Dukane 8421 User manual

Breakthrough classroom performance
with incredible picture quality, high reliability,
and lower cost of ownership.
Key Features
■XGA 1024 x 768 resolution
■3,000 ANSI lumens light output
■2500:1 contrast ratio
■4.500 hours lamp life (Standard mode)
6,000 hours lamp life (Eco mode)*
■ImageCare technology
■BrilliantColorTM
■Deeper black levels
■Wall color correction
■Filter free design
8421
The wireless remote control
enables you to easily control
a full complement of projector
functions.
Dukane’s 8421 DLP®projector represents the new standard for classroom
environments and versatility with high resolution XGA performance,
an innovative feature set and overall value. The 8421
incorporates 3,000 ANSI lumens light output and a
2500 : 1 contrast ratio for vibrant, bold images with
deeper black levels and razor-sharp text. Perfomance
versatility is enhanced by HDMI terminals which
accommodate many types of AV devices. Plus, Dukane’s Intelligent Eco
Mode with ImageCare combines optimal picture performance with energy
savings for a lower cost of ownership. For added peace of mind, Dukane’s
8421 is also backed by a generous warranty and our world-class service and
support programs.
8421 DLP®Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av

UNIQUE FEATURES
STANDARD FEATURES
Intelligent Eco Mode
Automatically changes the brightness of the lamp according
to the brightness level of the screen. Using ImageCare
technology, these features give optimal picture performance
with maximum energy savings.
ImageCare Technology
ImageCare is a lamp power control function that combines
optimal picture performance with maximum energy savings
by decreasing energy usage, improving contrast ratio and
lengthening lamp life. The result is a lower total cost of
ownership and decreased maintenance cost.
3,000 ANSI Lumens Light Output
The light output specification measures the brightness of light
output and with 3,000 ANSI lumens the result is bright, clear,
true to life images with incredible detail.
LIGHT OUTPUT
3000
2500:1 Contrast Ratio
Contrast can be automatically controlled through an active iris
to add depth perspective during both bright and dark scenes.
HDMI Input (HDCP)
Digital connectivity allows for highest image quality from your
HD device. Compliancy with HDCP.
6,000 Hour Lamp Life (Eco mode)*
Another key to low total cost of ownership is a long life lamp.
The lamp is rated at 4,500 hours in standard mode and 6,000
hours in Eco mode.
Power Saving Standby Mode
Power saving mode reduces the standby power consumption
to less than 0.5W.
Easy Maintenance
Easy maintenance is another attractive function, as the lamp
door is on top of the model.
SPECIFICATION HIGHLIGHTS
DLP®Technology
DLP technology was invented, developed and is owned by
Texas Instruments. The DLP chip is a digital semiconductor
that contains millions of microscopic mirrors. These projectors
use DLP technology to project images with amazing quality.
BrilliantColor™
BrilliantColor technology is setting a new
standard in color performance. BrilliantColor
offers color processing to enhance color
performance for rich, vibrant and accurate colors.
Wall Color Correction
This feature corrects the color of images projected on surfaces
that are not white to prevent color differences between the
source and projections. Five wall color modes include light
yellow, light green, blue, black board and pink.
3D Capable
Discover the teaching advantages of 3D! This DLP projector
offers the latest trend for the classroom with 3D viewing. It will
engage your students and can improve the learning process.
3D glasses and a special graphic card are required for 3D
viewing and are not included with the projector.
3D
3D
CAPABLE
3D
8421 DLP®Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user
settings and usage. Hours of average lamp life specified are not guaranteed and do not constitute part of the product or
lamp warranty. Lamp brightness decreases over time.
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av

Enhance the educational experience
with Dukane’s 8421.
The 8421 DLP
®
projector from Dukane is specifically
designed to enhance the educational experience
— for students and teachers. Leading edge DLP
®
projector technology helps stimulate the imagination
of students of all ages and makes lessons become
more interesting, compelling and memorable. Vivid
colors. Deeper blacks. Bold graphics. Crisp text.
The 8421 does it all in classrooms of all sizes. With
3,000 ANSI lumens light output, XGA 1024 x 768
resolution, the 8421 provides the perfect solution. It
also features exceptional reliability, a high contrast
ratio, HDMI terminals so you can connect many types
of AV devices, and wall color correction which corrects
the colors of images projected on surfaces that are not
white. With Dukane’s 8421, learning has never been
easier, more enjoyable or so engaging.
Input/Outputs
8421
Right Side Profile
Left Side Profile
Top View
41
12 1011
52 3 7 96 8
1. Control (RS-232C)
2. Service
3. HDMI
4. Computer in 2
5. Computer in 1
6. S-Video
7. Video
8. Audio In
9. Audio Out
10. Lock
11. Monitor Out (1 only)
12. AC In
Front 3/4 View
8421 DLP®Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av
5 Year Warranty
Closed Captioning
DLP Technology

* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
Accessories
Supplied
Accessories
Remote control, power cord,
computer cable, user’s manual
Optional
Accessories
N/A
Replacement Parts
Lamp 456-8420
Remote Control HL02961
Specifications
Display
Projection Technology 0.55" single chip DLP
Resolution XGA - 1024 x 768
Light Output 3,000 ANSI lumens
Colors 1.07 billion colors
Aspect Ratio Native 4:3 / 16:9 compatible
Contrast Ratio 2500 : 1
Throw Ratio
(distance : width)
1.86 - 2.04 : 1
Lens & Operation
Lens x 1.1 manual zoom
Lamp Wattage 196W
Expected Lamp Life* Approximately 4,500 hours (standard mode)
6,000 hours (Eco mode)
Speaker Output 2W x 1
Acoustic Noise Level 33 dB (29 dB in Eco mode)
Keystone +/- 30º vertical only
Compatibility
Computer VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/UXGA
(compressed), MAC 16"
H-Sync 31.5 kHz - 102 kHz
V-Sync 59.9 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 576p, 720p, 1080p, 1080p
Connectors
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 2
Computer Input 2 15-pin mini D-sub x 2
Computer Monitor Output 15-pin mini D-sub x 1 (computer in 1 only)
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin D-sub x 2 (shared with computer in 1/2)
Audio Input 3.5 mm stereo mini jack x 1
Audio Output 3.5 mm stereo mini jack x 1
Network LAN Wired N/A
Network LAN Wireless N/A
USB N/A
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 250W
Operating Temperature 32ºF - 95ºF (0ºC - 35ºC)
Dimensions (W x D x H)
10.4" x 8.8" x 3.2" (excl. protruding parts) / Shipping 12" x 11" x 9"
Weight approx. 4.8 lbs. / Shipping 11 lbs.
Approvals UL 60950-1 / cUL FCC Part 15 subpart B class B
Warranty Five (5) year limited warranty plus Dukane’s 1 year Peace of
Mind Loaner Program
UPC 00000060519400280
Projection Throw Chart (In inches)
Screen Size 4:3 Throw Distance
Desired
Distance
Max.
Diagonal
Max.
Diagonal
39 26 24
59 40 36
118 79 72
177 119 108
236 159 144
Throw Ratio: (distance : width)
1.86 - 2.04 : 1
8421
8421 DLP®Projector
