DTY X7 Series User manual

1
X7 Series
（H.264 AHD MDVR）
User manual
X7（2015.08.21 Version）
This manual applicable for X7 series, Please read it carefully before using the products!

H.264 AHD 4CH MOBILE DVR X7 Series User manual
2
Index
CHAPTER 1: Product introduction....................................................................................................... 3
1. Attentions before use.............................................................................................................. 3
2. Product Overview.................................................................................................................... 3
3. Main features.......................................................................................................................... 3
4. Contents of package................................................................................................................ 4
5. Product development stages.................................................................................................. 5
6. Application scope.................................................................................................................... 5
CHAPTER 2:Device installations.......................................................................................................... 7
1. Specifications...........................................................................................................................7
2. Connection instructions.......................................................................................................... 8
2.1. Connection diagram..................................................................................................... 8
2.2.Start up control mode................................................................................................... 9
2.3. Attentions..................................................................................................................... 9
3.Interface explanation............................................................................................................. 10
3.1. Interfaces....................................................................................................................10
3.2. IR remote control....................................................................................................... 11
3.3. Status indicators......................................................................................................... 12
3.4. Storage devices installation....................................................................................... 12
3.5. Memory occupancy calculation................................................................................. 13
3.6. Main frame installation..............................................................................................13
CHAPTER 3: System Menu.................................................................................................................15
1. Preview interface...................................................................................................................15
2. Menu introduction................................................................................................................ 16
3.Video Playback........................................................................................................................17
4. Menu setup........................................................................................................................... 18
4.1. Record Settings...........................................................................................................19
4.2. Color Settings:............................................................................................................ 19
4.3. Date and time.............................................................................................................20
4.4. Car License Number setup......................................................................................... 20
4.5. GPS set up.................................................................................................................. 21
4.6. Operation mode......................................................................................................... 21
4.7. Alarm in&Alarm out................................................................................................... 22
4.8. Channel titles..............................................................................................................22
4.9. Languages...................................................................................................................23
4.10. 3G/4G Network..................................................................................................... 23
4.11. Data Back up.............................................................................................................24
4.12. Factory settings........................................................................................................ 24
4.13. Format storage device..............................................................................................26
4.14. Firmware upgrade.................................................................................................... 27
CHAPTER 4: Windows Based Playback Software.............................................................................. 28
1. Software introduction:.......................................................................................................... 28
Appendix: SD Card low level formatting instructions....................................................................... 32

H.264 AHD 4CH MOBILE DVR X7 Series User manual
3
CHAPTER 1: Product introduction
1. Attentions before use
1.1. Before powering on the DVR, please connect all the external devices correctly.
1.2. Please disconnect or re-install all the external devices after power is off
1.3. Please remove or re-install the storage devices after power is off
1.4. Do not touch the metal parts of the SD Cards with hands.
1.5. Keep the unit away from water or other liquid, to avoid shortcut occurs.
1.6. To ensure the DVR works properly, please do not press two or more keys simultaneously.
1.7. Please make sure the DVR works under the range of rated voltage and rated current.
1.8. Please do not assemble, maintain, upgrade or replace the components without permission
1.9. As a professional equipment, regular maintenance to cable connection and storage device,
fan dust removal and work environment testing are necessary.
2. Product Overview
X7 Series product is a h.264 compression based, new generation high performance, low
consumption 4ch AHD(Analog High Definition), 720P full real time(PAL ：25FPS/NTSC ：30FPS)
mobile surveillance DVR, supports IR remote operation mode, Supports 4TB high capacity SATA
HDD and 128GB high speed SD/SDHC as storage devices, Supports extensible GPS option.
X7 Series support GPS function, Users can read longitude, latitude, moving speed and moving
path of vehicles on google map when playback the videos on PC.
X7 Series support 4.3 inch high definition LCD, which is useful for system set up and maintenance.
X7 Series can compatible with any AHD_M standard PAL/NTSC cameras.
3. Main features
3.1. Real time surveillance
DVR equipped with the standard VGA port& analog AV-OUT Port (named CVBS signal port), can
connect the external larger screen to realize real time monitoring.
3.2. Compression technology
DVR adopts advanced H.264 (Main Profile Level 5.0) video compression technology, each
channel"s video and audio adopts independent hardware real time compression technology,
make sure that the audio and video saved synchronously, and reduce the occupation of the
storage space. It saves above 2/3 memory space compare to the MPEG-4 compression
technology.
3.3. Safety storage
DVR supports 4TB high capacity SATA interface HDD and 128GB high capacity high speed SD Card,
Videos adopts professional encryption format, Users can not modify the data privately to ensure
the authenticity and safety.

