Drayton Lifestyle LP111 User manual

Changing the timings
Press the SET? button and you’ll see ‘SETPROG?’.
Set all weekdays
Firstyou set the times that are goingtobethe same for each
weekday, then you can select each day individually and make
any further adjustments. If you want eachdaytobequite
different, go straight to ‘Set each day’.
Press the YES button, and the display will ask ‘SETMONtoFRI
PROG?’.
Press YESandyou’ll see ON1, the start of yourfirstheating peri-
od. Adjust it in 1-minute steps usingthe–and + buttons.
If the–and + buttons are held down,the time changes in
10-minute steps.
Press SET?, and you’ll see OFF1, the end of your firstheating
period. Adjustthis in the same way, press SET?, then repeat
theprocedure for ON2, OFF2, ON3andOFF3.
Set eachday
If, after you’ve set OFF3 you want to fine-tune one or more
weekdays, press SET? until you find thefirst day you want to
adjust – then go throughtheprocedure, altering any time you
wish.Press SET? to move on to the next day. When you’ve
finished, press SET? until you see ‘SET SAT SUNPROG?’.
If you don’t want to alter any individual days, keeppressing
SET? until yousee ‘SET SAT SUNPROG?’.
Set weekend
Press YESand alter ON1, OFF1, ON2, OFF2, ON3 and OFF3
times in the same way.
Set eachday
If, after you’ve set OFF3 for both SAT & SUN, youwant to fine-
tune Saturday or Sunday, press SET? until you find the firstday
you want to adjust – then go through the procedure, alteringany
time you wish.Press SET? to move on to the next day. When
you press SET? after setting yourhot water for Sundays, the pro-
grammer will go back to normal operation.
If you don’t want to alter either day, keep pressing SET?
until theprogrammer goes back to normal operation.
SAT
THELP112 24hr ELECTRONICPROGRAMMER
LP112–a24hr program, with linked central heating and hot
water on for up to 3 heating periods each day, and everyday
the same.
If the timings haven’t been set for you,then your programmer
will still be on the factory-set standard 24hrprogram, with
central heating and hot water operating together on the
same settings for everyday of the week.But it’s easy to
make changes–just followtheinstructions.
Want to leaveatiming as it is? Press SET? and move on to
thenext one.
If you need to reset your timings to thestandard program
and start again,press ‘SET’ and ‘+’ together to go back to
the pre-set program.
If you don’t press anythingfortwo minutes, theprogrammer
automatically goesback to normal operation.
The standard program
Your system will comeonfor up to 3 heating periods every
24hrs. ON1 startsthefirstone, OFF1 finishesit, and so on.
Noticethat on the standardprogram ON2 and OFF2 are set
to the same time.* This means your system won’trespond,
but if you want to activate that middle period, or change any
other timings–read on.
Changing thetimings
Press the SET? button and you’ll see ‘SETPROG?’.
Press the YES button, and you’ll see ON1, the start of yourfirst
heating period. Adjust it in 1-minute steps using the – and +
buttons. If the–and + buttons areheld down,thetime changes
in 10-minute steps.
Press SET?, and you’ll see OFF1, the end of your firstheating
period. Adjustthis in the same way, press SET?, then repeat the
procedure for ON2, OFF2, ON3 and OFF3.
When youpress SET? after setting OFF3, theprogrammer will
return to normal operation.
THELP241 24hr ELECTRONICPROGRAMMER
LP241–a24hr program, with central heating and hot water
workingindependently for up to 3 heatingperiods eachday,
and every day thesame.
If the timings haven’t been set for you,then your programmer
will still be on the factory-set standard 24hrprogram, with
central heating and hot water operating together on the
same timings for every day of the week. But it’s easy to make
changes, and have heating and water workingindependently
– just follow the instructions.
Want to leaveatiming as it is? Press SET? and move on to
thenext one.
If you need to reset your timings to thestandard program
and start again,press ‘SET’ and ‘+’ together to go back to
the pre-set program.
If you don’t press anythingfortwo minutes, theprogrammer
automatically goesback to normal operation.
Thestandard program
Your systemwill come on for up to3heating periods every 24hrs.
ON1startsthe first one, OFF1 finishes it, and so on. Notice that on
thestandardprogramON2 and OFF2are set to the same timefor
bothcentral heating and hot water.*This means your system won’t
respond,butifyou want to activatethatmiddle period, or change
any other timings–read on.
Changing the timings
Press the SET? button and you’ll see ‘SETPROG?’.
DUAL
CHANNEL
LP112,LP241, LP522, LP722
SINGLE
CHANNEL
for heating OR hot water
LP111, LP711
Technical Helpline: 0333 7000 622
Email: [email protected]
Web: www.draytoncontrols.co.uk
for heating AND hot water
Installation Instructions
06490033001 ISS L
DUAL
CHANNEL
LP112,LP241,LP522,LP722
SINGLE
CHANNEL
User’s Instructions
TIMESWITCHES
for heating OR hot water
LP111,LP711
Technical Helpline: 0333 7000 622
Email: [email protected]
Web: www.draytoncontrols.co.uk
for heating AND hot water
User Instructions
06490033001 ISS L
INSTALLATION INSTRUCTIONS
PLEASE NOTE: INSTALLATIONMUST ONLY BE
CARRIED OUT BY A QUALIFIED ELECTRICIAN OR
HEATING ENGINEER.
