DSC RF5108-433 User manual

Thank you for purchasing the RF5108-433 Wireless Receiver. This product
is the result of several years of development and will allow you to connect
up to 8 wireless detection devices to the PC580, PC585, PC1555, PC1565, and the Power
Series control panels.
The RF5108-433 operates at 433 MHz. It provides several advantages:
• supervisory transmissions are sent every 64 minutes at fixed time intervals for NA
version, 12 minutes for the EU version.
• programmable supervisory window can be as long as 24 hours
• diversity antenna arrangement for better RF reception
• 2 PGM Outputs
In addition, the RF5108-433 features:
•6 digit serial numbers for all wireless devices: These new serial numbers include
hexadecimal digits. Please read Section 3.1 “A note on Electronic Serial Numbers (ESN)”
for more information on enrolling 6-digit devices.
We are confident you will find the RF5108-433 Wireless Receiver a unique and useful
control panel enhancement.
Section 1: Introduction
This manual describes how to install, program and maintain the RF5108-433.
It covers both North American (NA) and European (EU) market versions.
Before you install the RF5108-433 module, you should have completed the following
steps in your system installation:
1. Plan the installation and wiring of the security system (see the system Installation Manual ).
2. Install the control panel, and install and enroll at least one keypad to use for programming.
3. Install and enroll any hardwired zone expander modules (PC5108) you plan to use.
CAUTION!: This RF5108-433 EU equipment shall be installed by SERVICE PERSON-
NEL ONLY.
NOTE: PowerSeries panels v2.x and lower that support the PC5108 zone expander
modules occupy zones in 2 groups of 4 (e.g. zones 9-12 and zones 13-16). PowerSeries
panels v3.x and higher that support the PC5108 Zone Expander modules occupy zones
in groups of 8 (e.g. zones 9-16 and zones 17-24). None of the zones assigned to a
PC5108 module may be used for wireless devices.
Program the RF5108-433 from a system keypad or using downloading software on a remote
computer (e.g., DLS2002). Read your system Installation Manual for more information.
1.1 How to use this Manual
Read this manual before you begin installing the RF5108-433. To install and set up the
RF5108-433 and wireless devices, follow these steps. Refer to the sections listed below.
1. Temporarily mount and wire the RF5108-433 module (see Section 2 )
2. Enroll and program wireless devices (see Section 3 )
3. Complete zone and other programming on the system (see Section 4 )
4. Test the placement of all the wireless devices (see Section 5)
5. Permanently mount the RF5108-433 receiver and wireless devices (see Section 5)
For additional information on trouble conditions, RF jamming signal detection and battery
replacement, see Section 6. For help with troubleshooting, see Section 7.
WARNING: This manual contains information on limitations regarding
product use and function and information on the limitations as to liability
of the manufacturer.
RF5108-433 v1.0 Installation Manual

2
1.2 Specifications and Features
• Voltage: 12VDC
• Current Draw: 40mA
• Frequency: 433.92 MHz
• Zones - receiver can receive signals from up to 8 wireless zones and 8 wireless keys
• Internal antenna
• PGM Outputs: 2 Open-collector PGM outputs (50mA)
• Supervisory - programmable supervisory window, 4 - 24 hours, in 15 minute
increments
• Location
- can be wired up to 750 ft. / 230 m from the main panel with 22 gauge wire; the wiring
used in this circuit connection must be insulated with PVC, TFE, PTFE, FEP, Neoprene
or Polymide
- connects to Keybus
- for longer wire runs, thicker gauge wire must be used.
• Compatibility: The RF5108-433 v1.x can be connected to the following panels: PC5020,
PC501X, PC1555, PC1565, PC580, PC585
1.3 Compatible Wireless Devices
Please refer to the Instruction sheets of the following devices for more information.
The RF5108-433 v1.0 can receive signals from the following devices:
• WLS904L-433 Motion Detector • WLS912L-433 Glass Break Detector
• WLS904PL-433 Pet Immune PIR • WLS914 Pet Immune PIR
• WLS906-433 Smoke Detector • WLS919-433 Wireless Key
• WLS907T-433 Low Temperature Sensor • WLS925L-433 Mini Door/Window Contact
• WS4939 Wireless Key
1.4 DLS Compatibility
The RF5108-433 can support up to 8 wireless devices that can be assigned to any of zones
1 to 32 or RF Jam Zone. If the DLS user enters valid serial numbers for more than 8 wireless
devices and the wireless device serial numbers are downloaded, the RF5108-433 will
accept the serial numbers of the first 8 wireless devices (in order, starting with the lowest
zone number).
1.5 Batteries
The wireless devices are designed to use only specific brands and types of batteries.
Please see the appropriate instruction sheet for detailed information on the battery
brands and types.
NOTE: Do not use brands of batteries other than those specified. Using any other brand
may affect system operation.
Section 2: RF5108-433 Set Up & Wiring
This section describes how to set up and wire the RF5108-433 module.
2.1 Unpack the RF5108-433
Check that the following parts are in your RF5108-433 package:
• 1 WS4939 wireless key (WKK-1) or 2 with WKK-2
• RF5108-433 in cabinet
• Hardware for mounting the cabinet
• LED indicator plate
I N T R O D U C T I O N