H.264 AHD 4CH MOBILE DVR X7 Series User manual
4
3.3. Video Playback
Supports real time local playback function for all channels, and supports files search, events
search, single channel playback, multiple channels playback, Videos could be played back with
the equipped software, the software can upload google map and show the GPS data and moving
path on google maps.
3.4. Data Back Up.
Users can back up videos via USB 2.0 port, the back up device could be USB flash drive,
removable HDD, USB-DVDRW. Meanwhile, the equipped player also support the video back up
from the storage devices SD Card or HDD.
3.5. Characteristic Design:
DVR adopts 8 groups of power supply system and unique cooling system design to ensure the
whole system operates stably with high efficiency, device adopts modularized design philosophy,
make user can freely choose optional functions such as GPS, LCD. DVR adopts aviation port and
related aviation port extension cables. DVR will supply power for cameras through the aviation
cables. It adopts whole aluminum alloy clam shell design, with anti-theft lock to protect the HDD,
SD Card, LCD, and SIM Card in the DVR.
4. Contents of package
1. Standard accessories
Serial
No.
Descriptions
Serial
No.
Descriptions
1
One DVR
5
One IR remote control
2
One AV cable
6
Two keys
3
One Power cable with fuse
7
One printed user manual
4
One combined alarm and control
cable
8
One set of anti-vibration kit

H.264 AHD 4CH MOBILE DVR X7 Series User manual
5
2. Optional accessories(need to purchase separately)
Serial
No.
Descriptions
Seria
l No.
Descriptions
1
GPS function and one antenna
5
Aviation or CVBS extension cables
2
4.3” built in LCD
6
One CD
3
Four AVP cables（If customer need to
purchase cameras separately. ）
7
Storage devices(HDD or SD Card)
4
Four analog AHD Cameras （720
P/960P）
5. Product development stages
Generations
Period
Compression
technology
Basic functions
Optional
functions
1st generation
2006～
2008
MPEG4
(encrypted)
4 channel CIF,1T Hard disk,3.5”
LCD screen
GPS
2nd generation
2009～
2011
MPEG4
(encrypted)
3ch CIF and 1ch D1, 2TB HDD,
3.5” LCD Screen, 4ch alarm input,
C-BOX
GPS, GPRS
3rd generation
2012～
2014
H.264
(encrypted)
4channel D1,4TB HDD,64GB SD
Card,3.5” LCD Screen,USB mouse
operation, VGA, 8ch alarm input,
C-BOX, motion detect
GPS, 3G, WIFI,
G-Sensor,
Cloud Service,
Mobile monitor
4th generation
2015～
H.264
(encrypted)
4ch AHD 720P, 4TB HDD, 128GB
SD Card, 4.3” HD LCD Screen,
VGA, 8ch alarm input ,2ch alarm
output...
GPS, LCD, 3G,
4G, WIFI, APP
Next
generation
……
H.265
(encrypted)
4ch/8ch AHD 1080P HD Mobile
monitoring DVR...
……
6. Application scope
X7 Series products are 4ch AHD full real time Mobile monitoring and management system which

H.264 AHD 4CH MOBILE DVR X7 Series User manual
6
adopts Linux embedded operation system, based on H.264 digital high definition technology,
support extended functions such as LCD, GPS.
X7 Series equip with high performance and wide application scope, which applicable for buses,
taxi cabs, ships, vans, trains, etc. it is also applicable for the surveillance in fixed places such as
offices, factories, home, buildings.

