Dsc Rf5132-433 User manual

Warning – This manual contains information on limitations regarding product use and

function and information on the limitations as to liability of the manufacturer.

Attention – Ce manuel contient des informations sur les restrictions concernant le

fonctionnement et l’utilisation du produit et des informations sur les restrictions en ce qui

concerne la responsabilité du fabricant. La totalité du manuel doit être lu attentivement.

Advertencia – Por favor consulte el Manual de Instrucciones del Sistema para más

información acerca de las limitaciones conrelación al uso y funcionamiento del producto e

información acerca de las limitaciones como la responsabilidad del fabricante.

Importante – Questo manuale contiene informazioni sulle limitazioni riguardanti l’uso e la

funzione del prodotto, ed informazioni circa i limiti di responsabilità del produttore. Si

consiglia di leggere attentamente l’intero manuale.

Instruction Manual

Manuel d'installation

Manual de instalación

Manuale d'installazione

RF5132-433

Version 5.0

Warning Please Read Carefully

Note to Installers

This warning contains vital information. As the only individual in con-

tact with system users, it is your responsibility to bring each item in

this warning to the attention of the users of this system.

System Failures

This system has been carefully designed to be as effective as possible.

There are circumstances, however, involving fire, burglary, or other

types of emergencies where it may not provide protection. Any alarm

system of any type may be compromised deliberately or may fail to

operate as expected for a variety of reasons. Some but not all of these

reasons may be:

• Inadequate Installation

A security system must be installed properly in order to provide ade-

quate protection. Every installation should be evaluated by a security

professional to ensure that all access points and areas are covered.

Locks and latches on windows and doors must be secure and operate

as intended. Windows, doors, walls, ceilings and other building materi-

als must be of sufficient strength and construction to provide the level

of protection expected. A reevaluation must be done during and after

any construction activity. An evaluation by the fire and/or police

department is highly recommended if this service is available.

• Criminal Knowledge

This system contains security features which were known to be effec-

tive at the time of manufacture. It is possible for persons with criminal

intent to develop techniques which reduce the effectiveness of these

features. It is important that a security system be reviewed periodically

to ensure that its features remain effective and that it be updated or

replaced if it is found that it does not provide the protection expected.

• Access by Intruders

Intruders may enter through an unprotected access point, circumvent a

sensing device, evade detection by moving through an area of insuffi-

cient coverage, disconnect a warning device, or interfere with or pre-

vent the proper operation of the system.

•PowerFailure

Control units, intrusion detectors, smoke detectors and many other

security devices require an adequate power supply for proper opera-

tion. If a device operates from batteries, it is possible for the batteries

to fail. Even if the batteries have not failed, they must be charged, in

good condition and installed correctly. If a device operates only by AC

power, any interruption, however brief, will render that device inopera-

tive while it does not have power. Power interruptions of any length are

often accompanied by voltage fluctuations which may damage elec-

tronic equipment such as a security system. After a power interruption

has occurred, immediately conduct a complete system test to ensure

that the system operates as intended.

• Failure of Replaceable Batteries

This system’s wireless transmitters have been designed to provide sev-

eral years of battery life under normal conditions. The expected battery

life is a function of the device environment, usage and type. Ambient

conditions such as high humidity, high or low temperatures, or large

temperature fluctuations may reduce the expected battery life. While

each transmitting device has a low battery monitor which identifies

when the batteries need to be replaced, this monitor may fail to operate

as expected. Regular testing and maintenance will keep the system in

good operating condition.

• Compromise of Radio Frequency (Wireless) Devices

Signals may not reach the receiver under all circumstances which

could include metal objects placed on or near the radio path or deliber-

ate jamming or other inadvertent radio signal interference.

•SystemUsers

A user may not be able to operate a panic or emergency switch possi-

bly due to permanent or temporary physical disability, inability to

reach the device in time, or unfamiliarity with the correct operation. It

is important that all system users be trained in the correct operation of

the alarm system and that they know how to respond when the system

indicates an alarm.

• Smoke Detectors

Smoke detectors that are a part of this system may not properly alert

occupants of a fire for a number of reasons, some of which follow. The

smoke detectors may have been improperly installed or positioned.

Smoke may not be able to reach the smoke detectors, such as when the

fire is in a chimney, walls or roofs, or on the other side of closed doors.

Smoke detectors may not detect smoke from fires on another level of

the residence or building.

Every fire is different in the amount of smoke produced and the rate of

burning. Smoke detectors cannot sense all types of fires equally well.

Smoke detectors may not provide timely warning of fires caused by

carelessness or safety hazards such as smoking in bed, violent explo-

sions, escaping gas, improper storage of flammable materials, over-

loaded electrical circuits, children playing with matches or arson.

Even if the smoke detector operates as intended, there may be circum-

stances when there is insufficient warning to allow all occupants to

escape in time to avoid injury or death.

•MotionDetectors

Motion detectors can only detect motion within the designated areas as

shown in their respective installation instructions. They cannot dis-

criminate between intruders and intended occupants. Motion detectors

do not provide volumetric area protection. They have multiple beams

of detection and motion can only be detected in unobstructed areas

covered by these beams. They cannot detect motion which occurs

behind walls, ceilings, floor, closed doors, glass partitions, glass doors

or windows. Any type of tampering whether intentional or uninten-

tional such as masking, painting, or spraying of any material on the

lenses, mirrors, windows or any other part of the detection system will

impair its proper operation.

Passive infrared motion detectors operate by sensing changes in tem-

perature. However their effectiveness can be reduced when the ambi-

ent temperature rises near or above body temperature or if there are

intentional or unintentional sources of heat in or near the detection

area. Some of these heat sources could be heaters, radiators, stoves,

barbeques, fireplaces, sunlight, steam vents, lighting and so on.