3
2.2 Choose a Mounting Location for the RF5108-433
NOTE: Mount the RF5108-433 receiver and wireless devices after you have done
placement tests with the wireless devices (see sections 5.1 and 5.2).
Find a place that is:
• Indoor, non-hazardous
• Dry
• Central to the proposed placement of all wireless devices
• As high as possible
• Far from sources of interference, including: electrical noise such as computers,
televisions and electric motors in appliances and heating and air conditioning units; large
metal objects like heating ducts and plumbing which may shield the antenna.
Ensure the electrical wires will not run over the antenna(s) of the module when it is mounted.
NOTE: When mounting the RF5108-433 in a basement, place the module as high and as
close to the underside of the first floor as possible. The range of the module will be
reduced if the unit is mounted below ground level.
2.3 Antennas
The antennas have been installed at the factory.
CAUTION!: Do not attempt to touch or adjust the antennas.
2.4 PC5320 Compatibility
The PC5320 module can be used to add multiple wireless receivers to an installation to
increase the coverage area. The PC5320 can be used to connect up to four wireless
receivers of the same type:
• up to four RF5108-433 receivers or
• up to four RF5501-433 receivers or
• up to four PC5132-433 receivers
Please refer to the PC5320 Installation Instructions for more information.
NOTE: If the PC5320 module is used, the RF5108-433 PGM outputs can only be
programmed as RF5108 PGM Pulse or RF5108 PGM Toggle (Options 15 or 16).
2.5 Connect the RF5108-433 Receiver
CAUTION: Remove all power from the system while connecting modules to
the Keybus.
Connect the RF5108-433 to the 4-wire Keybus of the control panel according to the
following diagram.
Control Panel
KEYBUS
TO RF5108
S E T U P & W I R I N G

4
S E T U P & W I R I N G
2.6 RF5108-433 Programmable Outputs - PGM1 and PGM2
Each PGM output is an open collector switch to ground. That is,
when the PGM output is activated the terminal will switch to
ground. PGM1 and PGM2 are able to sink up to 50mA of current.
If more than 50mA of current is required a relay must be used.
Refer to diagram at right.
NOTE: The current used from PGM outputs should be taken
in consideration when using the maximum current available at
the AUX output in the control panel.
2.7 Connecting LED to
the RF5108-433
The LED can be used to indicate whether the system is armed
or disarmed. If the output is programmed as an armed status
output, the red LED will turn on when the system is armed and
will turn off when the system is disarmed.
2.8 Connecting a Garage Door to the RF5108-433
Connect an output of the RF5108-433 across the wall-mounted
push button or directly at the motor of the garage door opener
(please consult the garage door opener instructions for proper
connections). Set up the system and wireless key so that it is
programmed to pulse an output for a short duration (5 seconds)
so that every time the programmed key is pressed the garage
door is opened or closed. The system can also be set up so that
an output on the RF5108-433 will follow a main panel output that
is programmed as a command output and is set up on the
wireless key as such. Doing this will also activate an output on the
RF5108-433 for 5 seconds (please refer to the control panel
manual for a listing of available output types and their functions).
PGM 1 and/or PGM 2 on the RF5108-433 can be set up to open a garage door (refer to
Section 3.5). NOTE: Not to be used in UL Listed installations.
2.9 Connecting an X-10 Powerflash Module to the RF5108-433
When connecting an X-10 Powerflash module to the RF5108-
433, different lights within or outside the home can be controlled,
such as table lamps, or porch and driveway lights that illuminate
the entry / exit paths. This can be done by setting up the system
and wireless key in one of several ways:
• The wireless key can toggle an output ON/OFF, triggering the
X-10 Powerflash module, providing direct control of lighting.
• The wireless key can turn on an output for a programmable
amount of time (5 seconds to 99 minutes and 99 seconds),
turning on lights for the amount of time the homeowner requires.
• The RF5108 output can be programmed to follow a main panel
output which can turn on lights when the panel is armed and turn them off when
disarmed, turn on lights when an alarm occurs and turn them off when disarmed, etc.
PGM1 GRNYELBLKREDPGM2
DSC
RM-1/
RM-1C
RED
BLK
WHT (COM)
YEL (NC)
GRN (NO)
PGM1 GRNYELBLKREDPGM2
RED
BLACK
PGM1 GRNYELBLKREDPGM2
RED
BLK
WHT (COM)
YEL (NC)
GRN (NO)
Garage door
pushbutton
or motor
DSC
RM-1/
RM-1C
PGM1 GRNYELBLKREDPGM2
RED
BLK
WHT (COM)
YEL (NC)
GRN (NO)
X-10
Powerflash
Module
Lamp
Module
DSC
RM-1/
RM-1C

5
Please refer to the control panel Installation Manual for a listing of available output types
and their function. PGM 1 and/or PGM 2 on the RF5108-433 can be set up for this
operation (see Section 3.5).
After you have completed the wiring, reconnect the power to the security system.
Now that you have wired the RF5108-433, you should enroll and program the wireless
devices. See section 3 for instructions.
Section 3: Enrolling Wireless Devices
This section describes how to enroll wireless devices and wireless keys. For more
information on these devices, read the instruction sheet included with each device.
3.1 A Note about Electronic Serial Numbers
An electronic serial number (ESN) is printed on the back of each wireless device. ESNs
are used to enroll the wireless devices with the RF5108-433 receiver.
In order to reduce the occurrence of wireless devices with the same serial number, 6-
digit serial numbers are printed on the back of each wireless device. The 6-digit serial
numbers include hexadecimal digits. For instructions on programming hexadecimal
numbers, see your system Installation Manual , section 4: ‘How to Program’.
NOTE: 6-digit serial numbers are only supported on the following control panels: PC5020,
PC501X, PC1555, PC1565 and PC580, PC585 v2.0 and higher.
The WLS904L/904PL-433, WLS906-433, WLS907T-433, WLS912L-433, WLS914-433,
and WLS925L-433 devices have a 6-digit serial number printed on them. When
connecting the RF5108-433 to a PC5015 v2.x and higher, PC5020, PC5010, PC1555/
1565, or PC580/585 panel enter the 6-digit serial number.
3.2 Enrolling Wireless Devices
1. At a system keypad, enter [✱][8][Installer’s Code] to go to the Installer
Programming section.
2. Enter programming section [804].
3. Enter the 2-digit number corresponding to the zone the device is to occupy ([01]
to [32]).
NOTE: Hardwired and wireless devices cannot be assigned to the same zone.
PowerSeries panels v2.x and lower that support the PC5108 zone expander modules
occupy zones in 2 groups of 4 (e.g. zones 9-12 and zones 13-16). PowerSeries panels
v3.x and higher that support the PC5108 zone expander modules occupy zones in
groups of 8 (e.g. zone 9-16 and 17-24). None of the zones assigned to a PC5108 module
may be used for wireless devices. For more information on zone assignment, refer to
your System Installation Manual.
4. Enter the device’s ESN. Follow the instructions in section 3.1 above.
5. Record the serial number and the assigned zone number in the programming
worksheets in the back of this manual.
6. Repeat steps 3 - 5 until you have enrolled up to 8 wireless devices.
NOTE: The RF5108-433 supports programming of 8 wireless devices that can be as-
signed to any of zones 1 to 32 or RF Jam Zone. Once 8 wireless devices have been
programmed the RF5108-433 will not allow further programming. An error tone will be
heard at the keypad if further programming is attempted.
7. To exit press [#]. The device is now enrolled on the system.
NOTE: The devices will not work properly until you complete zone and partition program-
ming (see section 4).
S E T U P & W I R I N G

