DryAIR DryPro 7000 User manual

Dehumidifier Manual
DRY PRO 7000
313 North Oak Street Burlington, WA 98233
Tel: [phone] • Fax: [phone]
Toll Free U.S. & Canada: 888.755.9176
Email: [email protected] • www.dryairtech.com

DRYPRO™7000 OWNER’S MANUAL
1
Congratulations on your purchase of the
DryPro™7000. This dehumidifier has
been designed to offer you the
reliability, durability and portability you
need.
Your DryPro™7000 removes up to a
maximum of 120 pints per day at
saturation.
The DryPro™7000 includes factory-
installed wheels, handle and automatic
pump-out system.
SAFETY INFORMATION
Caution!
Unit operates on alternating
current:
110/120 volt, 60 Hz
Or 230 volt, 50 Hz
Do not operate your DryPro™7000
Dehumidifier with a cut or frayed power
cord. Do not unplug your dehumidifier
by pulling on its cord. Grasp the plug
firmly and pull it out of the wall socket.
The plug has a safety ground pin
installed that must not be removed. If
the pin is damaged or missing, have the
power cord replaced at once. Visually
inspect the power cord before each use.
Ignoring these safety precautions may
result in a fire or an electric shock.
Never operate electrical equipment in
standing water. There is a shock hazard.
Never drop the unit. Sudden and severe
impact may result in damage to internal
components.
Your DryPro™7000 Dehumidifier
should not be operated with the unit’s
outer cover removed. Personal injury
may result.
Drapes or other loose fabrics can be
drawn against the unit restricting its
airflow. This condition may cause the
unit to overheat. Assure that there is
sufficient space between the back of the
unit and these fabrics to avoid this
condition.
Save the shipping carton in case your
DryPro™7000 Dehumidifier must be
returned for repair. But, discard the
plastic bag to prevent children from
using it as a toy. Also, children should
not be allowed to play on or near a
running dehumidifier.
Never operate your DryPro™7000
Dehumidifier outside when it is raining
and never store your dehumidifier
outside.
This unit should never be serviced or
cleaned while it is plugged into a live
electrical power source.
Warning!
Ignoring these safety precautions may
result in serious personal injury.
OPERATING INSTRUCTIONS
1. If your unit is equipped with wheels,
block them to keep the unit from
accidentally rolling. Also, secure the
dehumidifier during transportation to
prevent its toppling over and to keep
it upright. Severe impact may
damage the compressor or electronic
components.
2. In the event that the unit has been
stored or transported on its side, set it
upright for at least one (1) hour
before starting.
3. Operate your DryPro™7000 only on
a level surface. This will prevent the
unit from spilling condensate or
flooding the area.

DRYPRO™7000 OWNER’S MANUAL
2
4. Plug the unit into a grounded
alternating current circuit and switch
on the unit.
5. Secure the 40 feet pump hose to a
sink or alternative drain.
6. To use the gravity drain, connect the
hose to the fitting on the back of the
unit under the drip tray. Place the
hose into a suitable receptacle or
drain connection.
7. Residual water left in the collection
tray can be removed by using the
manual purge switch. Continue to
depress switch until all water is
removed.
8. If the unit is shut down for any
reason, allow at least five minutes
before restarting. This will avoid
damage to the compressor.
9. Assure that the fan and compressor
are properly functioning before
leaving a running unit unattended.
MAINTENANCE
Warning!
Disconnect the unit from the power
supply before cleaning or servicing.
Filter Cleaning: The filter shroud must
be cleaned after every job. The filter
itself should be vacuumed frequently to
control the build-up of soil. On a
periodic basis, the filter should be
removed completely from the unit. It
can be washed with water and mild
detergent. Allow the filter to thoroughly
dry before reinstalling it in the unit.
Coil Cleaning: As the coils accumulate
soil, their heat transferring properties are
reduced. This can diminish water
extraction and create undue pressure on
the refrigeration system.
The coils should be cleaned about every
8 to 12 weeks. If the DryPro™7000
Dehumidifier is used in a dusty
environment, cleaning may need to be
accomplished more frequently. The
coils should be dry before the following
cleaning operation is performed.
Dry Method. Inject compressed air
through each coil. Clean the unit’s front
grill with a vacuum equipped with a
brush attachment. After removing the
dry particle contamination, a wet
cleaning process may be used.
Caution!
Do not use a hose to flush the coils
and do not permit water to leak
into the electrical compartment.
Wet method. Use a soft brush and soapy
water. If soils have been allowed to
accumulate over time, they may be dry
and hard. Soak time may be required to
dissolve and release these soils from the
coils. A spray bottle or a syringe can be
used to apply controlled amounts of
cleaning solution. After cleaning, make
sure that the drain port, the condensate
tray and drain tubing are free of any
residual soil.
Electrical Wiring & Cord: Inspect the
power cord periodically to make sure
that the insulation is in good condition.
Replace worn or damaged cords.
Remove the dehumidifier cover to
expose the wiring and terminal block.
Inspect wires to assure that they are
secured away from the fan blade.
Inspect the terminal block connections
and wires for abrasions, nicks or cuts.
Repair or replace as needed.

