DTC VBS2-250 User manual

DTC COMMUNICATIONS INCORPORATED PN OP1920256 REV6
VBS2-250 Frequency 2200-2300 MHz
VBS-250 Frequency 2400-2500 MHz
VBL-250 Frequency 1700-1850 MHz
1/4 W1/4 W
1/4 W1/4 W
1/4 Watt, Body Watt, Body W
att, Body Watt, Body W
att, Body Wornorn
ornorn
orn
VV
VV
Video Tideo T
ideo Tideo T
ideo Transmitterransmitter
ransmitterransmitter
ransmitter
ManualManual
ManualManual
Manual

DTC COMMUNICATIONS, INC.
2
How to contact DTC
For operator and troubleshooting
information, customers are encouraged to refer to
the details in this manual. For additional clarification
or instruction, or to order parts, contact DTC.
Customer Service is available Monday through
Friday between the hours of 9:00 AM and 5:00 PM
EST at:
Tel: [phone]
Fax: [phone]
Website: www.dtccom.com
Email: [email protected]
486 Amherst Street
Nashua, New Hampshire 03063
USA
Copyright Notice
Copyright © 2002
DTC Communications, Inc. All rights
reserved. No part of this document may be
reproduced, transmitted, transcribed, stored in a re-
trieval system or translated into any
language or computer language, in any form or by
any means, including but not limited to electronic,
magnetic, mechanical, optical, chemical, manual or
otherwise, without the prior written permission of DTC
Communications, Inc.
Disclaimer
The information in the document is subject to change
without notice. DTC makes no representations or war-
ranties with respect to the contents hereof, and spe-
cifically disclaims any implied warranties of merchant-
ability or fitness for a particular purpose. DTC reserves
the right to revise this publication and to make changes
from time to time in the content hereof without obliga-
tion of DTC to notify any person of such revision or
changes.
Trademarks
Trademarks of DTC Communications, Inc. include:
• DTC
• MiniPIX®
• DynaPIX®
Other product names used in this manual are the prop-
erties of their respective owners.
Warranty
DTC warrants its manufactured components against
defects in material and workmanship for a period of
two (2) years, commencing on the date of original pur-
chase.
Products manufactured by others that are approved
for use with DTC equipment are warranted for the
manufacturer’s warranty period, commencing from the
date of shipment from DTC.
FCC information
The following information is provided as a
service to our law enforcement customers who
require a Part 90 station license for video
surveillance operations using the 2450 to 2483.5 MHz
band.
You will need to provide:
• Form 600 (the application form)
Forms can be obtained from the FCC on their web-
site at:
www.fcc.gov
You can also contact the FCC using their FAX back
service at: [phone]
Additional instructions are available by telephone at:
[phone]
The filing fee form is returned to:
Federal Communications Commission
1270 Fairfield Road
Gettysburg, PA 17325-7245

DTC COMMUNICATIONS, INC. 3
Manual Conventions
NOTE Describes special issues you should be aware of
while using a particular function.
WARNING Calls out situations in which equipment
could be damaged or a process could be incorrectly
implemented, but in which operator safety is not a
factor.
TIP Describes application hints.
TABLE OF CONTENTS
RF EXPOSURE STATEMENT
When used as directed, the maximum SAR of this device is
2.7 W/kg, which meets the limits set forth by the FCC. Refer
to Appendix A in this manual for instruction in the proper use
of antennas with this device.
Quick Start ........................................................................... 4
Overview .............................................................................. 5
Features ............................................................................... 6
Specifications ....................................................................... 7
Battery Drain ........................................................................ 9
Connectors ......................................................................... 10
Connections ........................................................................11
Equipment Configurations ................................................. 13
Optional Accessories ........................................................ 14
Programming ..................................................................... 22
Appendix A ......................................................................... 26
FCC ID# H25VXS250

DTC COMMUNICATIONS, INC.
4
QUICK START GUIDE
1Make sure that the ON/OFF switch is set to OFF. (Red dot is OFF).
2Install 4 “AA” batteries in the internal battery compartment of the module.
(Lithium batteries are recommended)
3Using a screwdriver, turn the channel selector to the correct transmission
channel number.
4Connect an antenna to the ANTENNA connector on the module.
5Connect the microphone or microphones to the MIC-1 and MIC-2 connectors
on the module.
6Connect a video source to the Video/Multi I/O connector.
7Slide the power switch to the ON position (Green dot is ON) to apply power to
the transmitter.
Note: While installing the batteries, observe proper polarity as printed in the
battery compartment. Reverse polarity protection is a built-in design feature of
the transmitter. If a battery is installed backwards, this feature prevents the
transmitter from powering up, without damaging the transmitter or battery.
Warning: Do not apply power to the transmitter until an antenna has been
connected in step 4.
Warning: Refer to Appendix A of this manual for information on the proper
use of antennas.
5
7 1
46
3
2

