DriSteem TCI-W11-U-H User manual

Humidistat
Model TCI-W11-U-H, TCI-W11-U
Model TRI2 with BACnet®Humidistat
Installation, Operation, and
Maintenance Manual
Read and save these instructions
DRISTEEM HUMIDISTATS

THESE INSTALLATION INSTRUCTIONS ARE FOR THE HUMIDISTAT ONLY!
For DriSteem humidifier installation, follow DriSteem humidifier installation instructions.
WARNING
This product must be installed by a qualified heating and air
conditioning contractor. Failure to do so can result in serious
injury from electrical shock or damage to product, and can
void product warranty due to possible product misapplication.
WARNING
1. Contact with energized electrical circuits can cause
serious injury from electrical shock. Disconnect electrical
power to the humidifier before starting installation.
CAUTION
1. Do not set humidity higher than recommended or moisture
can accumulate, which can cause bacteria and mold
growth or dripping water into building spaces. Dripping
water can cause property damage; bacteria and mold
growth can cause illness.
2. Do not set humidity up to recommended levels if there is
condensation on the inside of windows. Condensation
damage
can result.
Warnings and cautions
2DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

OVERVIEW.................................................................4
Features and parameters ...................................4
TCI display .............................................5
TRI2 display ............................................6
SPECIFICATIONS .............................................................7
Model TCI and TRI2 specifications.............................7
Dimensions .............................................9
INSTALLATION .............................................................10
Installation instructions ....................................10
TRI2 wiring diagram .....................................11
SETUP AND CONFIGURATION .................................................12
Changing the parameters..................................12
BACnet®communication with DriSteem humidistats ................13
Configuration of BACnet®humidistat devices ....................15
Object list.............................................17
Description of available objects .............................20
Model TRI2 BACnet humidistat parameters ......................21
MAINTENANCE ............................................................22
Accessing the internal humidity sensor AES1-HT-Ax ................22
TROUBLESHOOTING AND REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Troubleshooting and replacement parts ........................23
Table of contents
3
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

FEATURES
• Digital display of humidity and setpoint.
• Mount to wall or standard junction box.
• One universal input for a remote humidity sensor.
• One 0 - 10VDC or 4 - 20mA output
NOTE: Actuators: Choose modulating actuators with an input signal type of
0 - 10VDC or 4 - 20mA. Minimum and maximum signal limitations may be
set with parameters. 3-point point actuators with constant running time are
recommended. The default parameters are for 2 - 10VDC actuators.
• Input voltage of either 24VAC or 24VDC.
ROOM MODELS
• Standard with 3% humidity element
• Replaceable internal humidity element (optional)
MODEL TRI2
• Touchscreen digital display of humidity and setpoint
• BACnet communications
PARAMETERS
The following functions can be changed from the parameters menu.
• Configure universal input for a 0 - 10VDC, 2 - 10VDC, 0 - 20mA, or
4 - 20mA remote humidity sensor, default is 0 - 10VDC
• Configure output for 0 - 10VDC, 2 - 10VDC, 0 - 20mA, or 4 - 20mA,
default is 2 - 10VDC
• Monitor alarms for high and low humidity, default disabled.
• Set min or max humidity display, default 0% and 100%
• Calibrate sensor
• Tune the PI control loop
• Enable security to prevent user from changing parameters.
• Convert between Fahrenheit or Celsius display.
• Change BACnet communication settings (Model TRI2).
WARNING!
This device is intended to be used for
comfort applications. Where a device
failure endangers human life and/or
property, it is the responsibility of the
owner, designer and installer to add
additional safety devices to prevent or
detect a system failure caused by such
a device failure. The manufacturer of
this device cannot be held liable for
any damage caused by such a failure.
WARNING!
Live electrical components
During installation, testing, servicing
and troubleshooting of DriSteem
products, it may be necessary to work
with live electrical components. Have
a qualified licensed electrician or other
individual who has been properly
trained in handling live electrical
components perform these tasks.
Failure to follow all electrical safety
precautions when exposed to live
electrical components could result in
death or serious injury.
OVERVIEW
Features and parameters
4DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

