RC EYE Imprimo
3D Print Version (Full/CF)
RC EYE Imprimo
3D Druckversion (Gesamtdruck/CF)
INTRODUCTION
There are two versions you can build with the help of 3D printed components:
Full version: all constructional components are 3D-printed
CF version: requires the carbonbre frame
3D-printed components you are required to print yourself, or have them printed by a
provider. The 3D models for both versions (Full/CF) are available for download from
www.droneart.com.
All company names and product designations contained herein are trademarks of
the respective owners. All rights reserved.
SAFETY INSTRUCTIONS
>Read the instructions carefully and store them in a safe place.
>Danger of injury! Sharp edges can result in cuts or similiar injury. Make sure to
deburr edges if necessary.
>Make sure to only use undamaged components. Check printed components
for damage before use.
ASSEMBLY
For assembly instructions, refer to the assembly page of this document
corresponding to your model, and the latest Imprimo instruction manual available
on www.droneart.com.
PRODUCT SUPPORT
Visit http://droneart.com/help-and-support/ or call +852 2559 2662 for product
support. Additionally, visit our Online Ticket System at https://droneart.com/ticket
for any DroneArt inquiry.
Assembly instructions
EINFÜHRUNG
Zwei Modelle können aus 3D-gedruckten Bauteilen erstellt werden:
Vollversion: alle Konstruktions-Bauteile sind 3D-gedruckt
CF Version: benötigt den Karbonrahmen
3D Bauteile müssen Sie selber ausdrucken oder durch einen Anbieter drucken
lassen. Die 3D-Modelle beider Versionen (Full/CF) stehen auf www.droneart.com
zum Herunterladen zur Verfügung.
Firmennamen und Produktbezeichnungen sind Warenzeichen der jeweiligen
Inhaber. Alle Rechte vorbehalten.
SICHERHEITSANWEISUNGEN
>Lesen Sie sich die Anleitung genau durch und bewahren Sie diese auf.
>Verletzungsgefahr! Scharfe Kanten führen zu Schnitten oder ähnlichen
Verletzungen. Entgraten Sie scharfe Kanten, falls notwendig.
>Verwenden Sie nur unbeschädigte Bauteile. Überprüfen Sie Bauteile vor der
Installation auf Beschädigung.
MONTAGE
Beachten Sie die Montageschritte auf der zu Ihrem Produkt passenden Seite
dieses Dokuments und die neueste Version der Bedienungsanleitung zum
Imprimo, erhältlich auf www.droneart.com.
PRODUKT-SUPPORT
Wenn Sie technische Hilfe benötigen, besuchen Sie http://droneart.com/help-and-
support/ oder rufen Sie uns an unter +852 2559 2662. Zusätzlich steht Ihnen für
Fragen rund um Drone Art unser Online-Ticket-System unter https://droneart.com/
ticket zur Verfügung.
Montageanleitung
Diese Anleitung wurden von CEI Conrad Electronic International (HK) Limited, 18th Floor, Tower 2, Nina Tower,
No. 8 Yeung Uk Road, Tsuen Wan, New Territories, Hong Kong veröffentlicht. Alle Rechte vorbehalten, einschl.
Übersetzung. Die Vervielfältigung durch irgendeine Methode, d.h. Fotokopie, Mikrolm oder in einer digitalen,
elektronischen, optischen oder in anderer Form erfordert die vorherige schriftliche Genehmigung vonseiten
des Herausgebers. Die Vervielfältigung durch Drucken, auch teilweise, ist ebenso untersagt. Diese Anleitung
entspricht dem technischen Stand bei Drucklegung.
© 2018 by CEI Conrad Electronic International (HK) Limited
88028_29_30_31_34_35RC_v1_0418_02_m_3DPrint_jh_en_(3)
No. 88028RC / 88029RC / 88030RC /
88031RC / 88034RC / 88035RC
Nr. 88028RC / 88029RC / 88030RC /
88031RC / 88034RC / 88035RC
REQUIRED 3D PARTS / ERFORDERLICHE 3D BAUTEILE
Full version / Gesamtdruck
CF version / CF Version

PB 1.7x5 self-tapping screws
PB 1.7x5 selbst-schneidende
Schrauben
M2x6 screws for motors
M2x6 Schrauben für Motoren
M2x6 screws for motors
M2x6 Schrauben für Motoren M2x6 screws for motors
M2x6 Schrauben für Motoren
M2x8 screws for prop guards
M2x8 Schrauben für Propellerschützer
M2x8 screws for prop guards
M2x8 Schrauben für Propellerschützer
M2x8 screws for prop guards
M2x8 Schrauben für Propellerschützer
M2x12 screws to mount FC/ESC
M2x12 Schrauben zur Installation von FC/ESC M2x12 screws to mount FC/ESC
M2x12 Schrauben zur Installation von FC/ESC
PB 1.7x5 self-tapping screws to mount VTx tray
PB 1.7x5 selbst-schneidende Schrauben zur
Installation von VTx Kunststoffeinsatz
Glue to VTx tray
Mit VTx Einsatz verkleben
Glue to frame
Mit dem Rahmen verkleben
Glue to frame
Mit dem Rahmen verkleben
FULL VERSION / GESAMTDRUCK
Imprimo FPV-HD Imprimo FPV Imprimo Non-FPV

PB 1.7x5 self-tapping screws
PB 1.7x5 selbst-schneidende Schauben
M2x6 screws for prop guards
M2x6 Schauben für Propellerschützer
M2x5 screw / M2 nut
M2x5 Schraube /
M2 Mutter
M2x6 screws for prop guards
M2x6 Schauben für Propellerschützer
M2x6 screws for prop guards
M2x6 Schauben für Propellerschützer
Use rubber band mount; M2x14 screws to mount FC/ESC
Gummiband-Halter verwenden; M2x14 Schauben zur Installation
von FC/ESC
Use rubber band mount; M2x14 screws to mount FC/ESC
Gummiband-Halter verwenden; M2x14 Schauben zur Installation
von FC/ESC
Glue to VTx tray
Mit VTx Einsatz verkleben
CF VERSION / CF VERSION
Imprimo FPV-HD Imprimo FPV Imprimo Non-FPV
This manual suits for next models