6
3.3 Enroll & Program Wireless Keys
For wireless keys to work on the system, you need to enroll them and then program the
function buttons. Wireless keys are not assigned to zones and require no zone
programming. You can enroll up to 8 wireless keys on the system.
Enroll Wireless keys
1. At a system keypad, enter [✱][8][Installer’s code] to go to the Installer
Programming section.
2. Enter programming section [804].
3. Enter a 2-digit number [41]-[48] to assign the wireless key a slot. These numbers
correspond to wireless key numbers 01-08.
4. Enter the key’s ESN. The entry
must be 6 digits. If an older key with a 5-digit ESN
is being enrolled, add the digit [0] to the beginning of the ESN. (E.g., if
ESN=61234, enter 061234)
5. The key is now enrolled on the system. Record the serial number and the assigned
slot number in the programming worksheets in the back of this manual.
6. Repeat steps 3 - 5 until all wireless keys have been enrolled.
7. ((
((
(PC5020/PC5020/
PC5020/PC5020/
PC5020/PC501PC501
PC501PC501
PC501XX
XX
Xonly)only)
only)only)
only) By default, all wireless keys are assigned to Partition 1.
To assign keys to Partitions 2 to 8, program the appropriate partition number in
section [69].
NOTE: A wireless key can only be assigned to one partition.
8. To exit press [#].
Program the Wireless Key Function Buttons
WS4939/WLS919-433 wireless keys have four programmable function buttons. By
default, all wireless key function buttons are set for 03, 04, 27, 30 (Stay Arm, Away Arm,
Disarm, Panic Alarm). The functions can be reprogrammed if desired. After the functions
are programmed, when you press and hold one of the buttons for two seconds, the system
will execute the programmed function.
For systems not using partitions: program the function buttons in section [61]. All
wireless keys will have the same four functions.
For systems using more than one partition (PC5020/PC501X only): All wireless keys
assigned to Partition 1 will have the four functions programmed in section [61]. Likewise, all
wireless keys assigned to Partition 2 will have the 4 functions programmed in section [62], and
all wireless keys assigned to Partition 8 will have the 4 functions programmed in section [68].
For example, if function button 1 in Section [61] is programmed for Stay arming, then pressing
the first button on wireless keys assigned to Partition 1 will Stay arm Partition 1.
NOTE: Wireless keys will not work when the partition they are assigned to is being
accessed for zone bypassing or programming.
1. At a system keypad, enter [✱][8][Installer’s code].
2. Enter programming section [804].
3. Enter programming section [61] to [68] for keys assigned to Partitions 1 to 8.
4. For each of the 4 function buttons, enter the 2-digit number of the function you
want to select. See the programming worksheets in the back of this manual for a
list of function key options.
5. Record your programming choices in the worksheets in the back of the manual.
6. To exit press [#].
W I R E L E S S D E V I C E S

7
3.4 Identified Wireless Keys
Reporting by the system of openings/closings by individual wireless keys and command
output [✱][7] activation by wireless key buttons may be supported on certain control panels.
To do this, the system will reserve access codes 17-24 for wireless keys 01-08 respectively.
You must program one access code for each wireless key (using [✱][5] access code
programming) for this feature to work correctly.
NOTE: Program these access codes on the system after you have connected the RF5108-
433 to the Keybus (see section 2.4).
Refer to your system Installation Manual for information on access code programming.
Opening/Closing By Wireless Key Reporting
NOTE: The Identified Wireless Key Closing option is only available with the PC5020,
PC501X, PC1555, PC1565, PC580, PC585 v2.0 and higher by turning section [015]
option 4 off.
To enable the reporting of openings and closings by identified wireless keys:
• Make sure the control panel is v2.0 or higher
• Program a valid access code for each key
• Program a closing and opening reporting code for each key’s access code
• Turn off the Quick Arm option in section [015] option [4] of the control panel programming
To ensure that an unidentified wireless key cannot disarm the system, turn off section [017],
option [1] (in the control panel programming). This option is available in control panels with
software version 2.1 or higher.
Command Output Activation
NOTE: The Identified Wireless Key Command Output Activation feature is only available
with the PC5020, PC501X, PC1555, PC1565, PC580, PC585 v2.0 and higher.
To enable command output activation by wireless keys, ensure that:
• The control panel is v2.0 or higher
• Program a valid access code for each key
• Enable the PGM output attribute Requires Access Code for each PGM output
programmed as [✱][7][1-4] in sections [141] to [154].
3.5 RF5108-433 PGM Outputs
The RF5108-433 has two on-board open collector PGM outputs. Each of these can be
individually programmed to:
1. Follow main panel PGM outputs 1 to 14.
NOTE: Please refer to your System Installation Manual for available PGM outputs.
NOTE: If the RF5108-433 is connected to the PC580/PC585/PC1555/PC1565/P-48/
P-6B, PC5010 v1.x, P832 v1.x or the WSS5010 1.0, 2.1, the RF5108-433 PGM out-
puts cannot be programmed to follow main panel PGM outputs 1 or 2. The PC1555MX
will have this functionality.
2. Activate for a programmable amount of time when a signal is received from a
wireless key programmed with output option 31 or 32 (RF5108-433 PGM pulse) and
the PGM output programming section [70] or [71] is programmed with option 15
(RF5108-433 PGM pulse). The amount of time that the PGM outputs can be
programmed to remain on is programmed in sections [72] and [73]. The default
activation time is 5 seconds.
3. Toggle state when a signal is received from a wireless key programmed with
option 31 or 32 and the PGM output programming section [70] or [71] is
programmed with option 16 (RF5108-433 PGM toggle).
W I R E L E S S D E V I C E S