MAKE SUREMAINS INPUT HASA3AMPFUSE.
TECHNICAL DATA
LifestyleProgrammers and Timeswitchesconform to the
essential requirements of these Directives:
2014/30/EU– Electromagnetic Compatibility Directive
2014/35/EU– Low Voltage Directive
BEFOREINSTALLATION
First, make sure the mainssupply is switched off!
PROGRAMMER ONLY
The programmer must be settothetype of system it is to con-
trol. The link on the back of the unithastwo settings –Pand G.
P = a fully pumpedand controlled system–allowing
heatingand hot water to be set separately.
G=agravity-fed hot water system – which does not allow
independentsetting of heating without hot water, though
hot water canbecontrolled alone.
USING AN EXISTING WALL-PLATE
Loosen the securingscrews on the old programmer and
unplug it. Check thatthere’s 70mm clearancetothe right of
the wall-plate,and25mmaboveit. Check the chart on the
nextpagetocompareterminals and if necessary, change the
wiring of the wall-plate to suit. Nowplug the Lifestyle unitinto
the wall-plateandtighten thesecuring screws.
Checkthe 3A fuse, andswitch on the mains.
FITTINGANEW WALL-PLATE
The ideal location is 1.4m above floor level, with reasonable
lighting, goodaccess, no condensation, no extremes of
temperature,andasupporting surface that fully covers the
back of the unit.
Position with 70mm clearancetotheright, 25mm above, and
sufficient room to accessthesecuring screws underneath.
Fix,withterminals at the top, either direct toaflat wall using wall
plugs and No. 6 x 1” (25mm) woodscrews, or on a flush mount-
ing single conduit boxtype UA1 (BS4662) using M3.5 x 14 bolts.
DO NOTUSEASURFACE MOUNTING BOX.
WIRINGTHETIMESWITCH
Make the wiringconnections as
above. Note that the output
contactsare voltage-free, so
powerneeds to be put on to
Terminal 1 either by linkingfrom
Terminal L or from a separate
supply with a 3A fuse.
WIRINGTHEPROGRAMMER
Arrowed numbers relate to
the junction box.
Consult boiler handbook
for details of pump
overrun wiring.
Connection Charts
Wiring Colour Codes
GR Grey
Y Yellow
BK Black
BL Blue
BR Brown
RD Red
WWhite
OR Orange
YG Yellow/Green
C Common
H Callfor Heat
SSatisfied
N Neutral
E Earth
LLive
*Thermostat Key
USING ADRAYTON SIMP-L-FIT, ALTHOUGH NOT
NECESSARY, WILL MAKE THIS INSTALLATION EASIER.
SWITCHINGSTANDARD PROGRAM
CH HW
ON 1 – start of firsttimedperiod 6.30am6.30am
OFF 1 – end of firsttimedperiod 8.30am8.30am
ON 2 – start of second timedperiod* 12.00pm12.00pm
OFF 2 – end of second timedperiod* 12.00pm12.00pm
ON 3 – start of thirdtimedperiod 4.30pm4.30pm
OFF 3 – final switch-off of theday10.30pm10.30pm
User’s Instructions
PROGRAMMERS
SWITCHING STANDARD PROGRAM
ON 1 – start of firsttimedperiod 6.30am
OFF 1 – end of firsttimedperiod 8.30am
ON 2 – start of second timedperiod* 12.00pm
OFF 2 – end of second timedperiod* 12.00pm
ON 3 – start of thirdtimedperiod 4.30pm
OFF 3 – final switch-off of theday10.30pm
INTRODUCTIONCont...
SWITCHING
ON 1 – start of firsttimedperiod
OFF 1 – end of firsttimedperiod
ON 2 – start of second timedperiod
OFF 2 – end of second timedperiod
ON 3 – start of thirdtimedperiod
OFF 3 – final switch-off of theday
INTRODUCTION
Lifestyle Timeswitches will automatically control yoursystem
by switching it on and off at times that suit you.Theredlight
on thefront of the timeswitchshows when it’s on.
LP111 –a24hr program, up to3heatingperiods
eachday, andeveryday the same.
LP711 –a7-dayprogram,allowingfor different
timings on eachday of the week, up to 3 heating periods
eachday.
If theengineer hasn’tsetyour timingsfor you,your timeswitch
willworkwith a standardprogram that has beenset at the
factory. If this doesn’t suityou, it’s veryeasy to change it –
when you’veread this introductorysection,simply turn to
the pageforyour timeswitch model.
Remember:
Makeyour changes using the SET?,YES/-,and + buttons.
You can’tsetON1 as the lasttimingbeforemidnight, but you
cansetOFF3after midnight–providing it’s not more than 23
hours and 59 minutes afterON1.
