Duracell DRPP300S1 User manual

Owner’s Guide
Duracell Powerpack 300
with 20 Watt Solar Panel

i
Trademarks
DURACELL®is a registered trademark of The Gillette
Company, used under license. All rights reserved.
Notice of Copyright
Duracell®Powerpack 300 With 20 Watt Solar Panel Owner’s
Guide © 2014 Duracell. All rights reserved.
Date and Revision
February 2014 Revision 20140204
Product Number
DRPP300S1
Contact Information
Phone: [phone]

ii

iii
About This Guide
Purpose
The purpose of this Owner’s Guide is to provide explanations
and procedures for installing, operating, maintaining, and
troubleshooting the Duracell®Powerpack 300 With 20 Watt Solar
Panel.
Conventions Used
The following conventions are used in this guide.
WARNING
Warnings identify conditions that could result in personal
injury or loss of life.
CAUTION
Cautions identify conditions or practices that could result in
damage to the product or to other equipment.
Important: These notes describe an important action item
or an item that you must pay attention to.
Related Information
You can find more information about Battery-Biz Inc. as well as its
products and services at www.battery-biz.com

iv
Important Safety Instructions
The Duracell®Powerpack 300 With 20W Solar Panel
generates a type of AC power similar to a normal household
wall outlet. Operating the Duracell®Powerpack incorrectly
or misusing it may damage the equipment or create
hazardous conditions for the user.
Important: Before using your Duracell®Powerpack 300
With 20W Solar Panel, be sure to read and save these
safety instructions.
Warnings and Cautions
WARNING: Shock hazard. Keep away from
children.
The Duracell®Powerpack 300 generates the same
potentially lethal AC power as a normal household wall
outlet. Do not insert foreign objects into the AC Outlet,
the DC Power Socket, the Jump-Start Cable Port, or the
ventilation holes. Do not expose this product to water, rain,
snow, or spray. Do not open the Duracell®Powerpack 300.
There are no user serviceable parts inside the unit.
CAUTION
The unit will be damaged if connected to any AC load that
has its neutral conductor connected to ground. Such loads
include AC distribution wiring and house wiring.
CAUTION
Do not expose the Duracell®Powerpack 300 to
temperatures over 40°C (104°F).

v
WARNING: Explosion hazard
Do not use this product where there are flammable fumes
or gases, such as in the bilge of a gasoline-powered
boat, or near propane tanks. Do not use this product in an
enclosure containing automotive-type lead-acid batteries.
These batteries, unlike the sealed AGM battery in the
Duracell®Powerpack 300, vent explosive hydrogen gas
which can be ignited by sparks from electrical connections.
When working on electrical equipment, always ensure
someone is nearby to help you in an emergency.
WARNING: Heated surface
Ensure at least 2” (5 cm) air space is maintained on all
sides of the Duracell®Powerpack 300. During operation,
keep away from materials that may be affected by high
temperatures such as blankets, pillows and sleeping bags.
WARNING: Fire hazard
Jump-start cable clamps must be connected positive to
positive (red clamp to battery “+”) and negative to negative
(black clamp to battery “–”). A reverse polarity connection
(positive to negative) may cause damage to the unit and/or
create a sparking/explosion hazard.
WARNING: Fire hazard
Never allow jump-start cables’ red and black clamps to
touch each other or another common metal conductor.
This could cause damage to the unit and/or create a
sparking/explosion hazard. Always store the clamps
in the appropriate holder on each side of the Duracell®
Powerpack after use.
WARNING: Medical equipment
This product is NOT tested, designed nor intended to
be used with life support systems or any other medical
devices.

vi
WARNING: Fire hazard
The jump-start feature is designed for short term operation
only—less than 4 seconds. Operating the jump-start
feature for more than 4 seconds may cause damage to the
unit. Allow the Duracell®Powerpack 300 to cool down for
at least 3 minutes after each jumpstart.
WARNING: Proper application
Do not use the appliance for any application except that for
which it is intended.
WARNING: Risk of unsafe operation
When using tools or equipment, basic safety precautions
should always be followed to reduce the risk of personal
injury. Improper operation, maintenance or modification
of equipment could result in serious injury and property
damage. We strongly recommend that this product NOT
be modified and/or used for any application other than for
which it was designed. Read and understand all warnings
and operating instructions before using any equipment.