8
3.6 Deleting Wireless Devices
To remove a wireless device from the system, follow the guideline for adding a wireless
device. Program the ESN as [000000]. The wireless device for the zone will be removed.
Now that you have enrolled all the wireless devices, you will need to program the system
to work properly with the devices. See section 4 for more information.
Section 4: Other Programming
4.1 Program Zones and Partitions
Now that you have enrolled the wireless devices, you should complete all zone program-
ming on the system. Although the exact programming required varies depending on which
control panel the RF5108-433 is connected to, you should check that the following
programming areas are completed correctly for each wireless zone:
• Enable zones and/or assign zones to one or more partitions (programming sections
[201]-[209], [201]-[265] for PC5020).
• Program the definition for each zone (programming sections [001]-[004]).
NOTE: WLS906 wireless smoke detectors must be assigned to zones defined as Delay
24-hr fire (wireless) [87] or Standard 24-hr fire (wireless) [88] for proper supervision.
• Enable the wireless zone attribute for each wireless zone (PC580, PC585, PC1555,
PC1565, PC5020, PC501X v2.0 and higher only) (sections [101]-[132]).
See your system
Installation Manual , for more information on each of the above program-
ming sections.
4.2 Enable RF5108-433 Supervision
The control panel will supervise the RF5108-433 receiver via the Keybus after at least one
device has been enrolled on the module (see section 3.2 “Enrolling Wireless Devices”). The
RF5108-433 is supervised as a PC5132.
To activate module supervision, after you enroll the first device(s):
1. Exit and then re-enter Installer Programming.
2. Enter programming section [902]. Wait approximately 1 minute.
3. To exit press [#].
The system will generate a General System Supervisory trouble if the module is removed
from the Keybus. If you need to remove the RF5108-433 module from an existing system,
you will have to disable supervision of the RF5108-433.
NOTE: Deleting all devices from the RF5108-433 or defaulting the RF5108-433 will
cause a PC5132 supervisory fault.
To disable RF5108-433 supervision:
1. Disconnect the RF5108-433 from the Keybus
2. Enter [✱][8][Installer’s Code]
3. Enter [902]. The control panel will clear all supervision and re-scan the system for
connected modules. The scan will take approximately one minute.
4. To exit press [#].
W I R E L E S S D E V I C E S

9
To review which modules the control panel is currently supervising:
1. Enter [✱][8][Installer’s Code]
2. Enter [903] to display all modules. On LED keypads, light [17] will indicate that
the RF5108-433 is present on the system. On LCD keypads, scroll until the
module name ‘PC5132’ appears on the display.
3. To exit press [#].
If the RF5108-433 module does not show on the keypad, one of the following conditions
may be present:
• the module is not connected properly to the Keybus
• there is a problem with the Keybus wiring run
• the module does not have enough power
• no devices have been enrolled on the RF5108-433
4.3 Enable Supervision of Wireless Zones
NOTE: (for PC5010 v1.x control panels only) For UL Listed installation, Double EOL
resistors must be enabled in the PC5010 for the wireless zones to be supervised. If nor-
mally Closed or Single EOL resistors are selected the PC5010 will not be able to supervise
the wireless devices. If a wireless device stops sending a supervisory signal (the unit stops
functioning) the panel will not indicate a supervisory trouble condition unless Double EOL
resistors are used. In addition, all hardwire zones must be wired for Double EOL resistors.
For more information, refer to your PC5010 v1.x Installation Manual.
NOTE: (PC5010 v2.0 and higher, PC5015 v2.2 and higher, PC5020, PC5008, PC1555,
PC1565, PC580, PC585 only): For wireless supervision to work, you must enable the
wireless zone attribute on all wireless zones (sections [101] to [132], option [8] ON).
Wireless Supervisory Window
Each wireless zone will send a supervisory signal at a fixed time interval (64 minutes for
NA, 12 minutes for EU). If the receiver does not receive a signal within the time
programmed for the Wireless Supervisory Window, it will generate a supervisory fault.
To program the wireless supervisory window:
1. Enter [✱][8][Installer’s Code] to enter Installer Programming.
2. Enter [804] to enter the RF5108-433 Module Programming.
3. Enter section [81].
4. Enter the time period for the supervisory window. The window is programmed in 15
minute increments.
• The default programming for NA is 96 (x15 minutes), which is equal to 24 hours.
Valid entries for NA are (16) - (96), equal to 4 - 24 hours.
• The default programming for EU is 10 (x15 minutes), which is equal to 2.5 hours. Valid
Entries for EU are (08) - (96), equal to 2 - 24 hours.
5. To exit press [#].
Disable/Enable Zone Supervision
All wireless zones have supervision enabled by default. To disable supervision for any
zone, enter the following at any system keypad:
1. Enter [✱][8][Installer’s Code] to enter Installer Programming.
2. Enter [804] to enter the RF5108-433 Module Programming.
3. Enter section [82]-[85]. Enable or disable supervision for each wireless zone by
turning each relevant option on or off.
4. To exit press [#].
NOTE: The RF Jam Detect zone must have the supervision option disabled.
O T H E R P R O G R A M M I N G