Vertical bar
(scrolls up/down, 10%
resolution with current
output)
Small digits
Display of set point
Typical Home screen
Left (Power)
Press >2 s: Turn unit OFF. Text
OFF displayed
(Parameter setting: ENTER to
select menu option, accept
parameter change)
Large digits
Display value of humidity
Either room humidity or duct
humidity
Right (Option)
(Parameter setting: ENTER
to select menu option,
accept parameter change)
FIGURE 5-1: USING THE DRISTEEM MODEL TCI HUMIDISTAT DISPLAY
Down
Decrease SET POINT
(Parameter setting:
SCROLL menu options
and parameters)
Up
Increase SET POINT
(Parameter setting:
SCROLL menu options
and parameters)
OVERVIEW
TCI display
5
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

Vertical bar
(scrolls up/down,
10% resolution with
current output)
Small digits
Display of set point
Typical Home screen
Left (Power)
Press >2 s: Turn
unit OFF. Text OFF
displayed
(Parameter setting:
ENTER to select
menu option, accept
parameter change)
Large digits
Display value
of humidity
Either room
humidity or
duct humidity
Right (Option)
(Parameter setting:
ENTER to select
menu option, accept
parameter change)
FIGURE 6-1: USING THE MODEL TRI2 BACNET DRISTEEM HUMIDISTAT DISPLAY
Down
Decrease SET POINT
(Parameter setting:
SCROLL menu
options and
parameters)
Up
Increase SET POINT
(Parameter setting:
SCROLL menu
options and
parameters)
OVERVIEW
TRI2 display
6DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

Table 7-1:
Model TCI and TRI2 specifications
Model TCI Model TRI2
Power Supply
Power requirements 24 AC/DC ±10%, 50/60 Hz, Class
2, 2.0A, 48 VA max. SELV to HD 384
Power consumption Maximum 3 VA Maximum 5 VA
Electrical connection Terminal connectors
0.34 - 2.5 mm2wire (AWG 22 - 13)
Terminal connectors
0.34 - 1.3 mm2wire (AWG 22 - 16)
Signal Inputs
Universal input Setting for voltage or current
Input signal 0 - 10 V or 0 - 20 mA
Resolution 9.76 mV or 0.019 mA (10 bit)
Impedance Voltage: 98kΩ, Current: 240Ω
Humidity sensor AEs3-HT-Ax Capacity sensor
Range 0 - 90% rH
Measuring accuracy ±3%
Hysteresis ±1%
Repeatability ±0.1%
Stability <0.5% / year
Signal Outputs
Analog output -
Output signal DC 0 to 10V/0 to 20mA
Resolution 9.76 mV / 0.019 mA
Maximum load Voltage: 5kΩ, Current: 250Ω ≥ 1kΩ
Insulation strength between relays contacts
and system electronics 2000 VAC to EN60730-1 1500 VAC to EN60730-1
1000 VAC to EN60730-1
Environment
Operation To IEC 721-3-3
Climatic conditions class 3K5
Temperature 0 to 50ºC (32 to 122ºF)
Humidity < 95% RH non-condensing <85% RH non-condensing
Transport & storage To IEC 721-3-2 and IEC 721-3-1
Climatic conditions class 3K5 and class 1K3
Temperature -25 to 70ºC (-13 to 158ºF)
Mechanical conditions class 2M2
Continued on next page
SPECIFICATIONS
Model TCI and TRI2 specifications
7
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