DTC COMMUNICATIONS, INC. 5
OVERVIEW
What should you expect to receive with your 250mW
Transmitter?
1VBS/VBL Video Transmitter
1Dipole antenna with right angle SMA connector
1One Video and Power In “Y” cable
1DTC programming software package
1DTC programming cable
8Batteries
NOTE: The dipole antenna included is not recommended for normal
use! This antenna enables you to quickly set up your transmitter
and ensure proper operation. DTC highly recommends the use of
circularly polarized antennas for the best rejection of multi-path.
NOTE: DTC has provided you with a “Y” cable (power and video)
terminated with an RCA connector and a BNC adapter for your
convenience.)
The VBL/VBS series video transmitters from DTC represent the first true “video body wires” available. DTC has developed a
fully user programmable video transmitter and mated it with an integral AA battery pack. This dramatically simplifies wiring,
lowers the risk of detection, and increases the chances of operational success.
For best results, DTC recommends the use of its VidiWIRE on body dual patch antenna system with phase matching module,
and a DTC diversity receiver.
Users should also consider using the VBL/VBS series transmitters for rapid deployment drop cameras. Packaging the
transmitters with miniature board cameras is exceptionally easy, and in the case of 5 volt cameras, power may be provided to
the camera directly from the VBL/VBS transmitter’s internal battery pack.
This product in only available for sale to legitimate state, local, federal and friendly foreign government agencies.

DTC COMMUNICATIONS, INC.
6
FEATURES
Feature Description
Remote Switching Capability
External Power Loop Through
Programmable
Audio
Efficient Switching Power Supply
Camera Power Available through
Multi I/O Connector
•You may turn the device ON remotely, by attaching a switch to one
of the pins on the Multi I/O connector. DTC provides hard-wired and wireless
switches for this application.
• The power applied to the Multi I/O pin is automatically looped through the
unit, and available on a second pin to power a remote device, such as a
camera. If you apply 9 Volts in, you will get 9 Volts out. Applying power through
the multi I/O connector automatically disables the internal AA battery pack.
WARNING: Make sure your camera will operate on the voltage being supplied
to the transmitter.
User programmable video channels, selectable in 250 kHz steps. Two user
programmable audio sub carriers, selectable in 10 kHz steps from 6 MHz to
7.5 MHz.
• Audio sub carriers are OFF unless microphones are attached. The
transmitter automatically senses when a microphone has been attached.
• The audio sub carriers are phase locked, and will not drift into the video
signal.
• Automatic Gain Control is provided on each audio input, amplifying soft
sounds.
• They generate far less heat than a traditional video transmitters.
• They operate significantly longer than traditional video transmitters on the
same power source.
• When powering the device using the internal battery pack, regulated 5 VDC is
available on the multi I/O connector, limited to 200 mA current drain.

DTC COMMUNICATIONS, INC. 7
SPECIFICATIONS
Specifications for the body worn VBS/VBL-250
Power Supply Internal batteries 4 “AA” batteries or external 9-16 VDC.
Power Consumption 2.5 Watts (not including camera)
Battery life 3 hours - Alkaline AA
Reverse polarity
protection Yes
Dimensions 2.5 x 4.5 x 0.675”
Camera Power Using external power input: Same as supply voltage,
switched (200 mA max)
Using internal batteries: 5 VDC @ 175 mA, switched
(internal regulator)
Controls 10 channel select rotary switch
Panel mounted, slide ON/OFF switch
Connectors 2 pin Lemo: Mic 1
2 pin Lemo: Mic 2
SMA: Antenna
6 pin Multi I/O: Video in, Data in, DC input 9 -16 VDC,
camera power, Remote ON/OFF, Multiplexed Data out,
Ground
Programmability Video: 2400 - 2500 MHz (VBS-250)
1700 - 1850 MHz (VBL-250)
250 KHz resolution steps
Audio: User programmable from 6.0 - 7.5 MHz, in
10 kHz steps
Chassis notes Machined solid aluminum with rounded edges.
Audio
General Mic level input (line level factory opt.) 50 - 3000 Hz
Phased locked with AGC on both inputs. Sub-carrier auto
sensing, only active when microphone is attached.
Number of sub-carriers 2
Sub-carriers frequencies 6.0 - 7.5 MHz , user programmable
Four lithium “AA” batteries
FRONT PATCH
ANTENNA
BACK PATCH
ANTENNA
SPLITTER
CAMERA
MICROPHONES
TRANSMITTER

