Dukane 8975WU User manual

Convenient and easy to use installation
projector with advanced technology
and 5,000 ANSI lumens brightness in
a low profile design.
Key Features
■WUXGA 1920 x 1200 resolution
■5,000 ANSI lumens white/color output
■16 watt audio output
■3000:1 contrast ratio
■HDMI 2 inputs
■20,000 hours hybrid lter*
■3,000 hours lamp life (Eco mode)**
■Power saving standby mode less
than .05W
8975WU
Dukane’s installation-friendly 8975WU LCD projector is designed to provide
maximum presentation impact in mid to large venue applications. It offers
a versatile array of innovative, performance-enhancing features along with
advanced video display technology providing bold, brilliant colors with
incredible image clarity and uniformity. Plus, with motorized zoom, focus and
superior lens shift, a variety of lens options, status monitor, and 360º display
rotation, the 8975WU is at the top of its class when it comes to installation
flexibility. All this, and with a lower cost of ownership. For added peace of
mind, Dukane’s 8975WU is also backed by a generous warranty and our
world-class service and support programs.
8975WU LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av

UNIQUE FEATURES
Perfect Fit 2
Enables the user to adjust individual corners and sides
independent of one another. Perfect Fit 2 provides vertical
and horizontal digital correction of either barrel or pin
cushion distortions. This feature helps correct geometric and
complicated distortions. Perfect Fit 2 allows the projected image
to fit correctly to the screen quickly and easily.
DICOM®Simulation Mode
Images in DICOM (Digital Imaging and Communications in
Medicine) Mode are reproduced with an advanced grayscale
level. This mode is ideal for viewing grayscale medical images
such as X-rays, and for training and educational purposes.
These projectors are not approved medical devices. They
should not be used for actual medical diagnosis.
Center Lens Design
This feature makes it easy to align the projector with the center
of the screen for faster and trouble-free setup.
Drawing Function with Optional Tablet (TB-1)
The optional Dukane wireless tablet and pen allows you
to engage your audience by annotating over any image.
Multiple Lens Options
In addition to the one ML703 middle throw standard lens,
four optional lenses are available: FL701 fixed; SL702 short
throw; LL704 long throw; and UL705 ultra-long throw.
4
Motorized Zoom, Focus and Lens
Shift Control
Allows for greater range of installation possibilities. With the
motorized function you can make fine adjustments through
the remote control or RS232/IP device.
360º Rotation
Display rotation of 360º for creative applications and greater
installation flexibility.
STANDARD FEATURES
Display via USB
Simply plug and play using the USB port
instead of the 15-pin D-sub VGA cable.
MyButton / MySource - Doc Camera
Two customizable buttons on the remote control
allow users to create a shortcut for any projector command such
as: Direct input (RGB1, S-video, etc.), picture mode or filter reset.
For connection to a document camera, MySource allows users to
add a third document camera source button.
Network Control, Maintenance and Security
Embedded networking gives you the ability to manage and
control multiple projectors over your LAN. Features include
scheduling of events, centralized reporting, image transfer and
e-mail alerts for reactive and routine maintenance.
PC-Less Presentation
By using a USB memory stick or other storage device, you
can use the projector without a computer. Menus are easy
to see with a thumbnail display. Additionally there is also a
slideshow function.
PIN Lock / MyScreen / MyText
PIN lock protection can limit projector users. MyScreen PIN
lock keeps captured images on the startup screen. Users can
set any name logo to MyScreen, clearly identifying ownership.
MyText provides the ability to write text on the startup screen
such as model name, serial number or location.
PJMessenger
PJMessenger function allows you to send and display text
messages and audio alerts on your networked projectors. It
is an easy and efficient way to send announcements out to
multiple units.
Present Content via LAN
Dukane’s suite of networking software allows you to easily
send content directly from your PC to the projector via your
LAN connection.
Serial Number and Media Access Control Label
A label is affixed to side of projector to more easily access
and read the model name and serial number while mounted
in ceiling use. This is a convenience for installers, end users
and auditors for instant accessibility.
Serial #
Template Function
Line templates in the projector menu can help when writing
on a whiteboard. There are four types of line templates to
choose from.
Transition Detector and Security Bar
A security sensor located inside the projector recognizes when
the projector has been moved. Moving the projector without
using the correct PIN code will disable the projector.
Wireless Presentation Ready
You can use a wireless network by connecting the projector
to a computer using the optional USB wireless adapter part
number USBWL11N. The adapter supports IEEE802.11b/g
and the latest 11n.
Picture By Picture
Dukane’s picture by picture enables the content from any two
input sources to be displayed simultaneously, side by side on
one screen. With such flexibility, the input source can originate
from different locations such as PC x 2 or video x 2, or PC x 1
and video x 1, with both images sharing equal screen size.
This feature is also ideal for teleconferencing applications.
Status Monitor
With Dukane’s status monitor, you’ll have access in real time
to projector diagnostics. Status updates include configuration
information, maintenance history, as well as error and alarm
messaging. For even greater user convenience, the status
monitor can be accessed on the rear input panel or through
the Dukane network tools software.
8975WU LCD Projector
* Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings
and usage. Hours of average filter life specified are not guaranteed and do not constitute part of the product warranty.
** Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user
settings and usage. Hours of average lamp life specified are not guaranteed and do not constitute part of the product or
lamp warranty. Lamp brightness decreases over time.
5 year Limited Warranty
Five (5) year limited year warranty plus Dukane’s 1 year Peace
of Mind Loaner Program.
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av