Table 8-1:
Model TCI and TRI2 specifications (continued)
Model TCI Model TRI2
Standards
conformity, EMC standard, low voltage
directive
2014/30/EU
2014/35/EU
Automatic electrical controls for household
and similar use EN 60730-1
Special requirement on temperature
dependent controls EN 60730-2-9 -
Electromagnetic compatibility for industrial
and domestic sector -Emissions: EN 60 730-1
Immunity: EN 60 730-1
Degree of protection IP30 to EN 60529
Pollution class II (EN 60730-1)
Safety class III (IEC60536) II (IEC60536)
Overvoltage category I (EN60730-1) II (EN60536)
General
Material: Cover, back part, mounting plate Fire proof ABS plastic (UL94 class V-0) Galvanized steel
Dimensions (H x W x D)
Front part: 15 X 113 X 72 mm (0.6 X
4.5 X 2.8in)
Power case: 58 x 32 mm (2.3" x 1.3")
Front part: 14 X 113 X 72 mm (0.6 X 4.5
X 2.8in)
Power case: 50 x 50 mm (2.0" x 2.0")
RoHS compliant according to 2011/65/EU
Weight (including package) 253 g (8.9 oz) 184 g (6.5 oz)
Network
Hardware interface - RS485 in accordance with EIA/TIA 485
Max nodes per network - 128
Max nodes per segment - 64
Conductors - Shield twisted pair (STP) cable
Impedance - 100 - 130 ohm
Nominal capacitance - 100 pF/m 16 pF/ft. or lower
Galvanic isolation - The communication circuitry is isolated
Line termination -
A line termination resistance (120 ohm)
shall be connected between the terminals
(+) and (-) of the furthermost node of the
network
Network topology - Daisy chain according EIA/TIA 485
specifications
Recommended maximum length per chain - 1200 m (4000 ft).
BACnet
Communication standard - BACnet MS/TP over RS485 BTL
tested and listed B-ASC
Communication speed - 9600, 19200, 38400, 57600, 76900,
115200
SPECIFICATIONS
Model TCI and TRI2 specifications (continued)
8DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

FIGURE 9-1: TCI HUMIDISTAT DIMENSIONS
OM-8063
0.60" (15 mm)
2.25" (57 mm)
1.94" (49 mm)1.20" (30 mm)
4.43" (113 mm)
2.84" (72 mm)
FIGURE 9-2: TRI2 HUMIDISTAT DIMENSIONS
SPECIFICATIONS
Dimensions
OM-8131
2.3" (59 mm)
1.38" (35 mm)
0.5" (13 mm)
2.1" (54 mm)
0.6" (15 mm)
2.64"
(67 mm)
2.0"
(50 mm)
2.4"
(60 mm)
0.6"
(15 mm)
4.4"
(113 mm)
2.4" (60 mm)
2.8"
(72 mm) 1.2"
(30 mm)
9
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

INSTALLATION
• Install the controller on an easily accessible interior
wall, approximately 1.5 m above the floor in an area
of average temperature.
• Avoid direct sunlight or other heat sources (e.g. above
radiators and heat emitting equipment).
• Avoid locations behind doors, outside walls,and below
or above air discharge grills and diffusers.
• Location of mounting is less critical if external sensors
are used.
• Ensure adequate air circulation to dissipate heat
generated during operation.
• Observe local regulations.
• Do not mount in a wet or condensation prone
environment.
INSTALLATION INSTRUCTIONS
1. Connect the wires to be connected to the terminals of
the power case according to wiring diagram.
2. Install the mounting plate to the flush mounting box.
Notes:
• Make sure the nipple with the front holding screw is
facing to the ground (TCI models only).
• Make sure the mounting screw heads do not stand out
more than 0.2" (5 mm) off the surface of the mounting
plate.
3. Ensure the jumpers are set correctly (TCI models only).
4. Slide the two latches located on the top of the front
part into the hooks at the upper side of the mounting
plate.
5. Carefully lower the front part until the interconnector
reaches the mounting-plate. Continue pressing in a
gentle way until the front part is fully connected. While
inserting the connectors, a slight resistance can be felt.
This is normal. Do not use excessive force.
6. With a Phillips-type screw driver of size #2, carefully
tighten the front holding screw to secure the front part
to the mounting plate. This screw is located on the
front lower side of the unit. There is no need to tighten
the screw too much (TCI models only).
JUMPER CONFIGURATION (TCI MODELS ONLY)
Jumpers are mounted vertically only.
1. A0 - Selection of output signal type
• Left position: voltage output (0 - 10 V) factory
default.
• Right position: current output (0 - 20 mA)
2. UI - Selection of input signal type
• Left position: voltage input (0 - 10 V) factory
default.
• Middle position: current input (0 - 20 mA)
• Right position: RT or dry-contact input
FIGURE 10-1: CONNECTION (TCI MODELS ONLY)
Table 10-1:
TCI Terminal connections
TCI-W11-U-H
(Room)
TCI-W11-U
(Duct)
G0 Ground 1 1
G 24VAC/21VDC 2 2
Y1 Control output 6 6
X1 Duct sensor Input — 7
INSTALLATION
Installation instructions
OM-8134
10 DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