DTC COMMUNICATIONS, INC.
8
SPECIFICATIONS Sub-carrier ON/OFF
control Subcarriers are activated when mic is connected.
Subcarrier frequency
stability +/- 0.003%, -30°C to +70°C
Sub-Carrier Deviation 50 kHz peak
Audio S/N 45 dB min.
Frequency Response BW1.5dB = 50 - 3000 Hz
Total Harmonic Distortion <2%
Input Level 8 mVpp @ 400 Hz for 50 kHz peak dev.
Pre-Emphasis 75 uS
Input Impedance 10 k Ohm
Video
Video Frequency
Response BW1.5dB = 6 Hz - 5.0 MHz
Input Impedance 75 Ohms
Input Level 1Vp-p Max.
S/N 60 dB min.
Pre-Emphasis Per CCIR 405 525 line curve
Differential Gain 5%
RF
Operating Frequency 1700 - 1850 MHz, 250 KHz resolution steps
2400 - 2500 MHz, 250 KHz resolution steps
Power output 250 mW min. @ nominal supply voltage, 25 Deg. C.
-3 dB @ 3.6 VDC int
-2 dB over temp.
Output Impedance 50 Ohms
Spurs and Harmonics
output -50 dBc
Load Pull Stability 8:1 VSWR

DTC COMMUNICATIONS, INC. 9
Frequency Stability +/- 0.003%, -30°C to +50°C
Modulation Sensitivity 8 MHz/V nom.
Modulation Sensitivity
Variation +/- 5% across the band
Peak Carrier Deviation 4 MHz nom.
Number of channels 10 max. (user programmable)
Sub-carrier sideband
level -28 dBc, +/- 2 dB
Environmental
Temperature Range -30°C - +70°C
Humidity 90% (non-condensing)
SPECIFICATIONS
Four lithium batteries
Transmitter & Camera
Battery Type Part Number Transmitter Only Camera 9V@153mA Camera 12V@120mA
9 AA Alkaline Pack 4045131 6 hours 3.3 hours 3.6 hours
(External)
9 AA Lithium 4045132 9 hours 5 hours 5.5 hours
(External)
9 AA NiMH 4045130 7 hours 4 hours 4.3 hours
Rechargeable
(External)
4 AA
(Internal)
4 AA Lithium
(Internal

DTC COMMUNICATIONS, INC.
10
MICROPHONE CONNECTORS
Two connectors accommodate two microphone inputs. Each connector has two
contacts and provides power to the microphone as well as connecting the audio
signal into the transmitter. The audio sub-carriers are activated by the presence of the
microphone. If a microphone is removed, that sub-carrier is removed from the
transmit signal. Turning off the unused sub-carrier saves power and improves picture
quality.
CONNECTORS
Microphone Connectors
Lemo Male Part # (FFS.01.250.DLAE31)
DTC Male Part # (8570003)
Hirose Part # HR10A-7P-6P (02)
DTC Part # 954020
Standard Male SMA connector
MATING CONNECTORS

DTC COMMUNICATIONS, INC. 11
ANTENNAS
A standard SMA connector is used as the antenna connector on both the VBS/VBL-
250. Refer to a list of DTC antennas available beginning on page 18.
TIP: You may use the VBS/VBL series transmitters with other manufacturers
antennas. Verify that they are suited for the band you are operating in.
WARNING: Refer to Appendix A of this manual for information on the proper use
of antennas.
CHASSIS MOUNTED POWER ON/OFF SWITCH
A slide switch is provided for local control of power ON and OFF. Green dot is ON,
Red dot is OFF.
NOTE: REMOTE ON overrides the chassis mounted OFF switch. (i.e. When the
chassis mounted power switch is set to OFF, REMOTE ON can be used to turn
the transmitter ON.)
CHANNEL SELECT SWITCH
Select a transmission channel by using the rotary switch located on the front surface of
the transmitter. Use a screwdriver to rotate the switch to the desired channel number.
MULTI I/O CONNECTOR
The multi I/O (6-pin Multi I/O) connector is mainly used as the video and external
power input connector. It also provides access to many transmitter functions, such as:
• Programming the device
• Video in
• Power in
• Remote on
• Camera power
CONNECTIONS
On/OFF
Switch
Antenna Connector
Channel Select
Multi I/O Connector
NOTE: Same as supply voltage. Do
not exceed 200mA.
Pin 3: Camera
Power Output
Pin 1: Ground
Pin 2: Ext power
input 9-16VDC
Pin 6: Video in
Pin 5: RS-232 in
Pin 4: Remote on,
switched to ground