10
4.4 Jamming Signal Detection
The RF5108-433 receiver detects jamming signals that can prevent the receiver from
properly receiving transmissions from enrolled devices. When jamming signals are
detected, the panel can report a jamming trouble condition in one of two ways. By default,
the panel will report an RF Jam Trouble (General System Tamper on the PC5010).
To turn OFF jamming signal detection indicates Trouble:
1. Enter [✱][8][Installer Code] to enter Installer Programming.
2. Enter [804] to enter the RF5108-433 Module Programming.
3. Turn ON section [90], option [7].
4. To exit press [#].
The RF5108-433 can also be programmed to indicate the jamming trouble condition with
the RF Jam Zone. For RF Jam Zone to work, you must select an unused zone to be used
as the RF Jam Detect zone. When the receiver detects an attempt to jam the RF signal, the
RF Jam Detect zone will be violated and the system will generate a tamper signal. When
the jamming signal is gone, the RF Jam Detect zone closes and the system sends a tamper
restore signal.
To enable RF jamming detection:
1. Enter [✱][8] [Installer's Code].
2. Enter programming section [804].
3. Enter section [93]. Enter the 2-digit number of the RF Jam Detect zone ([09] to
[32]) in the programming section.
NOTE: The RF5108-433 counts the RF jam zone as one of the 8 supported zones. If
section [93] is programmed, only 7 wireless devices may be programmed. If 8 wireless
devices are already programmed, section [93] will not be accessible.
4. Disable supervision for the RF Jam detect zone by turning the relevant option off in
section [82]-[85] (see section 4.3 for more information).
5. RF jamming detection is now enabled. To exit Installer programming, press [#].
NOTE: A jamming condition will be indicated as RF Jam Zone if section [93] is pro-
grammed, regardless of the RF Jam indicates Trouble option (section [90], option [7]).
4.5 RF5108-433 Software Default
Returning the RF5108-433 programming to factory default settings is a quick way to remove
all the enrolled devices from the system and reset all the programming in section [804].
NOTE: Performing this procedure will not change any programming sections except
[804]. Resetting the control panel to factory default settings will not return the RF5108-433
module to factory default settings.
To restore the RF5108-433 programming to the factory default settings perform the following:
1. Enter [✱][8] [Installer’s Code].
2. Enter programming section [996].
3. Enter the Installer’s Code, followed by [996] again. The software for the RF5108-
433 will be restored to its factory default settings.
For instructions on restoring the default programming of the control panel or any other
connected module, see your system Installation Manual .
4.6 Deleting Wireless Devices
To remove a wireless device from the system, follow the guideline for enrolling a wireless
device (see section 3.2). Program the ESN as [000000]. The wireless device for the zone
will be removed.
O T H E R P R O G R A M M I N G

11
Now that you have completed all RF5108-433 related programming, you can test and
install the receiver and devices. See section 5 for more information.
Section 5: Testing & Mounting
5.1 Test the Reception of Wireless Devices
It is very important to test the proposed placement of each wireless device before it is mounted.
Following these steps will test the placement of the wireless motion detectors (WLS904P(L)/
WLS914), wireless smoke detectors (WLS906), wireless glassbreak detectors (WLS912) and
wireless door/window contacts (WLS925L), based on the signal strength between the
RF5108-433 and the device.
NOTE: You cannot test the Wireless Keys (WS4939/WLS919) in this mode. See
section 5.2 for instructions on testing these devices. You cannot run a placement test
on the RF Jam Detect zone.
1. Temporarily place the device you want to test in the place you want to mount it.
2. At a system keypad, enter [✱][8][Installer Code].
3. Enter programming section [904].
4 Enter the 2-digit zone number for the device to be tested.
5. Activate the device being tested until a result is displayed on the keypad or
sounded by the keypad or bell.
WLS904P(L)-433/WLS914-433: Remove the detector from its backplate, wait for
1-2 seconds, then reattach the detector to its backplate.
WLS906-433: Remove the detector from its backplate, wait for 5 seconds, then
reattach the detector to its backplate. Or hold a magnet near the raised line on
the outer rim. Then remove the magnet.
WLS925L-433: Open and close the contact by moving the magnet away from
the unit. If the unit is attached to a door or a window, open and close the door or
window to activate the device.
WLS912L-433: Press and hold the test mode tab for 5 seconds. Release the
test mode tab. The keypad will display the test result.
6. Read the test results at the keypad:
Result LED Keypad LCD Keypad Buzzer/Bell
Good Light 1 On Steady “Good” 1 Beep/Squawk
Bad Light 3 On Steady “Bad” 3 Beeps/Squawks
Activate the device until you get 3 good results in a row. Wait 10 seconds between each
test on the same device. You may mount wireless devices where results were good.
Devices indicating a bad result must be moved to another location. You may only
have to move the device a few inches to correct a bad result.
NOTE: Do not mount any device where a “bad” test result was indicated.
If several wireless devices produce BAD test results, you may need to move the
RF5108-433 to a better location.
7. To test another device, press [#] once, then repeat steps 4 - 6. Continue to test
the devices until both the RF5108-433 and the devices are in good locations.
8. To exit installer programming, press [#] twice.
O T H E R P R O G R A M M I N G

12
5.2 Test Wireless Key Reception
The wireless key cannot be tested using the module placement test described above. To
ensure that the RF5108-433 is receiving transmissions from these devices, conduct the
following tests:
WS4939/WLS919: Use the function keys to arm and disarm the system at several
different points in the installation.
If these devices do not operate from all points in the installation, you will need to move
the RF5108-433 receiver. Moving the RF5108-433 higher will usually improve the
reception.
If you move the RF5108-433, repeat the tests described in sections 5.1 and 5.2 on
all the wireless devices. Continue to test the devices until you have found satisfactory
locations for the RF5108-433 and the devices, and there is good reception between
the RF5108-433 and the Wireless Keys.
Mount the RF5108-433 and Wireless Devices
When you have tested reception of the RF5108-433 with all the wireless devices (see
section 5.1) and you have a good mounting location, mount the RF5108-433:
1. Pull the Keybus wires through the hole at the bottom of the cabinet.
2. Mount the cabinet securely to the wall.
Mount the Devices
If you have conducted the placement test described in section 5.1 and got three “Good”
results in a row for each device, you can mount the wireless devices. See the Installation
Sheet for each device for mounting instructions.
Now that your RF5108-433 and wireless devices are mounted and working properly, read
section 6 for information on potential wireless trouble conditions, RF jamming signals, and
battery replacement.
T E S T I N G & M O U N T I N G