Table 11-1:
TRI Terminal connections
TRI2
(Room)
TRI2
(Duct)
GND Ground 1 1
V+ 24VAC/21VDC 2 2
AO1 Control output 3 3
UI6 Duct sensor input — 10
+ BACnet + 5 5
- BACnet - 6 6
INSTALLATION
FIGURE 11-1: TRI2 WIRING DIAGRAM
OM-8132
TRI2 wiring diagram
11
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

1. Press the UP and DOWN button simultaneously for three seconds. The
display will indicate the firmware version in the upper large digits and the
revision in the lower small digits. Press the RIGHT or POWER key to start
login.
2. CODE is shown in the small display.
3. The code for accessing the user parameters is 0009, for control
parameters it is 0241.
4. Select this by using the UP or DOWN buttons.
5. Press the RIGHT or POWER button after selecting the correct code.
6. Once logged in the parameter group can be selected with the UP and
DOWN key. Enter the group with the RIGHT or POWER key.
7. Once the group is selected, the parameter is displayed immediately.
8. Select the parameters with the UP/DOWN buttons. Change a parameter
by pressing the RIGHT button. Arrows 8 to 10 show up and indicate that
the parameter may be modified now. Use UP or DOWN buttons to adjust
the value.
9. Once complete, press RIGHT or POWER in order to save the new value of
the parameter and return to the selection level. Pressing the LEFT key will
discard the value and return to the selection menu without saving.
10.Press the LEFT key again so as to leave the parameter menu and return to
the group selection. Press LEFT key again while in the group selection to
return to normal operation.
11.The unit will return to normal operation if no key is pressed for more than
five minutes.
SETUP AND CONFIGURATION
Changing the parameters
12 DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

SETUP AND CONFIGURATION
BACnet®communication with DriSteem humidistats
FEATURES
• BACnet®MS/TP communication over RS485
• B-ASC Device Profile
• Slave type of communication
• Supports up to 128 nodes on one network
• Galvanic isolated bus connection
• Baud rates: Auto / 9600 / 19200 / 38400 / 57600 / 76800 / 115200
• LED indicators
X2-BAC (TRI2) PROTOCOL IMPLEMENTATION CONFORMANCE STATEMENT (PICS)
Vendor Name: Vector Controls
Product Name: X2 Controls series
X2 product description:
The X2 communicating BACnet® controllers are designed as universal controls
equipment suitable for a large number of applications. They may be used in
zoning and other applications which are monitored by a BACnet® MS/TP
network.
Table 13-1:
Supported BACnet Interoperability Blocks (BIBB)
The BACnet interface conforms to the B-ASC device profile (BACnet® Application Specific
Controller). The following BACnet Interoperability Building Blocks (BIBB) are supported.
BIBB Type Name
DS-RP-B Data sharing Read property - B
DS-RPM-B Data sharing Read property multiple - B
DS-WP-B Data sharing Write property - B
DM-DCC-B Device management Device communication Control - B
DM-DDB-B Device management Dynamic device binding - B
DM-DOB-B Device management Dynamic object binding - B
DM-TS-B Device management Time synchronization - B
DM-UTC-B Device management UTC Time synchronization - B
DM-RD-B Device management Reinitialize device - B
13
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

SETUP AND CONFIGURATION
BACnet®communication with DriSteem humidistats
SUPPORTED STANDARD BACNET® APPLICATION SERVICES
• ReadProperty
• ReadPropertyMultiple
• WriteProperty
• DeviceCommunication. Needs a password which is “Vector” (case sensitive
and without the quotes).
• I-Am
• I-Have
• TimeSynchronisation
• UTCTimeSynchronisation
• ReinitializeDevice (“cold” or “warm”). Needs a password which is “Vector”
(case sensitive and without the quotes).
SUPPORTED STANDARD OBJECT TYPES
• Device
• Analog input
• Analog value
• Binary value
• Multi-state Value
LED INDICATORS
The BACnet interface features a green LED and a red LED for indication of
traffic on the RS-485 bus. The green LED is lit when an incoming packet is
received, and the red LED is lit when an outgoing packet is transmitted to the
bus. At power-up, both LED blink twice simultaneously as a sign of the boot
process being completed. A constantly lit LED serves as an indication of a fault
condition in the reception or sending process.
14 DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

