Dukane ImagePro 8955H-RJ User manual

• •
8955H-RJ
ImagePro 8955H-RJ Portable LCD Projector
e ImagePro 8955H-RJ is a Network able (LAN),
easy-to-install portable LCD projector ideal
for classroom or conference room.
8955H-RJ FEATURES
• 4000 Lumens Brightness
• XGA Resolution
• Lamp access on top
• High performance (5000 HR)
hybrid filter with easy front access
• New 16 Watt audio output
• New Microphone Input
• New 3000/6000 hour lamp
• Built-in Anti-theft security
• Audio "passthrough" permits use of
sound system to play CDs on the PC
when projector is off
• Network (LAN) Control,
Maintenance and security
• 0.5 Watt Power Saving Standby Mode
• PC less presentations
• HDMI Input
NEW FRONT-LOADING HYBRID FILTER GIVES
5000 HOURS OF PROJECTOR PERFORMANCE
Filter life 5000 HRS
Education. Presentation. Inspiration.
T H E A L L N E W
Convey by Dukane delivers control of classroom audio visual assets in sync
with our Convey AClick Student Response System. Experience tomorrow's
classroom today with Convey. Visit www.conveyclassrooms.com.
Call Dukane: 866.280.4298
S O L U T I O N S
Convey
Toll-free: 866-280-4298•Web:www.dukane.com/av
Fax: 630-584-5156•E-mail:[email protected]

Specifications 8955H-RJ
Image Element 0.63” polysilicon active-matrix TFT x3
Brightness 4000 ANSI lumens
(3400 lumens in Eco Mode)
Resolution 1024 x 768 pixels (H X V), XGA
Contrast 2,000 : 1 Active iris
Scanning Frequency fh 15 -106 kHz, fv 50-120 Hz
Lens Manual zoom (F2.3 – 2.5), 1.2X
Lens Throw Ratio 1.46 –1.75:1 throw distance to image width
Keystone Correction Digital, vertical +/-30 deg
Aspect Ratio 4:3, 16:9 selectable
Computer SVGA, VGA, XGA, SXGA, UXGA
Compatibility MAC13” and MAC16”
Video Compatibility NTSC, NTSC4.43, PAL, SECAM,
PAL-M, PAL-N, Component Video,
HDTV (1080i/p, 720p, 576i, 480i/p)
Image Control Freeze function, electronic
magnification and pan
Mouse Control Using USB
Projection Modes Front/rear/ceiling
Color Reproduction 24 bit (16.7 million)
PC less presentations USB-A storage device slot
Lamp 210W UHP
Lamp Life 3000 hours (typical) 6000 hours
(Eco mode)
Audio Output 2 speakers 16 watt combined
Throw Distance 34” to 423”
Screen Size, diagonal 30” to 300”
Inputs, Video (1) Component, RCA x 3
(1) S-video, Mini DIN 4-pin
(1) Composite video, RCA x 1
Inputs, Computer (2) RGB, 15 pin D-sub
Input Digital (1) HDMI
Inputs, Audio (2) Stereo mini jack: for PC 1&2
(1) RCA x 2 (for video)
Input from Mic 3.5mm Mini Audio
Outputs, Audio (1) RCA x 2, adjustable
Outputs, Monitor RGB, 15 pin D-sub
Outputs, Control RS-232, 9 pin D-sub
USB Type B (Mouse control)
LAN Network Operation RJ-45
Security Kensington lock slot & Security Bar
Fan Level 35dB, ultra quiet; 29dB Eco Mode
Closed Caption CC!, CC2, CC3, CC4, T1,T2,T3,T4
Operating Temperature 41-95 deg F
Power AC 100-120V, AC 220-240V
50/60 Hz, 330 watt, >1W standby
Size (WxHxD) 12.5” x 3.9” x 11.3”
Weight 7.9 lbs.
Shipping Weight 14 lbs.
Carton Size 15” x 8” x 19”
Accessories Included Remote control, batteries, power cord,
RGB cable, operators manual, CD
Safety UL/C-UL, FCC Class B
Optional Accessories Lamp 456-8755J
Ceiling Mount, Universal; RPM-U
Filter; MU06481
ImagePro 8955H-RJ
Portable LCD projector
Five (5) year limited warranty on parts and labor in North America, lamp is 90 day
warranty (for other locations, local warranties apply).Includes Dukane’s FREE 1 year
Peace-of-Mind Loaner Program.
5YR
8955H-RJ Projection Table
Throw Ratio (distance to width) 1.46 to 1.75
Connections
Back Panel
•XGA(1024x768)resolution
•4000ANSIlumensofbrightness
•HDMIinput
•Easymaintenanceinceilingmountwithlampaccess
on top & 5000 hour filter with front access
•Monitorloopthrough&remotemousecontrol
•MicrophoneInputwithamplifier
•PClessoperationvisUSBmemorydevice
•2000:1Contrast
•Audiopassthroughforsoundwhenprojectorisoff
•16Wattaudiooutput
•3000/6000hourlamplife
•Lockslot,securitybarandtransitiondetector
•FiveYearWarrantyandOneYearPeaceofMindService
ImageProisaregisteredtrademarkofDukaneCorporation
Image Size 4:3 Throw Distance
Diagonal Width Min. Max.
Inches Inches Feet Feet
30 24 2.8 3.4
60 48 5.8 7.0
80 64 7.8 9.3
100 80 9.8 11.7
120 96 11.7 14.1
150 120 14.7 17.6
200 160 19.5 23.5
300 240 29.3 35.3
Key features:
Audio Visual Products
2900 Dukane Drive
St. Charles, Illinois 60174
Toll-free: 866.280.4298
Fax: [phone]
E-mail: [email protected]
Web: www.dukane.com/av
#10-00018-00
S-Video
Composite
Video
Component
Video
HDMI Monitor
Out
Control
(RS-232)
Kensington
LockSlot
Computer
RGBin2
Audio
In Audio
Out
Audio
In1&2
USB
Type A
USB
Type B
LAN
RJ-45
Mic
In
Computer
RGBin1
Specifications subject to change without notice.