• Warning Devices

Warning devices such as sirens, bells, horns, or strobes may not warn

people or waken someone sleeping if there is an intervening wall or

door. If warning devices are located on a different level of the resi-

dence or premise, then it is less likely that the occupants will be alerted

or awakened. Audible warning devices may be interfered with by

other noise sources such as stereos, radios, televisions, air conditioners

or other appliances, or passing traffic. Audible warning devices, how-

ever loud, may not be heard by a hearing-impaired person.

• Telephone Lines

If telephone lines are used to transmit alarms, they may be out of ser-

vice or busy for certain periods of time. Also an intruder may cut the

telephone line or defeat its operation by more sophisticated means

which may be difficult to detect.

• Insufficient Time

There may be circumstances when the system will operate as intended,

yet the occupants will not be protected from the emergency due to their

inability to respond to the warnings in a timely manner. If the system

is monitored, the response may not occur in time to protect the occu-

pants or their belongings.

• Component Failure

Although every effort has been made to make this system as reliable as

possible, the system may fail to function as intended due to the failure

of a component.

• Inadequate Testing

Most problems that would prevent an alarm system from operating as

intended can be found by regular testing and maintenance. The com-

plete system should be tested weekly and immediately after a break-in,

an attempted break-in, a fire, a storm, an earthquake, an accident, or

any kind of construction activity inside or outside the premises. The

testing should include all sensing devices, keypads, consoles, alarm

indicating devices and any other operational devices that are part of the

system.

• Security and Insurance

Regardless of its capabilities, an alarm system is not a substitute for

property or life insurance. An alarm system also is not a substitute for

property owners, renters, or other occupants to act prudently to prevent

or minimize the harmful effects of an emergency situation.marché en

cours du produit de remplacement sera facturé pour chaque unité de

remplacement.

Limited Warranty

Digital Security Controls warrants the original purchaser that for a

period of twelve months from the date of purchase, the product shall be

free of defects in materials and workmanship under normal use. Dur-

ing the warranty period, Digital Security Controls shall, at its option,

repair or replace any defective product upon return of the product to its

factory, at no charge for labour and materials. Any replacement and/or

repaired parts are warranted for the remainder of the original warranty

or ninety (90) days, whichever is longer. The original purchaser must

promptly notify Digital Security Controls in writing that there is defect

in material or workmanship, such written notice to be received in all

events prior to expiration of the warranty period. There is absolutely no

warranty on software and all software products are sold as a user

license under the terms of the software license agreement included

with the product. The Customer assumes all responsibility for the

proper selection, installation, operation and maintenance of any prod-

ucts purchased from DSC. Custom products are only warranted to the

extent that they do not function upon delivery. In such cases, DSC can

replace or credit at its option.

International Warranty

The warranty for international customers is the same as for any cus-

tomer within Canada and the United States, with the exception that

Digital Security Controls shall not be responsible for any customs fees,

taxes, or VAT that may be due.

Warranty Procedure

To obtain service under this warranty, please return the item(s) in ques-

tion to the point of purchase. All authorized distributors and dealers

have a warranty program. Anyone returning goods to Digital Security

Controls must first obtain an authorization number. Digital Security

Controls will not accept any shipment whatsoever for which prior

authorization has not been obtained.

Conditions to Void Warranty

This warranty applies only to defects in parts and workmanship relat-

ing to normal use. It does not cover:

• damage incurred in shipping or handling;

• damage caused by disaster such as fire, flood, wind, earthquake or

lightning;

• damage due to causes beyond the control of Digital Security Controls

such as excessive voltage, mechanical shock or water damage;

• damage caused by unauthorized attachment, alterations, modifications

or foreign objects;

• damage caused by peripherals (unless such peripherals were supplied

by Digital Security Controls);

• defects caused by failure to provide a suitable installation environment

for the products;

• damage caused by use of the products for purposes other than those

for which it was designed;

• damage from improper maintenance;

• damage arising out of any other abuse, mishandling or improper appli-

cation of the products.

Items Not Covered by Warranty

In addition to the items which void the Warranty, the following items

shall not be covered by Warranty: (i) freight cost to the repair centre;

(ii) products which are not identified with DSC's product label and lot

number or serial number; (iii) products disassembled or repaired in

such a manner as to adversely affect performance or prevent adequate

inspection or testing to verify any warranty claim. Access cards or tags

returned for replacement under warranty will be credited or replaced at

DSC's option. Products not covered by this warranty, or otherwise out

of warranty due to age, misuse, or damage shall be evaluated, and a

repair estimate shall be provided. No repair work will be performed

until a valid purchase order is received from the Customer and a

Return Merchandise Authorisation number (RMA) is issued by DSC's

Customer Service.

Digital Security Controls’s liability for failure to repair the product

under this warranty after a reasonable number of attempts will be lim-

ited to a replacement of the product, as the exclusive remedy for breach

of warranty. Under no circumstances shall Digital Security Controls be

liable for any special, incidental, or consequential damages based upon

breach of warranty, breach of contract, negligence, strict liability, or

any other legal theory. Such damages include, but are not limited to,

loss of profits, loss of the product or any associated equipment, cost of

capital, cost of substitute or replacement equipment, facilities or ser-

vices, down time, purchaser’s time, the claims of third parties, includ-

ing customers, and injury to property. The laws of some jurisdictions

limit or do not allow the disclaimer of consequential damages. If the

laws of such a jurisdiction apply to any claim by or against DSC, the

limitations and disclaimers contained here shall be to the greatest

extent permitted by law. Some states do not allow the exclusion or

limitation of incidental or consequential damages, so that the above

may not apply to you.

Disclaimer of Warranties

This warranty contains the entire warranty and shall be in lieu of any

and all other warranties, whether expressed or implied (including all

implied warranties of merchantability or fitness for a particular pur-

pose) and of all other obligations or liabilities on the part of Digital

Security Controls. Digital Security Controls neither assumes responsi-

bility for nor authorizes any other person purporting to act on its behalf

to modify or to change this warranty, nor to assume for it any other

warranty or liability concerning this product.