DRYPRO™7000 OWNER’S MANUAL
3
Warning!
The fan blade is sharp! Do not
touch the edges with your hands,
serious personal injury may result.
Fan Motor: Carefully remove dust and
debris from the fan motor and blade
assembly whenever you remove the
unit’s cover for interior cleaning.
Drain Hose: Inspect the gravity drain
hose to make sure it is in good condition.
The hose should be checked before your
DryPro™7000 Dehumidifier leaves the
shop and again before the unit is left on
the job.
Make sure that the drain hose is not
kinked or cracked. Avoid leaving the
drain hose in a folded position during
transport and storage.
DryPro™7000 FEATURES
The DryPro™7000 utilizes a 6,670 BTU
rotary compressor and “hot gas” bypass.
The DryPro™7000’s temperature
sensitive, intelligent “hot gas” defrost
not only activates only when
environmental conditions dictate but,
once engaged, gets the coils defrosted
and back into action much faster. This
means that the DryPro™7000 is pulling
water out of the air while other units are
defrosting.
To provide more protection for the coil,
the DryPro™7000 has an easily
removable and washable Quadrafoam
Filter. It is made with a special Uni-
Grid support and aluminum frame.
The DryPro™7000 features extra large
12 inch wheels to provide easy mobility
and two flip-up, rubber sleeve handles
mounted on both sides of the unit. This
makes transport much safer. Back strain
and stress is reduced during handling so
there is less chance of the unit being
damaged.
Several units can be operated on the
same circuit. A stainless steel chassis
provides a tough exterior that protects
the unit and will keep looking great for
years.
SPECIFICATIONS
Height: 17”
Width: 14”
Depth: 20”
Weight: 73 LBS
Operating Range: 33°F – 100°F
Max Capacity 120 Pints
Airflow: 200 CFM
Compressor: 6,670 BTU
Power Supply: 110/120V / 60 Hz
230V / 50 Hz
Amperage: 6 Amps
Refrigerant: R - 22
REPAIRS
1. Should an electrical component fail
consult your Distributor or the
Factory Service Center to obtain
OEM parts.
2. If a problem develops in the
refrigeration system, only a certified
refrigeration technician can correct
it. Contact your Distributor or the
Factory Service Center for more
information.
3. For technical support and general
information, contact your Distributor
or the Factory Service Center.

DryPro™PARTS LIST
Description Part Number
S/S Housing RD-00C-S4NA 0321
S/S Front Grill RD-00C-S5NA 0322
S/S Filter Grill RD-00C-S5NA 0323
Rubber Foot AF-00C-R4A10044
DryPro™Air Filter RD-00C-NNNN0178
20’ - Power Cord CF-00E-N4A10004
Strain Relief CF-00E-PNN10006
On/Off Rocker Switch GN-00E-P3B10218
Cover, Rocker Swtich GN-00C-R3NN0335
Momentary Switch GN-00E-P3B30217
DryPro™Drip Tray RD-00C-P6N10208
6,670 BTU Compressor RD-00M-N2A10223
Capacitor 240 VAC/50mf AF-00E-ANNN0235
Evaporator Coil RD-00M-N2AN0075
Condensor Coil RD-00M-N2AN0076
8” Fan Motor Assy RD-03M-NNNN0089
Condensate Pump RD-00M-P6NN0181
ICM Defrost Control RD-00E-N6NN0236
ICM Defrost Control Mount RD-00C-G8NN0407
Hour Meter RD-00E-P5AN0099
3/8 Fitting (Attached to Drip Tray) RD-00M-P3N70100
3/8 Hose Fitting (Attached to 1 ft hose
from pump to 40’ Discharge hose) RD-00M-P3A7031
¼” 40’ Discharge Hose RD-00M-P5A90230
¼ Barb Fitting (Attached to 40 ft hose) RD-00M-P3A70232
12” Wheels RD-00M-PNA10185
Upper Handle SV-00R-MNNN0020
Lower Handle SV-00R-MNNN0021
Star Knob RD-00F-P3A10128
Handles (side of DP 7000) RD-00C-M6A10123
DryPro™Bulkhead RD-00C-G1NN0176
DryPro™Base RD-00C-G1NN0177

