DTC AEON User manual

Resource Identifier 100249
Revision: 2.1
AEON Transmitter and Decoder User Guide
Commercial in Confidence

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 0-1
0. Preface
About this Document
This document contains relevant information required to identify, install and control the equipment or
system.
Since the available functions can be licensed and depend on the specific implementation, not all the
functions and or applications contained in this document may be relevant or applicable to the system you
will be working with.
The actual presentation may differ from those in this document due to hardware or software changes.
Intended Audience
This document is meant for anyone interested in how the system can best be used, but it is of most benefit
to:
Operators who oversee the daily operation of the equipment
Installers who are responsible for the pre-installation, on-site installation and configuration of the
system in the end-user environment
Maintainers who are responsible for maintaining the equipment or system
Notice about this Publication
While DTC makes every attempt to maintain the accuracy of the information contained in its product
manuals, the information is subject to change without notice.
Performance specifications included in this manual are for guidance. All particulars are given by DTC in
good faith, actual performance may vary.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 0-2
Text Conventions
This document uses these conventions to identify text that has a special meaning:
Text Convention Example
TEXT in capitals represents a key press on the keyboard.
The + sign means hold down the first key and press the second key.
ESC, F1, SHIFT
CTRL+C
< Text > Serves as a placeholder for variable text that is replaced as
appropriate, the text may be written in italics.
Use the filename
< system_name >.sys for…
Text in italics can represent a link to place in the existing document
(often these are hyperlinks) or a reference to another document.
Refer to Section 0.4, Text
Conventions .
Text in bold emphasises a new word or term of significance. We call this a protocol and
its function is…
Successive software menu selections are shown using arrows to indicate
sub-menus. This is often shown in bold.
Select Configuration>Global
then edit…
Symbols
This document uses these symbols to highlight important information:
WARNING: A notice of when a situation may result in personal injury or loss of life, or destruction of
equipment.
CAUTION: A notice of when a situation may result in loss of data or damage to equipment or systems.
Note:A notice to draw attention to something or supply additional information.
Copyright Statement
This document contains information that is proprietary to Domo Tactical Communications (DTC) Ltd. Any
copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2018 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 0-3
Related Documents
You may also need to refer to:
Document Source
NETNode Phase 5 Software User Guide DTC
Solo Concept Guide DTC
IP Concept Guide DTC
Document History
This is a controlled document, written and produced by the DTC Technical Publications team. Changes are
recorded in the table below.
Revision Date Author Summary of Changes
1.0 06/02/2018 IR First release
1.1 23/08/2018 IR Decoder rear panel amendments, upgrade procedures and
decoder configurations.
1.2 11/09/2018 IR USB supported dongles. Removed USB slot from Decoder.
Record playback syntax.
2.0 14/08/2019 IR Software updates and case temperature caution.
2.1 30/03/2020 IR Amended SDI input 3 to include 12G-SDI. Support for 8
channel audio. Software updates for 5.2.0.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 0-4
Contents
0. Preface......................................................................................................0-1
About this Document .................................................................................................................... 0-1
Intended Audience ........................................................................................................................ 0-1
Notice about this Publication........................................................................................................ 0-1
Text Conventions........................................................................................................................... 0-2
Symbols ........................................................................................................................................ 0-2
Copyright Statement..................................................................................................................... 0-2
Related Documents....................................................................................................................... 0-3
Document History.......................................................................................................................... 0-3
1. Product Overview ......................................................................................1-1
Product Family .............................................................................................................................. 1-1
AEON Transmitter ......................................................................................................................... 1-1
AEON Decoder ............................................................................................................................... 1-3
2. Product Package .......................................................................................2-4
Overview ....................................................................................................................................... 2-4
AEON Transmitter Parts List ......................................................................................................... 2-4
AEON Decoder Parts List ............................................................................................................... 2-4
Accessory Options ......................................................................................................................... 2-5
AEON Transmitter Licensing Options ............................................................................................ 2-5
AEON Transmitter Variants ........................................................................................................... 2-6
Labelling....................................................................................................................................... 2-7
3. Connections, Controls and Indicators........................................................3-8
Introduction .................................................................................................................................. 3-8
AEON Transmitter ......................................................................................................................... 3-8
AEON Rack Decoder .................................................................................................................... 3-14
4. Getting Started .......................................................................................4-16
Power .......................................................................................................................................... 4-16
Access the USB Stick .................................................................................................................. 4-16
Node Finder Application .............................................................................................................. 4-17
AEON Transmitter Web Browser Control...................................................................................... 4-19
Web Browser Control................................................................................................................... 4-20
LCD/OLED Display Control........................................................................................................... 4-20
5. AEON Transmitter Web Browser Operation...............................................5-21
Introduction ................................................................................................................................ 5-21
Unit Status>Overview Tab.......................................................................................................... 5-21
Unit Status>Service Tab............................................................................................................. 5-22
Unit Status>SDI/SFP Tab............................................................................................................ 5-22
Configuration Tab – Apply, Save and Refresh ............................................................................ 5-23

