INSTALLATION MANUAL
Utopia Diamond Pergola
H4-GS4X3CORPRG
Unique Product Reference Number:
__________________________________
Manufacturer:
Dunster House Ltd.
Caxton Road
Bedford
Bedfordshire
England
MK41 0LF
Customer Service Department:
[e-mail]
www.dunsterhouse.co.uk
C:\$VaultWorkspace\Designs\UtopiaPergola(2022)\UtopiaDiamondPergola\UtopiaCornerPergola.iam01/09/202302:39

Queries Procedure
Important Information
You will need
Please retain all documentation relating to your purchase.
In the unlikely event that you need to contact us, please do so in writing to:
Email: [e-mail]
Post: Dunster House Ltd, Caxton Road, Elms Farm Industrial Estate, Bedford, MK41 0LF, England.
Our Customer Service department is open 9 a.m. to 5 p.m. Monday to Friday. Please include your Sales Order (SO)
number or post code in any correspondence with Customer Service to enable them to locate your file.
The Nature of Wood
The wood provided for your garden building is softwood which has been kiln dried and is pressure treated for
protection against fungal decay and insect infestation. Wood is a natural product which may have knots, knot holes,
imperfections, cracks and warping.
Due to the inherent properties of wood we make no guarantees with regards to the above, nor will replace any
lengths of timber for any of the following reasons:
•Any timber that contains knots where they do not influence the structural stability of the product.
•Cosmetic appearances - colour variations e.g. caused by the structure or age of the product.
•Timber that has shakes, cracks or gaps that do not influence the structural strength of the product.
•Any timber that has been covered or buried underground.
•Twisted timber that can be installed.
•Queries arising from a neglectful manner of construction be in the foundation or erection of the product.
•Queries due to modifications by the owner causing timber to deform.
Any valid queries will be satisfied by the exchange or replacement of the defective parts only.
This product has been designed with the self build in mind. However, it is important that the assembly
instructions are followed carefully.
Precautions:
•Always use working gloves.
•It is essential to have an assistant.
•All screw holes need to be pre-drilled using a 3mm drill bit (not provided) to avoid timber splitting.
This product is pressure treated so you will not need to treat it immediately or apply a preservative.
Pressure treatment does not mean that the timbers are waterproof, so you may wish to apply water repellent.
Water repellent can also be applied to timbers treated with a preservative.
Colour Transfer
This product has been pressure treated with wood preservative and a brown colour additive. Consideration should
be given to the propensity of the material to stain light colour adjacent surfaces, such as paving flags, render or
coated timber surfaces. We recommend contact between the timber and these surfaces is limited, and careful
consideration to storing the product prior to assembly should been taken in order to prevent such discolouration.
2 People Measuring Tape Spirit Level Drill/Driver
Gloves Ladder Hammer Utility Knife
Mallet Pozidriv bits 3mm Drill bit Saw
Socket Set Spanner 16mm Masonry Drill Bit (Wall panels only)

BEAM
ANGLED BEAM
PURLIN
LNG_mm
WIDTH_mmTHK_mm
DESCRIPTION
PART NUMBER
QTY
19657070
Post
70x70x1965
5
LNG_mmWIDTH_mmTHK_mmDESCRIPTIONPART NUMBERQTY
16508643Beam86x43x16502
30438643
Beam
86x43x30432
ANG_degLNG_mmWIDTH_mmTHK_mmDESCRIPTIONPART NUMBERQTY
4520008643Beam86x43x2000.A1
LNG_mmWIDTH_mmTHK_mmDESCRIPTIONPART NUMBERQTY
15208643
Purlin
86x43x15202
25808643
Purlin
86x43x25802
31608643Purlin86x43x31602
37008643Purlin86x43x3700
1
Page 3
Components required for Utopia Diamond Pergola Installation Manual
Fix x1 Dunster House Logo to x1 70X70X1965
LNG_mm THK_mm
POST
LNG_mm
WIDTH_mm
THK_mm
LNG_mm
WIDTH_mm
THK_mm
LNG_mm WIDTH_mm
THK_mm
ANG_deg
WIDTH_mm
ANG_deg

SUPPORT BRACE
POST TRIM
ANG_degLNG_mmWIDTH_mmTHK_mmDESCRIPTIONPART NUMBERQTY
453507035Post Trim70x35x350.C10
ANG_degLNG_mm
WIDTH_mmTHK_mm
DESCRIPTION
PART NUMBER
QTY
45
6507035Post Trim70x35x650.C8
Page 4
Components required for Utopia Diamond Pergola Installation Manual
LNG_mm
THK_mm
WIDTH_mm
LNG_mm
WIDTH_mm
THK_mm
ANG_deg
ANG_deg
ANG_deg
ACCESSORIES AND FIXINGS
QTY Description
1Dunster House Logo
1 Customer Instructions
12 SCREW 95 mm
14 SCREW 120 mm
20 SCREW 50 mm
40 SCREW 70 mm

