FULL FACE MASK RESPIRATOR
DH FFM
Description
The Dromex® DHFFM full face mask provides the user with unparalleled
vision, comfort and reliability protecting against hazardous vapours, gases
and particulates, provided there is sufficient oxygen present in the
contaminated atmosphere.
The Dromex® full face mask utilizes the Dromex® twin uni-fit cartridges and
pre-filters only.
Special Instructions
All respiratory selections should be read in conjunction with BS EN 529:2005
“Respiratory Protective devices – Recommendations for selection, use, care and
maintenance”.
Do not use these respirators or enter in area where:
• The oxygen concentration is not known or is less than 19.5%.
• Contaminants or their concentrations are unknown or are known to be
immediately dangerous to life or health.
• Particulate concentrations exceed levels fixed by the applicable health
and safety regulations or protection factor 40 NPF whichever is lower.
• Gases and/or vapours are present except for respirators designated as
protecting against vapours, in which case vapour concentrations should
not exceed 20 NPF.
• The requirement for leak tightness is unlikely to be achieved if worn
against a beard or facial stubble.
• Do not wear standard eye glasses with a full-face respirator
• Not to be used for firefighting.
• These respirators do not supply oxygen. Do NOT use in oxygen deficient
atmospheres (e.g. tanks or other poorly ventilated areas).
• Do not use in explosive atmospheres.
• Do not modify or alter this device.
Compliance & Conformity
NRCS Homologated to SANS 50136:1998 CL1 as required by the Occupational
Health and Safety Act, 1993 (Act No. 85 of 1993)
EN136:2008 approved: Respiratory protective devices full face masks —
Requirements, testing, marking quality system as per ISO9001:2008.
Specifications
Type: Class1 full face masks for light duty use
Material: Thermo Plastic Elastomer/Rubber
Colour: Black
Harness: 5-point comfort harness with 2 grip holes for easier fitting
on and removing with gloves and accommodation of
women’s hair (ability to wear a pony tail).
Withstands a pull of up to 15KG or 150N
Visor: Polycarbonate anti-fog and impact resistant with
peripheral optical vision of 220 degree’s (110 on the left
and right). The natural field of vision is greater than
the 70% specified of EN136:2008 standards.
One size mask body: Accommodates small to large facial size's
Temperature: Designed to withstand temperatures of up to 70 ± 3˚
Light weight dual filter cartridge system evenly
distributes weight of mask and cartridges on the face.
DHFFM
10
-20˚C
+40˚C
<75% RH DHFFM
Packaging, Storage & Obsolescence
DHFFM - Packed individually sealed in cardboard box,10 masks per
carton for shipping.
When not in use, store the full-face mask with filters in the Dromex®
full face mask storage bag that can be worn on the operator’s waist.
Store in a cool dry place, away from direct sunlight at temperature
between-20˚C and + 40˚C and where relative humidity is less than
75% and away from sources of possible contamination and physical
damage.
Cleaning & Maintenance
- Remove cartridge filters from connectors and all inhalation and
exhalations valves.
- Clean / disinfect the face piece and components with a damp cloth,
using lukewarm with all-purpose detergent
(neutral, pH 6-8, e.g.: washing-up liquid), warm soapy water or cleaning
solution not exceeding 30 degrees.
- Do not immerse the product in water or use abrasive cleaners.
- Do not use solvents (e.g alcohol, acetone, turpentine), hot water, strong
detergents, bleaches or petroleum based products to clean any part of
masks.
- Dry in air at room temperature.
- Replace all components after cleaning and inspect for visible damage.
Shelf life
5 years, with correct maintenance and storage procedures. Discard
immediately if mask is damaged and tears are visible.
Materials
None of the materials used in the manufacture are known to adversely
affect the hygiene or health.
Disposal
All industrial waste should be disposed of correctly according to local
regulations and good disposal practice. Respiratory protective
devices should be disposed of considering the hazardous substance
they were used for. Please consider recycling.

Fitting your Full Face Mask
•Visually inspect the mask for any tears or damage, ensuring all
components is in place and secure.
•Connect filtering cartridges to face piece
•Fully extend all head straps prior use.
•Centre the face mask onto your face by placing your chin and nose in the
chin and nose cup simultaneously whilst placing the extended harness
over your head
•Adjust harness straps, by first pulling the neck straps, towards the shape
of your head followed by temple straps and head strap
•Never pull harness straps away from the shape of your head as harness
straps can result in damage, rendering mask un-usable.
•Once tighten securely, conduct negative and positive pressure seal checks
of the masks
Mask leak tests
Negative pressure:
-Cover inhalation filters with the palm of your hand, inhale and hold your
breath for 5 seconds.
-The facepiece will collapse and remain collapsed against the face.
-Remove hand and breathe normally.
-If the facepiece did not remain collapsed during the test, or any leakage is
noticed, readjust straps and perform Negative Pressure Seal Test again.
Positive pressure check:
-Place palm of your hand over the exhalation valve and exhale.
The face piece should not leak around the face seal
-Maintain positive pressure for at least 5 seconds
a) If no outward leakage is detected, the test has been passed.
b) If leakage is detected (usually felt as a cool sensation against the
skin or as a loss of pressure hold), either the respirator is
malfunctioning or a gross leak exists between the face and face
piece
Removal of your mask
-Push harness buckles forward to loosen and fully extend the
harness straps.
-Insert thumbs under the bottom harness strap to pull face mask up
and away from face.
Materials
Marking
Each mask is marked as indicated below:
DH-FFM DX-02
S~L
DX-06
EN 136:1998 CL1
No. DESCRIPTION NO. DESCRIPTION.
DX1 Harness DX11 Face cup value support-side valve
DX2 Full face sealing DX12 Mask body
DX3 Clear visor DX13 Valve seal ring-front
DX4 Metal buckle DX14 Exhalation valve support front
DX5 Adjustable clip DX15 Exhalation valve diaphragm
DX6 Full mask frame-top DX16 Exhalation valve cover-front
DX7 Full mask frame-base DX17 Valve seal ring-side
DX8 M4 stainless steel support-side valve DX18 Inhalation valve support-side valve
DX9 M4 cupper nut DX19 Inhalation valve diaphragm
DX10 Inhalation valve
