feafures
Options
15
RX9200S
0.8 ~ 16km/h (0.5 ~ 10 mph)
●
●
0 ~ 16% (Dual Incline
System™ - Patent Pending)
AC 2HP
(Max. 3HP treadmill duty)
Ø100mm (3.9”)
1620 x 520 mm
(63.8” x 20.5”) L x W
2184 x 933 x 1537 mm
(86” x 36.7” x 60.5”) L x W x H
180kg (400 lbs)
190kg (420 lbs)
Multi-color 16x48
Dot Matrix LED, 6 FND
Speed Range, Inclination,
Time, Distance, Calorie,
Heart-Rate
MANUAL, FAT BURN, CARDIO,
PROGRAM, MARATHON
Intelligent Heart Rate
Control with Hand Touch
Sensor or Polar Telemetry
System
Emergency Stop Button
Supported
Auto Belt Tension System
Smart Shock Absorption
System
Message Focus
Display Function™
Polar Heart Rate Receiver
R-Link wireless communication
System among machines
RX9200
0.8 ~ 16km/h (0.5 ~ 10 mph)
0 ~ 16% (Dual Incline
System™ - Patent Pending)
AC 2HP
(Max. 3HP treadmill duty)
Ø100mm (3.9”)
1620 x 520 mm
(63.8” x 20.5”) L x W
2184 x 933 x 1537 mm
(86” x 36.7” x 60.5”) L x W x H
180kg (400 lbs)
190kg (420 lbs)
Multi-color 16x48
Dot Matrix LED, 6 FND
Speed Range, Inclination,
Time, Distance, Calorie,
Heart-Rate
MANUAL, FAT BURN, CARDIO,
PROGRAM, MARATHON
Intelligent Heart Rate
Control with Hand Touch
Sensor or Polar Telemetry
System
AC 220-230V, 50/60Hz, 2.2kW (EU)
AC 100-120V, 50/60Hz, 2.2kW (US)
AC 220-230V, 50/60Hz, 2.2kW (EU)
AC 100-120V, 50/60Hz, 2.2kW (US)
AC 220-230V, 50/60Hz, 2.2kW (EU)
AC 100-120V, 50/60Hz, 2.2kW (US)
Emergency Stop Button
Supported
Auto Belt Tension System
Smart Shock Absorption
System
Message Focus
Display Function™
-
-
Polar Heart Rate Receiver
R-Link wireless communication
System among machines
RX9300
0.8 ~ 20km/h (0.5 ~ 12.4 mph)
0 ~ 20% (Dual Incline
System™ - Patent Pending)
AC 2HP
(Max. 3HP treadmill duty)
Ø100mm (3.9”)
1620 x 520 mm
(63.8” x 20.5”) L x W
2184 x 933 x 1537 mm
(86” x 36.7” x 60.5”) L x W x H
180kg (400 lbs)
190kg (420 lbs)
Multi-color 16x48
Dot Matrix LED, 6 FND
Speed Range, Inclination,
Time, Distance, Calorie,
Heart-Rate
MANUAL, FAT BURN, CARDIO,
PROGRAM, MARATHON
Intelligent Heart Rate
Control with Hand Touch
Sensor or Polar Telemetry
System
AC 220-230V, 50/60Hz, 2.2kW (EU)
AC 100-120V, 50/60Hz, 2.2kW (US)
Emergency Stop Button
Supported
Auto Belt Tension System
Smart Shock Absorption
System
Message Focus
Display Function™
-
-
Polar Heart Rate Receiver
R-Link wireless communication
System among machines

6 MAINTENANCE
TROUBLE SHOOTING _
• Machine has no power
- Check the power supply by plugging another device into the power point.
- Check the power switch on the machine.
- Check the power cord is connected properly at both ends.
- Remove the power cord from the power supply and inspect it for damage.
- If the problem continues contact DRAX INC. Customer Support Center.
• Treadmill Belt is slipping
- Refer to section 2.5 of this manual ‒ Adjustment of Belt Tension.
• Rubbing or scraping sound coming from the machine
- Check for any foreign objects that might be lodged underneath the machine.
- Check the tracking of the running belt.
• Speed Sync feature is unresponsive
- Switch the treadmill off at the power supply and wait for 1 minute.
Then switch the power back on re starting the treadmill. Note: Make sure that there is no one on
the treadmill during the start up. The treadmill calibrates the load cells under the treadmill deck
during start up. If there is weight on the deck during this period the machine will not calibrate correctly
causing the Speed Sync to be un responsive.
• Treadmill Suddenly Stops
- Check that the Emergency-stop hasn’t been activated.
Always only use the grounding type power cord that is supplied with
the exercise equipment.
Notice
Please Contact DRAX INC. Customer Support Center for assistance.
Notice
16
REDON