Assembly 2
Assembly 1
View B
View A
View C
COMPONENTS REQUIRED
QTY
PART NUMBER
286x43x3043
1
86x43x1650
470x70x1965
12SCREW 70 mm
View B
View A
View C
Page 5
Assembly Steps for Utopia Diamond Pergola
**Avoid splitting timber parts by pre-drilling all screw holes**
Step 1
•Prepare the Assembly 1 and Assembly 2 of Beams and Posts as shown in the diagrams below using 1x
86x43x3043 and 1x 86x43x1650.
2870
2995
86x43x3043
Assembly 1
70x70x1965
86x43x3043
86x43x1650
1520
1640
Assembly 2
86x43x1650
43
Secure using 2x
70mm screws.
Beam
overhangs
by 43mm.
Beam is
flush with
post .
SCREW 70 mm
SCREW 70 mm
SCREW 70 mm
Secure using 2x
70mm screws.
Secure using 2x
70mm screws per
end.
•Fix by screwing through the Posts into the Beams using 4x screws provided for each Assembly.
•Position Assembly 1 and Assembly 2 opposite each other as shown below.

Result
View E
View D
View E
View D
Page 6
Assembly Steps for Utopia Diamond Pergola
**Avoid splitting timber parts by pre-drilling all screw holes**
Step 1 (Continued)
•Join Assembly 1 and Assembly 2 together using 1x 86x43x3043 beam as shown.
•Secure with 4x screws.
Assembly 1
Assembly 2
86x43x1650
Assembly 1
86x43x3043
Assembly 2
86x43x3043
70x70x1965
86x43x3043
SCREW 70 mm
SCREW 70 mm
86x43x3043 86x43x3043
86x43x1650
86x43x3043
Secure using 2x
70mm.
Secure using 2x
70mm .

Assembly 3
Result
COMPONENTS REQUIRED
QTYPART NUMBER
186x43x2000.A
186x43x1650
170x70x1965
4
SCREW 95 mm
4
SCREW 70 mm
Page 7
Assembly Steps for Utopia Diamond Pergola
Step 2
**Avoid splitting timber parts by pre-drilling all screw holes**
•Connect Assembly 2 and Assembly 3 using 1x 86x43x2000.A. Secure the beam each post using 2x screws per
post to complete the overall structure.
•Prepare Assembly 3 using image below for reference.
•Attach Assembly 3 to the post attached to the end of Assembly 1 with 2x screws.
Assembly 1
Assembly 3
86x43x1650
Assembly 1
Assembly 3
86x43x1650
SCREW 70 mm
Assembly 2
86x43x2000.A SCREW 70 mm
SCREW 95 mm
Connection to Post

View G
View F
View G
View F
Page 8
Assembly Steps for Utopia Diamond Pergola
**Avoid splitting timber parts by pre-drilling all screw holes**
Posts and Beams Layout
Please note that this layout is to assist you with step 2.
70x70x1965
86x43x1650
SCREW 70 mm
86x43x2000.A
3043
1650
2000
3163
86x43x2000.A
4052
Plan View
86x43x3043
SCREW 95 mm
SCREW 70 mm
Ensure that the structure
is straight by measuring
the dimensions as
shown.

View H View I
COMPONENTS REQUIRED
QTYPART NUMBER
870x35x650.C
8SCREW 95 mm
24SCREW 70 mm
View H
View I
Page 9
Assembly Steps for Utopia Diamond Pergola
Step 3
**Avoid splitting timber parts by pre-drilling all screw holes**
70x35x650.C
70x35x650.C
70x35x650.C
70x35x650.C
70x35x650.C SCREW 70 mm
SCREW 70 mm
•Once the frame is assembled, fix the braces in positions shown using 4x screws provided per brace. Use the diagram
below for reference.
SCREW 95 mm
SCREW 70 mm
70x35x650.C

COMPONENTS REQUIRED
QTY
PART NUMBER
1
86x43x3700
286x43x1520
286x43x2580
286x43x3160
14120mm Screw
Page 10
Assembly Steps for Utopia Diamond Pergola
Step 4
**Avoid splitting timber parts by pre-drilling all screw holes**
Please note that
these dimensions
are approximate.
86x43x3160 86x43x3700
86x43x3160
86x43x2580
86x43x1520
120mm Screw
EqEqEqEqEq
•Using the diagram above as reference, fix the beams into place. Use 1x screw
at each end of the beam.
•Ensure that the beams are evenly spaced, as shown in the diagram below.
120mm Screw
Eq

