DT-RDX-V2
Firmware update manual
DTRONICS
DT-RDX-V2
MANUAL
INTRODUCTION
The DT-RDX-V2 is equipped with bootloader functionality. This is a
piece of software that can be used to update the software inside the
DT-RDX-V2.
With this technology you are able to update your DT-RDX-V2 to the
latest firmware version.
DTRONICS
DT-RDX-V2
MANUAL
Index
INTRODUCTION...................................................................................2
Document revisions ............................................................................4
Software revisions...............................................................................4
1Firmware Update...............................................................................5
What do you need...............................................................................5
Current Firmware version DT-RDX-V2.................................................6
How does it work. ...............................................................................7
DTRONICS
DT-RDX-V2
MANUAL
Document revisions
Date
Version
Change
18-10-2023 R10 Initial document
15-12-2023 R11
Added V2 image and changed minor
things.
Software revisions
Date
Version
Change
18-10-2023 R21 Initial release
15-12-2023
R22
Optimized software, fixed MIDI-IN bug
DTRONICS
DT-RDX-V2
MANUAL
Current Firmware version DT-RDX-V2
The firmware version of the DT-RDX-V2 is shown
while powering up the DT-RDX-V2. The right 8 LEDS
indicate the firmware version on power up. This
image shows version 1.2
DTRONICS
DT-RDX-V2
MANUAL
How does it work.
Updating the DT-RDX-V2 is done by sending the new firmware file to
the DT-RDX-V2 in System Exclusive format (or simply SysEx).
Updating steps:
-Download the latest firmware version from our website.
-Install a midi program that has SysEx support in this manual we
are using MIDI-OX
-Connect the MIDI IN from the DT-RDX-V2 with the MIDI OUT from
the computer running the MIDI software
-HOLD OPSEL 3 switch (button 5, see figure 1)
while turning on the DT-RDX-V2. OPSEL 3 will
go on. Now you can release the button. The DT-
RDX-V2 is now in bootloader mode.
-Open MIDI-OX and select the right midi output
device that you are using. Menu Options -> MIDI Devices
-Do NOT connect the midi out of the programmer.
DTRONICS
DT-RDX-V2
MANUAL
-In the MIDI Devices menu check if the MIDI output device is right
DTRONICS
DT-RDX-V2
MANUAL
-
-Navigate to menu View -> SysEx
-The SysEx menu will open.
DTRONICS
DT-RDX-V2
MANUAL
-
-
-Navigate to Sysex > Configure
Set delay between buffers and delay after f7 to 100
make sure the box before "delay after F7" is checked.
DTRONICS
DT-RDX-V2
MANUAL
-Click on File and select the option Send Sysex File.
-Select the downloaded firmware file and press OK. Uploading the
file will take a few minutes.
-After completion, the DT-RDX-V2 will reset and start up and the
LED’s will shown the new firmware version.
Any questions please let us know.
