DT Research SA1350 Assembly instructions

SA1350/ CA1350D/ DT135D
P/N: 28-610-135010 OPERATION GUIDE
ENGLISH
BASIC OPERATION GUIDE
SA1350/ CA1350D/ DT135D
Digital Signage Appliance
Cloud Compung Appliance/ Thin Client
Embedded Controller/ System
ENGLISH 4
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com
Copyright © 2012, DT Research, Inc. All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
BOG030912DT135ENG
INTRODUCTION
Thank you for acquiring the latest addion to DT Research’s product line - the SA1350/
CA1350D/ DT135D, featuring compact, robust designs and powered by the high-performance,
energy-efficient AMD Fusion processor. Combined with DT Research’s applicaon-specific
soware, these products provide digital signage, cloud compung, or embedded controller
compung soluons. These products also support major embedded operang systems such as
Linux, Microso® Windows® XP Embedded, Windows® CE, or Windows® Embedded Standard
7 for a variety of compung needs.
Package Contents
One SA1350/ CA1350D/ DT135D
AC/DC Power Adapter
VESA-compliant Mounng Bracket
Quick Start Guide
Basic Operaon Guide
Stand for vercal placement (CA1350D only)
Soware and User Guide (CA1350 Linux zero client and SA1350 only)
1
1
2 3 6
2
3
4
5
6
7
Opons
This product is designed to work with a range of custom and off-the-shelf opons to enhance its
applicability for various deployments.
•Built-in wireless LAN with external antenna
•Smart card reader module (except for SA1350)
Note: The actual package contents may vary depending on the product acquired.
SA1350 Server Installaon and Appliance Registraon
Please refer to the corresponding User Guides for server soware installaon instrucons.
Aer turning on the SA1350 for the first me, a screen prompt is displayed for registering the
appliance. If the screen prompt is not shown, please follow the instrucons below:
Press and hold “ 1. Control + Shi+ Space”to exit the WCM
Player soware.
Navigate to2. Start | All Programs | DT Research | WebDT
Signage Player
Select3. Register WebDT Signage Player Again. The Player
Registraon screen should appear. Fill in all fields to register.
The required informaon is marked.
Click4. OK to register and connect to the WebDT Signage
Appliance Publish Server.
NOTE: If your CA1350D comes with the smart card reader module, make sure the card slot faces up.
Step 1:
Remove the two side screws.•
Step 2:
Place the stand, screw and ghten the two M3 x•
10mm screws included in the package.
Stand Installaon for CA1350D

SA1350/ CA1350D/ DT135D
ENGLISH 23ENGLISH
I/O Ports
Rear ViewFront View
Powering ON and OFF
The Power Buon is located in the front of the product. The Power Buon may be configured
to funcon differently depending on the power opons of the operang system. In general, to
turn on the product, push and release the Power Buon on the front bezel. The adjacent power
LED will be lit (blue) and the corresponding interface will be displayed on the display monitor.
To turn offthe device, again depending on soware operang system, push and release the
Power Buon or use a soware shutdown interface. In the event of system lockup, the Power
Buon may be used to perform a reset on the device. To do that, push and hold the Power
Buon for at least 4 seconds. The system will shut down and all unsaved work may be lost.
Pushing on the Power Buon again will restart the device.
NOTE: The SA1350 is programmed to Power On automacally when power is first applied or
re-established.
Precauons
•Always exercise care when operang and handling.
•Never disassemble any poron of the enclosure. It will void any product warranty.
•Do not use any AC/DC adapter other than the one provided with the device or
acquired from the manufacturer or its partners.
•In the unlikely event that smoke, abnormal noise, or strange odor is present,
immediately power down the product and disconnect all power sources.
•Please report the problem to your device provider immediately.
A B C D E F G H
Power buon
USB 2.0 (4)
RS232 COM ports (2)
A D F
B E G
C H
DC-in
DisplayPort
DVI-I port
Ethernet port
Audio jacks (2)
Device Ports
The product features an opmal set of I/O ports while preserving the compact size of the
system. The DisplayPort and DVI-I connectors, COM ports, Network (10/100/1000 BaseT
Ethernet), and Power ports are supplemented by a set of four USB 2.0 and two Audio ports.
Through its USB ports, the product supports a wide range of USB-based peripherals. These
peripherals are applicable in providing the means for soware installaon, applicaon storage,
data storage, and system soware recovery and updates.
VESA Mounng Bracket Installaon Guide
The product package includes a VESA-compliant mounng bracket (1) which mounts the
product (2) onto a VESA-compable monitor or display.
NOTE: The VESA Mounng Bracket is compable with most displays and monitors that support
the VESA standard.
Step1:
Locate the exisng mounng holes on the monitor.•
Line the bracket holes up with the holes on the back of the•
monitor, as shown to the right.
Place the screws to hold the mounng bracket in place and•
ghten the screws (do not over-ghten).
Step2:
Remove the two M3 screws (3) originally on the product.•
Place the product (2) on the bracket rail with the interface•
ports side facing downwards so that the two mounng
holes on the appliance are aligned with the exisng holes
on the rail (see picture).
Step 3:
Apply and ghten the screws into their original locaons•
and make sure that the bracket and the product are
properly secured.
<1>
<2>
<3>