You need to set the timings in sequence – i.e. ON1, OFF1, ON2,
OFF2, ON3,OFF3.Ifyouget out of sequence, the display will
flash a warning.
SINGLE
CHANNEL
Timeswitch
DUAL
CHANNEL
Programmer
Lifestyle
SINGLE
CHANNEL
Timeswitch
DUAL
CHANNEL
Programmer
Lifestyle
What isaprogrammer?
...an explanation for householders
Programmers allow you to set ‘On’ and ‘Off’ time periods.
Some models switch the central heating and domestic hot
water on and off at the same time, while others allow the
domestic hot water and heating to come on and go off at
different times.
Set the ‘On’ and ‘Off’ time periods to suit your own lifestyle.
On some programmers you must also set whether you want
the heating and hot water to run continuously, run under the
chosen ‘On’ and ‘Off’ heating periods, or be permanently off.
The time on the programmer must be correct. Some types
have to be adjusted in spring and autumn at the changes
between Greenwich Mean Time and British Summer Time.
You may be able to temporarily adjust the heating pro-
gramme, for example, ‘Override’, ‘Advance’ or ‘Boost’. These
are explained in the manufacturer’s instructions.
The heating will not work if the room thermostat has switched
the heating off. And, if you haveahot-water cylinder, the
water heating will not work if the cylinder thermostat detects
that the hot water has reached the correct temperature.
If theengineer has set yourprogram and timings–you won’t
need to do anythingelse. Just keep this guide inasafe place
forfuturereference.
Sometimes you might need to change theway you use your
system temporarily – perhapsdue to an exceptionally coldday.
Here’s how to do it–without affectingthe timings in your
program.
DAY-TO-DAY VARIATIONS
THE LP111 24hr ELECTRONIC TIMESWITCH
Switching on and off
Over-ridingthe program
OFF= continuously off.
TIMED = on for up to 3 periods a day.
ONCE= on for 1 periodaday, from the start of ON1
to the end of OFF3.
ON = continuously on.
At the side of the display there are
four operating modes:
UsetheSELECT button under the flap to change the mode.
Thiswon’talter the timings in your program, whichyoucan
return to by selecting TIMED.
LP111–a24hrprogram, up to 3 heatingperiods each day,
and every day the same.
Want to leaveatiming as it is? Just press SET? and move on
to thenext one.
If you need to reset your timings to the standard program
and start again,press ‘SET’ and ‘+’ together to go back to
thepre-set program.
Thestandard program
Your systemwill comeonfor up to 3 heating periods every
24hrs.ON1starts the firstone,OFF1finishes it, andsoon.
Notice that ON2andOFF2aresettothesame time.*This
meansyour systemwon’trespond, but if youwanttoactivate
that middleperiod or change any othertimings–readon.
SWITCHING STANDARD PROGRAM
ON 1 – start of firsttimedperiod 6.30am
OFF 1 – end of firsttimedperiod 8.30am
ON 2 – start of second timedperiod* 12.00pm
OFF 2 – end of second timedperiod* 12.00pm
ON 3 – start of thirdtimedperiod 4.30pm
OFF 3 – final switch-off of theday10.30pm
Press the YES button,andyou’llseeON1, the start of your
first heatingperiod. Adjust it in 1-minute steps using the –
and + buttons. If the–and + buttons are held down, the
time changes in 10-minute steps.
Press SET?,andyou’ll see OFF1, theend of your first heating
period.Adjust this in the same way, pressSET?, thenrepeat the
procedure forON2,OFF2,ON3andOFF3.
WhenyoupressSET?after settingOFF3, the timeswitchwill
return to normaloperation.
On thefront of the timeswitch there is an Advance/Boostbutton.
It allowsyoutoswitchyour systemeither on or off, irrespective of
the program. So if the heatingisoff, andyou want warmth now,
youcaneither –
1. Press Advanceto switch it on (ADV will be displayed), and it will
stay on untiltheend of the nextperiod.Orifthe heating is on
andyoudon’tneedit,press Advanceanditwillgooff untilthe
beginning of the nextONperiod.
Advancewillonlyoperate in TIMEDorONCE modes.
2. Press&HoldBoostto switch on for an extra hour ( & BST will
be displayed), then Pressagainfortwo ( ) or three ( ) hours.
To cancelBoost, PressBoost again ( ). Or if the heating is
alreadyon, usingBoostwillextend the ON time by one,two or
threehours.
Changing the timings
Press the SET? buttonandyou’llsee‘SET PROG?’.
If theengineerhas set your program and timings–you
wontneed to do anythingelse. Just keepthis guide inasafe
placeforfuturereference.
INTRODUCTION
Thereare 4 models in the Lifestyle range:
LP112 –a24hr program, with linked central heating and hot
water on for up to 3 heating periods each day, and every day
the same.
LP241 –a24hr program, with central heating and
hot water working independently for up to 3 heating periods
eachday, and every day the same.
LP522–a5/2-day program allowing for different
timings at the weekends, with centralheating and hot water
workingindependently for up to3heating periods each day.
