4- TECHNICAL FEATURES
The XR300 BEAM is a new compact moving head with an extremely high light power, projecting a
parallel and very concentrated beam.
With its new optical unit, the XR300 BEAM generates 135.000 Lux at 5 metres, using only a 300 W
lamp, giving an exceptional balance between performance and power consumption.
The XR300 BEAM is designed for a wide range of professional applications, like concerts, shows, tours,
television, theatre, and big events. XR300 BEAM ensures in fact great flexibility in use, because in a
single projector it incorporates a range of functions normally available only on different units (long-throw
projectors with high-power lamps, PAR 64 ACL, moving heads).
The XR300 BEAM features a breakthrough in moving-head technology, dubbed Free Axis Rotation
("FAR"). The FAR system allows limitless pan and tilt rotation: the XR300 BEAM head rotates freely on
its axes, horizontally or vertically, without interruption, in either direction, never having to reverse motion.
The XR300 BEAM's ability to quickly and precisely select any point within its limitless sphere of
movement means faster looks and scene changes.
The XR300 BEAM also offers unmatched creative control to the lighting designer. Unique geometrical
designs, shapes, and scenes, unobtainable with conventional moving heads, are now possible for
application in concerts, theatres, studios, etc.
The FAR system is guaranteed and has been thoroughly tested.
The XR300 BEAM offers:
* Exceptional light power (135.000 Lux at 5 metres);
* The capacity to project a highly condensed and intense beam of light even over great distances, thanks
to the high efficiency of the new optical group;
* Variety of colours (CMY synthesis + 7-colour wheel + CTO);
* Customizable gobo wheel (7 rotating gobos);
* Insertable frost filter (soft edge);
* Unlimited Pan and Tilt movements (new FAR technology).
The XR300 BEAM is also the ideal light for a vast range of applications in which quiet operation is a
priority, thanks to its silent ventilation system and silent pan/tilt operation.
Access to every feature of the internal menu is simple and direct, thanks to the new user interface
featuring a LCD backlit graphic display (128 x 64).
XR300 BEAM FAR E.B.
(Cod. 03.MB002.EB.LF)
• FAR system • CMY • Electronic ballast
XR300 BEAM FAR
(Cod. 03.MB002.LF)
• FAR system • CMY • Electromagnetic ballast
XR300 BEAM E.B.
(Cod. 03.MB002.EB.L)
• CMY • Electronic ballast
XR300 BEAM BF
(Cod. 03.MB003.L)
• Electromagnetic ballast
Lamp
Optical group
135.000 Lux at 5 m (6° beam angle)
Fresnel lens (Ø 195 mm)
Dichroic glass reflector
Dimmer / shutter / strobo
Linear dimmer
Shutter
Strobe from 0,85 flash/sec to 10 flash/sec
Philips MSD Gold 300/2 Mini FastFit (300W / 22.000 Lumens)
Automatic switching on of lamp in case of accidental switching off
Lamp on/off via DMX; reset via DMX
5XR300 BEAM
