DSC MD12 User manual

MD12
Modem
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Software Version 1.0
Introduction
The DSC modem is a communication device designed to enable computer terminals, through use of an RS232 port to
communicate via telephone lines with the DSC line of downloadable security systems.
Although the DSC modem uses the Hayes command set as a template, not all Hayes commands are supported. As a result,
some communication packages that are Hayes compatible may not work.
The modem is compatible with Bell 103-300 and 110 baud data communication standards, using standard Hayes commands.
LEDs
The LED indicators on the top of the modem indicate Power (Red), Received Data (RX) (Green), and Transmitted Data (TX) (Red).
Connections
The six pin connection on the left hand side of the modem is used to connect the modem to the RS232 port on the computer.
The connection is made using the 6 pin - 25 pin adapter that is shipped with the modem and a 6 pin “swapped” cable. When
looking at both ends of the cable (held facing the same way and in the same direction) the color codes of the wires inside the
connectors should be opposite to each other. The right-hand 4 pin connector is where the phone line is connected to the
modem. The middle 4 pin connection is for an optional phone.
Jumper Settings
JP1 selects the pulse dialing option. OFF = North American, ON = European.
Power Supply
Input - 110VAC
Output - 12 VAC, 150mA
Parts
1 DSC modem
1 6-pin patch cable
1 6- to 25-pin adapter
1 12 VAC 800mA power supply
1 4-pin patch cable
Connection to Computer
DO NOT apply power until all connections have been made and verified. Improper connection may damage your computer or
modem.
Connect the 6-25 pin adapter to your RS232 port using the female to female connector. Connect the 6 pin cable from the 6-
25 pin adapter to the 6 pin connector on the Modem.
Connection to Phone Line
On the modem, there are two four-pin connections. The middle 4-pin connector is for an optional phone. The connector on the
right is for the incoming phone line from the wall connector. When the modem is in communication, the optional phone
connection will be automatically disconnected for the duration of the communication.
Specifications
Baud Rate: ..............................110, 300 and 1200 bps
Parity: ......................................8 data bits, no parity, 1 stop bit
Dialing: ....................................Touch Tone dialing (DTMF) or Pulse dialing
Power Requirements: ............12 VAC, 150mA
Operating Temperature: ........0 - 40 oC, 32 - 110 oF
Usage
Note: The MD-12 can only be used with DLS-1 v6.2 and up. Please refer to the DLS manual for modem communication
instructions and computer configuration requirements.

© 1996 Digital Security Controls Ltd.
1645 Flint Road, Downsview, Ontario, Canada M3J 2J6
[phone] • 1-800-387-3630
Printed in Canada 29002080 R0
INDUSTRY CANADA NOTICE
NOTICE: The Industry Canada label identifies certified equipment. This
certification means that the equipment meets certain telecommunications network
protective, operational and safety requirements. Industry Canada does not
guarantee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company. The
equipment must also be installed using an acceptable method of connection. The
customer should be aware that compliance with the above conditions may not
prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian
maintenance facility designated by the supplier. Any repairs or alterations made by
the user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the
equipment.
User should ensure for their own protection that the electrical ground connections
of the power utility, telephone lines and internal metallic water pipe system, if
present, are connected together. This precaution may be particularly important in
rural areas.
CAUTION: Users should not attempt to make such connections themselves, but
should contact the appropriate electric inspection authority, or electrician, as
appropriate.
NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal
device provides an indication of the maximum number of terminals allowed to be
connected to a telephone interface. The termination on an interface may consist of
any combination of devices subject only to the requirement that the sum of the
Ringer Equivalence Number of all the devices does not exceed 5.
The REN of this unit is 0.5B.
AVIS: L’étiquette de l’Industrie Canada identifie le matériel homologué. Cette
étiquette certifie que le matériel est conforme à certaines normes de protection,
d’exploitation et de sécurité des réseaux de télécommunications. Industrie
Canada n’assure toutefois pas que le matériel fonctionnera à la satisfaction de
l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le
raccorder aux installations de l’entreprise locale de télécommunication. Le
matériel doit également être installé en suivant une méthode acceptée de
raccordement. L’abonné ne doit pas oublier qu’il est possible que la conformité
aux conditions énoncées ci-dessus n’empêchent pas la dégradation du service
dans certaines situations.