SETUP AND CONFIGURATION
Configuration of BACnet®humidistat devices
CONFIGURATION OF BACNET HUMIDISTAT DEVICES
The communication parameters may be set via operation terminals. Login to the
controller as follows:
1. Press UP/DOWN buttons simultaneously for three seconds. The display will
show firmware version and revision number. Press the OPTION button to
start login.
2. CODE is shown in small display.
3. Select 241 using UP/DOWN buttons.
4. Press OPTION after selecting the correct code.
5. Once logged in with 241 control modules are displayed (Lp1, Lp2, 1u,
2u, etc.) – select with UP/DOWN the communication parameters CO and
open with OPTION. As soon as the module is open its parameters are
displayed.
6. Select the parameters with the UP/DOWN buttons. Change a parameter
by pressing the OPTION button. Three arrows are displayed to indicate
that the parameter may be modified. Use UP/DOWN buttons to adjust the
value.
7. After you are done, press OPTION to save the new value and return to
the selection level (arrows disappear when selection is saved). Pressing left
hand POWER button without pressing OPTION will discard the value and
return without saving. For control parameters press POWER again to leave
parameter selection and return to control module selection.
Press the POWER to leave the menu. The unit will return to normal operation if
no button is pressed for more than 5 minutes.
CHANGING PARAMETERS OF THE CONTROLLER THROUGH BUS COMMUNICATION
It is possible to remotely changing parameters through an indirect read/write
mode using objects AV12 and AV13. Find details on the procedure required
and how to interpret values in the application note: Parameters access through
AEX-BAC V1.2 at www.vectorcontrols.com
15
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

SETUP AND CONFIGURATION
Configuration of BACnet®humidistat devices
Table 16-1:
COM Parameters
Parameter Description Range Default
CO 00 Bus plug-in hardware id (read only) 0…255 3
CO 01 Bus plug-in software version (read only) 0…255 12
CO 02 Bus plug-in software revision (read only) 0…255 13
CO 03 Communication address (must be unique in network) 1…127 1
CO 04
Baud rate:
0 = Auto-detect1
1 = 9600
2 = 19200
3 = 38400
4 = 57600
5 = 76800
6 = 115200
0…6 0 (Auto-detect)
CO 05 Highest master 1…127 127
CO 06 Device object ID1 000000xx 0…99 00
CO 07 Device object ID2 0000xx00 0…99 00
CO 08 Device object ID3 00xx0000 0…99 01
CO 09 Device object ID4 0x000000 0…4 0
CO 10 Send I-am at boot 1, 0 (ON, OFF) 1 (ON)
CO 11 Not used. 0…255 255
CO 12 Not used. 0…255 255
CO 13 Not used. 0…255 255
CO 14 Not used. 0…255 255
CO 15
Auto increment2 and auto-build3 of “device object name” flags:
0 = Auto increment and auto-build of device object name disabled
1 = Auto increment is enabled, auto-build of device object name disabled
2 = Auto increment disabled; auto-build of device object name enabled
3 = Auto increment and auto-build of device object name enabled
0…3 2
1 “Auto-detect baud rate”-mode
When this option is selected, the AEC-BAC will detect the baud rate of the RS485 network. The AEX-BAC will stay in baud rate detection mode until
it successfully decodes a package sent from device with address = 0 with a baud rate which is supported by the AEX-BAC. The baud rate detection
mode will be entered once at hardware start-up and after a prolonged communication failure.
2 “Auto increment”-function
When this function is enabled and an automatic AEC-PM1 parameter load is executed at power up of the controller, the following variables will be
incremented and written back to the AEC-PM1 unit:
- CO03 Communication address. This is incremented only if the value is not already 127 with respect to CO05 – the address of the highest master. If
CO05 is equal or less than the newly incremented value of CO03, then CO05 is written to be 127 (the maximum value of CO05 possible).
- CO06 … CO09 Device object ID. This is incremented only if the value is not already “4194304”.
3 “Auto-build of device object name”-function
The BACnet standard requires that the each BACnet endpoint has a unique name on the network (device object name). The initial name of the AEX-
BAC module is “AEX-BAC” equal for all devices. This means that device object names need to be edited manually.
Using the auto-build-function the device object name can be automatically assembled using the label AEX-BAC followed by the contents of CO06 –
CO09 (The device object ID). For example, AEX-BAC-01050001.
If one writes the device object name manually through BACnet, the auto-build function will automatically be disabled (CO15 set to 0 or 1). In this
case, the auto increment function will not have an effect on the device object name, only on the device object ID.
16 DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