LP722 –a7-day program allowing for different
timings on each day of the week, with central heating and
hot water working independently for up to 3 heating periods
eachday.
If the engineer hasn’t set your timings for you, your programmer
will work with a standard program that has been set at the
factory. If this doesn’t suit you, it’s very easy to change it –
when you’ve readthis introductory section, simplygotothe
section thatcontains your programmer model.
Remember:
Lifestyle programmers will automaticallyswitch your central
heating and hot water on and off at times that suit you.
Depending on yoursystem, central heating and hot water can
either both come on and off at thesame time, or work
independently. Theredlight on thefront of the programmer
shows whem eachone is on
Make your changes usingthe SET?, YES/-, and + buttons on
the programmer, found under the bottom flap.
You can’t set ON1 as the last timing beforemidnight,but you
can set OFF3 after midnight–providing it’s notmore than 23
hours and 59 minutes after ON1.
You need to set thetimings in sequence – i.e. ON1, OFF1, ON2,
OFF2, ON3, OFF3. If youget out of sequence, the display will
flash a warning.
SWITCHING
ON 1 – start of firsttimedperiod
OFF 1 – end of firsttimedperiod
ON 2 – start of second timedperi-
od
OFF 2 – end of second timedperi-
od
ON 3 – start of thirdtimedperiod
OFF 3 – final switch-off of theday
Theengineer has set yourprogram and timings–you
won’tneed to do anythingelse. Just keepthis guide in a
safe place forfuturereference.
Sometimes you mightneed to change theway you use your
central heating or hot water temporarily – perhaps due to an
unusually cold day, or exceptional demand for hot water.
Here’s how to do it–without affecting yourprogram.
Switching on andoff
On the front of the programmer there are two Advance/Boost
buttons–oneforcentralheating and one for hot water. They
allow you to switchyour system either on or off, irrespective of
theprogram. So if theheatingorhotwater is off, and you want
warmth or hot water now, you can either –
1. Press Advanceto switch it on (ADV will be displayed), and it
will stay on until the end of the next period. Or if the heating/hot
water is on and you don’t need it, press Advance and it will go
off until the beginning of the next ON period.
Advancewill only operate in TIMED or ONCE modes.
2. Press & Hold Boostto switch on for an extra hour( & BST will
be displayed), thenPress again for two ( ) or three ( ) hours.
To cancel Boost, Press Boost again ( ). Or if the heating/hot
water is already on, using Boost will extend the ON time by one,
two or threehours.
Over-riding the program
On each side of the display there are four operating modes –
one group for central heating, the other for hot water. You can
change modes withimmediate effect by usingthe appropriate
SELECT button.Thiswon’t alter the timings in your program,
which you can return to by selecting TIMED.
OFF= continuously off.
TIMED = on for up to 3 periods a day.
ONCE= on for 1 periodaday, from the start of ON1
to theendofOFF3.
ON = continuously on.
DAY-TO-DAY VARIATIONS
THELP711 7-DAY ELECTRONICTIMESWITCH
LP711–a7-day program, allowingfor different
timings on each day of the week, up to 3 heating periods
each day.
Want to leaveatiming as it is? Just press SET? and move on
to thenext one.
If you need to reset your timings to thestandard program and
start again, press ‘SET’ and ‘+’ together to go back to the
pre-set program.
The standard program
Your system will comeonfor up to 3 heating periods every
24hrs. ON1 startsthefirstone, OFF1 finishesit, and so on.
Noticethat ON2 and OFF2 are set to the sametime.* This
means your system won’t respond, but if you want to activate
that middle period or change any other timings–readon.
SWITCHINGSTANDARD PROGRAM
MON-FRI SAT-SUN
ON 1 – start of firsttimedperiod 6.30am7.00am
OFF 1 – end of firsttimedperiod 8.30am9.00am
ON 2 – start of second timedperiod* 12.00pm12.00pm
OFF 2 – end of second timedperiod* 12.00pm12.00pm
ON 3 – start of thirdtimedperiod 4.30pm4.00pm
OFF 3 – final switch-off of theday10.30pm11.00pm
06490033001 ISS L6/06/2016
on the programmer, found under the bottom flap.
LP241Si, LP522Si & LP722Si PROGRAMMERS
LP111Si & LP711Si TIMESWITCHES
Voltage230V a.c. +10% - 10% 50Hz
Programmer Rating2(1) A 230V a.c. each switch
Timeswitch Rating2(1) A 230V a.c.