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 0-5
Configuration>Global Tab .......................................................................................................... 5-23
Configuration>Unit Tab.............................................................................................................. 5-30
Configuration>Encoder Tab........................................................................................................ 5-31
Configuration>Audio Tab ........................................................................................................... 5-32
Configuration>Data Tab......................................................................................................... 5-35
Configuration>Streamer......................................................................................................... 5-36
Configuration>Modulator Tab................................................................................................. 5-40
Engineering>Information Tab................................................................................................. 5-45
Engineering>Calibration Tab.................................................................................................. 5-45
Engineering>Uploads ............................................................................................................. 5-46
Engineering>Configs .............................................................................................................. 5-48
6. AEON-MESH Web Browser Operation........................................................6-49
Introduction ................................................................................................................................ 6-49
AEON-MESH with AEON Encoder ................................................................................................. 6-50
AEON-MESH with SDR Dual Encoder ........................................................................................... 6-51
7. AEON Transmitter LCD Display Operation ................................................7-53
Overview ..................................................................................................................................... 7-53
Icons and Controls...................................................................................................................... 7-53
Navigating the Menu .................................................................................................................. 7-54
8. AEON Decoder Operation .........................................................................8-55
Introduction ................................................................................................................................ 8-55
OLED Display............................................................................................................................... 8-55
Menus ......................................................................................................................................... 8-56
Software Upgrades ..................................................................................................................... 8-57
9. Example Applications..............................................................................9-59
Single AEON 4K HEVC System ..................................................................................................... 9-59
MESH Application........................................................................................................................ 9-62
10. Appendix A – Reference Material .......................................................10-65
How to Configure a PC IP Address......................................................................................... 10-65
AEON Transmitter Pinouts..................................................................................................... 10-66
AEON Decoder Pinouts........................................................................................................... 10-69
11. Appendix B – After Sales Support ......................................................11-71
Documentation and Software................................................................................................ 11-71
Contact Technical Support.................................................................................................... 11-71
Using the DTC RMA Service................................................................................................... 11-71
12. Appendix C – Safety and Maintenance...............................................12-73
Cautions and Warnings......................................................................................................... 12-73
Repairs and Alterations ........................................................................................................ 12-74

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 0-6
Caring for your Equipment .................................................................................................... 12-74
Charging ............................................................................................................................... 12-74
Working with Lithium Batteries............................................................................................. 12-75
Cleaning................................................................................................................................ 12-75
Storage.................................................................................................................................. 12-75
13. Appendix D – Glossary .......................................................................13-77