DTC COMMUNICATIONS, INC.
12
EXTERNAL CAMERA POWER
TRANSMITTER
SPLITTER
CAMERA
FRONT PATCH
ANTENNA
BACK PATCH
ANTENNA
MICROPHONE
MICROPHONE
+
-
The basic VBS/VBL-250 configuration
consists of the video transmitter, Vidi-Wire
Antenna, and DTC cable part number
4045170-024. This cable is connected to the
multi I/O port of the transmitter, and is
configured to supply:
• The video signal from the camera to the
transmitter.
• Power to the transmitter through the
internal battery pack.
NOTE: You will need external camera
power if voltage to the transmitter is not
compatible with your camera’s operating
voltage, and/or you need greater battery
life, and/or your camera draws more than
200mA.

DTC COMMUNICATIONS, INC. 13
The basic VBS/VBL-250 configuration consists
of the video transmitter, Vidi-Wire Antenna, and
DTC cable part number 4045194-024. This
cable is connected to the multi I/O port of the
transmitter, and is configured to supply:
• The video signal from the camera to the
transmitter.
• Power to the transmitter and camera
through the internal battery pack.
FRONT PATCH
ANTENNA
BACK PATCH
ANTENNA
SPLITTER
CAMERA
MICROPHONES
TRANSMITTER
TRANSMITTER AND CAMERA (INT)

DTC COMMUNICATIONS, INC.
14
EXTERNAL TRANSMITTER POWER The VMS/VML-250 configuration, which uses
the loop through power source for the camera,
consists of the video transmitter and DTC cable
part number 4045189-024 . This cable is
connected to the multi I/O port of the transmit-
ter.
It is configured to supply:
• The video signal to the transmitter
from the camera.
• Power to the transmitter through a
molex connector that can be easily
connected to DTC’s battery packs.
• Power to the camera through a
molex connector that can easily be
connected to DTC’s optional
cameras.
CAMERA
ANTENNA
POWER SOURCE
for transmitter only,
9-16 V.
STRIPPED AND
TINNED LEADS
STANDARD
A
B
C
OPTIONAL
BATTERY
PACKS
TRANSMITTE
R
A4045131 (AA non-rechargeable)
B4045177( D-Cell battery pack)
Alkaline
C4045130 (AA rechargeable)
MiMH

DTC COMMUNICATIONS, INC. 15
NOTE: You will need external camera power if
voltage to the transmitter is not compatible
with camera’s operating voltage, and/or you
need greater battery life, and/or your camera
draws more than 200mA.
This configuration consists of the video transmitter,
Vidi-Wire antenna, and DTC cable part number
4045192-024. This cable is connected to the multi/
IO port of the transmitter, and is configured to
supply:
• The video signal from the camera to the
transmitter.
• Power to the transmitter and camera through
the internal battery pack.
• Remote on function through a hard wired
switch or remote Key FOB transmitter. This
remote on function overrides the OFF switch
located on the transmitter chassis.
ADDING REMOTE ON FUNCTION TO BASIC
FRONT PATCH
ANTENNA
BACK PATCH
ANTENNA
SPLITTER
CAMERA
MICROPHONES
TRANSMITTER
HARD WIRED
SWITCH
KEY FOB
SWITCH
RECEIVER
KEY FOB
SWITCH
TRANSMITTER
STRIPPED AND
TINNED LEADS
STANDARD

DTC COMMUNICATIONS, INC.
16
ACCESSORIES Part Number Description
1088185 Vidi Vest™
The VidiVest™ is designed to be used in conjunction with
DTC’s body worn video transmitter. The vest supplies
compartments for the video transmitter, associated wiring,
antenna system (i.e. VidiWire™), microphones, and a button
camera. The garment is ventilated for comfort and can be
adjusted with velcro straps at the waist and shoulders. The
vest is intended to be worn as an undergarment with a loose
fitting shirt or other garment over the vest.
4045181 Camera with 3-pin connector
Assembly
This camera is a high-resolution color CCD type, which has
been modified to look like a shirt button. This allows for easy
concealment through a regular button hole.
4045192-024 VidiVest cable harness
This cable harness connects all of the components, such as,
the transmitter, battery packs, microphones, and VidiWire
antenna system.