13
Section 6: Additional Notes
6.1 Trouble Conditions
The control panel always watches for possible trouble conditions. If a trouble condition
occurs, the keypad “Trouble” light will turn on and the keypad will beep. Press [✱][2] to
display the trouble conditions.
The following trouble conditions apply to the RF5108-433 and/or any enrolled devices.
General System Tamper - This trouble is generated when the RF5108-433 plastic cover
is removed and/or if there is a jamming condition present.
General System Supervisory - This trouble will be indicated if the panel loses
communication with any module connected to the Keybus. The event buffer will log a
detailed description of the event.
Device Low Battery - This trouble is generated when a wireless device exhibits a low
battery condition. Press [7] one, two, or three times to view which devices are
experiencing battery failure. An LED keypad will indicate battery failure using zone lights
1 to 8.
Zone Tamper - This trouble is generated when an enrolled wireless device is removed
from its mounting location.
Zone Fault - Each wireless zone will send a supervisory signal at a fixed time interval (64
minutes for NA, 12 minutes for EU). If the receiver does not receive a signal within the time
programmed for the Wireless Supervisory Window, it will generate a zone fault.
Tamper Switches
For the European (EU) version, there are 2 tamper switches on the RF5108-433 board.
Removing the plastic cover and/or the RF5108-433 from its mounting location causes
a general system tamper.
6.2 Jamming Signal Detection
The RF5108-433 receiver detects jamming signals that can prevent the receiver from
properly receiving transmissions from enrolled devices. See section 4.4 “Jamming Signal
Detection” for information on jamming signal detection programming.
6.3 Wireless Zone Low Battery Transmission
Within any transmission, the device will indicate the status of the battery. If a battery is low,
the system will indicate a Device Low Battery trouble.
The system will delay reporting the event to the central station for the number of days
programmed for Zone Low Battery Transmission Delay in section [370]. This will
prevent unnecessary reporting of the event if the user has been instructed on how to
replace batteries.
Replacing Batteries in Wireless Devices
1. Remove the cover of the device from its back plate. This creates a tamper
condition on the zone.
2. Refer to the battery installation instructions on the Installation Sheet of each component.
Be sure to note the proper orientation of the batteries as you install them.
3. When the fresh batteries are in place, re-attach the cover to the back plate. The
tamper is restored and the zone sends a battery trouble restoral signal to the
RF5108-433. The battery trouble is now clear and the device should function
normally.
NOTE: When batteries in one device need to be replaced, the batteries in all devices may
need to be replaced at the same time.
T E S T I N G & M O U N T I N G

14
Section 7: Troubleshooting
1. When I enter the 2-digit zone number when adding a wireless device, the
keypad gives me a long beep.
You cannot enter ESNs unless a RF5108-433 wireless receiver is connected to the
Keybus. See section 2 for instructions on setting up and wiring the RF5108-433 module.
2. I have entered the ESN for the device but when I violate the device, the
zone does not show open on the keypad.
Check the following:
• Ensure the ESN has been entered correctly
• Ensure that the zone is enabled for the partition (if partition programming is used).
• Ensure that the wireless zone is not assigned to a zone used by PC5108 modules, an
on-board zone, or a keypad zone.
• Ensure that the zone is programmed for something other than “Null Operation”, and that
the wireless zone attribute is turned on.
3. When I try a module placement test I get no result or “Bad” results.
Check the following (see sections 5.1 and 5.2 for more information on testing devices):
• Verify that you are testing the correct zone
• Verify that the correct ESN was entered when the device was enrolled
• Verify that the device is in range of the RF5108-433. Try testing the device in the same
room as the receiver.
• Confirm that the RF5108-433 is properly connected to the Keybus (see section 2 for
RF5108-433 set up and wiring instructions).
• Check that you are testing the zone correctly (see sections 5.1 and 5.2 for testing
instructions)
• Check that the batteries are working and installed correctly.
• Look for large metal objects that may be preventing the signal from reaching the
RF5108-433.
The device must be located where consistent “Good” results are obtained. If several
devices show “Bad” results, move the receiver. See section 2.2 for tips on choosing a
mounting location for the RF5108-433.
4. The LED on the motion detector does not turn on when I walk in front of
the unit.
The LED is for walk test purposes only. See your WLS904-433/WLS904P-433 Instruction
Sheet for walk test instructions.
ADDITIONAL NOTES