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 1-1
1. Product Overview
Product Family
The subject equipment of this user guide is:
Product Code Product Description
AEON-TX AEON HEVC Transmitter
AEON-DEC AEON 4K Decoder
AEON Transmitter
1.2.1 Description
A compact and feature rich COFDM digital video transmitter, specifically designed for high quality wireless
link applications. With proven Domo COFDM and next generation HEVC encoder technology at its core
enabling Ultra High Definition images the small size and actively cooled enclosure give maximum
operational performance. Designed to offer future proof connectivity, the unit supports native 12G-SDI, dual
6G-SDI, quad 3G-SDI, as well as SFP+ expansion. Two true balanced audio inputs are included with
phantom power. The transmitter has an integrated control panel with sunlight-readable LCD display
covering all major functions and has 16 user-defined presets, as well as IP based control.
The HEVC codec used in AEON products offers a step change in compression efficiency over H.264 systems,
whilst maintaining low end to end latency suitable for live events.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 1-2
1.2.2 Features
Ultra-low latency HEVC SD, HD and 4K encoding
Video formats up to 2160p60, 10-bit and 4:2:2 chroma sampling
Industry standard DVB-T modulation for interoperability with existing systems
Domo Broadcast UMVL modulation for enhanced high frequency/high speed performance
Controlled via IP or integrated sunlight-readable LCD display
Designed for sports and events coverage, newsgathering and wireless studio camera applications
Low power consumption and active cooling for extended field performance
1.2.3 Basic Specifications
Dimensions L 190mm (170mm excluding connectors)
W 115mm, (105mm excluding connectors)
D 55mm (without battery plates) or
D 89mm (with V-Lock plates) or
D 82mm (with Anton Bauer plates)
Weight 1576g
DC Input 9.2 to 17.8V reverse polarity protected
Power consumption Typically 30.0W @ 100mW RF power and 4K video
Temperature range -10°C to +50°C
Note: Detailed technical specifications are provided in the product datasheet. Please see
http://www.domotactical.com/products/wireless-broadcast-solutions/.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 1-3
AEON Decoder
1.3.1 Description
The AEON HEVC Rack Decoder provides low latency HEVC Ultra High Definition decoding from ASI/IP input.
Ideal for adding decode support for the AEON Transmitter to existing receiver systems. Each decoder can
support single 4K or up to two HD streams via quad 3G-SDI outputs and has two stereo balanced audio
outputs available. The decoder has an integrated control panel with sunlight-readable OLED display
covering all major functions, as well as IP based control.
The HEVC codec used in AEON products offers a step change in compression efficiency over H.264 systems,
whilst maintaining low end to end latency suitable for live events.
1.3.2 Features
Ultra-low latency HEVC SD, HD and 4K decoding with tri-level sync genlock
Video formats up to 2160p60, 10-bit and 4:2:2 Chroma sampling, future HDR support
Controlled via IP or integrated sunlight-readable OLED display
Designed for sports and events coverage, newsgathering and wireless studio camera applications
Scalable decoding platform supporting single 4K or two HD services
Low power consumption and active cooling for extended field performance
Compact 1/2 1RU rack form factor
1.3.3 Basic Specifications
Dimensions 180mm (L), 222mm (W), 43mm (W)
Weight 1155g
DC Input 12V to 17V
Power consumption Typically 16.0W with 4K decoding
Temperature range -10°C to +50°
Humidity Less than 85% non-condensing
Note: Detailed technical specifications are given in the product datasheet. Please see
http://www.domotactical.com/products/wireless-broadcast-solutions/.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 2-4
2. Product Package
Overview
Carefully open the packaging and remove the device. Verify that all the components have been included in
the package as shown in the packing list. Inspect the unit for shipping damage.
Note: If you don’t have all the parts or you are not happy with the condition of your delivered product, please
call DTC and we’ll get this solved for you. See Section 11.2 .
Retain the packing list and all the packing materials for storage. The codes mean:
CA – cable assembly
SA – sub assembly
AP – assembly part
The codes are useful for identification and if you need to order a new part at some time.
AEON Transmitter Parts List
Part Number Description
AEON-TX AEON HEVC Transmitter
CA0579 XLR audio input cable
CA3348 AEON-TX UHD BNC to R/A HD-BNC 1855A 250mm cable
SA4075 AEON HEVC support USB stick consisting:
Node Finder application, AEON User Guide
AEON Decoder Parts List
Part Number Description
AEON-DEC AEON HEVC Rack Decoder
CA0512 XLR audio output cable
CA0649 XLR 12V 6.67A 80W desktop PSU
SA4075 AEON HEVC support USB stick consisting:
Node Finder application, AEON User Guide