Ambient temp Operating: 0º to 45ºC
Storage: -20ºC to 50ºC
Without mains powerDisplay: blank
Time: always kept
Program times: always preserved
Programming resolution 1 minute
WiringFixed wiring only, to comply with
current IEE regulations
Maintenance Must be maintained byaqualified
electrician or heating engineer
Pollution degree
Software class
Ball pressure test
temperature
Rated impulse voltage
2
2
75ºC
2.5kV
Drayton Tempus 6,7 N L 1 2 3 4
Drayton Lifestyle LP112, LP241, LP522, LP722 N L 1 2 3 4
Switchmaster N L 4 3 1400, 600
(no connection to terminal 4 on 600)
Switchmaster 805, 900, 900i N L 4 2 3 1
ACL MP (Towerchron) 2 1
ACL FP (Towerchron) 2 1 8 11 6 10
Tempus 3, 4, 6,7(old models),
Danfoss Randall
CP15, CP715,FP15,FP715 (Mk18 ) E N L 1 2 3 4
Danfoss Randall 3020P, 3060 E 7 6 4 2
Danfoss Randall 4033 (link 1-6) E 7 6 5 3 4 2
Danfoss Randall 102, 102E, 102E5, 102E7 (link 6-3) E 5 6 1 2
Danfoss Randall 701 (link L-5 and 5-6) E N L 3 1
Danfoss Randall 702 (link L-5 and 5-6) E N L 4 2 3 1
Danfoss Randall 922, 972 (link L-2 and 2-5) E N L 1 4 3 6
Danfoss Randall E N L 3 6 1 4SET2, SET2E, SET3E, SET3M, FP975
SET5 (link L-2 and 2-5)
Grasslin Towerchron DP 72, QE2 N L 1 2 3 4
Honeywell ST 699/799 (link L-5 and 5-8) N L 7 4 6 3
Honeywell ST 6200, ST 6300, ST 6400, ST 6450 N L 1 2 3 4
Honeywell ST 7100 (link L-3 and 3-6) N L 7 4 8 5
Horstmann E N L 3 6 1 4525, 527, 425 Diadem, H21, H27,
H121, Tiara (link L-2 and 2-5)
Landis&Staefa* N L 1 2 3 4RWB2, RWB2E, 20, 40, 102, 200,
252 & 270, RWB9
Myson Microtimer (link L-5 and 5-8) N L 7 4 6 3
Potterton Myson N L 1 2 3 4All EP2000’s, EP3000’s, EP6000’s
(link L-5 and N-N)
Potterton Myson* Mini Minder N L 1 2 3 4
Sunvic Select 207, SunPro 2000 N L 1 2 3 4
Sunvic SP50, SP100 (link L-3) N L 1 4 2 5
Drayton Tempus 1, 2 (new models) N L 1 2 3 4
Drayton Lifestyle
LP111, LP711, LP111Si, LP711Si N L 1 2 3 4
Switchmaster 300 N L 4 1
ACL TC (Towerchron) 2 1 4 7
Drayton Tempus 1, 2 (old models) N L 1 2 3 4
Switchmaster 980 N L 4 1
Danfoss Randall TS15, 75 (Mk18) E N L 1 4 2 5/6
Danfoss Randall TS715, TS715Si N L 1 4 2 3
Danfoss Randall TS975 E N L 5 4 6 1,2,3
Danfoss Randall SET1, SET1E E N L 5 4 6
Danfoss Randall SET4 E N L 5 4 6
Danfoss Randall 103, 103E, 103E5, 103E7 4 5 6 3 1 2
Danfoss Randall 911, 971 E N L 5 6 4 2
Grasslin Towerchron QE1 N L 2 4
Grasslin Towerchron T2001, T2001Q E N L 7
Honeywell ST 6100A, ST 6100C N L 1 4 2
Honeywell ST 7000B
Horstmann Centaur SC1, SC7 L
Horstmann
Centaur Plus, C11, C17, C17-ZW N L 2 4 3
Horstmann Emerald 423, Pearl Auto N L 2 4
Horstmann 517, Coronet, H11, H17 E N L 3 4
Landis&Staefa RWB3 N L 4 3
Landis&Staefa RWB30, RWB50, 100, 152, 170 N L 4 4 3
Landis&Staefa RWB7
Potterton Myson EP4000, 4001, 4002, 5002 N L 5 4 2
Sangamo M6
Smiths Centroller Mk1, Mk2 N L 3 2
Smiths Centroller 30 1 2 3/4
Smiths Centroller 300, 980 N L 4 1
Sunvic Select 107, SunProl1000 N L 1 3 2 4
Sunvic SP20, SP35 N L 3 5 4 5
Venner Vennerette N L LINE LOAD
TIMESWITCHTERMINALCOMPARISONS
Earth Neutral Live
Common
On Off Spare
MAKE MODEL
PROGRAMMER TERMINALCOMPARISONS
Current Models
Earth Neutral Live Ch1 on Chl2 on Ch3 on Ch4 on
MAKE MODEL
Discontinued/Competitors’ Models
E4 6 31
Salus EP101, SP120 43
NL
Myson
Myson
N L 1 3 2 4
MEPIC
4
Mictrotimer (link L-5 and 5-8) E N L 5 6
EN L 4
23
3
3 2
N L 1 2 3 4
British Gas EMT2, UT1, UT2 N L 1 324
Drayton
Drayton
Drayton
N L 1 2 3 4
N L 1 2 3 4
N L 1 2 3 4
SM1
miGenie Wish 1
MiTimeMT711R, MiTime RF Pack1
Current Models
Discontinued/Competitors’ Models
Sangamo M5 (link 1-6) N L 1 8
N L 1 2 3 4
Salus EP200, SP220
Myson MEP2C N L 1 2 3 4
Drayton
Drayton
Drayton
British Gas
SM2
miGenie Wish 2
MiTime MT721R, MiTimeRF Pack 2 & 3
EMP2, UP1, UP2
N L 1 2 3 4
N L 1 2 3 4
N L 1 2 3 4
N L 1 2 3 4
Can simply be removed from the backplate and replaced without any disturbance to the existing wiring.