15
[804] RF5108-433 Wireless Expansion Programming
• 6-digit entry is required. See Section 3.1 “A note on Electronic Serial Numbers”
for details on programming 6-digit serial numbers.
NOTE: The RF5108-433 supports programming of 8 wireless devices that can be
assigned to any of zones 1 to 32 or RF Jam Zone. Once 8 wireless devices have been
programmed the RF5108-433 will not allow further programming. An error tone will be
heard at the keypad if further programming is attempted.
Zone Serial Numbers (Default = 000000)
[01] Zone 1 l
_____l _____l _____l _____l _____l _____l
[02] Zone 2 l
_____l _____l _____l _____l _____l _____l
[03] Zone 3 l
_____l _____l _____l _____l _____l _____l
[04] Zone 4 l
_____l _____l _____l _____l _____l _____l
[05] Zone 5 l
_____l _____l _____l _____l _____l _____l
[06] Zone 6 l
_____l _____l _____l _____l _____l _____l
[07] Zone 7 l
_____l _____l _____l _____l _____l _____l
[08] Zone 8 l
_____l _____l _____l _____l _____l _____l
[09] Zone 9 l
_____l _____l _____l _____l _____l _____l
[10] Zone 10 l
_____l _____l _____l _____l _____l _____l
[11] Zone 11 l
_____l _____l _____l _____l _____l _____l
[12] Zone 12 l
_____l _____l _____l _____l _____l _____l
[13] Zone 13 l
_____l _____l _____l _____l _____l _____l
[14] Zone 14 l
_____l _____l _____l _____l _____l _____l
[15] Zone 15 l
_____l _____l _____l _____l _____l _____l
[16] Zone 16 l
_____l _____l _____l _____l _____l _____l
Section 8: Programming Worksheets
Wireless Key Serial Numbers (Default = 000000)
[41] Key 01 l
_____l _____l _____l _____l _____l _____l
[42] Key 02 l
_____l _____l _____l _____l _____l _____l
[43] Key 03 l
_____l _____l _____l _____l _____l _____l
[44] Key 04 l
_____l _____l _____l _____l _____l _____l
[45] Key 05 l
_____l _____l _____l _____l _____l _____l
[46] Key 05 l
_____l _____l _____l _____l _____l _____l
[47] Key 07 l
_____l _____l _____l _____l _____l _____l
[48] Key 08 l
_____l _____l _____l _____l _____l _____l
[17] Zone 17 l
_____l _____l _____l _____l _____l _____l
[18] Zone 18 l
_____l _____l _____l _____l _____l _____l
[19] Zone 19 l
_____l _____l _____l _____l _____l _____l
[20] Zone 20 l
_____l _____l _____l _____l _____l _____l
[21] Zone 21 l
_____l _____l _____l _____l _____l _____l
[22] Zone 22 l
_____l _____l _____l _____l _____l _____l
[23] Zone 23 l
_____l _____l _____l _____l _____l _____l
[24] Zone 24 l
_____l _____l _____l _____l _____l _____l
[25] Zone 25 l
_____l _____l _____l _____l _____l _____l
[26] Zone 26 l
_____l _____l _____l _____l _____l _____l
[27] Zone 27 l
_____l _____l _____l _____l _____l _____l
[28] Zone 28 l
_____l _____l _____l _____l _____l _____l
[29] Zone 29 l
_____l _____l _____l _____l _____l _____l
[30] Zone 30 l
_____l _____l _____l _____l _____l _____l
[31] Zone 31 l
_____l _____l _____l _____l _____l _____l
[32] Zone 32 l
_____l _____l _____l _____l _____l _____l
P R O G R A M M I N G W O R K S H E E T S

16
P R O G R A M M I N G W O R K S H E E T S
Wireless Key Function Key Options
*Please refer to your System Installation Manual for feature availability.
Partition 1 Wireless Key Options
[61] Function Key 1 03 l
____l __ _ _lFunction Key 3 27 l ____l __ _ _ l
Function Key 2 04 l
____l __ _ _lFunction Key 4 30 l ____l __ _ _ l
Partition 2 Wireless Key Options
[62] Function Key 1 03 l
____l __ _ _lFunction Key 3 27 l ____l __ _ _ l
Function Key 2 04 l
____l __ _ _lFunction Key 4 30 l ____l __ _ _ l
Partition 3 Wireless Key Options
[63] Function Key 1 03 l
____l __ _ _lFunction Key 3 27 l ____l __ _ _ l
Function Key 2 04 l
____l __ _ _lFunction Key 4 30 l ____l __ _ _ l
Partition 4 Wireless Key Options
[64] Function Key 1 03 l
____l __ _ _lFunction Key 3 27 l ____l __ _ _ l
Function Key 2 04 l
____l __ _ _lFunction Key 4 30 l ____l __ _ _ l
Partition 5 Wireless Key Options
[65] Function Key 1 03 l
____l __ _ _lFunction Key 3 27 l ____l __ _ _ l
Function Key 2 04 l
____l __ _ _lFunction Key 4 30 l ____l __ _ _ l
Partition 6 Wireless Key Options
[66] Function Key 1 03 l
____l __ _ _lFunction Key 3 27 l ____l __ _ _ l
Function Key 2 04 l
____l __ _ _lFunction Key 4 30 l ____l __ _ _ l

17
P R O G R A M M I N G W O R K S H E E T S
Partition 7 Wireless Key Options
[67] Function Key 1 03 l
____l __ _ _ lFunction Key 3 27 l ____l __ _ _l
Function Key 2 04 l
____l __ _ _ lFunction Key 4 30 l ____l __ _ _l
Partition 8 Wireless Key Options
[68] Function Key 1 03 l
____l __ _ _ lFunction Key 3 27 l ____l __ _ _l
Function Key 2 04 l
____l __ _ _ lFunction Key 4 30 l ____l __ _ _l
[69] Wireless Keys (1-8) Partition Assignments
Default = 01
Wireless Key 01 l
____l __ _ _l
Wireless Key 02 l
____l __ _ _l
Wireless Key 03 l
____l __ _ _l
Wireless Key 04 l
____l __ _ _l
PGM Output Options
Entry Description
00 Null (No Operation)
01 Main Panel PGM1
02 Main Panel PGM2
03 PC5208 PGM3
04 PC5208 PGM4
05 PC5208 PGM5
06 PC5208 PGM6
07 PC5208 PGM7
08 PC5208 PGM8
Wireless Key 05 l
____l __ _ _l
Wireless Key 06 l
____l __ _ _l
Wireless Key 07 l
____l __ _ _l
Wireless Key 08 l
____l __ _ _l
Entry Description
09 PC5208 PGM9
10 PC5208 PGM10
11 PC5204 PGM11
12 PC5204 PGM12
13 PC5204 PGM13
14 PC5204 PGM14
15 RF5108 PGM Pulse (local)
16 RF5108 PGM Toggle (local)
[70] RF5108 PGM1 Output Option
Default = 01
PGM1 Output Option l
________l________l
[71] RF5108 PGM2 Output Option
Default = 02
PGM2 Output Option l
________l________l
[72] RF5108 - PGM1 Output Activation Time
Default = 00
PGM1 Output Activation Time (Minutes) l
________l________l
Default = 05
PGM1 Output Activation Time (Seconds) l
________l________l
[73] RF5108 - PGM2 Output Activation Time
Default = 00
PGM2 Output Activation Time (Minutes) l
________l________l
Default = 05
PGM2 Output Activation Time (Seconds) l
________l________l
NOTE: Sections [72] and [73] have a valid minimum programmable value of 00 minutes 01
seconds, and a valid maximum programmable value of 99 minutes 99 seconds.