COMPONENTS REQUIRED
QTYPART NUMBER
1070x35x350.C
20SCREW 50 mm
Page 11
Assembly Steps for Utopia Diamond Pergola
Step 4
**Avoid splitting timber parts by pre-drilling all screw holes**
Congratulations on building your new Pergola !
•On the base of the posts, fix 2x Post Fascia to each post.
•Use 2x screws per component to fix into position.
2x 50mm screws
required per post fascia
SCREW 50 mm

Installation Manual
For
Utopia Diamond Pergola
(Additional Wall Panel Pack)
Unique product reference number
.........................................................................
http://www.dunsterhouse.co.uk
Dunster House Ltd.

Page 13
Utopia Diamond Pergola - Pack May Contain :
2m Solid Wall Panel
Pressure Treated
Solid Wall Panel
3m
Pressure Treated
Pressure Treated
Glass Wall Panel
LOOSE COMPONENTS
2m
2x
2x
Horizontal Beading Timber - Per Window
Pressure Treated
Vertical Beading Timber - Per Window
Pressure Treated
850850
701860
1860 70
850
702860
877
741
19
19
19
19

ACCESSORIES
QTYPART NUMBER
Varies
Solid Wall Panel 3m
Varies70mm Screws
Page 14
Utopia Diamond Pergola - Pack May Contain :
Pressure Treated
Glass Wall Panel
LOOSE COMPONENTS
3m
2x
2x
Horizontal Beading Trim - Per Window
Pressure Treated
Vertical Beading Trim - Per Window
Pressure Treated
70
2860
850
19
19
905
19
19
741

Page 15
Utopia Diamond Pergola - Pack May Contain :
3m Wall Panel
Pressure Treated
35
2860
900

Page 16
Utopia Diamond Pergola - Additional Panel Assembly
All dimensions are approximate and subject to the limitations of the material used and the methods of manufacture
Full Height Wall Panel Assembly
•Position the solid wall panels between posts as shown in the diagram below.
•Connect panels to posts using 6x screws. (Repeat this process dependant on how many panels have been purchased).
•Position a further set of panels directly above previously secured panels and connect using 2x screws as shown in
the diagram below. (Repeat this process dependant on how many Panels have been purchased).
•Connect panels to posts using 6x screws.
•Use Sealant to seal any gaps which might appear between the panel and the posts.
**Quantity of components will vary, depending on your purchase
PART NUMBER QTY
3m Solid Wall Panel Varies
70mm Screws Varies
SCREW 70mm
SCREW 70mm SCREW 70mm

Page 17
Utopia Diamond Pergola - Additional Panel Assembly
All dimensions are approximate and subject to the limitations of the material used and the methods of manufacture
Full Height Wall Panel Assembly
**Quantity of components will vary, depending on your purchase
•Position the solid wall panels between posts as shown in the diagram below.
•Connect panels to posts using 8x screws. (Repeat this process dependant on how many panels have been purchased).
•Position a further set of panels directly above previously secured panels.Connect using U metal brackets with 10x
screws as shown in the diagram below. (Repeat this process dependant on how many Panels have been
purchased).
•Connect panels to posts using 6x screws.
•Use Sealant to seal any gaps which might appear between the panel and the posts.
SCREW 70mm
U metal Bracket 70x38x1mm
SCREW 20mm
PART NUMBER QTY
3m Slatted Panel Varies
70mm screws Varies
20mm screws Varies
U metal Bracket 70x38x1mm Varies
SCREW 70mm

Page 18
Utopia Diamond Pergola - Additional Panel Assembly
All dimensions are approximate and subject to the limitations of the material used and the methods of manufacture
Half Height Wall Panel Assembly
•See Previous page for Solid Wall Panel Installation.
Glass Wall Panel Assembly
SKIP STEP IF CUSTOMER HAS NOT PURCHASED ADDITIONAL GLASS WALL PANELS
•Position Glass Wall Panels directly above previously secured Solid Wall Panels and connect using 2x screws as
provided. (Repeat this process dependant on how many Glass Wall Panels have been purchased).
•Connect Glass Wall Panels to posts using 6x screws.
•Use Sealant to seal any gaps which might appear between the panel and the posts.
**Quantity of components will vary, depending on your purchase
PART NUMBER QTY
3m Solid Wall Panel Varies
3m Glass Wall Panel Varies
70mm Screws Varies
SCREW 70mm SCREW 70mm