Dry Air Technology 10 Year Limited Warranty
Refrigerant Dehumidifier Products
Warrantor: Dry Air Technology, 313 North Oak Street, Burlington, WA 98233. Telephone: 888-755-
9176, local: 360-755-9176, fax: [phone].
Who Is Covered: This warranty extends to the original end-user of refrigerant dehumidifiers
manufactured by Dry Air Technology, and may not be assigned or transferred.
Warranty Period: The term of the warranty coverage from the date of purchase is:
10 years on the cabinet, chassis and housing
5 years on the parts of the sealed refrigeration system
1 year on parts, labor and reasonable shipping costs, excluding filters and accessories.
Warranty Coverage: Dry Air Technology warrants that, for one year refrigerant dehumidifiers
manufactured by Dry Air Technology will operate free from defects in material or workmanship, or Dry Air
Technology, at its option, will repair or replace the defective part(s), free of charge.
Dry Air Technology further warrants that for a period of five (5) years, the condenser, evaporator and
compressor of dehumidifiers manufactured by Dry Air Technology will operate free from defects in
material or workmanship, or Dry Air Technology, at its option, will repair or replace the defective part(s),
provided that all labor and shipping costs for the defective part(s) shall be borne by the end-user.
Dry Air Technology further warrants that for a period of ten (10) years, the cabinet, chassis and housing
of dehumidifiers manufactured by Dry Air Technology, will be free from defects in material or
workmanship, or Dry Air Technology, at its option, will repair or replace the defective part(s), provided
that all labor and shipping costs for the defective part(s) shall be borne by the end-user.
This warranty does not cover any defect, malfunction, etc. resulting from misuse, abuse, lack of normal
care, corrosion from chemicals, freezing, tampering, modification, unauthorized or improper repair or
operation, accident, acts of nature or any other cause beyond Dry Air Technology’s reasonable control.
End-User Responsibilities: Warranty service must be performed by a firm or individual authorized
by Dry Air Technology. If the end-user is unable to locate or obtain warranty service from an authorized
firm or individual, he should contact Dry Air Technology at the above location, which will arrange for
covered warranty service. All covered warranty service will be performed during normal business hours.
Limitations and Exclusions: If any part of a dehumidifier manufactured by Dry Air Technology is
repaired or replaced, the new part shall be warranted only for the remainder of the original warranty
period of the dehumidifier (but all warranties will be extended by the period of time, if any, that the Dry
Air Technology dehumidifier is out of service while waiting for covered warranty service).
UPON THE EXPIRATION OF THE WRITTEN WARRANTY APPLICABLE TO THE DRY AIR TECHNOLOGY
DEHUMIDIFIER OR ANY PART THEROF, ALL OTHER WARRANTIES IMPLIED BY LAW, INCLUDING
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL ALSO EXPIRE. ALL WARRANTIES
MADE BY DRY AIR TECHNOLOGY ARE SET FORTH HEREIN, AND NO CLAIM MAY BE MADE AGAINST DRY
AIR TECHNOLOGY BASED ON ANY ORAL WARRANTY. IN NO EVENT SHALL DRY AIR TECHNOLOGY, IN
CONNECTION WITH THE SALE, OPERATION, REPAIR OR REPLACEMENT OF ANY DRY AIR TECHNOLOGY
DEHUMIDIFIER OR PART THEREOF BE LIABLE UNDER ANY LEGAL THEORY FOR ANY SPECIAL, INDIRECT
OR CONSEQUENTIAL DAMAGES INCLUDING WITHOUT LIMITATION WATER DAMAGE (THE END-USER
SHOULD TAKE PRECAUTIONS AGAINST SAME), LOST PROFITS, DELAY, OR LOSS OF USE OR DAMAGE TO
ANY REAL OR PERSONAL PROPERTY.
Some states do not allow limitations on how long an implied warranty lasts, and some do not allow the
exclusion or limitation of incidental or consequential damages, so one or both of these limitations may not
apply to you.
Legal Rights: This warranty gives you specific legal rights, and you may also have other rights, which
vary from state to state. DRY AIR TECHNOLOGY, BURLINGTON, WASHINGTON