H.264 AHD 4CH MOBILE DVR X7 Series User manual
7
CHAPTER 2:Device installations
1.Specifications
Attentions:
If customer need to purchase the AHD_M Cameras by themselves, please make sure the
definition of pin ports on aviation connector should match with our DVR connector"s
Parameters
Descriptions
Model
X7 Series
Basic functions
with basic functions such as REC,PLAYBACK,ALARM, VGA,USB,IR,HDD,SD,
TV-OUT, etc.
Optional functions
4.5” LCD
GPS
Wi-Fi: not available now
3G/4G:not available now
Power Supply
Car battery（For mobile monitoring）/Power adapter（For other applications）
Power input
DC12V ～DC36V(Standard power input:DC12V~DC24V, ultimate power input:
DC8V～DC38V)
Working Current
Model
300 ±10 mA (the reference voltage is: DC24V)
Power output
DC12V/3A （Provide power for cameras,with built in re-settable fuses. ）
Working
temperature
- 10℃～ + 50℃ （ultimate working temperature: - 20℃～ + 60℃）
Video Technology
H.264(Data encryption, need to use the playback software to play the videos）
Storage
interface
Standard SATA II HDD interface, SD Card and USB devices
Storage Capacity
2.5"" SATA II 4TB HDD/128GB SD/SDHC Card（suggest to use the SD Card with
the speed over Class10)
Storage mode
Boot record, cycle recording
Camera
AHD_M standard cameras
Video Standard
PAL system or NTSC system （Please make sure the camera"s video standard
compatible to the DVR）
Video input
Input standard: input frequency: Vp-p=1.0V, input impedance: 75Ù
Resolution
4ch AHD 720P full real time recording, also support the playback function while
recording.
Frame rate
PAL（1～100FPS optional）and NTSC（1～120FPS optional）
Video quality
Multi-grade adjustable
Output signal
CVBS（4ch video + 4ch audio,but only support 1ch audio output at a same time)
Ethernet Port
One 10M/100M Ethernet port (RJ45)
Alarm input
8ch independent alarm input port (isolating function)
Alarm output
2ch independent alarm output port
USB Standard
2 USB 2.0 port（support USB back up and system upgrade）
IR Receiver
One IR receiver（beside the USB port）
DVR dimension
210（Length）*180（Width）*50（Height）mm
mainframe weight
Around 1000g

H.264 AHD 4CH MOBILE DVR X7 Series User manual
8
definitions! And please make sure the TV system of camera match with the TV system of the
DVR.
2. Connection instructions
2.1. Connection diagram
ALARM/RS485 Ports:
ALARM/RS485 Ports：
PIN port
9
10
11
12
13
14
15
16
Function
AL-IN 8
AL- IN 7
AL- IN 6
AL- IN 5
AL- IN 4
AL- IN 3
AL- IN 2
AL- IN 1
PIN port
8
7
6
5
4
3
2
1
Function
AL-OUT1_A
AL-OUT1_B
GND
AL-OUT2_A
AL-OUT2_B
GND
RS485A
RS485B

H.264 AHD 4CH MOBILE DVR X7 Series User manual
9
Definitions and descriptions of ports:
AL-IN1~AL-IN8: alarm input port ALARM-IN1~ALARM-IN8, need to set up and work together
with the related function in the system menu. Support support NO/NC switch control signal
and high/low level control signal（DC 0.7V < high level <DC 12V, low level< DC 0.6V）
AL-OUT1 &AL-OUT2 :Two independent relay based alarm output ports, need to work
together with related function in the menu, with Normal Open contact ,can controlled by
the signal under 1A
RS485A&RS485B: PTZ control port
The common ground wire port
2.2.Start up control mode
1Auto switch on/off start up mode,applicable for vehicles.
2Manually switch on/off control mode, applicable for the fixed places.
Notes：ACC+ Cable is the start up control wire, effective when triggered by high level, usually
works with the car cigarette lighter.
2.3. Attentions
1As there are many control ports for the DVR, so we do not use the special
designed terminal for each port, Please use the insulating tape to bind up, in
case the short circuit occurs with other wires, and affect the other control wires.
2If the power indicator has light up, it means that the power has input correctly.
3After the DVR connect to power supply, please make sure that the ACC+ also
connect to the power, or the device can not start up.