SETUP AND CONFIGURATION
Object list
Table 17-1:
Object List
Property Description Range/Type R/W
Device Object
APDU_Timeout Time between retransmissions in milliseconds. This device does not support
retransmissions, so this always reads as “0”. 0 R
App Software Version Controller Firmware Version (assembled by firmware)
XX.XrYY (“X” = version; “Y” = revision) String R
Database_Revision Increases if the settings change 16 bit R
Daylight_Savings_Status Daylight savings status of host controller True/False R
Description Description of controller or location 32 Bytes R/W
Device Address Binding Address binds List R
Firmware_Revision BACnet Firmware Revision String R
Local_Date Date of host controller in format YYYY-MM-DD-DOW YYYY-MM-DD-DOW R
Local_Time Time of host controller in format HH:MM:SS HH:MM:SS R
Max APDU Length Accepted The maximum APDU length supported by this device is 480. 16 bit R
Max Info Frames The value specifies the maximum number of information frames the node
may send before it must pass the token. 1 R/W
Max_Master Number of the highest addressed node 1…127 R/W
Model_Name
“X2-abcde-BAC” (assembled by firmware)
a = number of loops
b = number of passive inputs
c = number of universal inputs
d = number of binary outputs
e = number of analog outputs
String R
Number_of_APDU_Retries Number of retransmissions. This device does not support retransmissions,
so this always reads as “0”. 0 R
Object_Identifier Device object identifier (CO06…CO09) 22 bit R/W
Object_Name Name of device 32 Bytes R/W
Object_Type The value is always “Device” for the device object 10 bit R
Protocol_Objects_Supported The enumeration of the supported object types List R
Protocol_Services_Supported The enumeration of the supported services List R
Protocol_Version BACnet protocol version number 1 R
Protocol_Revision BACnet protocol revision number 14 R
Segmentation_Supported This device does not support segmentation, so this always reads as “NO_
SEGMENTATION (3)”. 0…3 R
System_Status
Current physical and logical status supported:
• OPERATIONAL (0)
• DOWNLOAD_REQUIRED (2) (IF INT. EEPROM CONF. ERRORS)
• NON_OPERATIONAL (4) (IF INT. I2C BUS ERRORS)
0…5 R
UTC_Offset Offset to UTC time in case UTC time synchronization is used -780…780 R/W
Vendor_Identifier 561 R
Vendor_Name Vector Controls GmbH String R
Object_List List of all objects currently implemented in the device List R
17
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