Set the month
IPress SET? and the month will start to flash. Use the – and +
buttons to adjust.
Set the day
IPress SET? and the day will start to flash. Use the – and + but-
tons to adjust.
Set the Day Light Saving
IPress SET? and the current DLS status will start to flash for day
light saving (British Summer Time). Use the – and + buttons to
turn on or off.
IPress SET? to go back to normal operation.
WEEKDAYS WEEKENDS
HW CH HW CH
ON 1 – start f first timed peri d 6.30am 6.30am 7.00am 7.00am
OFF 1 – end f first timed peri d 8.30am 8.30am 9.00am 9.00am
ON 2 – start f sec nd timed peri d* 12.00pm 12.00pm 12.00pm 12.00pm
OFF 2 – end f sec nd timed peri d* 12.00pm 12.00pm 12.00pm 12.00pm
ON 3 – start f third timed peri d 4.30pm 4.30pm 4.00pm 4.00pm
OFF 3 – final switch- ff f the day 10.30pm 10.30pm 11.00pm 11.00pm
SWI CHING
WEEKDAYS WEEKENDS
HW CH HW CH
ON 1 – start f first timed peri d 6.30am 6.30am 7.00am 7.00am
OFF 1 – end f first timed peri d 8.30am 8.30am 9.00am 9.00am
ON 2 – start f sec nd timed peri d* 12.00pm 12.00pm 12.00pm 12.00pm
OFF 2 – end f sec nd timed peri d* 12.00pm 12.00pm 12.00pm 12.00pm
ON 3 – start f third timed peri d 4.30pm 4.30pm 4.00pm 4.00pm
OFF 3 – final switch- ff f the day 10.30pm 10.30pm 11.00pm 11.00pm
SWI CHING
THE LP522 5/2-DAY ELECTRONIC PROGRAMMER Cont...
Set weekday hot water
IWhen you press SET? after setting O 3 for the central heating,
the display will ask ‘SET HW MON to RI PROG?’.
IPress YES, then set your times in the same way. Remember, in
this mode you can have different times to your central heating if
you wish.
Set weekend central heating
IWhen you press SET? after O 3 for the weekday hot water,
the display will ask ‘SET CH SAT SUN PROG?’. Press YES to
confirm, and alter the times in the same way.
Set weekend hot water
IWhen you press SET? after O 3 for the weekend central
heating, the display will ask ‘SET HW SAT SUN PROG?’.
Press YES, and follow the procedure.
IWhen you press SET? after O 3 for HW SAT SUN, the
programmer will go back to normal operation.
THE LP522 5/2-DAY ELECTRONIC PROGRAMMER
LP522 – a 5/2-day program allowing for different timings at
the weekends, with central heating and hot water working
independently for up to 3 heating periods each day.
If the timings haven’t been set for you, then your programmer
will still be on the factory-set standard program. This means
that central heating and hot water will operate together, with
the same timings for weekdays and different ones for the
weekend. But it’s easy to make changes, and have heating
and water working independently – just follow the instructions.
Want to leave a timing as it is? Press SET? and move on to
the next one.
If you need to reset your timings to the standard program
and start again, press ‘SET’ and ‘+’ together to go back to
the pre-set program.
If you don’t press anything for two minutes, the programmer
automatically goes back to normal operation.
The standard program
Your system will come on for up to 3 heating periods every
24hrs. ON1 starts the first period, O 1 finishes it, and so on.
Notice that ON2 and O 2 are set to the same time.* This
means your system won’t respond, but if you want to activate
that middle period, or change any other timings – read on.
Changing the timings
IPress the SET? button and you’ll see ‘SET PROG?’.
Set the weekday central heating
IPress the YES button, and the display will ask ‘SET CH MON to
RI PROG?’.
IPress YES and you’ll see ON1, the start of your first central heat-
ing period. Adjust it in 1-minute steps using the – and + but-
tons. If the – and + buttons are held down, the time changes in
10-minute steps.
IPress SET?, and you’ll see O 1, the end of your first central
heating period. Adjust this in the same way, press SET?, then
repeat the procedure for ON2, O 2, ON3 and O 3.
THE LP722 7-DAY ELECTRONIC PROGRAMMER Cont...
IWhen you press SET? after setting O 3 for the weekday central
heating, the display will ask ‘SET HW MON to RI PROG?’.
IPress YES, then set your hot water times in the same way.
Remember, in this mode you can have different times to your
central heating if you wish.
Set each day
If, after you’ve set O 3 for your hot water, you want to fine-tune
one or more weekdays, press SET? until you find the first day
you want to adjust – then go through the procedure, altering any
time you wish. Press SET? to move on to the next day. When
you’ve finished, press SET? until you see ‘SET SAT SUN
PROG?’.