This disclaimer of warranties and limited warranty are governed by the

laws of the province of Ontario, Canada.

WA R N I N G : Digital Security Controls recommends that the entire

system be completely tested on a regular basis. However, despite fre-

quent testing, and due to, but not limited to, criminal tampering or elec-

trical disruption, it is possible for this product to fail to perform as

expected.

Out of Warranty Repairs

Digital Security Controls will at its option repair or replace out-of-war-

ranty products which are returned to its factory according to the fol-

lowing conditions. Anyone returning goods to Digital Security

Controls must first obtain an authorization number. Digital Security

Controls will not accept any shipment whatsoever for which prior

authorization has not been obtained.

Products which Digital Security Controls determines to be repairable

will be repaired and returned. A set fee which Digital Security Controls

has predetermined and which may be revised from time to time, will be

charged for each unit repaired.

Table of Contents

Section 1: Introduction ...............................2

1.1 What’s New to Version 5.X ..................................2

1.2 How to Use this Manual .....................................2

1.3 Specifications and Features .................................2

1.4 Compatible Wireless Devices ...............................3

1.5 Safety Instructions ..............................................3

Section 2: RF5132-433 Set Up & Wiring ...4

2.1 Unpack the RF5132-433 ...................................4

2.2 Choose a Mounting Location for the RF5132-433 4

2.3 Connect the RF5132-433 Receiver ......................4

2.4 Tamper ..............................................................4

Section 3: Receiver Programming ..............5

3.1 Identified Wireless Keys ......................................5

3.2 A Note about Electronic Serial Numbers (ESN) .....5

3.3 Enroll Wireless Devices Using Zones .....................5

3.4 Enroll & Program Wireless Keys ...........................6

3.5 RF5132-433 LEDs .............................................7

3.6 Deleting Wireless Devices ....................................7

Section 4: Other Programming ..................8

4.1 Program Zones and Partitions ............................. 8

4.2 Enable RF5132-433 Supervision ....................... 8

4.3 Enable Supervision of Wireless Zones .................. 9

4.4 RF Jam Detect Zone ............................................9

4.5 RF5132-433 Software Default .........................10

4.6 Deleting Wireless Devices .................................10

Section 5: Testing & Mounting ................. 11

5.1 Test the Reception of Wireless Devices ...............11

5.2 Mount the RF5132-433 and Wireless Devices ...12

Section 6: Additional Notes ..................... 14

6.1 Trouble Conditions ............................................14

6.2 Jamming Signal Detection ................................14

6.3 Wireless Zone Low Battery Transmission ............14

Section 7: Troubleshooting ...................... 15

Section 8: Programming Worksheets ...... 16

Français...................................................... 22

Español...................................................... 44

Italiano...................................................... 66

This manual shall be used in conjunction with the Installation Manual of the alarm control panel.

Section 1: Introduction

This manual describes how to install, program and maintain the RF5132-433.

Before you install the RF5132-433 module, you should complete the following steps in your system installation:

1. Plan the installation and wiring of the security system (see your system Installation Manual).

2. Install the control panel, and install and enroll at least one keypadto use for programming.

3. Install and enroll any hardwired zone expander modules (PC5108) you plan to use.

Program the RF5132-433 from a system keypad or using downloading software on a remote computer. Read your

system Installation Manual for more information.

1.1 What’s New to Version 5.X

1. Section 2.3 Connect the RF5132-433 Receiver - a fifth terminal was added to the RF5132-433 which should

remain unused.

2. Section 2.4 Tamper - programmable wall and case tamper for RF5132-433.

3. Section 3.5 LED - addition of LEDs to assist in installation.

4. Section 6.1 Trouble Conditions - addition of RF delinquency (EU only).

5. Programming Sections [61] - [69] - 8 partition support for wireless devices.

6. RF5132-433 v5.0 DLS Driver Pack is required for this product.

1.2 How to Use this Manual

Read this manual before you begin installing the RF5132-433. To install and set up the RF5132-433 and wireless

devices, follow these steps. Refer to thesections listed below.

1. Temporarily mount and wire the RF5132-433 module (see Section 2).

2. Enroll and program wireless devices (see Section 3).

3. Complete zone and other programming on the system (see Section 4).

4. Test the placement of all the wireless devices (see Section 5).

5. Permanently mount the RF5132-433 receiver and wireless devices (see Section 5).

For additional information on trouble conditions, RF jamming signal detection and battery replacement, see Section 6.

For help with troubleshooting, see Section 7.

1.3 Specifications and Features

• Current Draw: 50 mA

• Frequency: 433 MHz

• Zones - receiver can receive signals from up to 32 wireless zones and 16 wireless keys

• Supervisory - programmable supervisory window

•Location

- can be wired up to 750 ft. / 230 m from the main panel with 22 gauge wire

- connects to Keybus

- for longer wire runs, thicker gauge wire must be used.

• Compatibility: The RF5132-433 v5.X can be connected to the following panels: PC501X, PC5020, PC1555, PC580,

PC1616, PC1832, PC1864.

• Operating temperature: 0-50°C / 32-122°F

•Separate built-in wall and case tamper

1.4 Compatible Wireless Devices

Please refer to the Instruction sheets of the following devices for more information.

The RF5132-433 v5.X can receive signals from the following devices:

• WLS904L-433 Motion Detector • WS4916 Smoke Detector

• WLS904PL-433 Pet Immune PIR • WS4938 Panic Button

• WLS906-433 Smoke Detector • WS4939 Wireless Key

• WLS912L-433 Glass Break Detector • WS4949 2-Button Wireless Key

• WLS914-433 Pet Immune PIR • WS4959 5-Button Wireless Key

• WLS919-433 Wireless Key • WS4969 Wireless Key with LED

• WLS925L-433 Mini Door/Window Contact

1.5 Safety Instructions

•This equipment shall be installed by Service Persons only (service person is defined as a person having the

appropriate technical training and experience necessary to be aware of hazards to which that person may be

exposed in performing a task and of measures to minimize the risks to that person or other persons). It shall be

installed and used within an environment that provides the pollution degree max 2, over voltages category II, in

non-hazardous, indoor locations only.

