DualLite EVC Series Manual

Hubbell Lighting, Inc.
WARNING – This product contains chemicals known to the State of California to cause cancer, birth
defects and/or other reproductive harm. Thoroughly wash hands after installing, handling, cleaning,
or otherwise touching this product.
Emergency Lighting Equipment For Use in Damp Locations
Damp location listed exits are suitable for installation in:
1. Interior locations subject to moderate degrees of moisture, such as some basements, some barns, some cold storage
warehouses, and the like.
2. Partially protected locations under canopies, marquees, roofed open porches and the like.
Architectural LED Combination Exit/Emergency Light
Standard, Remote, and Spectron®Equipped Models
Installation, Operation, and Service Instructions
EVC Series
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following.
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. Do not use outdoors (unless suitable for damp location).
2. Do not mount near gas or electric heaters.
3. Equipment should be mounted in locations and at heights where it will not readily be subject
to tampering by unauthorized personnel.
4. The use of accessory equipment not authorized by the manufacturer may cause an unsafe condition.
5. Do not use this equipment for other than its intended purpose.
6. Servicing of this equipment should be performed by qualified service personnel.
7. Test cycling: the Life Safety Code (NFPA 101) requires testing of emergency lighting units once a month
for a minimum of 30 seconds, and once a year for a minimum of 90 minutes.
INSTALLER:
•SEE UNIT LABEL FOR ADDITIONAL MODEL SPECIFICATIONS
•SAVE THESE INSTRUCTIONS FOR USE BY OWNER/OCCUPANT
B
2 1
2 1
A
B
A
ALBALBEC-1008100016/17/111
REV DATE RECORD DESN CHCK
SHT 1
2 SHTS
N/A N/A
93036965
93036965
1
ILL-CTN LBL EVC
ALB 06/16/11
ALB 06/16/11
---
ALB 06/16/11
DRAWING NO.
SIZE
A
SCALE
CATALOG NO.
ENGINEERING:
CHECKED BY:
DIMENSIONS IN INCHES
DIMENSIONS IN [ ] IN MM
CONFORMS TO ASME Y14.5M
DO NOT SCALE PRINT
DRAWN:
THIRD ANGLE PROJECTION
MATERIAL: FINISH: PART NO.
REV.
CRITICAL DIMENSIONS
This document contains confidential and proprietary information of Dual Lite.
Receipt or possession of this document does not convey any rights to
reproduce or disclose its contents, or to make, use , or sell anything it may
disclose. Reproduction, disclosure, or use of the document or its contents,
without the specific written authorization of Dual Lite, may violate the
intellectual property rights of Dual Lite.
UNSPECIFED TOLERANCES: INCHES
X.X=±0.1 X.XX=±0.03 X.XXX=±0.010
FRACTIONS=±1/32 ANGULAR TOLERANCE=±1°
NTS
93036965
RECYCLING INFORMATION
All steel, aluminum and thermoplastic parts are recyclable.
NOTICE: Emergency units contain rechargeable batteries which
must be recycled or disposed of properly.
Hubbell Lighting, Inc. Life Safety Products • www.dual-lite.com
Copyright
©
Hubbell Lighting, Inc., All Rights Reserved • Specifications subject to change without notice. • Printed in China
93031684B 06/17
93036965
93043558
93043559
93043560
93044309
OPERATION
SERVICE / MAINTENANCE
This emergency lighting sign should be tested and maintained in
accordance with National Electrical Code and NFPA 101 Life Safety Code
requirements. It is recommended that emergency lighting xtures be tested
for 30 seconds once a month and for 90 minutes once a year.
Taking A Unit Out Of Service
If a sign is to be deliberately taken out of service for an extended period,
the battery lead connector should be disconnected from the charger circuit
board so that the battery will go into storage in a fully charged condition.
Replacing The Battery
1. De-energize the AC power
2. Remove stencil face-plate from frame.
3. Disconnect the battery leads from the charger circuit board.
4. Remove the battery from the Exit frame.
5. Replace with a new battery (see model label for part number of the battery).
6. Reassemble stencil face-plate to frame.
Replacing LED Lamps
The LED lamps inside the exit are not replaceable or eld serviceable.
Troubleshooting
Emergency circuit does not work
• Batteries are shipped uncharged and disconnected. Connect the battery leads and charge 24 hours before testing.
• Make sure the charger board and test button/light pipe are properly seated and aligned.
• Check all wiring connections.
“AC On” LED is illuminated when AC power is present.
NOTE: All models are supplied with an AC lock-out circuit, which prevents the emergency lights from illuminating when the battery is connected
and no AC power is present.
NOTE: All models are supplied with a Low Voltage Disconnect circuit which prevents damage to the battery from deep discharge during pro-
longed emergency operation.
NOTE: Batteries are often shipped in a discharged state - this is normal. The battery will require charging. Allow 24 hours of charging before
testing the unit.
Models with Spectron®Self-Testing/Self-Diagnostic Circuitry
Models equipped with the Spectron® self-testing/self-diagnostic electronics system provide:’
• Visual indication of AC power status • Visual indication of self-diagnostic test status and results
Visual indication of any unit malfunction include
• Battery Disconnected • Battery Fault • Charger Fault • LED Driver Fault • Lamp Fault
Spectron® equipped signs also include:
Brown-out protection: sign will automatically transfer to emergency operation upon detection of low AC power (approximately 80% of nominal
line).
Time Delay Re-Transfer: upon return of normal AC power, unit will remain in emergency mode for an additional 15 minutes to allow AC power to
stabilize.