Quality, reliability and installation
convenience.
From mid-size to very large auditoriums and
conference halls, Dukane’s 8975WU LCD projector
is the perfect solution. With 5,000 ANSI lumens
brightness and WUXGA 1920 x 1200 resolution, the
8975WU will deliver dynamic images guaranteed
to dazzle any audience. Incorporating Dukane’s
leading-edge technology, the 8975WU features high
contrast ratio, long lamp life, picture by picture so
you can project two images on one screen at the
same time, a variety of lens options to accommodate
your specific application, and is wireless presentation
ready. Plus, embedded networking gives you the
ability to manage and control multiple projectors over
your LAN (scheduling of events, centralized reporting,
image transfer, and e-mail alerts). The 8975WU
comes equipped with a status monitor so you'll have
access in real time to projector diagnostics. Even with
the array of advanced features, Dukane’s 8975WU is
designed for user-friendly operation and installation
convenience.
Input/Outputs
8975WU
Side Profile
Rear View
Top View
321
1921 17 16 15 14 121320 18
4 5 6 87
9
10
11
1. Status Monitor
2. LAN
3. USB Type A
4. USB Type B
5. Composite Video
6. HDMI x 2
7. Audio in 3
8. Computer in 2
9. Computer in 1
10. Audio in 1
11. Audio in 2
12. Security Bar
13. Monitor Out
14. Component
15. Kensington Lock
16. Audio Out
17. S-Video
18. Remote Control
19. Control (RS-323C)
20. AC Inlet
21. Remote Sensor
Front 3/4 View
8975WU LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av
5 Year Warranty
Closed Captioning
3LCD Technology

Specifications subjext to change without notice.
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Accessories and Lenses
Supplied
Accessories
Remote control, power cord, computer
cable, one standard ML703 lens, lens
cover, user's manual, security label,
application CD, adapter cover
Optional
Accessories
USBWL11N USB wireless adapter,
TB-1 wireless USB tablet
Optional Lenses 4 optional lenses are available: FL701,
SL702, LL704, UL705
Replacement Parts
Lamp 456-8971
Remote Control HL02801
Filter MU06642
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution WUXGA - 1920 x 1200
White Light Output 5,000 ANSI lumens
Color Light Output 5,000 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 16:10 and 4:3 / 16:9 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
1.5 - 3.0 : 1
(with standard lens)
Lens & Operation
Lens x2.0 with motorized zoom, focus and lens shift
Lamp Wattage 330W UHP
Expected Lamp Life* Approximately 2,500 hours (standard mode)
3,000 hours (Eco mode)
Expected Filter Life** Approximately 20,000 hours
Speaker Output 16W (8W x 2)
Acoustic Noise Level 37 dB (31 dB in Eco mode)
Keystone H: +/- 15º and V: +/- 35º
Compatibility
Computer VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA,
WSXGA+, WUXGA, MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
Computer signal TMDS Clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 2 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 BNC x 5
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video RCA jack x 3
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port / 100-base-T
Network LAN Wireless IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less, wireless adapter, TB-1)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 480W
Operating Temperature 32ºF - 104ºF (0ºC - 40ºC)
Dimensions (W x D x H) 19.6" x 15.6" x 5.3" / Shipping 27" x 22" x 9"
Weight 19.0 lbs. / Shipping 28 lbs.
Approvals UL 60950-1 / cUL FCC Part 15 subpart B class A
Warranty Five (5) year limited warranty plus Dukane’s 1 year Peace of
Mind Loaner Program.
UPC 00000060519400258
Projection Throw Chart
Screen Size 16:10 Throw Distance
Diagonal Width Min Max
30 24 38 76
60 48 76 151
80 64 101 202
100 80 127 252
150 120 190 377
200 160 253 503
250 200 316 628
300 240 379 754
Throw Ratio: 1.5 - 3.0 : 1 (distance : width)
Screen size and throw distance are measured in inches
with standard lens ML703.
Projection Lens Chart
Lens Inches Meters
ML703 127 - 252 3.2 - 6.4
FL701 69 1.8
SL702 100 - 151 2.5 - 3.8
LL704 240 - 407 6.1 - 10.3
UL705 407 - 691 10.3 - 17.6
Projection distances measured in inches and meters with standard lens
and optional lenses when projecting onto a 100" diagonal screen.
8975WU
8975WU LCD Projector
DUKANE CORP
Audio Visual Products
2900 Dukane Drive, St. Charles, Illinois 60174
Toll-free: 888-245-1966 •Fax: [phone]
E-mail: [email protected]
www.dukane.com/av
HI0057-04/12
