Dukane ImagePro 8911 User manual

8911
S-Video
Audio
R & L
RGB
Out Control
RS-232
Composite
Video
USB
Type A
LAN
RJ-45
DC
Power
Out
ImagePro 8911
Portable LCD Projector
• 2700 lumen brightness
• XGA resolution
• 500:1 contrast ratio
• Four 3 watt speakers
• Auto vertical keystone correction
• Remote with laser pointer
• Network capability (RJ45)
Power Remote
On/Off
Switch
DVI-D
Audio
In Audio
Out
RGB
In
Component
Video

ImagePro 8911
Premium-quality LCD projector Specifications 8911
Image Element 0.8” polysilicon TFT x3, MLA
Brightness 2700 ANSI lumens
2100 (whisper mode)
Resolution 1024 x 768 pixels (H X V), XGA
Contrast 500:1
Scanning Frequency fh 15-91 kHz, fv 50-120 Hz
Lens Manual zoom (F=1.7 to 2.1), 1.3X
Lens Throw Ratio 2.3 -3.0 :1 throw distance
to image width
Keystone Correction Digital, vertical +/-15 deg, automatic
horizontal +/- 5 deg
Aspect Ratio 4:3, 16:9, selectable
Computer SVGA, VGA, XGA, and
Compatibility SXGA Compressed, MAC16"
Video Compatibility NTSC, NTSC 4.43, PAL, PAL-M,
PAL-N, PAL60, SECAM,
HDTV 1080i, 720p, 575i, 480i/p
Image Control Freeze function, electronic
magnification and pan
Mouse Control Using USB
Projection Modes Front/rear/ceiling
Color Reproduction 24 bit (16.7 million)
Lamp 230W UHB
Lamp Life 2000 hours
Audio 3.0 W x 4
Throw Distance 46” to 364”
Screen Size, diagonal 40” to 500”
Inputs, Video (1) Component, RCA x 3
(1) S-video, Min DIN 4-pin,
(1) Composite video, RCA x 1
Audio, Stereo, RCA x 2, (L/R)
Inputs, Computer (2) RGB Signal: D-sub, 15 pin
(1) DVI (digital RGB)
Audio, Stereo mini jack x 1
Outputs Monitor 15 pin, D-sub
Outputs Audio Audio, Stereo mini jack x 1
Outputs,Control 9 pin D-sub Connector, RS232C
USB connector x 1
3.5mm mini jack (wired remote control)
Network RJ-45 port / 10Base-T
Security Kensington slot
Fan Level 38dB, (33dB in whisper mode)
Operating Temperature 32 to 95 deg. F (0-35 deg C)
Power AC 100-120V, AC220-240V
50/60 Hz, 370 watt
Size (WxHxD) 13.2” x 3.7” x 10.4”
Weight 8.3 lbs.
Carton Size 14.3" x 16" x 17.3
Shipping Weight 20.2 lbs.
Accessories Included Remote control w/ laser pointer, batteries,
power cord, RGB Cable, filter cover,
operator/safety manual, soft case.
Safety UL, C-UL, FCC Class B, CE, TUV
Optional Accessories Lamp 456-8915
Rolling briefcase; 185-406,
Ceiling mount , universal; PJF-UNV-S
Key features:
The Dukane ImagePro 8911 is a powerful yet versa-
tile LCD projector designed to open new possibilities
in multimedia projection. Bright enough for most large
classrooms and conference rooms, the 8911 is sure to
impress with realistic colors, sharp contrast, and bril-
liant images.
Save money with the 8911 by eliminating the need
for additional external speakers. By incorporating four
built-in 3W speakers, which is typically sufficient for
most classrooms, you can be sure your message is
heard. In addition, full
connectivity and network-
ing capabilities make
this one of the most ver-
satile and efficient pro-
jectors available today.
• 2700 lumens brightness
• XGA (1024 x 768) resolution
• 500:1 contrast ratio
• Vibrant rich colored images
• Four 3 watt speakers
• Automatic vertical keystone correction
• Remote with laser pointer
• HDTV compatible
• Five Year Warranty and One Year Peace of
Mind Service
Five (5) year limited warranty
on parts and labor in North America, lamp excluded
(for other locations, local warranties apply).
Includes Dukane’s FREE 1 year
Peace-of-Mind Loaner Program.
5YR
Audiovisual Products
2900 Dukane Drive
St. Charles, Illinois 60174
www.dukcorp.com/av
ImagePro is a registered trademark of Dukane Corporation
Toll-free: 800-676-2485
Fax: [phone]
E-mail: [email protected]
#11679-G-05.1
Diagonal Width Min. Max.
Inches Inches Feet Feet
40 32 5.9 7.8
60 48 9.0 11.8
80 64 12.1 15.8
100 80 15.2 19.8
120 96 18.3 23.8
150 120 22.8 29.9
200 160 30.5 39.9
250 200 38.2 49.9
300 240 45.9 59.9
Image Size 4:3 Throw Distance
8911 Projection Table
Throw Ratio (distance to width) 2.3 3.0
