Dr. Clark Mini User manual

Mesh Nebulizer User Manual
This device utilizes state-of-the-art microporous atomizing mesh technology that
sprays liquid medication into aerosol/vapor form and delivers it directly to the
patient for inhalation. Both adult and pediatric patients suffer from asthma,
Chronic Obstructive Pulmonary Disease (COPD) such as emphysema and chronic
bronchitis, or other respiratory disease that are characterized by obstruction to air
flow and/or patients who are on and off ventilation or other positive pressure
breathing assistance.
For pure soluble liquid only. Please don't use purified water, oil, milk, or thick
liquid. The atomization volume varies varies with the concentration of the
liquid.
Clean the mesh plate after each use to avoid blockage. Note: Do not touch the
mesh with your hand, brushes or any hard objects.
Do not rinse or immerse the nubulizer in any liquid. Any liquid spilled on or
inside the nubulizer should be allowed to dry before operating.
Do not place the nubulizer on heated surfaces.
Do not turn on the nebulizer when the medicine container has no liquid.
Medicine container lid
Medicine container
Nebulizer
Charge port
ON/OFF button / operation LEDs
Masks (2)
Mouthpieces (2)
Mesh plate cover
USB charging cable
1.
2.
3.
4.
5.
6.
7.
8.
9.
Brief Introduction
Warning
Description of Device and Accessories
1
2
9
8
3
4
5
6
7

Function
Three atomization modes: strong, medium and weak. Chose the modes by
pressing the ON/OFF button.
LED light indicator. The light turns yellow when the atomizer is charging. It
turns green when it completes charging and is ready to atomize. It turns green
and yellow alternately when it is performing an automatic cleaning.
Automatic cleaning. Press the ON/OFF button for 5 seconds to start automatic
cleaning.
20 minute timed shutdown.
Built-in lithium battery.
1.
2.
3.
4.
5.
Usage
Preparing the nebulizer
For reasons of hygiene, it is imperative that the nebulizer and accessories are
cleaned and disinfected after every use.
Using the nebulizer
Turn the medicine container lid anticlockwise to open it, and fill the medicine
container with an isotonic saline solution or medicine. Do not overfill. The
maximum recommended fill amount is 25 ml. Then tighten the medicine
container lid.
Attach other parts like the mouthpiece or mask to the nebulizer based on your
need.
To use the mouthpiece: Place the device in your mouth and close your lips
firmly around the mouthpiece.
To use the mask: Place the mask over your nose and mouth.
Press the ON/OFF button to choose your preferred working mode. For
example, 5 ml of medicine will take about 15 minutes with the strong mode
and about 30 minutes with the weak mode.
Start the device using the ON/OFF button.
The spray mist coming from the device and the illuminated green light shows
that the device is working perfectly.
The nebulizer turns off automatically after 20 minutes. Press the ON/OFF
button again to continue using the device.
1.
2.
3.
4.
5.
6.
7.
8.
Charging
If the therapy requires that different medicines be inhaled in succession, ensure
that the nebulizer is cleaned after every use.
The device is rechargeable by USB cable.
When plugged in, the yellow light will stay on. The light turns green after the
device is fully charged.
The device can be used for about 80 minutes on a full charge.
1.
2.
3.

Cleaning and Maintenance
Accessories: Remove the mouth piece and any accessories from
the nebulizer and disinfect them with a medical alcohol wipe or
soak.
Nebulizer: Add 6 ml of clean water to the medicine container and
switch on the device to start automatic cleaning. Remove any
medicine residue from the mesh plate.
Clean the device with a soft, dry and clean towel.
Put the mesh plate cover back on the device after cleaning. Store
all parts in a dry and cool place.
Recharge the device every two months to ensure longer battery
life.
1.
2.
3.
4.
5.
Device and Accessories
1 x Mini nebulizer
1 x USB cable
2 x Face masks (for kids and adults)
2 x Mouthpieces
1 x User manual
Technical Specifications
Main connection: 100-240V, 50-60Hz, 0.15A
Input: 5V/1A
Atomized particles: ≤5 micrometer
Medication flow rate: approx. 0.2 ml/min
Noise: ≤50 dB(A)
Volume: max. 25 ml
Product weight: 100 g + 5% (not including accessories)
Size: 118 mm (height), 39.5 mm (diameter)
Housing material: ABS
Operating conditions: temperature +5°C - +40°C
Relative humidity: 15% - 93%
Storage and transport conditions: temperature -10°C - +45°C

Insufficient medicine in the nebulizer.
The nebulizer is not held in an upright position.
The medicine used is unsuitable for spraying
(e. g. too thick, viscosity must be less than 3).
The indoor temperature is too low. Fill with 3 to
6 ml of hot water (above 80°F), then nebulize it
completely. Do not inhale this spray.
1.
2.
3.
4.
Power shortage. Recharge the device or
replace the battery.
There are air bubbles inside the medicine
container that are preventing the medicine
from coming into continuous contact with the
mesh plate. Check and remove any bubbles.
Particles on the mesh are impeding output. To
remove the particles, fill the nebulizer with 2 to
3 drops of vinegar and 3 to 6 ml of water, then
nebulize this solution completely. Do not
inhale this spray and ensure that you clean and
disinfect the medicine container afterwards.
Mesh plate is worn out.
1.
2.
3.
4.
This is normal and occurs for technical reasons.
Stop inhaling as soon as you can hear a difference
in sound from the nebulizer, or when the device
switches off automatically due to insufficient
inhalant.
For babies, the mask should cover the mouth
and nose to guarantee effective inhalation.
For children, the mask should cover the
mouth and nose.
Children should only use the device with help
and under supervision of an adult. Never leave
a child alone with the nebulizer.
1.
2.
3.
Only a doctor can advise you on which medicine
to use for your condition. Consult your physician .
With the mesh nebulizer, you can only atomize
medicines with a viscosity lower than 3.
Troubleshooting / FAQ
Problem / Question Possible Cause / Answer
The nebulizer produces
little or no aerosol
Output is too low
Some inhalation solution
remains in the nebulizer
What special steps should
be taken for babies or
children?
Does each user need their
own accessories?
Yes, this is absolutely necessary for hygiene
reasons.
What medicines can be
nebulized?
