2- IMPORTANT SAFETY INFORMATION
2.1 Fire prevention:
XR-LASER GREEN is fitted with a 300 mW DSPP green color laser
-Minimum distance from flammable materials: 1 MT.
-Minimum distance from the closest illuminable surface: 2 MT.
-Replace any blown or damaged fuses only with those of identical value. Refer to the wiring diagram if
there is any doubt.
-Connect the projector to mains power via a thermal magnetic circuit breaker.
2.2 Prevention of electric shock:
-High voltage is present inside the unit. Unplug the unit prior to performing any function which involves
touching the inside of the moving head.
-The level of technology inherent in the XR-LASER GREEN requires the assistance of specialised
personnel for all servicing.Please refer to an authorised DTS service centre.
-A good earth connection is essential for proper functioning of the projector.
-Never connect the unit without proper earth connection.
-The fixture should be located in places with a good air ventilation.
2.3 Protection against direct exposure to laser beam:
-NO PERSON OTHER THAN A THROUGLY TRAINED OPERATOR SHOULD BE ALLOWED TO
USE THE LASER UNIT OR DIRECT OR MANIPULATE THE OUTPUT BEAM.
-Never turn on the unit if any of the lenses, filters or ABS covering is damaged. Their respective
shielding functions will only operate efficiently if they are in perfect working order.
-
.
Class 3B laser
Lasers in this category can cause permanent
eye damage with exposures of 1/100th of a second or less depending on the strength of the
laser.D
In an environment
with potential exposure to laser beams, suitable eye protection is recommended for beams
of Class 3B and Class 4.
A laser is an electronic-optical device that emits coherent light radiation,in a narrow, low-divergence
monochromatic beam with a well-defined wavelength. In this respect, laser light is in sharp contrast with
such light sources as the incandescent light bulb, which emits light over a wide area and over a wide
spectrum of wavelengths.
A Class 3B laser is hazardous if the eye is exposed directly.
iffuse reflections such as from paper or other matte surfaces are not harmful.Protective eyewear
is typically required where direct viewing of a class 3B laser beam may occur.
Protective eyewear in the form of spectacles or goggles with appropriately filtering optics can protect the
eyes from the reflected or scattered laser light with a hazardous beam power, as well as from direct
exposure to a laser beam. Eyewear must be selected for the specific type of laser, to block or attenuate
in the appropriate wavelength range.In addition to an optical density sufficient to reduce beam power to
below the maximum permissible exposure, laser eyewear used where direct beam exposure is possible
should be able to withstand a direct hit from the laser beam without breaking.
In the U.S., guidance for the use of protective eyewear, and other elements of
safe laser use, is given in the ANSI Z136 series of standards. In the European Community, eye
protection requirements are specified in European norm EN 207.
LASER RADIATION
LASER RADIATION
AVOID EXPOSURE TO THE BEAM
CLASS 3B LASER PRODUCT
XR-LASER GREEN