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 2-5
Accessory Options
If you have purchased these options, they will also be in the package.
Part Number Description
PRORXD-1RU Professional Receiver 1RU
PRORXD-2RU Professional Receiver 2RU
SOL8KF-043 Three button key fob (433.05-434.79MHz)
CA0340 RS-232 data input cable
CA3421 0B Lemo 15V 6.0A 90W desktop PSU
AEON Transmitter Licensing Options
Device licensing is viewable from the web browser software control application. See Section 5.13 .
Part Number Description
Silver (included) DVB-T, Ultra Mobile Video Link (UMVL), Single HD Encoder
Gold Silver plus DVB-T2 (future development)
Platinum Gold plus Single 4K and Quad HD Encoder
AEON-TX-HDUP Additional transmitter HD license
AES128TX AES128 encryption
AES256TX AES256 encryption

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 2-6
AEON Transmitter Variants
2.6.1 Product Code
This part number will be on the AEON-TX label. This will identify which variant has been delivered to you.
Part Number Product Description
AEON-TX-AB-198750D-044 AEON-TX 1.98-2.70GHz, 6.40-7.50GHz, 410-480MHz telemetry, AB-mount
AEON-TX-V-198750D-044 AEON-TX 1.98-2.70GHz, 6.40-7.50GHz, 410-480MHz telemetry, V-mount
AEON-TX-AB-440500-043 AEON-TX 4.40-5.00GHz, 433.05-434.79MHz telemetry, AB-mount
AEON-TX-V-440500-043 AEON-TX 4.40-5.00GHz, 433.05-434.79MHz telemetry, V-mount
2.6.2 Dual Band Frequency Code
Where the COFDM frequency is dual band, the primary frequency will transmit on ports Tx/RX A and Tx/Rx B
and the secondary frequency band will transmit on Tx C only.
For example:
198750 = 1.98-2.70GHz (Tx/RX A and Tx/Rx B) and 6.40-7.50GHz (Tx C only)
Note: This will be configured using the web browser control application, see Section 5.12 .

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 2-7
Labelling
This topic contains information covering labels and markings on your device. The legend and location of
each label or marking will be identified and explained for safety or maintenance significant information.
Figure 2-1 AEON Label
No. Description
1 Product code – this will include the product name, battery mount and variant.
2 Indicates that the unit should be disposed of in accordance with the WEEE Directive.
3 The CE marking certifies that a product has met EU consumer safety, health and environmental
requirements.
4 Barcoded six-digit serial number. This may be required during a support call.
5 Power requirements.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 3-8
3. Connections, Controls and Indicators
Introduction
This chapter will help you identify all the connections and interfaces to help you install and control the
AEON Transmitter or Decoder.
AEON Transmitter
The AEON-TX has several facets which have been given nominal titles; Top Panel, Bottom Panel, Left Panel
(LCD), Right Panel, Camera Mount Plate and Battery Mount Plate.
3.2.1 Top Panel
No. Item Purpose
1 LCD display control knob Knob can be rotated and pushed up, down, left and right to navigate
the LCD display menu.
Left/right moves through the menu levels
Up/down changes the menu selection
Rotate to change a value
Short push to enter a value.
Note: For full details of LCD display operation, refer to Chapter 7 .
2 SMA socket Telemetry antenna connector.
3 LED indicator Power/RF status:
Red = unit has booted up, no RF power
Green = RF output on (TX mode) or in link (Mesh mode)