• Secure the receiver to the building structure before applying power to the alarm controller.

•Use at least two screws and/or adequate mounting means to secure the receiver to the building structure (e.g.

Screws # 6×3/4” flat Philips).

Section 2: RF5132-433 Set Up & Wiring

This section describes how to set up and wire the RF5132-433 module.

2.1 Unpack the RF5132-433

Check that the following parts are in your RF5132-433 package:

• RF5132-433 PCB • Hardware for mounting the cabinet

•RF5132-433 plastic cabinet

2.2 Choose a Mounting Location for the RF5132-433

NOTE: Mount the RF5132-433 receiver and wireless devices after you have done placement tests with the wireless

devices (see sections 5.1 and 5.2).

Find a place that is:

•Dry

•Within operating temperature range

•Central to the proposed placement of all wireless devices

• As high as possible

•Far from sources of interference, including: electrical noise (computers, televisions and electric motors in appliances

and heating and air conditioning units); large metal objects like heating ducts and plumbing which may shield the

electro-magnetic waves.

For proper unit tamper operation, the surface that the RF5132-433 is installed onto should be smooth and free of

obstructions that allows access to the rear of the unit.

Make sure that electrical wires will not run over and under the module when it is mounted.

When mounting the RF5132-433 in a basement, place the module as high and as close to the underside of the first

floor as possible. The range of the module will be reduced if the unit is mounted below ground level.

2.3 Connect the RF5132-433 Receiver

CAUTION: Remove all power from the system while connecting modules to the Keybus.

Connect the RF5132-433 to the four-wire Keybus of the control panel according to the following diagram.

After you have completed the wiring, reconnect the power to the

security system.

The RF5132-433 has a fifth terminal labeled ‘GND’, which should

remain unused.

Now that you have wired the RF5132-433, you should enroll and

program the wireless devices. See section 3 for instructions.

2.4 Tamper

The unit incorporates separate built-in wall and case tampers. The

tampers are disabled by default on the NA version (Default on EU version: Active). Section [90] option 3 and 4 can

enable or disable the tampers.

When properly installed the wall tamper will be depressed by the wall where the RF5132-433 is installed on. The wall

tamper activates when the unit is removed from the wall. The case tamper activates when the case is opened and

restores when the case is closed.

KEYBUS

RF5132

Section 3: Receiver Programming

Enroll & Program Devices

This section describes how to enroll and program:

•wireless devices using zones (WLS904PL-433, WLS906-433, WS4916, WLS912L-433, WLS914-433, WS4938,

WLS925L-433)

• wireless keys (WLS919-433, WS49X9)

For more information on these devices, read the instruction sheet included with each device.

3.1 Identified Wireless Keys

Reporting by the system of openings/closings by individual wireless keys and command output [*][7] activation by

wireless key buttons may be supported on certain control panels. Todo this, the system will reserve access codes 17 –

32 for wireless keys 01-16 respectively. You must program one access code for each wireless key (using [*][5] access

code programming) for this feature to work correctly.

NOTE: Program these access codes on the system after you have connected the RF5132-433 to the Keybus (see

section 2.4).

Refer to your system Installation Manual for information on access code programming.

Opening/Closing By Wireless Key Reporting

NOTE: The Identified Wireless Key Closing option is only available with the PC5020, PC1616, PC1864, PC501X

v2.0 and higher, PC1555(MX), PC580/585 v2.0 and higher.

To enable the reporting of openings and closings by identifiedwireless keys:

• Make sure the control panel is v2.0 or higher

• Program a valid access code for each key

• Program a closing and opening reporting code for each key’s access code

• Turn off the Quick Arm option in section [015] option [4] of the control panel programming

To ensure that an unidentified wireless key cannot disarm the system, turn off section [017], option [1] (in the control

panel programming). This option is available in control panels with software version 2.1 or higher.

3.2 A Note about Electronic Serial Numbers (ESN)

An electronic serial number (ESN) is printed on each wireless device. ESNs are used to enroll the wireless devices with

the RF5132-433 receiver.

In order to reduce the occurrence of wireless devices with the same serial number, 6-digit serial numbers are printed on

the back of each wireless device. The 6-digit serial numbers include hexadecimal digits. For instructions on

programming hexadecimal numbers, see your system Installation Manual, Section 4: How to Program.

NOTE: 6-digit serial numbers are only supported on the following control panels: PC5020, PC1616, PC1832,

PC1864, PC501X v2.0 & higher, PC1555(MX), PC580/585.

3.3 Enroll Wireless Devices Using Zones

Enroll wireless devices which use zones (universal transmitters, motion detectors, smoke detectors, and panic

pendants):

1. At a system keypad, enter [*][8][Installer’s code] to go into the installer’s programming section.

2. Enter programming section [804].

3. Enter the 2-digit number corresponding to the zone the device is to occupy ([01] to [32]).

NOTE: Hardwired and wireless devices cannot be assigned to the same zone. PC5108 zone expander modules

occupy zones in 2 groups of 4 (e.g. zones 9-12 and zones 13-16). None of the zones assigned to a PC5108

module may be used for wireless devices. For more information on zone assignment, consult your system

Installation Manual.

4. Enter the device ESN. The entry must be 6 digits.

5. The device is now enrolled on the system. Record the serial number and the assigned zone number in the

programming worksheets in the back of this manual.

6. Continue with steps 3 - 5 until you have enrolled all wireless devices.

7. To exit press [#].

NOTE: The devices will not work properly until you complete zone and partition programming (see section 4).

3.4 Enroll & Program Wireless Keys

For wireless keys to work on the system, you need to enroll them and then program the function buttons, if the default

values are not the functions desired. Wireless keys are not assigned to zones and require no zone programming. You

can enroll up to 16 wireless keys on the system.