If you don’t want to alter any individual days, keep pressing
SET? until you see ‘SET SAT SUN PROG?’.
THE LP722 7-DAY ELECTRONIC PROGRAMMER
LP722 – a 7-day program allowing for different timings on each
day of the week, with central heating and hot water working
independently for up to 3 heating periods each day.
If the timings haven’t been set for you, then your programmer
will still be on the factory-set standard program. This has central
heating and hot water operating together – with the option of
having different timings for each day of the week. But it’s easy
to make changes, and have heating and water working
independently – just follow the instructions.
Want to leave a timing as it is? Press SET? and move on to the
next one.
If you need to reset your timings to the standard program and
start again, press ‘SET’ and ‘+’ together to go back to the
pre-set program.
If you don’t press anything for two minutes, the programmer
automatically goes back to normal operation.
The standard program
Your system will come on for up to 3 heating periods every
24hrs. ON1 starts the first period, O 1 finishes it, and so on.
Notice that ON2 and O 2 are set to the same time.* This
means your system won’t respond, but if you want to activate
that middle period, change any other timings – read on.
Changing the timings
IPress the SET? button and you’ll see ‘SET PROG?’.
Set all weekdays
irst you set the times that are going to be the same for each
weekday, then you can select each day individually and make
any further adjustments. If you want each day to be quite differ-
ent, go straight to ‘Set each day.’
IPress the YES button, and the display will ask ‘SET MON to RI
PROG?’.
IPress YES and the display will ask ‘SET CH MON to RI
PROG?’.
IPress YES, and you’ll see ON1, the start of your first central
heating period. Adjust it in 1-minute steps using the – and +
buttons. If the – and + buttons are held down, the time changes
in 10-minute steps.
IPress SET?, and you’ll see O 1, the end of your first central
heating period. Adjust this in the same way, press SET?, then
repeat the procedure for ON2, O 2, ON3 and O 3.
Technical Helpline: 0333 7000 622
Email: [e-mail]
Web: www.draytoncontrols.co.uk
USERS NOTES
SETTING THE CLOCK Cont...
Set the minute
IPress SET?, and the minutes will start to flash. Use the – and +
buttons to set the exact time.
IPress SET?, and ‘SET DATE?’ appears in the display.
If you don’t want to change the date press SET? to go back to
normal operation. If you do, go on to the next section.
SETTING THE DATE
The weekday is automatically calculated from the date, so if
the weekday is incorrect you’ll need to reset the date.
IPress the SET? button until you see SET DATE?.
Set the year
IPress YES and the year will start to flash. Use the – and + but-
tons to adjust.
Set weekend
IPress YES, and alter the central heating and hot water times in
the same way.
IWhen you press SET? after O 3 for HW SAT SUN, the pro-
grammer will ask the question TEST? If you want to test your
program, see below, otherwise press SET? again. If you don’t
want to test your program, press SET? again – and you’ll be
asked the question SET H’DAY? If you want to set a holiday
switch off, see page 23, otherwise press SET? again.If you’re not
going to program in a holiday switch-off, then press SET? again
and your programmer will go back to normal operation.
Test your program
IThis test facility allows you to run through your program to check
that the timings are exactly what you want.
IAnswer YES to TEST? and the display will show Monday and
a time just past midnight. Press YES again and hold it down –
and the display will start to run through the days of the week,
pausing for a few seconds when it reaches an ON or an O
time. At each pause, the appropriate lights and circuits will come
on.
IRelease the YES button, and the display will stop running
and give you longer to identify a timing.
IPress YES once more, and the display will start running again –
and will continue all through the week until you press SET?
IPress SET? and your programmer will go back to normal
operation.
emember - The display shows the strict time sequence, so
ON1 for HW could be followed by ON1 for CH, then OFF1 for
HW etc Using this feature you can program your system to
Using this feature you can program your system to switch off
while you’re on holiday, then switch back on again in time to
have the house warm for your return.
IPress SET? three times and you’ll see ‘SET H’DAY?’
IPress YES to SET H’DAY? and the display will show ‘00’.
IUsing + and -, set the number of days you want the system to
be off.
IPress SET, the display will show ‘H’DAY’ and the programmer
will switch off the system. It will then return to normal operation
after the set number of days.
emember - The programmer counts each pass through
midnight as a day. So if on a Saturday morning you don’t want
the heating on again until Tuesday morning, set for 3 days.
SETTING THE CLOCK AND DATE
Applicable to all models.
SETTING THE CLOCK
The clock in your programmer has been set at the factory,
and automatically accounts for British Summer Time.
However, should you need to set the clock, read on.
IRING THE PROGRAMMER Cont...
Connection Charts
Make the wiring connections, as above, for the appropriate system.
or surface wiring, snap out the cable entry strip on the bottom edge
of the wall-plate. Lifestyle units are double-insulated and need no earth
connection, but an earthing continuity (loop) terminal is provided for
convenience.
After wiring, plug in the unit and tighten the securing screws.