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 3-9
No. Item Purpose
4 N-type socket COFDM TX only antenna C connector. Read note below.
This port transmits in the secondary frequency band. See Section
2.6.2 .
When transmitting in this band, port C is the only TX output.
5 N-type socket COFDM TX/RX antenna A connector. Read note below.
This port transmits in the primary frequency band. See Section 2.6.2 .
When transmitting in this band and configured as a SOL-TX, this will
be a selectable TX only port.
When configured as a MESH, it can become a TX/RX port.
6 N-type socket COFDM TX/RX antenna B connector. Read note below.
This port transmits in the primary frequency band, 1.98–2.7GHz or
4.4–5GHz or 5.5–6GHz.
When transmitting in this band and configured as a SOL-TX, this will
be a selectable TX only port.
When configured as a MESH, it can become a TX/RX port.
Note: The transmit port selection is achieved by selecting the modulation frequency in the web browser
control application, see Section 5.12 .

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 3-10
3.2.2 Bottom Panel
Note: See Section 10.2 for pinout where relevant.
No. Item Purpose
1 Hirose 10-way jack (pins) Data and power to the camera.
2 Lemo 5-way jack (sockets) Tally light control.
3 Fans Provides cooling for internal components. Take care not to
obstruct.
4 RJ45 jack Ethernet connection for IP control and video streaming.
5 Lemo 4-way jack (sockets) RS-232 data interface.
6 Lemo 5-way jack (sockets) Channel 1 balanced left and right audio input with switchable
48V phantom power.
7 Lemo 5-way jack (sockets) Channel 2 balanced left and right audio input with switchable
48V phantom power.
8 Lemo 4-way jack (sockets) 12V DC input (9.2V – 17.8V).

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 3-11
3.2.3 Right Panel
No. Item Purpose
1 High density BNC
socket x 2
ASI video IN and OUT.
Note: ASI IN can be set up as an SDI input when the AEON Mesh is
configured as an SDR Dual Encoder (see Section 6.3.4 ).
2 3.5mm jack socket x 2 Microphone and headphone audio for talkback.
3 High density BNC
socket x 4
Note: 6G/12G-SDI
inputs are marked by
a circle around the
connector.
SDI video input 1. Supports 12G-SDI (single input), 6G-SDI (dual input)
or 3G-SDI (quad input).
The supplied CA3348 cables will adapt the HD-BNC connectors to BNC.
SDI video input 2. Supports 3G-SDI (quad input).
The supplied CA3348 cables will adapt the HD-BNC connectors to BNC.
SDI video input 3. Supports 12G-SDI(single input), 6G-SDI (dual input)
or 3G-SDI (quad input).
The supplied CA3348 cables will adapt the HD-BNC connectors to BNC.
SDI video input 4. Supports 3G-SDI (quad input).
The supplied CA3348 cables will adapt the HD-BNC connectors to BNC.
4 USB jack USB host or peripheral device connection.
See Section 5.6 for supported Wi-Fi and 4G dongles.
5 SFP+ jack Can be used for a single 12G-SDI or dual 6G-SDI input.
Note: This will override SDI input 1 or 3 when using 12G-SDI. One
channel may be used in conjunction with SDI input 1 or 3 when using
6G-SDI as a dual input.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 3-12
No. Item Purpose
6 D-tap supply This terminal can tap up to 50W of power from the battery for auxiliary
use.
3.2.4 Left Panel (LCD)
Note: For full details of LCD display operation, refer to Chapter 7 .
No. Item Purpose
1 LCD display A sunlight-readable LCD display covering all major functions.
2 LCD display control knob Use this knob to navigate the LCD display menu.

Revision 2.1
AEON Transmitter and Decoder User Guide
Copyright © 2018 Domo Tactical Communications (DTC) Limited. All rights reserved.
Commercial in Confidence
Page 3-13
3.2.5 Camera Mount Plate
The AEON-TX camera mount plate will assemble the AEON-TX to the camera. The AEON-TX will have either
an AB or V mount option.
Figure 3-1 AB Camera Mount (left) and V Camera Mount (right)
3.2.6 Battery Mount Plate
The AEON-TX battery mount plate will assemble the battery to the AEON-TX. The AEON-TX will have either AB
or V mount option.
Figure 3-2 AB Battery Mount (left) and V Battery Mount (right)