Enroll Wireless Keys

1. Enter [*][8][Installer’s Code] to go to the installer’s programming section.

2. Enter programming section [804].

3. Enter a 2-digit number [41]-[56] to program the wireless key serial number. These numbers correspond to wireless

key numbers 01- 16.

4. Enter the device ESN. The entry must be six digits.

5. The key is now enrolled on the system. Record the serial number and the assigned slot number in the programming

worksheets in the back of this manual.

6. Repeat steps 3 - 5 until all wireless keys have been enrolled.

7. (PC5020/PC1616/PC1832/PC1864/PC501X only) By default, all wireless keys are assigned to Partition

1. To assign keys to different partition, see programming section [69].

NOTE: A wireless key can only be assigned to one partition.

8. To exit press [#].

Programming the Wireless Keys Function Buttons

Wireless keys have four programmable function buttons. Default functions have been assigned, but you may program

other functions if desired. After the functions are programmed, when you press and hold one of the four buttons for one

second, the system will execute the programmed function.

For systems using partitions (PC5020/PC1616/PC1832/PC1864/PC501X only): All wireless keys

assigned to Partition 1 will have the four functions programmed in section [61]. All wireless keys assigned to Partition

2-8 will have the four functions programmed in section [62-68]. For example, if function button 1 in Section [61] is

programmed for Stay arming, then pressing the first button on any wireless key assigned to Partition 1 will Stay arm

Partition 1.

NOTE: Wireless keys will not work when the partition they are assigned to is being accessed for zone bypassing or

programming.

1. At a system keypad, enter [*][8][Installer’s Code].

2. Enter programming section [804].

3. Enter programming section [61] to [68] for partitions 1 to 8.

4. For each of the 4 function buttons, enter the 2-digit number of the function you want to select. See the

programming worksheets in the back of this manual for a list of function key options.

5. Record your programming choices in the worksheets in the back of the manual.

6. To exit press [#].

3.5 RF5132-433 LEDs

The RF5132-433 v5.0 features two LEDs to help with the installation of devices and troubleshoot the operation of the

unit. In normal operation the LEDs will indicate if the signal received is from an enrolled device or not.

• The green LED will flash when receiving a signal from an enrolled device.

• The red LED will flash when receiving a signal from a non-enrolled device.

Alternatively, when the panel is in placement test mode, the green LED will only flash for the specific serial number

entered. All other signals (including signals from valid enrolled devices) will flash red.

3.6 Deleting Wireless Devices

To remove a wireless device from the system, follow the guideline for adding a wireless device. Program the ESN as

[000000]. The wireless device for the zone will be removed.

Now that you have enrolled all the wireless devices, you will need to program the system to

work properly with the devices. See section 4 for more information.

Section 4: Other Programming

4.1 Program Zones and Partitions

Now that you have enrolled the wireless devices, you should complete all zone programming on the system. Although

the exact programming required varies depending on which control panel the RF5132-433 is connected to, you should

check that the following programming areas are completed correctly for each wireless zone:

•Enable zones and/or assign zones to one or more partitions (programming sections [202]-[205] or [202] to [265]

for the PC5020/PC1616/PC1864).

• Program the definition for each zone (programming sections [001]-[004]).

•Enable the wireless zone attribute for each wireless zone (PC580, PC1555, PC1616, PC1832, PC1864, PC501X

v2.0, PC5020 v3.0 and higher only) (sections [101]-[132]).

See your system Installation Manual, for more information on each of the above programming sections.

4.2 Enable RF5132-433 Supervision

The control panel will supervise the RF5132-433 receiver via the Keybus after at least one device has been enrolled on

the module (see section 3.2 “Enrolling Wireless Devices”).

To activate module supervision, after you enroll the first device(s):

1. Exit and then re-enter installer’s programming

2. Enter programming section [902]. Wait approximately 1 minute.

3. To exit press [#].

The system will generate a General System Supervisory trouble ifthe module is removed from the Keybus. If you need

to remove the RF5132-433 module from an existing system, you will have to disable supervision of the RF5132-433.

NOTE: Deleting all devices from the RF5132-433 or defaulting the RF5132-433 will cause a supervisory fault

To disable RF5132-433 supervision:

1. Disconnect the RF5132-433 from the Keybus

2. Enter [*][8][Installer Code]

3. Enter [902]. The control panel will clear all supervision and re-scan the system for connected modules. The scan

will take approximately one minute.

4. To exit press [#].

To review which modules the control panel is currently supervising:

1. Enter [*][8][Installer’s Code]

2. Enter [903] to display all modules. On a LED 32 zone keypad, light [17] will indicate that the RF5132-433 is

present on the system. On LCD keypads, scroll until the module name appears on thedisplay.

3. To exit press [#].

If the RF5132-433 module does not show on the keypad, one of the following conditions may be present:

•the module is not connected properly to the Keybus

• there is a problem with the Keybus wiring run

•the module does not have enough power

•no devices have been enrolled on the RF5132-433

4.3 Enable Supervision of Wireless Zones

NOTE: (for PC5010 v1.x control panels only) In order for wireless zones to be supervised, you must enable Double

End of Line (DEOL) supervision in the PC5010 control panel. For more information, refer to your Installation

Manual.

NOTE: (PC5020, PC1616, PC1832, PC1864, PC501X, PC1555, PC580 v2.0 and higher only) For wireless

supervision to work, you must enable the wireless zone attribute on all wireless zones (sections [101] to [132],

option [8] ON).

Wireless Supervisory Window

Each wireless device (excluding wireless keys) will send a supervisory signal periodically. If the receiver does not receive

a signal within the time programmedfor the Wireless Supervisory Window, it will generate a supervisory fault.

To program the wireless supervisory window:

1. Enter [*][8][Installer Code] to enter Installer Programming.

2. Enter [804] to enter the RF5132-433 Module Programming.

3. Enter section [81].

4. Enter the time period for the supervisory window. The window is programmed in 15 minute increments. The default

programming is:

• 96 (x15minutes), which is equal to 24 hours for NA version, or

• 10 (x15minutes), which is equal to 2.5 hours for EU version.