Check the mains input has a 3A fuse, and switch on the mains.
Then set the timings as shown in the User’s Guide.
ALWAYS SWITCH OFF THE MAINS BEFORE REMOVING
THE LIFESTYLE TIMESWITCH/PROGRAMMER – AND
NEVER FIT IT TO A LIVE WALL-PLATE!
INSTALLERS/ENGINEERS NOTES
THE LP241 24hr ELECTRONIC PROGRAMMER Cont...
Set the central heating
IPress the YES button, and the display will ask ‘SET CH PROG?’.
IPress YES and you’ll see ON1, the start of your first central heat-
ing period. Adjust it in 1-minute steps using the – and + but-
tons. If the – and + buttons are held down, the time changes in
10-minute steps.
IPress SET?, and you’ll see O 1, the end of your first central
heating period. Adjust this in the same way, press SET?, then
repeat the procedure for ON2, O 2, ON3 and O 3.
Set the hot water
IWhen you press SET? after setting O 3 for the central heating,
the display will ask ‘SET HW PROG?’.
IPress YES, then set your times in the same way. Remember, in
this mode you can have different times to your central heating if
you wish.
IWhen you press SET? after setting O 3 for the hot water, the
programmer will return to normal operation.
Set the hour
IPress the SET? button until you see SET CLOCK?.
SET A HOLIDAY S ITCH-OFF
Applicable to all models.
IPress YES once, and then the hour will start to flash. Use the
– and + buttons to set the hour, checking for AM and PM.
Technical Helpline: 0333 7000 622
Email: [e-mail]
Web: www.draytoncontrols.co.uk
LWC3 Junction Box Pump Boiler
Room Thermostat Cyl. Thermostat Programmer
Mains Input
230V a.c.
Motorized Valves
*7 2 E
LNE
* 1 2 3 7
NESwitch
L
Perm.
L
RTS 1&2
RTS 4,6,9&10
Function
N
N
N
L
LE
L 1
3
3
COM
CALL
SAT.
Function
COM CALL
SAT.
Drayton
HTS 3 C12Lifestyle LP722 LP522 LP241 LP112 SM2
NOT
USED
2
N
1
L1 2 3 4
HW
OFF
CH
OFF
HW
ON
CH
ON
Mains
Isolator
1
L
2
N
3
E
3A Drayton
22mm 3 Port Mid Position Valve
28mm 3 Port Mid Position Valve
Function of
Leads
Blue
Yell/Green
Grey
Orange
White
3 2 1 4 56 7 8
8 6 4
CH
On
HW
Off
Boiler
Live &
HW on
N E
5 8 723
1234 5 67 8 9 10 11 12
L N E
Refer to Boiler Handbook
for wiring details of Pump
Overrun boilers. Use boiler
manufactures instructions.
*
Mid-Position Valve System
LWC3 Junction Box Pump Boiler
Room Thermostat Cyl. Thermostat Programmer
Mains Input
230V 50HZ
*7 2 3
LNE
* 1 2 3 7
NESwitch
L
Perm.
L
Refer to Boiler Handbook
for wiring details of Pump
Overrun boilers. Use boiler
manufactures instructions.
*
RTS 1&2
RTS 4,6,9&10
Function
N
N
N
L
LE
L 1
3
3
COM
CALL
SAT.
Function
COM CALL
SAT.
Drayton
HTS 3 C12Lifestyle LP722 LP522 LP241 LP112 SM2
NOT
USED
2
N
1
L1 2 3 4
HW
OFF
CH
OFF
HW
ON
CH
ON
Mains
Isolator
1
L
2
N
3
E
3A
3 2 1 4 58 6 84
21 34 5 67 8 9 10 11 12
L N E
Motorized Valves
The white wire (28mm Valves) becomes live when the valve closes, it is not
used and is wired to ‘spare’ terminals for sale isolation.
Drayton
22mm 2 Port Valve
28mm 2 Port Valve
Function of
Leads
DHW VALVE
Motor Aux.SW
LL
Motor Aux.SW
CH VALVE
NN
22
N.O N.O N.C N.C EE
33
CC
6 7 7 11 9105
Brown
Brown
Blue
Blue
Yell/Green Yell/Green
Orange
Grey
Orange
Grey
White(28mm only)
White(28mm only)
Spring-Return 2-Valve System
Gravity HW, Pumped CH with Room Stats
Pump
LNE
5 2 3
Boiler
* 1 2 3 7
NESwitch
L
Perm.
L
LWC3 Junction Box
1234 5 67 8 9 10 11 12
L N E
Programmer
Lifestyle LP722 LP522 LP241 LP112 SM2
NOT
USED
2
N
1
L1 2 3 4
HW
OFF
CH
OFF
HW
ON
CH
ON
74
Mains Input
230V a.c.
Mains
Isolator
1
L
2
N
3
E
3A
Room Thermostat
RTS 1&2
RTS 4,6,9&10
Function
N
N
L
LE
L 1
3
3
COM
CALL
SAT.
3 1 2 4 5
N
06490033001 ISS L 6/06/2016