H.264 AHD 4CH MOBILE DVR X7 Series User manual
10
3.Interface explanation
3.1. Interfaces

H.264 AHD 4CH MOBILE DVR X7 Series User manual
11
3.2. IR remote control
Serial
No.
Buttons
Functions
Serial
No.
Button
s
Functions
1
Record
13
Ch1 full screen display
2
Stop Record
14
Ch2 full screen display
3
Menu
15
Ch3 full screen display
4
Confirm
16
Ch4 full screen display
5
Play
17
Ch5 full screen display
6
Back to previous menu
/Exit
18
Ch6 full screen display
7
Upward key/Video
channels shift button
19
Ch7 full screen display
8
Downward key/Video
channels shift button
20
Ch8 full screen display
9
Left side key/ Video
channels shift button
21
Display all channels in
preview mode
10
Right side key/ Video
channels shift button
22
PTZ function
11
Rewind
23
PTZ zoom out
12
Fast forward
24
PTZ zoom in

H.264 AHD 4CH MOBILE DVR X7 Series User manual
12
3.3. Status indicators
PWR:Power input indicator, when there is power input, the indicator will keeps on.
RUN: DVR running indicator, it will keeps on after the DVR is triggered to work by ACC+
REC: Record indicator, it will blink when device record and save normally.
GPS: It will keeps on after GPS system positioning correctly
3G/4G: It will keeps on after 3G/4G module dial-up successful ,It will blink when the
module starting to transmit the video stream.
3.4. Storage devices installation
3.4.1. Attentions before installation:
Mother board and hard disk are consist of many integrated circuit components,
Integrated chip,etc,And these electronic parts are very easy to be damaged by the
static electricity. So please take notes the following issues before installing the HDD:
1Disconnect power of DVR before installing and removing HDD
2To avoid the HDD damaged by static electricity, please wear anti static wrist
strip or touch grounded and metal objects before you touching the HDD,
like metal cases, metal tap.
3Please do not use the HDD in shaken and dusty place.
3.4.2. How to install HDD?

H.264 AHD 4CH MOBILE DVR X7 Series User manual
13
Steps:
1Unlock the DVR with the key, open the DVR clam shell, unscrew the 4 screws on the
HDD case.
2Remove the cover of HDD case, connect the HDD to the SATA interface, and put the
HDD correctly.
3Put back the cover of HDD case, screw up the 4 screws.
3.5. Memory occupancy calculation
When you install the 4ch HDD/SD card mobile DVR for the first time,please check if any hard
disk/SD Card is installed. And check the write protect switch(if with SD card),Otherwise,the video
files can not be recorded into the SD Card properly.
Maximum capacity of the memory storage devices HDD/SD Card supported:
4CH mobile DVR X7 series support SATA HDD up to 4TB and high capacity SD Card up to
128GB. Users can choose the appropriate memory storage as their request:
How to choose HDD/SD Card`s capacity?
Formula for Storage space occupation:
Total storage capacity（M）= numbers of channels（CH）* required time（H）* occupied capacity
per hour（M/H）
Formula for recording time:
Recording time（H）= Total storage capacity（M）/【numbers of channels（CH）* occupied capacity
per hour（M/H）】
Please notes:X7 series MDVR adopt H.264 compression technology,with comparatively wide
dynamic range,and different video input devices will affect the bit stream statistics obviously. So
when users calculate the parameters above,please refer to all channels bit stream info in menu,to
make sure the calculation as accurate as possible. It will assist users to choose more appropriate
storage devices.
For instance:
The user uses a standard hard disk of 1TB/SATAII,and set 4 ch recording at 720P/25FPS(high
quality recording).Each single channel needs around 2GB capacity per hour,the recording time of
4ch real time high quality recording will be:1TB/(2GB×4CH)≈128hours(8hrs/day×16 working days
or 24 hrs/day×5 working days).
3.6. Main frame installation
3.6.1. Firstly, fit the anti-vibration rubber pad onto the mounting plate(smooth side
of plate faces up), then fix the rubber pad with matched screws. Then install the
mounting plate with the fixing screws in the place where need to install the DVR.

H.264 AHD 4CH MOBILE DVR X7 Series User manual
14
3.6.2. Install the DVR onto the anti-vibration rubber pad according to the mounting
hole(locate the DVR vertically with the mounting plate)
3.6.3. Install the metal gaskets, nuts, cap nuts in turn and screw up the nuts, and finish the
installation.
3.6.4. Mounting done.

H.264 AHD 4CH MOBILE DVR X7 Series User manual
15
CHAPTER 3: System Menu
1. Preview interface
It will enter into the image preview mode after device starts up normally, system will show quad
display screen.
In preview mode, operate 1,2,3,4 key on IR remote control can trigger single channel full screen
display and output the audio of present channel. When DVR is in quad display screen, the DVR
can not output the audio.
Press "MENU" key in preview mode and can enter system menu, Press “ESC” key can exit menu
or return to previous menu,Press "PLAY" key can play back videos.
Notes: System will automatically return to preview model if no operations over 30 seconds.
you do not set in the setting of system menu within 30 sec.