18
P R O G R A M M I N G W O R K S H E E T S
Supervision
[81] Wireless Supervisory Window
Default: NA = 96, EU=10
l____l____l The window is programmed in 15 minute increments.
• The default programming for NA is 96 (x15 minutes), which is equal to 24 hours.
Valid entries for NA are (16) - (96), equal to 4 - 24 hours.
• The default programming for EU is 10 (x15 minutes), which is equal to 2.5 hours. Valid
Entries for EU are (08) - (96), equal to 2 - 24 hours.
[82] Zone Device Supervision Options (1-8)
Default Option ON Option OFF
ON l
________lOption 1 Zone 01 Supervision enabled Disabled
ON l
________lOption 2 Zone 02 Supervision enabled Disabled
ON l
________lOption 3 Zone 03 Supervision enabled Disabled
ON l
________lOption 4 Zone 04 Supervision enabled Disabled
ON l
________lOption 5 Zone 05 Supervision enabled Disabled
ON l
________lOption 6 Zone 06 Supervision enabled Disabled
ON l
________lOption 7 Zone 07 Supervision enabled Disabled
ON l
________lOption 8 Zone 08 Supervision enabled Disabled
[83] Zone Device Supervision Options (9-16)
Default Option ON Option OFF
ON l
________lOption 1 Zone 09 Supervision enabled Disabled
ON l
________lOption 2 Zone 10 Supervision enabled Disabled
ON l
________lOption 3 Zone 11 Supervision enabled Disabled
ON l
________lOption 4 Zone 12 Supervision enabled Disabled
ON l
________lOption 5 Zone 13 Supervision enabled Disabled
ON l
________lOption 6 Zone 14 Supervision enabled Disabled
ON l
________lOption 7 Zone 15 Supervision enabled Disabled
ON l
________lOption 8 Zone 16 Supervision enabled Disabled
[84] Zone Device Supervision Options (17-24)
Default Option ON Option OFF
ON l
________lOption 1 Zone 17 Supervision enabled Disabled
ON l
________lOption 2 Zone 18 Supervision enabled Disabled

19
ON l
________lOption 3 Zone 19 Supervision enabled Disabled
ON l
________lOption 4 Zone 20 Supervision enabled Disabled
ON l
________lOption 5 Zone 21 Supervision enabled Disabled
ON l
________lOption 6 Zone 22 Supervision enabled Disabled
ON l
________lOption 7 Zone 23 Supervision enabled Disabled
ON l
________lOption 8 Zone 24 Supervision enabled Disabled
[85] Zone Device Supervision Options (25-32)
Default Option ON Option OFF
ON l
________lOption 1 Zone 25 Supervision enabled Disabled
ON l
________lOption 2 Zone 26 Supervision enabled Disabled
ON l
________lOption 3 Zone 27 Supervision enabled Disabled
ON l
________lOption 4 Zone 28 Supervision enabled Disabled
ON l
________lOption 5 Zone 29 Supervision enabled Disabled
ON l
________lOption 6 Zone 30 Supervision enabled Disabled
ON l
________lOption 7 Zone 31 Supervision enabled Disabled
ON l
________lOption 8 Zone 32 Supervision enabled Disabled
[90] Other Options
Default Option ON Option OFF
OFF l
________lOption 1-6 For Future Use
NA=ON l
________lOption 7* RF Jam Detect Disabled Enabled
EU=OFF
OFF l
________lOption 8 Global Placement Test Individual Placement Test
RF Jamming Detection
[93] RF Jam Detect Zone
Default = 00*
l
____l __ _ _lSelect an unused zone that will be set to the tamper state when a jamming
signal is detected. (Valid entries = 01 - 32, 00 = No RF Jam zone selected)
NOTE: *For UL Listed installations the RF Jam detection zone must be enabled.
Use a non hardwired zone (9-32) for UL when selecting an RF jamming zone.
Ensure the zone type selected is 03 (Instant) when programmed in the control
panel portion.
P R O G R A M M I N G W O R K S H E E
P R O G R A M M I N G W O R K S H E E T S

20
Guidelines for Locating Smoke Detectors
Experience has shown that all hostile fires in family living units generate smoke to a greater or lesser
extent. Experiments using typical fires in family living units indicate that detectable quantities of smoke
precede detectable levels of heat in most cases. In existing homes, NFPA Standard 72 requires that
a smoke detector be installed outside each sleeping area and on each additional story of the family unit.
On smooth ceilings, detectors may be spaced 9.1m (30 feet) apart as a guide. Other spacing may be
required depending on ceiling height, air movement, the presence of joists, uninsulated ceilings, etc.
Consult National Fire Alarm Code NFPA 72, CAN/ULS-S553-M86 or other appropriate national standards
for installation recommendations.
• Do not locate smoke detectors at the top of peaked or gabled ceilings; the dead air
space in these locations may prevent the unit from detecting smoke.
• Avoid areas with turbulent air flow, such as near doors, fans or windows. Rapid air
movement around the detector may prevent smoke from entering the unit.
• Do not locate detectors in areas of high humidity.
• Do not locate detectors in areas where the temperature rises above 38oC (100oF) or
falls below 5oC (41oF).
Smoke detectors should always be installed in accordance with NFPA 72, the National Fire Alarm Code.
Smoke detectors should always be located in accordance with:
• Paragraph 2-2.1.1.1 of NFPA 72:
“Smoke detectors shall be installed outside of each separate sleeping
area in the immediate vicinity of the bedrooms and on each additional story of the family living unit,
including basements and excluding crawl spaces and unfinished attics. In new construction, a smoke
detector also shall be installed in each sleeping room.”
• Paragraph 2-2.1.1.2 of NFPA 72: “Split level arrangement. Smoke detectors are required where shown.
Smoke detectors are optional where a door is not provided between living room and recreation room.”
The Smoke Detector is designed to use Eveready Energizer EN91 Alkaline
Batteries. Do not use other brands of batteries with the Smoke Detector. Using
brands other than the Eveready Energizer will void UL approval, and may affect
the system’s operation.