MAINTENANCE _
• Cleaning the unit
-
Spray a clean cloth with a mild cleaning agent, such as a water and dish soap solution and wipe the
unit with the damp cloth.
- Do not spray cleaning solution directly on the unit. Direct spraying could cause damage to electronics
and may void warranty.
- Do not use harsh cleaning products that contain ammonia or acids.
- Keep the area around the unit clean and free from dust.
• Inspect the unit
visually inspect the unit for and damage or loose bolts.
• Test the unit
-
Test all of the units functions and adjustments and listen for any abnormal noises.
- Before using the treadmill, check if any foreign substances are stuck on the running belt or deck.
- Check if the running belt of treadmill is twisted.
- To adjust the running belt, refer to this manual or contact the customer center.
• Check running alignment and tension
- Refer to section 2.5 of this manual
- Adjustment of Belt Tension.
• Prevention for defect of heart rate (pulse) detector
If the heart rate (pulse) is irregular or abnormal, then do the following.
- Use the sensor so that it can be touched by the hand.
- Clean the exterior of the sensor by using a moist cloth.
- If necessary, dry your hands so that your hands do not slip.
- Apply a constant pressure to the sensor.
Notice
Always disconnect power supply when servicing/cleaning or during
extended periods of non-operation of this exercise equipment.
Do not attempt to disassemble this exercise equipment. Only use authorized service providers
to service this equipment. Do not operate this exercise equipment if damaged or if any abnormal
noises are heard. Please Contact DRAX INC. Customer Support Center for assistance.
17

* Use horizontal indicator to check.
• Product Management Schedule
Please follow the following schedule for maintenance of product and prevention of defects.
Component Weekly
Clean
Clean
Inspect
Inspect
Inspect
Clean
Clean / Inspect
Clean
Clean
Clean
Clean
*Inspect
Monthly
Common
Inspect
Inspect
Inspect / Adjust
Vacuum Clean
Twice a YearQuarterly
Inspect
Inspect
Inspect
Inspect
Inspect
Inspect
Inspect
Inspect
Inspect
Inspect
Inspect
Yearly
Display
Switch
USB, Audio port
Cup holder
E-Stop Switch
Front Handle
Side Handrail
Moto Cover
Motor Room
Motor Belt
Level Foot
Running Belt
Front Roller
Rear Roller
Running Deck
Sensor
Bolts / Nuts
Frame, Rear Cover
Belt Alignment
Machine horizontal
Please use a soft, light cloth when you clean the exterior of product.
R
ather than cleaning the product directly, clean it by using a vacuum
cleaner after using a cloth.
Notice
18
REDON

6 LIMITED WARRANTY
1. DRAX warrants this product to be free from defects in workmanship and material, under normal use
and seruce cibdutuibsm for a period of one year from the date of purchase(Running Belt and Motor
Belt for six months from the date of purchase). This warranty extends only to the original purchaser.
DRAX obigatio nunder this warranty is limited to replacing or repairing, at DRAX option, the product
at one of its authorized service centers. All products for which warranty claim is made must be received
by DRAX at one of its authorized service centers with all freight and other transportation charges prepaid,
accompanied by sufficient proof of purchase. All returns must be pre-autorized by DRAX. This warranty
does not extend to any product or damage to a product caused by or attributable to DRAX authorized
service center, to products used for specifically set forth above is authorized by DRAX.
2.
DRAX is not responsible or liable for indirect, special or con sequential damages arising out of or in
connection with the use or performance of the product or damages with respect to any economic loss,
loss of property, loss of revenues or profits, loss of enjoyment or use, costs of removal, installation or
ot her consequential damages of whatsoever nature.
3.
The warranty extended hereunded is in lieu of any and all other warranties and aony implied warranties
of merchantability or fitness for a particual purpose is limited in its scope and duration to the terms
set forth herein.
Product Name
Model Name
Serial No.
Warranty Period
Purchase Date
REDON RX9300 / RX9200 Series
19