DTC COMMUNICATIONS, INC. 17
Part Number Description
VW-ANT-2-SMA VidiWire antenna system 2.4-2.5 GHz
VW-ANT-1-SMA VidiWire antenna system 1.7-1.9 GHz
The VidiWire™ antenna system was specifically designed for video transmission
from on-body transmitters. This DTC Proprietary system provides the best
possible omnidirectional video transmission from a body-worn system. The
system is composed of three parts: two special patch-type antennas, and a
phasing module.
WARNING: VidiWire Antennas are housed in a milled aluminum cover which
shields the wearer from RF energy. Make sure the antennas radiating side is
directed away from the body.
WARNING: Do not use the VidiWire antenna system on the body with any
transmitter outputting more than 250mW of RF energy.
COMPONENTS
WARNING: Refer to Appendix A of this manual for information on the proper
use of antennas.
Specifications
Type DTC proprietary
VidiWire™ design
Polarization Dual Polarized
Peak Gain Pseudo-Isotropic
Horizontal Beamwidth Omnidirectional
Vertical Beamwidth Omnidirectional
Nominal Impedance 50 Ohms
Groundplane Requirements Not applicable
Size Antennas: 2.0” W x 2.0” H x 0.25” D
(51 mm x 51 mm x 6.35 mm)
Phasing Unit 2.0” W x 1.5” H x 0.25” D
(51mm x 38mm x 6.35mm)
Net Weight 6oz
VW-ANT-2-SMA 2.4 to 2.5 GHz SMA male connector
VW-ANT-2-TNC 2.4 to 2.5 GHz TNC male connector
VW-ANT-1-SMA 1.7 to 1.9 GHz SMA male connector

DTC COMMUNICATIONS, INC.
18
ACCESSORIES Part Number Description
4045170-024 Video In, 24”standard.
Video In: Multi I/O to RCA(M) with BNC
adaptor. (YELLOW)
4045193-024 Video In/Remote On, 24”standard.
Video In: Multi I/O to RCA(M) with BNC
adaptor. (YELLOW)
Remote On: 24 AWG wire with a molex
connector and stripped and tinned leads. (GREEN)
4045189-024 Video In/EXT Power/Camera Power cable, 24”standard.
Video In: Multi I/O to RCA(M) with BNC
adaptor. (YELLOW)
Ext. Power: 24 AWG wire with a molex connector
and stripped and tinned leads. (RED)
Camera Power:24 AWG wire with a molex
connector and stripped and tinned leads.(GRAY)

DTC COMMUNICATIONS, INC. 19
ACCESSORIES
Part Number Description
4045194-024 Video In/Camera Power, 24”standard.
Video In: Multi I/O to RCA(M) with BNC
adaptor. (YELLOW)
Camera Power: 24 AWG wire with a molex
connector and stripped and tinned leads. (GRAY)
4045192-024 Video In/Camera Power/Remote On, 24”standard.
Video In: Multi I/O to RCA(M) with BNC
adaptor. (YELLOW)
Camera Power: 24 AWG wire with a molex
connector and stripped and tinned leads.(GRAY)
Remote On: 24 AWG wire with a molex
connector and stripped and tinned leads. (GREEN)

DTC COMMUNICATIONS, INC.
20
ANTENNAS Part Number Description
VDAR-1 Single 5 dBic “Hybrid-Patch”™ Antenna with mounting
options.
Connector: TNC Female on chassis
The VDAR video antennas are designed to operate with traditional single video
receivers and multiple antenna configurations for diversity receivers. The antenna
uses the DTC Hybrid-Patch system to ensure high purity circular polarization. This
ensures the highest possible performance in video reception, especially in
diversity systems. It is available in three different bands. Reversible and adjust-
able suction cup mounts come standard for quick and easy installation on the
inside or outside of window or other hard, smooth surfaces.
VDAR-1
Specifications
Type Three Hybrid Patch™
elements
Polarization RHCP
Peak Gain 5dBic
Horizontal Beamwidth 90°
Vertical Beamwidth 90°
Nominal Impedance 50 Ohms
Groundplane Req. Built-in
Size 6.6” H x 6.6” W
(167mm x 167 mm)
Weight 12 Oz. (34g)
DTC Part Number Frequency Range
7011156-1 1700 to 1850 MHz
7011156-3 1990 to 2110 MHz
7011156-2 2400 to 2500 MHz WARNING: Refer to Appendix A of this manual for information on the proper
use of antennas.