Valid entries are (10) to (96), equal to 2.5 to 24 hours.

5. To exit press [#].

NOTE: Supervision must be enabled for RF Delinquency.

Disable/Enable Zone Supervision

All wireless zones have supervision enabled by default. To disable supervision for any zone, enter the following at any

system keypad:

1. Enter [*][8][Installer Code] to enter Installer Programming.

2. Enter [804] to enter the RF5132-433 Module Programming.

3. Enter sections [82], [83], [84] and [85]. Enable or disable supervision for each wireless zone by turning each

relevant option on or off.

4. To exit press [#].

4.4 RF Jam Detect Zone

For RF jamming detection to work, you must select an unused zone to be used as the RF Jam Detect zone. When the

receiver detects an attempt to jam the RF signal, the RF Jam Detect zone will be violated and the system will generate

a tamper signal. When the jamming signal is gone, the RF Jam Detect zone closes and the system sends a tamper

restore signal.

To enable RF jamming detection by zone:

1. Enter [*][8] [Installer’s Code].

2. Enter programming section [804].

3. Select an unused zone to be the RF Jam Detect zone. Enter the 2-digit number ([01] to[32]) of the RF Jam Detect

zone on the keypad, then program the serial number as [200000].

4. Enter section [93]. Enter the 2-digit number of the RF Jam Detect zone ([01] to [32]) in the programming section.

5. Disable supervision for the RF Jam detect zone by turning the relevant option off in section [82], [83], [84] or [85].

(See section 4.3 for more information.)

6. RF jamming detection is now enabled. To exit Installer programming, press [#].

NOTE: For UL Listed installations, the RF Jam feature must be enabled - Section [804], subsection [90], Option [7]

OFF. Ensure the wireless bit is enabled and jam bit in section [90] is disabled.

4.5 RF5132-433 Software Default

Returning the RF5132-433 programming to factory default settings is a quick way to remove all the enrolled devices

from the system and reset all the programming in section [804].

NOTE: Performing this procedure will not change any programming sections except [804]. Resetting the control

panel to factory default settings will not return the RF5132-433 module to factory default settings.

To restore the RF5132-433 programming to the factory default settings:

1. Enter [*][8] [Installer’s Code].

2. Enter programming section [996].

3. Enter the Installer’s Code, followed by [996] again. The software for the RF5132-433 will be restored to its factory

default settings.

4. To continue programming the unit, exit installer’s programming by pressing [#] and then re-enter installer’s

programming by entering [*][8] [Installer’s Code].

For instructions on restoring the default programming of the control panel or any other connected module, see your

system Installation Manual.

4.6 Deleting Wireless Devices

To remove a wireless device from the system, follow the guideline for enrolling a wireless device (see section 3.2).

Program the ESN as [000000]. The wireless device for the zone will be removed.

NOTE: You may need to remove power from the panel in order to clear troubles caused by deleted zones.

Now that you have completed all RF5132-433 related programming, you can test and mount

the receiver and devices. See section 5 for more information.

Section 5: Testing & Mounting

5.1 Test the Reception of Wireless Devices

It is very important to test the proposed placement of each wireless device before it is mounted. Following these steps

will test the signal strength between the RF5132-433 and the wireless devices.

You can test all of the devices together (global placement testing) or test each device individually. To test all the devices

together, see ‘Testing All Wireless Devices Together’ below. To test wireless devices individually, see ‘TestingIndividual

Devices’.

NOTE: After you have enrolled the wireless devices, you must exit and then re-enter Installer’s Programming at least

once before you can perform a placement test.

Testing All Wireless Devices Together:

1. Temporarily put the wireless devices in the places you want to mount them.

2. At a system keypad, enter [*][8][Installer Code].

3. Enable the Global Module Placement test by entering section [804]. Then enter sub-section [90] and turn on

option [8].

4. Press [#] twice.

5. Enter programming section [904], then enter [01].

6. Activate one of the devices being tested until a result is displayed on the keypad or sounded by the keypad or bell:

Motion Detectors: To perform a Placement Test on the WLS904P-433, remove the detector from the back

plate and then replace it. Once the detector is replaced on the back plate the LED on the detector will flash rapidly 5

times (4 times for the WLS914-433) to indicate that it has sent a transmission. The panel will show and/or sound

the result of the placement test on the keypad. To perform a 2nd and 3rd test, repeat this procedure. Carefully

replace the backplate onto the detector, ensuring that “TOP” is facing upward, or you may

damage the tamper switch.

NOTE: When you remove the detector from the backplate (tamper the unit), the detector will also be put into

“Detector Walk Test” mode. While in Walk Test mode the detector will activate the LED when motion is

detected. The detector will also send a signal to the receiver 5 seconds after motion is detected, indicated by 5

rapid flashes by the LED. The LED will only work in this fashion for 10 motion detections after a tamper/restore.

Note that the panel will ignore these transmission signals with respect to a placement test. The only way in

which the panel will acknowledge a placement test is if the backplate has, each time, been removed and

restored.

Smoke Detector: Remove the detector from its backplate, wait 5 seconds and re-attach it, or hold a magnet

near the raised line on the outer rim, then remove it.

Door/Window Transmitter: Open the contact by moving the magnet away from the unit. The keypad will

show/sound the test result. After the first test result has been generated (about 10 seconds) close the contact to

generate another test result. If the unit is attached to a door or a window, open and close the door or window to

activate the device.

Glassbreak Detector: Press and hold the test mode tab for 5 seconds. Release the test mode tab. The keypad

will display the test result.

Read the test results at the keypad::

Activate the device until you get 3 ‘good’ results in a row.

You may mount the WLS devices where results were good.

Devices indicating a bad result must be moved to another location. You may only have to move the device a

few inches to correct a bad result.

Do not mount any device where a “bad” test result was indicated.