H.264 AHD 4CH MOBILE DVR X7 Series User manual
16
In all preview mode,DVR will will display date,time,channel title, car license number, GPS speed,
audio recording status,GPS connecting status and video recording status with icons.
2. Menu introduction
Menu
Function
Record setting
Set each channel"s frame rate,video image quality, video
resolution, etc.
Image setting
Set each channel"s image brightness, contrast and color
Date&time setting
Set date,time and time zone(GPS can update the system time) etc.
GPS setting
GPS speed watermark display, GPS speed unit and GPS" serial
communication baud rate, etc.
Car license number
Set up car license number/series number watermark display and
the specific details of car license number, etc.
Working mode
Set power off delay time and turn on/off audio record function etc.
Alarm setting
Set the alarm input, alarm output and related configuration, etc.
Channel title setting
Set up every channel title and watermark
display etc.
Languages
Set the system menu language
3G/4G
Set 3G/4G parameters
Data back up
Search video file according to the date ,back up the data to USB
Default settings
Restore factory default settings
Format HDD
Format storage device (SD card ,HDD and SSD)
Firmware upgrade
Show the current system firmware version and upgrade the system
firmware.
Serial No.
Icon
Function
Serial No.
Icon
Function
1
Video Recording
2
Audio
Recording
3
GPS connecting
4
GPS Speed
5
current preview
channels
6
Channel
title
7
car license number
8

H.264 AHD 4CH MOBILE DVR X7 Series User manual
17
3.Video Playback
In preview mode, operate"PLAY" key, enter the pack back interface, Operate "up" and "down" key
to choose the video need to play according to time period, ,Operate "PLAY" or"OK" to play the
chosen file, Press"PLAY" can pause playback when playing back ,press "STOP" can stop playing
back current files. Press “ESC” can exit to previews menu.
In the process of video playing back, Press 1,2,3,4 and "ALL" key can switch single channel full
screen display and quad screen display. The system able to output audio if single channel full
screen display, and system can not output audio when system shows quad screen display。

H.264 AHD 4CH MOBILE DVR X7 Series User manual
18
4. Menu setup
Press “Ok” key and enter into the sub-menu, Then choose the parameters by left and right key,
and to modify the parameters by up and down keys.
When choose or set a parameters, when the corresponding option will show a high light box,
means the parameters has been chosen, now we can start to modify the value of the parameters.
Then Press “OK” to confirm the setting and skip to the next option.
If do not need to modify present parameters, we can press “OK” key directly and skip to the next
option, and finally choose “save” option to save the settings on current page
If do not need to set the parameters, Press “ESC” return to the previews menu or the menu
setting interface.
NOTES: The IR remote control’s operation rule and method will be same for all settings.

H.264 AHD 4CH MOBILE DVR X7 Series User manual
19
4.1. Record Settings
Under the “Record” page, It is available to set the frame rate, image quality and resolution.
Frame rate: Adjustable range is 5fps~25fps in PAL, and adjustable range is 5fps~30fps in NTSC，
default value is 25FPS or 30FPS.
Image quality：Setting the image quality, Best/Better/Normal three grade adjustable. The default
is “Best”
Resolution: 720P/VGA
4.2. Color Settings:
Under the ”color” page, adjust the brightness Contrast and Saturation. We can set each channel
separately.

H.264 AHD 4CH MOBILE DVR X7 Series User manual
20
4.3. Date and time
Under the“TIME”page, we can set Date Time and Time Zone. If DVR support GPS function, The
GPS and time zone setting will automatically update the time and date of DVR system.
Time Zone: London GMT+0,Berlin GMT+1, Cairo GMT+2, Moscow GMT+3, New Delhi
GMT+5,Bangkok GMT+7,Beijing and Hong Kong GMT+8,Tokyo GMT+9,Sydney GMT+10,Hawaii
GMT-10,Alaska GMT-9,Pacific Ocean GMT-8,MST GMT-7,CST GMT-6,EST GMT-5,AST
GMT-4 ,Brazil GMT-3, Central Atlantic GMT-2.
4.4. Car License Number setup
Under “ Vehicle number” page, We can set the car license number, and choose display or do not
display the car license number in preview interface.
Car license number can be consist of 10 numbers and letters.