vii
Precautions When Working With
Batteries
WARNING: Explosion Fire or Burns
Follow all instructions published by the battery manufacturer
and the manufacturer of the equipment in which the battery is
installed.
1. Make sure the area around the battery is well ventilated.
2. Never smoke or allow a spark or flame near the engine or
batteries.
3. Be careful not to drop a metal object on the battery or
allow a metal tool to simultaneously touch the positive and
negative cable ends or battery terminals. It might spark or
short-circuit the battery or other electrical parts and cause
an explosion.
4. Remove personal metal items such as rings, bracelets,
necklaces, and watches when working with a lead-acid
battery. A lead-acid battery produces a short-circuit current
high enough to weld a ring or other similar objects to metal,
causing a severe burn.
5. If you need to remove a battery, always remove the positive
terminal from the battery first. Make sure all accessories
are off so you don’t cause an arc.
6. Someone should be within range of your voice, or close
enough to come to your aid when you work near a lead-
acid battery.
7. Have plenty of fresh water and soap nearby in case battery
acid contacts skin, clothing, and eyes.
8. Wear complete eye protection and clothing protection.
Avoid touching your eyes while working near batteries.
9. If battery acid contacts skin or clothing, wash immediately
with soap and water. If acid enters your eyes, immediately
flood them with running cold water for at least twenty
minutes and get medical attention immediately.
10. Keep a supply of baking soda on hand in the area of
the batteries. Baking soda neutralizes lead-acid battery
electrolyte.

viii
Precautions for Using
Rechargeable Appliances
CAUTION
The output of the Duracell®Powerpack 300 inverter is
a non-sinusoidal modified sine wave, which is different
from pure sine wave utility-supplied electricity. Certain
types of load equipment may be damaged.
Most rechargeable battery-operated equipment uses a
separate charger or transformer that is plugged into
an AC receptacle and produces a low voltage charging
output.
Some chargers for rechargeable batteries can be
damaged if connected to the Duracell®Powerpack 300.
Do not use the following with the Duracell®
Powerpack 300:
• Small battery-operated appliances like flashlights,
razors, and night lights that can be plugged directly
into an AC receptacle to recharge.
• Some chargers for battery packs used in hand
power tools. These affected chargers display a
warning label stating that dangerous voltages are
present at the battery terminals.
Note: If you are unsure about using your rechargeable
appliance with the Duracell®Powerpack, contact the
equipment manufacturer to determine the rechargeable
appliance’s compatibility with the modified sine wave
(non-sinusoidal) AC waveform.

ix
Contents
1 • Introduction
About the Duracell®Powerpack 300 With Solar Panel....1
Comprehensive Protection...............................................1
Automatic Overload .........................................................1
Overheating ....................................................................1
Low Battery Protection ....................................................1
2 • Features
Materials List ...................................................................2
Duracell®Powerpack Features .......................................3
Front Panel Detail ...........................................................3
Left Side View .................................................................4
Accessories......................................................................4
Solar Panel Features.......................................................5
3 • Operation
Operating Conditions and Guidelines .............................6
Choosing a Location........................................................7
Using Duracell®Powerpack 300 for the First Time .........8
Recharging with the AC Charger ....................................8
Using the Built-in Light.....................................................9
Using the USB Port .........................................................9
Operating AC Appliances ..............................................10
Understanding AC Appliances ......................................10
Run Time on Typical AC Appliances..............................10
High Surge Appliances...................................................11
Trouble Appliances ........................................................11
Operating Several Appliances at Once .........................11
Operating an AC Appliance............................................12
Operating 12 V DC Appliances......................................12
Jump-Starting a Vehicle’s Engine..................................14
Using the Air Compressor..............................................16
Over-temperature Safety Protection..............................16
Inflating Tires..................................................................17
Inflating Small Sports Equipment...................................18
Connecting to an External Battery.................................19