7. Go to the next device to be tested and activate it until the test result is displayed/sounded.

NOTE: Wait until the placement test of one device is shown/sounded before beginning to test the next

device.

Continue to test the devices until both the RF5132-433 and the devices are in good locations. If several

wireless devices produce ‘bad’ test results, you may need to move the RF5132-433 to a better location.

(See section 2.2 for tips on finding a location for the RF5132-433.)

8. To exit the placement test and return to installer programming, press [#] twice.

Testing Individual Devices:

1. Temporarily place the device where you want to mount it.

2. At a system keypad, enter [*][8][Installer Code].

3. Enter programming section [904].

4. Ensure option 8 in section [90] is disabled.

5. Enter the 2-digit zone number for the device to be tested.

6. Activate the device being tested until a result is displayed on the keypad or sounded by the keypad or bell.

(Same as step 5 in the Global Placement Test section, previous page.)

7. To test another device, press [#] once, then repeat steps 4 - 5. Continue to test the devices until both the

RF5132-433 and the devices are in good locations.

If several wireless devices produce ‘bad’ test results, you may need to move the RF5132-433 to a better

location. (See section 2.2 for tips on finding a location for the RF5132-433.)

8. To exit the placement test and installer programming, press [#] twice.

Testing Individual Wireless Keys:

Do not use the individual device test described above to test the wireless keys. To ensure that the RF5132-433

receiver is receiving transmissions from these devices, use the function keys on these devices at several different

points in the installation.

5.2 Mount the RF5132-433 and Wireless Devices

When you have tested reception of the RF5132-433 with all the wireless devices (see section 5.1) and you have a

good mounting location, mount the RF5132-433:

1. Pull the Keybus wires through the hole at the bottom of the cabinet.

2. Mount the cabinet securely to the wall.

Result LED Keypad LCD Keypad Buzzer/Bell

Good Light 1 On Steady “Good” 1 Beep/Squawk

Bad Light 3 On Steady “Bad” 3 Beeps/Squawks

Mount the Devices

If you have conducted the placement test described in section 5.1 and got 3 ‘good’ results in a row for each device,

you can mount the wireless devices. See the Installation Sheet for each device for mounting instructions.

Now that your RF5132-433 and wireless devices are mounted and working properly, read

section 6 for information on potential wireless trouble conditions, RF jamming signals, and

battery replacement.

Section 6: Additional Notes

6.1 Trouble Conditions

The control panel always watches for possible trouble conditions. If a trouble condition occurs, the keypad “Trouble”

light will turn on and the keypad will beep. Press [*][2] to display the trouble conditions.

The following trouble conditions apply to the RF5132-433 and/or any enrolled devices.

•General System Tamper (on Power panels v.2.01 and below) - This trouble is generated when the RF5132-

433 detects an RF Jamming condition.

•General System Supervisory - This trouble will be generated if the panel loses communication with any

module connected to the Keybus. The event buffer will log a detailed description of the event.

•Device Low Battery - This trouble is generated when a wireless device exhibits a low battery condition. Press [7]

one, two, or three times to view which devices are experiencing battery failure. An LED keypad will indicate battery

failure using zone lights 1 to 8.

•Zone Tamper - This trouble is generated when an enrolled wireless device is removed from its mounting location.

•Zone Fault - Each wireless device will send a supervisory signal every 64 minutes (15 minutes for EU). If the

receiver does not receive a signal within the time programmed for the Wireless Supervisory Window, it will generate

a zone fault.

•RF Delinquency (EU only) - Each wireless zone will send a supervisory signal every 15 minutes. If the receiver

does not receive a signal within 15 minutes, it will generate a RF Delinquency Trouble for that zone. This condition

exists only on PC1614/PC1832/PC1864 panels v4.1.

6.2 Jamming Signal Detection

The RF5132-433 receiver detects jamming signals that can prevent the receiver from properly receiving transmissions

from enrolled devices. See section 4.4 “RF Jam Detect Zone” for information on jamming signal detection

programming.

NOTE: For UL Listed installations, the RF Jam feature must be enabled - Section [804], subsection [90],

Option [7] OFF.

6.3 Wireless Zone Low Battery Transmission

Within any transmission, the device will indicate the status of the battery. If a battery is low, the system will indicate a

Device Low Battery trouble.

The system will delay reporting the event to the central station for the number of days programmed for Zone Low

Battery Transmission Delay in section [370] of the panel. This will prevent unnecessary reporting of the event if

the user has been instructed on how to replace batteries.

Replacing Batteries in Wireless Devices

1. Refer to the battery installation instructions on the installation sheet of each device. Be sure to note the proper

orientation of the batteries as you install them.

2. When the fresh batteries are in place and the device tamper is restored, the device sends a battery trouble restoral

signal to the RF5132-433. The battery trouble is now clear and the device should function normally.

NOTE: When batteries in one device need to be replaced, the batteries in all devices may need to be replaced

at the same time.

Section 7: Troubleshooting

The RF5132-433 v5.0 features two LEDs to help and with the installation of devices troubleshoot the operation of the

unit. In normal operation the LEDs will indicate if the signal received is from an enrolled device or not.

• The green LED will flash when receiving a signal from an enrolled device.

• The red LED will flash when receiving a signal from a non-enrolled device.

Alternatively, when the panel is in placement test mode, the green LED will only flash for the specific serial number

entered. All other signals (including signals from valid enrolled devices) will flash red.

1. When I enter the 2-digit zone number for adding a wireless device, the keypad gives me

a long beep.

ESNs can be entered only when a RF5132-433 wireless receiver is connected to the Keybus. See section 2 for

instructions on setting up and wiring the RF5132-433 module.

2. I have entered the ESN for the device but when I violate the device, the zone does not

show open on the keypad.

Check the following:

• Ensure the ESN has been entered correctly

•Ensure that the zone is enabled for the partition (if partition programming is used).

•Ensure that the wireless zone is not assigned to a zone used by PC5108 modules, an on-board zone, or a keypad

zone.