SETUP AND CONFIGURATION
Object list (continued)
Table 18-1:
Object List (continued)
Property Description / Property Description Range/Type R/W
Analog Input Object
Object_Identifier AI number 8bit R
Object_Name Name of the input, Assembled from template plus number String R
Description Description of the input 16 Bytes R/W
Preset_Value Current value of input, writable only if out of service is set Floating Point R
Status_Flags In_Alarm, Fault, Overridden, Out_Of_Service Flags R
Event_State Always NORMAL Flags R
Reliability
NO_FAULT_DETECTED, NO_SENSOR, OVER_RANGE, UNDER_RANGE,
OPEN_LOOP, SHORTED_LOOP, COMMUNICATION_FAILURE,
UNRELIABLE_OTHER
List R
Out_Of_Service Writing to Out_Of_Service property is not supported Flag R
Units Describes the units used. Degree Celsius or Fahrenheit has to be set by
MV02. 8bit R
Analog Value Object
Object_Identifier AV number 8bit R
Object_Name Name of the value, Assembled from template plus number String R
Description Description of the input 16 Bytes R/W(1)
Preset_Value Current value of input, writable only if out of service is set Floating Point R/W(2)
Status_Flags In_Alarm, Fault, Overridden, Out_Of_Service Flags R
Event_State Always NORMAL Flags R
Out_Of_Service Writing to Out_Of_Service property is not supported Flag R
Units Describes the units used. Degree Celsius or Fahrenheit has to be set by
MV02. Coded Value R
Binary Value Object
Object_Identifier BV number 8bit R
Object_Name Name of the input, Assembled from template plus number String R
Description Description of the input 16 Bytes R/W(3)
Preset_Value True or False, writable only if out of service is set ON, OFF R/W
Status_Flags In_Alarm, Fault, Overridden, Out_Of_Service Flags R
Event_State Always NORMAL Flags R
Out_Of_Service Writing to Out_Of_Service property is not supported Flag R
(1) Writable for objects with writable Present Value property only. (AVxx > AV11)
(2) Writable for AV indexes greater than 11.
(3) Writable for objects with Instance Number greater than 100.
18 DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

SETUP AND CONFIGURATION
Object list (continued)
Table 19-1:
Object List (continued)
Property Description / Property Description Range/Type R/W
Multi State Value Object
Object_Identifier MV number 8bit R
Object_Name Name of the input, Assembled from template plus number String R
Description Description of the input 16 Bytes R/W(1)
Preset_Value Unsigned Integer 8bit R/W
Status_Flags In_Alarm, Fault, Overridden, Out_Of_Service Flags R
Event_State Always NORMAL Flags R
Out_Of_Service Writing to Out_Of_Service property is not supported Flag R
Number_Of_States Unsigned Integer 8bit R
State_Text Array of strings 8bytes/state maximum R
(1) Writable for objects with Instance Number greater than 100.
19
DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL

SETUP AND CONFIGURATION
Description of available objects
Table 20-2:
Description of Available Objects
Object Name (8 Bytes) Description Range/Type R/W
Controller Information
AV 08 #Alarm Number of alarms 8bit R
Controller State
BV 00 OpStOo Operation state On - Off: Inactive / Active BV R/W
MV 02 Degree Operation state Celsius – Fahrenheit: 1 = Celsius, 2 =
Fahrenheit MV R/W
BV 04 AccSp Enable access to set points BV R/W
MV 03 OpStOPMS Operation State Master/Slave mode: “Master” /
“Slave” MV R/W
MV 04 OpStWink Operation State “Wink” function: “WinkON” /
“WinkOFF” MV R/W
Universal Inputs
AI 101 UI-01 Universal Input 01, 16 bytes Room RH R
AV 101 UI-01-OS Universal Input 01 Offset (calibration = 01u6), 16 bytes Room RH
Offset R/W
AI 106 UI-06 Universal Input 06, 16 bytes Duct RH R
AV 106 UI-06-OS Universal Input 06 Offset, 16 bytes Duct RH
Offset R/W
Alarms
MV 601 AL-01 Alarm 1: Not Active, Active, Need confirmation, 16
bytes Hi/Low Input R/W(1)
Control Loops
AV 211 LP-01-SSP Saved set point, 16 bytes R/W
AV 212 LP-01-CSP Calculated set point R
AV 213 LP-01-PROP Proportional output R
Analog Outputs
MV 311 AO-01-ST Analog Output 1 state R
AV 311 AO-01-VAL Analog Output 1 Value, 16 bytes R
AV 312 AO-01-OV Analog Output 1 Override Value R/W
(1) Writable to “not active” only, if state is “not active, need confirmation”.
Note: The DriSteem application of the X2 controller on DriSteem model TRI2 does not use all available BACnet points.
This list includes only the BACnet points as used with DriSteem humidifiers. Some points apply only to duct sensor
applications and others apply only to room wall sensor applications.
20 DRISTEEM TCI AND TRI2 HUMIDISTAT INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
