INTRODUCTION:
SPECIFICATIONS:
Thank you for choosing the Auto-G2 V2 gyro-copter. The Auto-G2 V2 will bring you a flying experience like
no other, it is pure fun to fly and have you smiling every time the wheels lift into the air. The original Auto-G
raised the bar by being the first Plug-N-Fly autogyro on the market, the Auto-G2 V2 has raised that bar
even higher. It is still very simple to assemble, looks amazing, and is brilliant fun to fly, in fact, it is
everything you have come to expect from the Durafly brand.
Take-offs are very straightforward as the Auto-G2 V2 has an auto-start rotor run-up system. This system
uses a small electric motor which you engage via a separate channel to spin up the rotors prior to take-off.
Once up to speed you perform a normal take-off, the one-way bearing assembly allows the rotors to spin
even faster as you accelerate and once airborne you switch the run-up motor off. Landings are a dream,
you can land the Auto-G2 V2 very similar to a conventional fixed-wing model. But with practice, very short
almost vertical landings are achievable with next to no ground run.
Autogyros are very unique aircraft utilizing an unpowered free-spinning main rotor to develop lift, and a
powered propeller to provide thrust. This makes them quite different from traditional fixed wing aircraft. The
Auto-G2 V2 offers you this very interesting design in an easy and simple to use plug and fly model.
For those of you looking for a new flying experience, the Auto-G2 V2 is just the ticket. This model will be
especially appealing to those who fly both helicopters and fixed wing aircraft as this model falls somewhere
between the two. With its very unique flight characteristics, the Auto-G2 V2 is by far one of the most
interesting models you'll ever have flown. In addition to its super slow flight and auto-rotation capability, it
can even perform simple aerobatics such as gentle stall turns.
This being the Auto-G2 V2, it has the following
improvements over the original version.
• Upgraded more durable rotor-head plate.
• Fibre reinforced pushrods.
• The rotor mast has now be fully encased and is more streamlined.
• Landing gear is wider giving more stability on the ground.
• Larger wheels so that it can be flown off of a variety of flying strips
• Landing gear has been braced to make it stronger.
• Motor has been cowled in.
• New color scheme.
• 3D printed pilots head.
The Auto-G2 V2 has been designed for intermediate and
experienced model pilots, so you will need some experience in
assembling, and flying models.
•Length : 795mm (31.3 inch)
•Height : 392mm (15.43 inch)
•Weight : 720g
•ESC : Durafly 20A brushless ESC
•Motor : Brushless motor x 1 (8OOkv)
•Servo : 9g x 4
•Radio : 5+ Channel
•Rotor Diameter (Three rotor blades) : 821 mm (2.33 inch)
•Battery : LiPo 11.1 v 1300mAh 30-50C x 1
1