Les réparations de matériel homologué doivent être effectuées par un centre
d’entretien canadien autorisé désigné par le fournisseur. La compagnie de
télécommunications peut demander à l’utilisateur de débrancher un appareil à la
suite de réparations ou de modifications effectuées par l’utilisateur ou à cause de
mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit s’assurer que tous les fils de mise à la
terre de la source d’énergie électrique, les lignes téléphoniques et les
canalisations d’eau métalliques, s’il y en a, sont raccordés ensemble. Cette
précaution est particulièrement importante dans les régions rurales.
AVERTISSEMENT: L’utilisateur ne doit pas tenter de faire ces raccordements
lui-même; il doit avoir recours à un service d’inspection des installations
électriques, ou à un électricien, selon le cas.
AVIS: L’indice d’équivalence de la sonnerie (IES) assigné à chaque dispositif
terminal indique le nombre maximal de terminaux qui peuvent être raccordés à
une interface. La terminaison d’une interface téléphonique peut consister en une
combinaison de quelques dispositifs, à la seule condition que la somme
d’indices d’équivalence de la sonnerie de tous les dispositifs n’excède pas 5.
L’indice d’équivalence de la sonnerie (IES) de ce produit est 0.5B.
FCC COMPLIANCE STATEMENT
CAUTION: Changes or modifications not expressly approved by Digital Security Controls
Ltd. could void your authority to use this equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
■Re-orient the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
■Consult the dealer or an experienced radio/television technician for help.
The user may find the following booklet prepared by the FCC useful: “How to Identify
and Resolve Radio/Television Interference Problems”. This booklet is available from the
U.S. Government Printing Office, Washington D.C. 20402, Stock # 004-000-00345-4.
IMPORTANT INFORMATION
This equipment complies with Part 68 of the FCC Rules. On the side of this equipment is
a label that contains, among other information, the FCC registration number of this
equipment.
NOTIFICATION TO TELEPHONE COMPANY Upon request, the customer shall
notify the telephone company of the particular line to which the connection will be
made, and provide the FCC registration number and the ringer equivalence of the
protective circuit.
MD12 FCC Registration Number: F53CAN-30487-DT-E
Ringer Equivalence Number: 0.5B
TELEPHONE CONNECTION REQUIREMENTS Except for the telephone company
provided ringers, all connections to the telephone network shall be made through
standard plugs and telephone company provided jacks, or equivalent, in such a manner
as to allow for easy, immediate disconnection of the terminal equipment. Standard
jacks shall be so arranged that, if the plug connected thereto is withdrawn, no
interference to the operation of the equipment at the customer’s premises which
remains connected to the telephone network shall occur by reason of such withdrawal.
INCIDENCE OF HARM Should terminal equipment or protective circuitry cause
harm to the telephone network, the telephone company shall, where practicable,
notify the customer that temporary disconnection of service may be required; however,
where prior notice is not practicable, the telephone company may temporarily
discontinue service if such action is deemed reasonable in the circumstances. In the
case of such temporary discontinuance, the telephone company shall promptly notify
the customer and will be given the opportunity to correct the situation.
ADDITIONAL TELEPHONE COMPANY INFORMATION The security control
panel must be properly connected to the telephone line with a USOC RJ-31X telephone
jack.
The FCC prohibits customer-provided terminal equipment be connected to party lines or
to be used in conjunction with coin telephone service. Inter-connect rules may vary from
state to state.
CHANGES IN TELEPHONE COMPANY EQUIPMENT OR FACILITIES The tel-
ephone company may make changes in its communications facilities, equipment, opera-
tions or procedures, where such actions are reasonably required and proper in its
business. Should any such changes render the customer’s terminal equipment incompat-
ible with the telephone company facilities the customer shall be given adequate notice to
the effect modifications to maintain uninterrupted service.
RINGER EQUIVALENCE NUMBER (REN) The REN is useful to determine the
quantity of devices that you may connect to your telephone line and still have all of those
devices ring when your telephone number is called. In most, but not all areas, the sum of
the RENs of all devices connected to one line should not exceed five (5.0). To be certain
of the number of devices that you may connect to your line, you may want to contact
your local telephone company.
EQUIPMENT MAINTENANCE FACILITY If you experience trouble with this tel-
ephone equipment, please contact the facility indicated below for information on obtain-
ing service or repairs. The telephone company may ask that you disconnect this equip-
ment from the network until the problem has been corrected or until you are sure that the
equipment is not malfunctioning.
Digital Security Controls Ltd. 160 Washburn St., Lockport, NY 14094
