Dry-Matic Boost Bar Manual

Fan to Boost Bar Connectors
The Fan to Boost Bar Connectors not only help
guide all of the airow into the Boost Bar, increas-
ing pressure and air velocity out of the 90deg
Adaptor, but they also tether the Airmover and
Drymatic Boost Bar together.
This reduces the risk of the policyholder seperat-
ing the two items on a claim and minimises the
chances of disruption to your drying regime.
Phone: [phone]
Email@ [e-mail]
Website: www.drymatic.com
https://facebook.com/DBKDrymatic
DRYMATIC BOOST BAR - 90DEG ADAPTOR SETUP
The intended purpose of the Drymatic Boost Bar is to heat the airow generated by a Centrifugal or Radial Air-Mover.
The system adds Heat Energy to the airow, resulting in greater evaporation potential.
• Read the Owner’s Manual fully before setting up and operating the Drymatic Boost Bar
• This presentation material oers set-up and use guidelines but DOES NOT substitute for fully reading the Owner’s
Manual.
• The Owner’s Manual and additional product information can be found on www.drymatic.com
Operating as a Target Drying System:
The Drymatic Boost Bar can be used to raise the ambient temperature within tented chambers, voids, suboor spaces,
and cavities. Increasing the temperature of the aected materials will result in an increase in evaporation potential.
This guide will walk you through the use of the Boost Bar with the 90deg Adaptor.
Step 1: The Drymatic Boost Bar should be placed in front of a centrifugal or radial airmover (not axial) – it is
recommended that the airmover have a similar outlet size to that of the Boost Bar. A Fan to Boost Bar Connector
should be used to maximise airow between the two units. The Boost to Fan connector is xed using the Velcro strap
on either side of the connector, this allows for various outlet sizes.

Phone: [phone]
Email@ [e-mail]
Website: www.drymatic.com
https://facebook.com/DBKDrymatic
DRYMATIC BOOST BAR - 90DEG ADAPTOR SETUP
Step 2: The user can set a Maximum Temperature limit on the Boost Bar. This controls the Air Out temperature
conditions and this is incredibly useful when target drying sensitive construction materials such as lathe and plaster.
To set the ‘Max Air O’ limit you need to go to the settings screen via the button on the Home Screen.
Once in the settings screen, you can change the ‘Max Air O’ by pressing the value and increasing/decreasing the
number to suit your requirements.
The User can‘RESET’ the ‘Hours Run’ and ‘kWh’ via the Reset Button in the settings menu. The User can also set a
Maximum Current Limit for situations where Amperage on the Distribution Board is limited. This Current Limiter will
restrict the number of heater banks used (3 Heater Banks in Total)
Step 3: The 90deg Adaptor can be connected to the Drymatic Boost Bar using the xing brackets connected to the
device. The clasp locks on to the bracket on the outlet of the Drymatic Boost Bar for a quick and easy connection,
without the need for additional xings. It can be used in two orientations, diverting air upwards into a room (or void
using layat ducting), or downwards into a suboor space.

Attachment of the 90deg Adaptor
1. Place the 90deg Adaptor in the outlet of the Drymatic
Boost Bar (facing upwards or downwards)
2. Connect the metal clasps on the adaptor to the metal
brackets on the sides of the Boost Bar.
3. Place the outlet of the adaptor over the opening in the
suboor if diverting air into a suboor space OR place the
system in a suitable location if blowing upwards into the
room (or into a ceiling void using layat ducting)
Phone: [phone]
Email@ [e-mail]
Website: www.drymatic.com
https://facebook.com/DBKDrymatic
DRYMATIC BOOST BAR - 90 DEG ADAPTOR SETUP
Divert Upwards Divert Downward