• Ensure that the zone is programmed for something other than “Null Operation”, and that the wireless zone attribute

is turned on.

3. When I try a module placement test I get no result or ‘bad’ results.

Check the following (see sections 5.1 and 5.2 for more information on testing devices):

• Verify that you are testing the correct zone.

• Verify that the correct ESN was entered when the device was enrolled.

•Verify thatthe device is in range of the RF5132-433. Try testing the device in the same room as the receiver.

• Confirm that the RF5132-433 is properly connected to the Keybus (see section 2 for RF5132-433 set up and wiring

instructions).

• Check that you are testing the zone correctly (see sections 5.1 and 5.2 for testing instructions).

•Check that the batteries are working and installed correctly.

•Look for large metal objects that may be preventing the signal from reaching the RF5132-433.

The device must be located where consistent ‘good’ results are obtained. If several devices show ‘bad’ results, move the

receiver. See section 2.2 for tips on choosing a mounting location for the RF5132-433.

4. The LED on the motion detector does not turn on when I walk in front of the unit.

The LED is for walk test purposes only. See your Wireless PIR Instruction Sheet for walk test instructions.

Section 8: Programming Worksheets

[804] RF5132-433 Wireless Expansion Programming

•6-digit entry is required. See Section 3.2 “A note on Electronic Serial Numbers” for details on programming 6-digit

serial numbers.

Zone Serial Numbers

Default = 000000

Wireless Key Serial Numbers

Default = 000000

[01] Zone 1 l_____l_____l_____l_____l_____l_____l [17] Zone 17 l_____l_____l_____l_____l_____l_____l

[02] Zone 2 l_____l_____l_____l_____l_____l_____l [18] Zone 18 l_____l_____l_____l_____l_____l_____l

[03] Zone 3 l_____l_____l_____l_____l_____l_____l [19] Zone 19 l_____l_____l_____l_____l_____l_____l

[04] Zone 4 l_____l_____l_____l_____l_____l_____l [20] Zone 20 l_____l_____l_____l_____l_____l_____l

[05] Zone 5 l_____l_____l_____l_____l_____l_____l [21] Zone 21 l_____l_____l_____l_____l_____l_____l

[06] Zone 6 l_____l_____l_____l_____l_____l_____l [22] Zone 22 l_____l_____l_____l_____l_____l_____l

[07] Zone 7 l_____l_____l_____l_____l_____l_____l [23] Zone 23 l_____l_____l_____l_____l_____l_____l

[08] Zone 8 l_____l_____l_____l_____l_____l_____l [24] Zone 24 l_____l_____l_____l_____l_____l_____l

[09] Zone 9 l_____l_____l_____l_____l_____l_____l [25] Zone 25 l_____l_____l_____l_____l_____l_____l

[10] Zone 10 l_____l_____l_____l_____l_____l_____l [26] Zone 26 l_____l_____l_____l_____l_____l_____l

[11] Zone 11 l_____l_____l_____l_____l_____l_____l [27] Zone 27 l_____l_____l_____l_____l_____l_____l

[12] Zone 12 l_____l_____l_____l_____l_____l_____l [28] Zone 28 l_____l_____l_____l_____l_____l_____l

[13] Zone 13 l_____l_____l_____l_____l_____l_____l [29] Zone 29 l_____l_____l_____l_____l_____l_____l

[14] Zone 14 l_____l_____l_____l_____l_____l_____l [30] Zone 31 l_____l_____l_____l_____l_____l_____l

[15] Zone 15 l_____l_____l_____l_____l_____l_____l [31] Zone 31 l_____l_____l_____l_____l_____l_____l

[16] Zone 16 l_____l_____l_____l_____l_____l_____l [32] Zone 32 l_____l_____l_____l_____l_____l_____l

[41] Key 01 l_____l_____l_____l_____l_____l_____l [49] Key 09 l_____l_____l_____l_____l_____l_____l

[42] Key 02 l_____l_____l_____l_____l_____l_____l [50] Key 10 l_____l_____l_____l_____l_____l_____l

[43] Key 03 l_____l_____l_____l_____l_____l_____l [51] Key 11 l_____l_____l_____l_____l_____l_____l

[44] Key 04 l_____l_____l_____l_____l_____l_____l [52] Key 12 l_____l_____l_____l_____l_____l_____l

[45] Key 05 l_____l_____l_____l_____l_____l_____l [53] Key 13 l_____l_____l_____l_____l_____l_____l

[46] Key 06 l_____l_____l_____l_____l_____l_____l [54] Key 14 l_____l_____l_____l_____l_____l_____l

[47] Key 07 l_____l_____l_____l_____l_____l_____l [55] Key 15 l_____l_____l_____l_____l_____l_____l

[48] Key 08 l_____l_____l_____l_____l_____l_____l [56] Key 16 l_____l_____l_____l_____l_____l_____l

Wireless Key Function Key Options

Wireless Key Options

Partition 1 Wireless Key Options

Partition 2 Wireless Key Options

Partition 3 Wireless Key Options

Partition 4 Wireless Key Options

Partition 5 Wireless Key Options

Partition 6 Wireless Key Options

Entry Key Description Entry Key Description

00 Null Key 16 [*][0] Quick Exit

01-02 For Future Use 17 [*][1] Reactivate Stay/Away

03 Stay Arm 18 For Future Use

04 Away Arm 19 [*][7][3] Command Output #3

05 [*][9] No-Entry Arm 20 For Future Use

06 Chime ON/OFF 21 [*][7][4] Command Output #4

07 [*][6][---][4] System Test 22-26 For Future Use

08-12 For Future Use 27 Disarm (OFF)

13 [*][7][1] Command Output #1 28 For Future Use

14 For Future Use 29 Auxiliary Alarm

15 For Future Use 30 Panic Alarm

[61] Function Key 1 Default: 03 l____l____l Function Key 3 Default: 27 l____l____l
