Dukane 6235W User manual

Contents
Product Description, Lens Specs, Notes and Formulas Pg 1
Diagrams & Distance Charts Pg 2
Cabinet Dimensions Pg 3-4
Ceiling Mount Dimensions Pg 5
Input Panel and Control Codes Pg 6
Product Description
Type: 1 Chip DLP Projector Dimensions: 14.5” (W) x 5.3” (H) x 11.5” (D)
0.65” DMD Weight: 8.2 lbs
Resolution: 1280 x 800
Brightness: 3500 Lumens Fan Noise: 39 dB / 33dB @ 1 meter
BTU’s: 1208 BTU/hour Power Consumption: 354W (max)
Lens Specifications
Throw Ratio: 0.48:1 (for 100” diagonal) Focal Length: 17.5mm –29.0mm
Offset Angle: 40.8° (for 100” diagonal) F/#: 1.7 - 2.1
Screen Sizes: 60” - 150” diagonal (16:10) Manual Focus
Notes
For screen sizes not indicated on the projection tables, use the formulas below.
If the figures on the tables do not match the results of formulas, use the figures in the table.
All calculations are based on a 16:10 aspect ratio.
Distances are in inches, for millimeters multiply by 25.4.
Distances may vary 5%.
Formulas
The Projection Formulas use the image width for calculation. For proper projection placement, determine the image width
for the desired screen size. Use the Screen Formulas below to calculate all screen dimensions. Plug in the width for “W” in
the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2:
Definitions: 16:10 Screen Formulas:
W = Image Width W = H x 16/10
H = Image Height (size) H = W x 10/16
B = Vertical distance between lens center and screen center Screen Diagonal = W x 18.868/16
C = Throw distance
D = Vertical distance between lens center and screen top
(screen bottom for desktop application)
α= Throw Angle
Projection Formulas:
B= 0.4051W
C = 0.48W (wide)
D= 0.0926W
α= tan-1(B/C)
www.dukaneav.com 6235W Installation Guide-00 Page 1 0f 6
6235W Installation Guide
Ceiling Mounted and Desktop Rev 1
Dukane AV Division

Diagrams and Distance Charts
The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of
installation.
Distances are in inches. For millimeters multiply by 25.4.
Ceiling Mounted Desktop
Distance Chart for popular 16:10 screens
Note: For screen sizes not indicated on the projection
table, use the formulas on page 1.
Diagonal Width(W) Height (H)
inches inches inches inches inches inches degrees
57 48 30 19 23 4 40.2
60 51 32 21 25 5 40.2
70 59 37 24 28 5 40.2
79 67 42 27 32 6 40.2
91 77 48 31 37 7 40.2
100 85 53 34 41 8 40.2
104 88 55 36 42 8 40.2
110 93 58 38 45 9 40.2
120 102 64 41 49 9 40.2
130 110 69 45 53 10 40.2
140 119 74 48 57 11 40.2
150 127 79 52 61 12 40.2
D
α
Image Size (16:10) on a
(16:10) screen
B
C


3.20
5.88
6.16
www.dukaneav.com 6235W Installation Guide-00 Page 2 0f 6
6235W Installation Guide
Ceiling Mounted and Desktop Rev 1
Dukane AV Division

Cabinet Dimensions
The following drawings show the cabinet dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
2.386
5.3
4.9
4.232 1
2.307
3.839
14.5
11.5
11.3
FOCUSLEVER
LAMP
LENS CENTER
IR RECEIVER
EXHAUST
AIR INTAKE
AC INLET
www.dukaneav.com 6235W Installation Guide-00 Page 3 0f 6
6235W Installation Guide
Ceiling Mounted and Desktop Rev 1
Dukane AV Division
Note: The Dukane model described in this document is manufactured by NEC and use the same
rmware, software programs, control code, and accessory parts. The equivalent Dukane to NEC
model is 6235W, (M352WS).

Cabinet Dimensions (continued)
The following drawings show the cabinet dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
5.232
7.417
6.571 5.87
9.484
0.197 7.677 6.89
5.118
5.906
M4 x 8 Depth
FOR CEILING MOUNT KIT
www.dukaneav.com 6235W Installation Guide-00 Page 40f 6
6235W Installation Guide
Ceiling Mounted and Desktop Rev 1
Dukane AV Division

Optional Ceiling Mount Dimensions (Model #: MP300CM)
The following drawings show the ceiling mount dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
M300WS with Optional Ceiling Mount (Model #: MP300CM)
5.88
6.16
3.20
6235W Installation Guide
Ceiling Mounted and Desktop Rev 1
Dukane AV Division
www.dukaneav.com 6235W Installation Guide-00 Page 5 0f 6
or use universal mount PRG-UNV.

Input / Output Panel
PC Control Codes
Function Code Data
POWER ON 02H 00H 00H 00H 00H 02H
POWER OFF 02H 01H 00H 00H 00H 03H
INPUT SELECT COMPUTER1 02H 03H 00H 00H 02H 01H 01H 09H
INPUT SELECT COMPUTER2 02H 03H 00H 00H 02H 01H 02H 0AH
INPUT SELECT HDMI 02H 03H 00H 00H 02H 01H 1AH 22H
INPUT SELECT VIDEO 02H 03H 00H 00H 02H 01H 06H 0EH
INPUT SELECT S-VIDEO 02H 03H 00H 00H 02H 01H 0BH 13H
INPUT SELECT VIEWER 02H 03H 00H 00H 02H 01H 1FH 27H
INPUT SELECT NETWORK 02H 03H 00H 00H 02H 01H 20H 28H
INPUT SELECT USB DISPLAY 02H 03H 00H 00H 02H 01H 22H 2AH
PICTURE MUTE ON 02H 10H 00H 00H 00H 12H
PICTURE MUTE OFF 02H 11H 00H 00H 00H 13H
SOUND MUTE ON 02H 12H 00H 00H 00H 14H
SOUND MUTE OFF 02H 13H 00H 00H 00H 15H
PROJECTOR INFORMATION REQUEST 00H BFH 00H 00H 01H 02H C2H
ERROR STATUS REQUEST 00H 88H 00H 00H 00H 88H
INFORMATION REQUEST 03H 8AH 00H 00H 00H 8DH
Note: Contact your 󰾡 󰾡 rep for codes not listed.
Cable Connection
Communication Protocol:
Baud Rate: 38400 bps
Data Length: 8 bits
Parity: No Parity
Stop Bit: One Bit
X on/off: None
Communications: Full duplex
PC Control Connector (D-Sub 9P)
NOTE 1 : Pins 1, 4, 6, and 9 are used inside the projector.
NOTE 2: For long cable runs it is recommended to set communication speed within the projector to 9600 bps.
NOTE 3: Jumper “Request to Send” and “Clear to Send” together on both ends of the cable to simplify cable connection.
1 2 3 4 5
6 7 8 9
To GND of PC
To RxD of PC
To TxD of PC
To CTS of PC
To RTS of PC
6235W Installation Guide
Ceiling Mounted and Desktop Rev 1
Dukane AV Division
www.dukaneav.com 6235W Installation Guide-00 Page 6 0f 6