LED Status Indicator
A bicolor LED (Green/Red) is provided on the control panel of all models equipped with the Spectron® option.
Green Operating Status LED
Serves as both an AC power and self-test indicator. During normal operation, the Green Operating Status LED will be illuminated indicating the
presence of AC power. During all automatic or manual self-test cycles, the Green Operating Status LED will blink twice every second.
Red Service Alert LED
Under normal operating conditions, the Red Service Alert LED indicator will remain off. If the Spectron® controller detects a malfunction, the
Red Service Alert LED will blink in the pattern listed in the following table:
RED Status LED Code Description
One Blink ON/pause Battery Dis-connected
Two Blinks ON/pause Battery Fault
Three Blinks ON/pause Charger Fault
Four Blinks ON/pause LED Driver Fault
Five Blinks ON/pause Lamp Fault
Ten Blinks ON/pause Load Learn Failure
Red/Green Alternating Load Learn in Progress
Testing Period Duration of Test
Once a month 1 minute
Once every 6 months Alternating 30 or 60 minutes
Automatic Tests
The exit will automatically initiate a self-test/self-diagnostic cycle
based on the following:
Initiating Action Test Cycle
Press test switch once 1 minute
Press test switch twice 90 minutes
Manual Tests
Using the exit test switch, users can initiate different test cycles
based on the following table:
Pressing the test switch any time after a 90 minute test cycle
has begun cancels the remainder of the 90 minute test & returns
the unit to normal operation.
Note: After clearing a 5 blink lamp fault by initiating a load learn test, a 60 second
manual test must be initiated.

INSTALLATION INSTALLATION
See back page for additional option wiring information.
93043559
93043558
93043560
93044309
93043559
Ceiling, End, or Wall Mount AC Input Leads
Ceiling Mount AC Input Leads
1a. Feed (provided) wires through center of mtg plate and screw mtg
plate to J-box.
2a. Feed wires through center of canopy and snap both canopy
ngers into mounting plate.
3a. Secure Canopy to mounting plate with two (provided) screws.
4a. Route wire leads into sign and make connections using quick
connectors in sign. (Note: Trim wire leads if needed).
End Mount AC Input Leads
1b. Feed AC input wires (provided) through center of mounting plate
and screw mounting plate to J-box.
2b. Feed wires through center square of canopy and snap both
canopy ngers into mounting plate.
3b. Secure canopy to mounting plate with the two screws (provided).
4b. Route wire leads into sign and make connections using quick
connectors in sign. (Note: Trim wire leads if
needed).
Wall Mount AC Input Leads
1c. Remove center K.O. in back plate.
2c. Remove appropriate back plate K.O.’s for J-box
mounting screws.
3c. Feed (provided) wires through center K.O. from
J-box and mount back plate to J-box.
4c. Feed wire under frame dress in wire posts and
make connections using quick connectors in sign
(excess wire to be stuffed back into J-box).
1a
2a
3b
3a
4a
1c 2c
3c
Remote Capacity Wiring Connection
Wire Routing Thru Canopy From J-Box
FAP Option Input Wiring Connection
Route remote capacity leads (provided into
sign, trim to t & make connections using
quick connectors in sign
Route Violet FAP leads
(provided) into sign trim to
t & make connections at
terminal block on option PCB.
Route both FAP wires
in outer wire channel.
NOTE: Afx Violet FAP
wires in any order in
terminal block.
NOTE: If needed apply
FAP label to FAP leads
(provided) for I.D. Option PCB
FRONT OF SIGN
AC Input
Remote High
Capacity
FAP
Note polarity of wires when
making connections
IMPORTANT: Option connection wires must be run before sign housing
is attached to canopy.
FIRE ALARM PANEL(-FAP) OPTION
FAP option connects to 24 volt AC or DC (Violet wires).
Flash Rate: .5 seconds ON, .5 seconds OFF.
FLASHER MODULE (-FM) OPTION
Emergency Mode Flash Rate: .5 seconds ON, .5 seconds OFF.
AUDIBLE/FLASHER MODULE (-AF) OPTION
Emergency Mode Beep/Flash Rate: .5 seconds ON, .5 seconds OFF.
REMOTE CAPACITY MODEL NOTE
EVC-D4 & EVC-D4I Models Only
Remote capacity models provide sufcient battery capacity to operate 2
additional LED remote lighting xtures or additional run-time. The jumper
setting from the factory will be in position “B”. This will provide the sign
with a longer run-time in emergency mode with no added LED remote
lighting xtures. If the jumper is located to position “A”, you can run 2
additional LED remote lighting xtures.
** Once a remote capacity model is properly installed (jumper is in
position “A”), press and hold the test button for more than 5 seconds
to initiate the load learn process calibrating the 2 additional LED remote
xtures.
The EVC sign is designed to be wall, ceiling or end mounted. Provide standard
and Spectron® equipped signs with single un-switched supply from a 120 or
277VAC branch circuit used for normal lighting in the area to be protected.
For Spectron® remote capacity signs, provide with 120, 240, or 277VAC
branch circuit as needed.
EVC signs are equipped with intelligent wiring. Connect the black wire from
the sign to the HOT building wire (120 or 277VAC) and the white wire to the
building neutral wire.
EXCEPTION: The models with -24K should be connected to 220 - 240VAC
supplies only.
Plug 2-pin battery
connector onto
charger PCB
header.
NOTE: If canopy snaps do not engage sign frame loosen
screws(3b) until canopy is at and all canopy snaps are able to
engage in exit frame.
Charger PCB
Test Button
Battery Pack
Press wires into
wire channel
2b
1b
4b
4c
